2010.5 Citroen C ZERO Owner's Manual

8
Practical information
95
)Slacken the bolts using the wheelbrace.)Place the jack in contact with one of the
two front A or rear B
locations provided
on the underbody, whichever is closest to
the wheel to be changed.
Removing the wheel
) Using the handle, extend the jack until its base plate is in contact with the ground.
Ensure that the centreline of the jack base
plate is directly below the location A or Bused.)
Raise the vehicle until there is sufficientspace between the wheel and the ground.
)
Remove the bolts and store them in a clean place. )
Remove the wheel.

i
Practical information
96
Fitting the wheel
)Put the wheel in place on the hub. )Screw in the bolts by hand.)Pre-tighten the bolts using the wheelbrace.
) Lower the vehicle fully. )
Fold the jack and detach it.)Tighten the bolts using the wheelbrace.



After changing a wheel

Have the tightening of the bolts andthe pressure of the new wheel checked by a CITROËN dealer or a qualifiedworkshop without delay.

8
!
Practical information
97








Changing a bulb
1.Direction indicators(W21W - 21 W).2.Sidelamps (W5W - 5 W).3.Main beam headlamps (HB3 - 60 W).4.Dipped beam headlamps (H11 - 55 W).

The headlamps are fitted with polycarbonate glass with a protectivecoating:)do not clean them using a dry or abrasive cloth, nor with a detergent or solvent product,)
use a sponge and soapy water, )
when using a high pressure washer on persistent marks, do not directat the lamps or their outlines for too long, so as not to damage their protective coating and seals.
)
Do not touch the bulb directly with your fingers, use lint-free cloths.
Changing a bulb should only be done after the headlamp has been switched
off for a few minutes (risk of serious burns). It is imperative to use only anti-ultraviolet (UV) type bulbs in order notto damage the headlamp. Always replace a failed bulb witha new bulb with the same type andspecification.
Front lamps
5. Front foglamps(H8 - 35 W).6.Daytime running lamps (P13W - 13 W).

Practical information
98
) Lift the cover B
, using a screwdriver
protected by a cloth.) Slacken fixing screw C
until the head of the screw touches the trim.
)Remove the bumper retaining clips, usinga screwdriver. )Carefully lift the bumper. To replace a failed bulb,
you must first remove
the lamp. To remove the lamp:)Open the bonnet. )Press tab A to release the connector.
Access to bulbs

8
Practical information
99
Slacken fixing screw D , while holding the
bumper away.)Slacken fixing screw E.
) Pull the lamp towards you, and disengage
the tab Fto remove it completely.

i
Practical information
100

Changing a sidelamp bulb
)
Turn the bulb holder to the left and
pull it out.) Pull the bulb out and replace it.
To r efit, carry out these operations in reverseorder.


Changing a main beam headlampbulb
)Turn the bulb holder to the left andpull it out. )Pull the bulb out, pressing its tab. )Replace the bulb.
To r efit, carry out these operations in reverse order.
Changing a direction indicator
bulb
)Turn the bulb holder to the left andremove it.)Pull the bulb and change it.
To r e f i t , c a r ry out these operations in reverse order.
Coloured bulbs must be replaced with bulbs of identical specification andcolour.

8
Practical information
101
Changing a dipped beamheadlamp bulb
)Turn the bulb holder to the left andpull it out. )Remove the bulb by pressing its tab. )Replace the bulb.
To r efit, carry out these operations in reverse order.

Changing a foglamp/daytime running lamp bulb
)
Turn the wheels onto full lock to improveaccess. )
Remove the clips holding the protective cover over the bulb holder. )
Pull the cover away.
)
Turn the bulb holder ( Afor the foglamp, Bfor the daytime running lamps) to the left
and pull it out.
) Pull the bulb out and replace it.
To r e f i t , c a r ry out these operations in reverseorder.

i
i
Practical information
102
1.Brake lamps/Sidelamps (LEDs).2. Direction indicators(W Y21W - 21 W).3.Reversing lamps (W21W - 21 W).
Rear lamps
Amber coloured bulbs, such as the direction indicators, must be replaced with bulbs of identical specification and colour.
In some weather conditions (e.g. lowtemperature or humidity), the presenceof misting on the internal surface of the glass of the headlamps and rear lamps is normal; it disappears after the lampshave been on for a few minutes.
Changing an integrated directionindicator side repeater(WY5W - 5 W)
)Push the repeater towards the rear anddetach it. )Turn the bulb holder to the left andpull it out. )Pull the bulb out and replace it.
To r e f i t , c a r ry out these operations in reverse order.
