2010.5 Citroen C ZERO Owner's Manual

127
The system is coded in such a way that it will only
operate in your vehicle. If it is to be installed in another vehicle, contact your CITROËN dealer for confi guration py
of the system.

AUDIO SYSTEM/BLUETOOTH

01 First steps


For safety reasons, the driver must only carry out
operations which require prolonged attention while
the vehicle is stationary.
When the motor is switched off and to
prevent
discharging of the battery, the audio system may switch off after a few minutes.



CONTENTS

02 Radio

03 Audio

04 Using the telephone

05 Audio settings

06 Configuration

07 Screen menu map

Frequently asked questions p.
p.
p.
p.
p.
p.
p.
p. 128
129
132
138
144
145
146
147
After a battery disconnection, a code has to be enteredfor operation of the radio.

A maximum of fi ve attempts are possible. For the last
two attempts, a 15 minutes wait is imposed between each attempt.
R
efer to the end of this document to fi nd the label indicating this code:

1
2
74
5
6
3
8
9
7
01
128
FIRST STEPS
1. On/Off and volume adjustment.
2. CD e
ject.
3. Selection of source:
FM1, FM2, CD, USB, AUX, Streamin
g.
Accept an incoming call.
Long press:


- access to calls lo
g of the telephoneconnected,

- or end a call in pro
gress.
4.
Selection of a preset radio station.
Radio: lon
g press: preset a radio station.

Other than radio: see relevant sections.

5. Displa
y the list of stations received, theCD/USB tracks or folders.
Lon
g press: update the list of stationsreceived.

6. Abandon current operation
Up one level
(menu or folder). 7. Automatic search
for a lower/higher radio
frequency.
Selection of
previous/next CD, USB track.
Navigation in a list.
Maintained press:
fast forwards or backwards.
8. Main menu.
9. Audio settings:
e
qualizer, treble, bass, loudness,
distribution, left/right balance, front/rear
balance, automatic volume.

11
02
1
2
129
RADIO
Press SRC/TEL several times insuccession and select the FM1 or FM2radio band.
Press a button to listen to the corresponding preset station.
Select the desired radio station and confi rm by pressing "OK".







RADIO

Press LIST
to display the list of stations
received in alphabetical order.
The exterior environment
(hills, buildings, tunnel, car park, below ground...) may prevent reception, even in RDS station tracking mode. Thisphenomenon is normal in the propagation of radio waves and is in no way indicative of a fault with the audio system.

A long press on LIST
builds or updates
the list of stations; audio reception is cut
momentarily.
Make a lon
g press on one of the buttons
to preset the station being heard.
The name of the station is displayedaccompanied by an audible signal to confi rm the preset.

A press chan
ges to the next or previous
letter (e.g. A, B, D, F, G, J, K, ...). MANAGE THE LIST
PRESETTING AND SELECTING A STATION

1
2
02
1
2
130
RDS, if displayed, enables you to continue listening to the same station by automatic retuning to alternative frequencies. However,
in certain conditions, coverage of an RDS station may not be assured throughout the country as radio stations do not cover
100 % of the territory. This explains the loss of reception of thestation during a journey.

RADIO


RDS


When the radio is displayed in
the screen, press MENUthen select "Radio" .

Select or deselect "RDS"
to activate or deactivate RDS then confi rm with "OK"
to save the setting.


ENTER A FREQUENCY MANUALLY
Press MENU
, select "Radio"
, thenselect "Write freq."
.
Pr
ess + or -
to select the desired
frequency and confi rm with "OK".

1
2
02
1
131
RADIO

Radio text is information transmitted by the radio station related to
the current programme or song.

With the radio displayed on the screen, press MENUthen select "Radio".


Select or deselect "TXT"to activate or deactivate the display of Radio Text.



DISPLAY RADIO TEXT






RECEIVING TA MESSAGES


The TA (Traffi c Announcement) function gives priority to TA alert messages. To operate, this function needs good reception of a
radio station transmitting this type of message. When a traffi c
report is transmitted, the current audio source (Radio, CD,USB, ...) is interrupted automatically to play the TA message.
Normal playback of the audio source resumes at the end of
the transmission of the message.

Pr
ess MENU, select "Radio", then select or deselect "TA"
to activate or deactivate the reception of traffi cmessages.

03
1
2
132
AUDIO






AUDIO CD


Insert 12 cm diameter circular compact discs only.
Some anti-piratin
g systems, on original discs or CDs copied using
a personal recorder, may cause faults which are no refl ection on
the quality of the original player.

Without pressing the EJECT
button, insert a CD in the player, playbegins automatically.

To pla
y a disc which has already been
inserted, press the SRC/TEL
button several times until CD play is displayed.

Pr
ess one of the buttons to select
a track on the CD.
Pr
ess and hold one of the buttons for fast forward or backward.
PLAYING A CD

03
133
AUDIO











CD, USB


INFORMATION AND ADVICE
On a single disc, the CD player can read up to 255 MP3 fi les spread
over 8 folder levels with a maximum of 192 folders. However, it is
recommended that this be kept to 2 levels so as to limit the time taken
to access and play the CD.
Durin
g play, the folder structure is not observed.
In order to be able to pla
y a recorded CDR or CDRW, when recordingit is preferable to select standards ISO 9660 level 1. 2 or Joliet.
If the disc is recorded in another format, it ma
y not be played correctly.
It is recommended that the same recording standard is always usedfor an individual disc, with as low a speed as possible (4x maximum)for optimum sound quality.
In the particular case o
f a multi-session CD, the Joliet standard is
recommended.
Do not connect a hard disk or U
SB device other than audio players to
the USB port. This may cause damage to your installation.
The audio s
ystem will only play fi les with ".mp3", ".wma", ".wav" and".ogg" extension on USB.

A high compression rate can adversely affect sound quality.

The pla
ylists accepted on CD, MP3, iPod and USB connection are
types ".m3u" and ".wpl".
The number of fi les reco
gnised is limited to 5 000 in 500 folders on
a maximum of 8 levels.

03
1
3
2
4
134











CD, USB
AUDIO


PLAYING A COMPILATION

Insert an MP3 compilation in the CD pla
yer or connect a memory stick to the USB port.
The system creates playlists
(temporary memory) the creation timefor which can take from a few seconds to several minutes.
The pla
ylists are updated every time the ignition is switched off or
a USB memory stick is connected.
Pla
y starts automatically after a period which depends on the capacity of the USB memory stick.

At a fi rst connection, the order suggested is by folder.When connecting again, the order previously chosen is retained.
To pla
y a disc or memory stick whichhas already been inserted, press
SRC/TELseveral times in succession and select"CD "or "USB ".


Press one of the buttons to select
the next or previous track.

Pr
ess one of the buttons to select
the next or previous folder in the order
chosen.

Pr
ess and hold one of the buttons for
fast forwards or backwards.
