2010.5 Citroen C ZERO Owner's Manual

7
i
!
Safety
71

Operating fault

When the vehicle is stationar
y

The warning lamp comes on for a few seconds when the ignition is switchedon (ON position). If it does not go off or does not come on, contact a CITROËNdealer or a qualified workshop. I
f this warning lamp comes oncontinuously it indicates a malfunction of the wheel anti-lock braking system
which could result in a loss of controlof the vehicle on braking.
You must stop as soon as it is safe to do so.Contact a CITROËN dealer or a qualifiedworkshop.
When the vehicle is moving
Illumination of these twowarning lamps indicates a
malfunction of the electronic brake force distributionwhich could result in a loss of control of
the vehicle on braking.
You must stop as soon as it is safe to do so.Contact a CITROËN dealer or a qualifiedworkshop.
When replacing wheels (tyres and rims),
ensure that they conform to the manufacturer's recommendations.
The illumination o
f this warning lampit indicates a malfunction of the wheelanti-lock braking system, which could result in a loss of control of thevehicle when braking.
Contact a CITROËN dealer or a qualified
workshop.
Emergency braking assistance
System which, in an emergency, enables you
to obtain the optimum braking pressure more quickly, thus reducing the stopping distance.
Activation
It is triggered by the speed at which the brake pedal is pressed.
The effect of this is a reduction in theresistance of the pedal and an increase in
braking efficiency.
When braking in an emergency, press firmly without releasing the pressure.

!
Safety
72
Anti-slip regulation (ASR)
and electronic stability
programme (ESP)














Trajectory control systems



Deactivation

In exceptional conditions (starting a vehicle
which is bogged down, stuck in snow, on soft ground, ...), it may be advisable to deactivate
the ASR and ESP systems, so that the wheels can move freely and regain grip. ) Press this button button, located on the
dashboard to the right of the steeringwheel, until the corresponding symbol
appears in the instrument panel screen.
Activation
These systems are activated automatically each time the vehicle is started.
They come into operation in the event of a grip
or trajectory problem.
The displa
y of this symbol indicates
that the ASR and ESP systems are deactivated.

Reactivation

These systems are not reactivated automatically.
)Press this button again to reactivate themmanually.
The symbol going off in the instrument panel indicates
the reactivation of the ASR and ESP systems. The anti-slip regulation (also known as Traction Control) optimises traction to prevent skidding
of the wheels, by acting on the brakes of the
driving wheels and on the engine.
The electronic stability programme acts on the
brake of one or more wheels and on the engine
to keep the vehicle on the trajectory requiredby the driver, within the limits of the laws of physics.
This is indicated b
y flashing of this
warning lamp in the instrument panel.


The ASR/ESP systems offer exceptional safety in normal driving, butthis should not encourage the driver to take extra risks or drive at high speed.
The correct functioning of these systems depends on obser vation of the manufacturer’s recommendationsregarding the wheels (tyres and rims),the braking components, the electronic components and the assembly and repair procedures used by theCITROËN dealer network.
After an impact, have these systems checked by a CITROËN dealer or a qualified workshop.



Operating fault
The display of this message in the instrument panel indicates a malfunction of
these systems.
Contact a CITROËN dealer or a
qualified workshop
to have the ASR /ESP systems checked.

7
Safety
73
Seat belts


Front seat belts
Fastening
)
Pull the strap, then inser t the tongue inthe buckle A.)
Check that the seat belt is fastened correctly by pulling the strap.



Front seat belt not fastened/
unfastened warning lamp

If the driver does not fasten their seat
belt within one minute after switching on
the ignition, the warning lamp flashes
accompanied by an intermittent audible signal.
After about 90 seconds, the warning lamp, the
audible signal and the display stop, and then
return until the driver fastens their seat belt.
If the seat belt is unfastened while the vehicle is moving
, you are warned by the same alerts.

Th
e front seat belts are fitted with a
pretensioning and force limiting system.
This system improves safety in the frontseats in the event of a front or side impact.
Depending on the severity of the impact,
the pretensioning system instantly tightens
the seat belts against the body of the
occupants.

The pretensioning seat belts are active when
the ignition is on.
The force limiter reduces the pressure of
the seat belt on the chest of the occupant,so improving their protection.

Unfastening
)
Press the red button on the buckle A
.

When the ignition is switched on, this
warning lamp comes on accompanied
by an audible signal for a few secondsif the driver and/or passenger has notfastened their seat belt.

Safety
74
Rear seat belts
Each rear seat is fitted with a three-point inertia
reel seat belt.

Fastening
)
Pull the strap, then inser t the tongue inthe buckle.)
Check that the seat belt is fastened correctly by pulling the strap.


Unfastening
)
Press the red button in the buckle.



Seat belt unfastened warninglamps
Right hand rear seat belt warning lamp.
Left hand rear seat belt warning lamp.

Illumination of one of these warning lamps in
the instrument panel indicates that one of the
rear passengers has unbuckled their seat belt.

7
i
Safety
75




The driver must ensure that passengers usethe seat belts correctly and that they are allrestrained securely before setting off.
Wherever you are seated in the vehicle, always fasten your seat belt, even for short journeys.
Do not interchange the seat belt buckles asthey will not fulfil their role fully.
The seat belts are fitted with an inertia reel permitting automatic adjustment of the length of the strap to your size. The seat belt isstowed automatically when not in use.
Before and after use, ensure that the seatbelt is reeled in correctly.
The lower par t of the strap must bepositioned as low as possible on the pelvis.
The upper par t must be positioned inthe hollow of the shoulder.
The inertia reels are fitted with an automatic locking device which comes into operation inthe event of a collision, emergency braking or if the vehicle rolls over. You can releasethe device by pulling firmly on the strap and releasing it so that it reels in slightly.
Recommendations for children
Use a suitable child seat if the passenger isless than 12 years old or shor ter than one and a half metres. Never use the same seat belt to secure morethan one person. Never allow a child to travel on your lap.

In order to be effective, a seat belt must:


- be tightened as close to the body as possible,


- be pulled in front of you with a smooth movement, checking that it does nottwist,

- be used to restrain only one person,

- not bear any trace of cuts or fraying,

- not be converted or modified to avoid affecting its per formance.
In accordance with current safety regulations, for all repairs on your vehicle, go to a qualified workshop with the skills and equipment needed, which a CITROËN dealer is able to provide.
Have your seat belts checked regularly by a CITROËN dealer or a qualified workshop, particularly if the straps show signs of damage.
Clean the seat belt straps with soapywater or a textile cleaning product, sold by CITROËN dealers.
After folding or moving a seat or rear bench seat, ensure that the seat belt is positioned and reeled in correctly.
In the event of an impact
Depending on the nature and seriousness of the impact
, thepretensioning device may be deployedbefore and independently of the airbags.Deployment of the pretensioners isaccompanied by a slight discharge of harmless smoke and a noise, due to the activation of the pyrotechnic cartridge incorporated in the system.In all cases, the airbag warning lampcomes on.Following an impact, have the seat belts system checked, and if necessary replaced,by a CITROËN dealer or a qualified workshop.

i
!
Safety
76





Airbags
The airbags have been designed to maximise
the safety of the occupants in the event of
violent collisions. They supplement the action
of the force-limiting seat belts. In this case, the electronic detectors record and analyse the front and side impacts suffered in
the impact detection zones:
- in the event of a serious impact, the airbags are deployed instantaneously and protect
the occupants of the vehicle; immediately after the impact, the airbags deflate rapidlyso that they do not hinder the visibility of
the occupants or their possible exit from
t
he vehicle,
- in the event of a minor impact or rear impact and in cer tain roll-over conditions,
the airbags will not be deployed; the seat
belt alone is su
fficient to provide maximum protection in these situations.

The airbags do not operate whenthe ignition is off.
This equipment only operates once. If a
second impact occurs (during the sameor a subsequent accident), the airbagwill not operate.
The deployment of one or more airbags is accompanied by a slight discharge of harmless smoke and a noise, due to theactivation of the pyrotechnic cartridgeincorporated in the system.This smoke is not harmful, but sensitiveindividuals may experience some irritation.
The noise of the detonation may result in a slight loss of hearing for a shorttime.

Impact detection zones
A.
Front impact zone. B.
Side impact zone.
Front airbags


Deployment

The airbags are deployed simultaneously,
unless the passenger's front airbag is
deactivated, in the event of a serious front
impact applied to all or par t of the front impact
z
one A , in the longitudinal centreline of the
vehicle on a horizontal plane and directed from
th
e front to the rear of the vehicle.
The front airbag inflates between the front
occupant of the vehicle and the dashboard to
cushion their forward movement. S
ystem which protects the head and chest of
the driver and front passenger in the event of
a front impact.
The driver's airbag is fitted in the centre of the steering wheel; the front passenger's airbag isfitted in the dashboard above the glove box.

7
!
Safety
77

Deactivation
Only the front passenger's airbag can be deactivated:)with the ignition off, inser t the key in thefpassenger airbag deactivation switch A , )turn it to the "OFF"position, )remove the key.
This warning lamp comes on in the centreconsole when the ignition is on and until
the airbag is reactivated.
To ensure the safety of your child, thepassenger airbag must be deactivatedwhen you install a "rear facing" childseat on the front passenger seat. Other wise, the child would risk beingseriously injured or killed if the airbag were deployed.


Reactivation

When you remove the child seat, turn switch A
to the "ON"position to reactivate the airbag andso ensure the safety of your front passenger in
the event of an impact.
The associated warnin
g lamp goes off.


Operating fault

If this warning lamp comes on in the
instrument panel, contact a CITROËN
dealer or a qualified workshop to have
t
he system checked. The airbags may no longer be deployed in the event of
a serious impact.

!
Safety
78
Lateral airbags
Deployment
The lateral airbags are deployed unilaterally in
the event of a serious side impact applied to all
or par t of the side impact zone B, perpendicular
to the longitudinal centreline of the vehicle on a horizontal plane and directed from the outside
towards the inside of the vehicle.
The lateral airbag inflates between the hip andshoulder of the front occupant of the vehicle and the corresponding door trim panel.
System which protects the driver and frontpassenger in the event of a serious side impact
in order to limit the risk of injury to the chest,
between the hip and the shoulder.
Each lateral airba
g is fitted in the seat backrest frame, door side.

Impact detection zones
A.
Front impact zone.
B. Side impact zone.


Curtain airbags
System which protects the driver and
passengers in the event of a serious side
impact in order to limit the risk of injury tothe head.
Each curtain airbag is fitted in the pillars
and the upper section of the passenger compartment.
In the event of a minor impact or bump on the side of the vehicle or if the vehicle rolls over, the airbag may not be triggered.
In the event of a rear or front collision, the airbag is not triggered.


Deployment

Each curtain airbag is deployed at the same
time as the corresponding lateral airbag in the event of a serious side impact applied to all or par t of the side impact zone B, perpendicular
to the longitudinal centreline of the vehicle on
a horizontal plane and directed from the outside
towards the inside of the vehicle.
The cur tain airbag inflates between the front or
rear occupant of the vehicle and the windows.

I
f this warning lamp comes on in
the instrument panel, contact a
CITROËN dealer or a qualified workshop to have the systemchecked. The airbags may no longer be deployed in the event of a seriousimpact.



Operating fault
