2009 VOLVO XC90 Owner´s Manual

04 Interior
Rear seats
04
105
2. Pull up the handle, illustration 1 above.
3. Push the seat cushion firmly rearward,
under the backrest.
4.
Fold down the backrests
2 (the head
restraints fold down automatically) to the
horizontal position.
Returning the backrest to the upright
position1. Fold up the backrest to the upright posi-
tion.
2. Grasp the strap (see illustration 3 above)
and pull the seat cushion out until it locks
in place. This also locks the backrest in the
upright position.2Please note that the head restraints in this row cannot be vertically adjusted.

04 InteriorInterior lighting
04106
Reading lights and courtesy light
G026960
Driver's side front reading lampCourtesy lightsPassenger's side front reading lamp The
reading lights can be switched on or off by
pressing buttons 1 or 3. The courtesy light-
ing (including footwell lighting) can be
turned on or off by pressing button 2. This
also activates the automatic function.
G027153
Rear reading lights
Driver's side rear reading lightPassenger's side rear reading light The
rear reading lights can be switched on and
off by pressing buttons (4) or (5).
Automatic functionThe reading lights and courtesy lights will
switch off automatically approximately
10 minutes after the engine has been turned
off. The lights can be turned off sooner by
pressing the respective buttons.The courtesy lights come on automatically
1
and remain on for approximately 30 seconds
when:•
The vehicle has been unlocked from the
outside with the remote control or key
•
If the engine has been switched off and the
ignition key has been turned to position 0
The courtesy lights will come on and remain on
for approximately 10 minutes when:
•
One of the doors is opened (assuming the
courtesy lighting has not previously been
switched off)
The courtesy lighting will go off when:
•
The engine is started
•
The vehicle is locked from the outside with
the remote control or key
The automatic function can be disconnected
by pressing button (2) for more than 3 seconds.
Briefly pressing the button again automatically
reconnects the function.
The courtesy light timer periods can be
changed. Contact a trained and qualified Volvo
service technician.
1This function is light dependent and is only activated in dark conditions.

04 InteriorInterior lighting
04
107 Vanity mirror
G027045
The light comes on when you open the cover.Glove compartment lightingThe light in the glove compartment comes on
or switches off when its door is opened or
closed.

04 InteriorStorage compartments
04108
G033089

04 Interior
Storage compartments
04``109
Storage compartment in optional third row
of seatsStorage compartmentGlove compartmentStorage compartment in center consoleRear seat cup holdersStorage pocket (also in front edge of front
seats)Grocery bag holderWARNING
Make sure that no hard, sharp or heavy
objects lie on or in any of the storage areas
where they might cause injury during sud-
den braking.
Storage compartment in the center
console
G027019
To open the lid on the storage compartment,
press the lower edge of the opening latch (see
illustration above). This lid can be folded back
to form a small table area for rear seat passen-
gers.
Lift the tray under the lid to expose the deep
storage bin with slots for CD storage.
G027020
Cup holders for the front seatsTwo cup holders are provided for the front seat
occupants. Press lightly on the rear edge of the
cover to open it.Ashtray (accessory)An ashtray insert is available from your Volvo
retailer. This insert slides into either of the cup
holders.Pen holderThere is a pen holder in the center console, in
front of the gear selector.

04 InteriorStorage compartments
04110
G027018
Storage compartment in rear side of the
center consoleGrasp the upper edge of cover and pull to open
this compartment.Ashtray (accessory)An ashtray insert is available from your Volvo
retailer.
G027063
Cup holders for the rear seats•
Grasp the lower edge of the panel to pull
out the cup holders in the rear side of the
center console.
•
The cup holder insert can be removed to
provide space for a large plastic bottle. Pull
the insert straight up to remove it. Press
down to reinsert it.
ATTENTIONPakjdskdl ioiuip kjöpp opoodidåuswi
CSOUNDMENU80ENTERLSEEEXITMY KEYRTO
AIRBAG
G027025
Glove compartmentThe glove compartment can be used to store
things such as the owner's manual, maps,
pens, etc.

04 Interior
Storage compartments
04
111
G027028
Coat hangerThe jacket hanger is located on the inboard
side of the front passenger's seat head
restraint. It is only intended for hanging light
garments.
G027026
Storage space between rear seats
(seven-seat models) – optionThis storage space provides compartments for
pens or other small items.
G027040
Rear side storage compartments and
cup holders (seven-seat models)Lift the lid to access the storage compartment.

04 InteriorSecuring cargo
04112
G027031
As a safety precaution, all cargo in your vehicle
should be securely anchored to keep it from
being thrown forward in the event of sudden
braking, etc. The vehicle is equipped with eye-
lets in the cargo space to which straps or other
cargo restraints can be attached.
WARNING
The eyelets are not to be used as passenger
restraints or as anchorages for child
restraints.Consult your Volvo retailer about suitable
accessories for this purpose.Remember that an object weighing 44 lbs
(20 kg) produces a force of 2,200 lbs
(1,000 kg) in a head-on collision at 30 mph
(50 km/h)!
Keep the following in mind when loading the
vehicle:
•
The load carrying capacity of your vehicle
is determined by factors such as the num-
ber of passengers, the amount of cargo,
the weight of any accessories that may be
installed, etc. See the section "Vehicle
loading" in the chapter "Wheel and tires"
for more detailed information.
•
Load the cargo against the backrest.
•
Load heavy cargo as low as possible.
•
If no one is sitting in the outboard rear
seat(s), reinforce the backrest by fastening
the seat belts.
•
Never load cargo above the backrest with-
out a cargo net.WARNING
When the rear backrest(s) are folded down,
the vehicle should not be loaded to a level
higher than 2 in. (5 cm) below the upper
edge of the rear side windows. Objects
placed higher than this level could impede
the function of the inflatable curtain.
G027058
Attachment bracketNylon cargo net (accessory)The Volvo XC90 can be equipped with a cargo
net made of strong nylon fabric.
This net can be installed in two places:•
Behind the rear seat backrests (the second
row of seats in seven-seat models)
•
Behind the front seat backrests if the rear
seat backrests (the second row of seats in
seven-seat models) have been folded
down.
