2009 VOLVO XC90 Owner´s Manual

02 Instruments and controlsManually unlocking the fuel filler door
0265
G027077
Panel on passenger's side of cargo areaTo manually unlock the fuel filler door1. Open the upper and lower sections of the
tailgate, and fold up the rear section of the
cargo area floor.
2. If the vehicle is equipped with the optional
grocery bag holder, detach the holder's
bands.
3. Remove the corner panel from the floor of
the cargo area.
4. Open the cover in the side panel by pulling
the tab upward/outward.
5. Pull down the insulating material (4) to
access the fuel filler door motor (5).
G027034
6. Move the catch (6) rearward to unlock the
fuel filler door lock, or move it forward to
lock the filler door.

02 Instruments and controlsLeft-side steering wheel lever
0266
Lever positions
G026954
Turn signals, lane change positionTurn signals, position for normal turnsHigh beam flashToggle between high and low beams,
Home Safe lighting
Turn signalsWhen turningMove the lever as far up or down as possible
(to position 2) to start the turn signals. The turn
signals will be cancelled automatically by the
movement of the steering wheel, or the lever
can be returned to its initial position by hand.When changing lanesThe driver can automatically flash the turn sig-
nals 3 times by:•
Moving the turn signal lever up or down to
position (1) and releasing it.
•
Moving the lever up or down to position (2)
and immediately back to its original posi-
tion.NOTE
•
This automatic flashing sequence can
be interrupted by immediately moving
the lever in the opposite direction.
•
If the turn signal indicator flashes faster
than normal, check for a burned-out
turn signal bulb.
High/low beam headlightsContinuous high beams1.
Turn the ignition key to position II.
2. With the light switch (1) in position
, (see page 63) pull the turn signal
lever toward the steering wheel (position 4)
to toggle between high and low beams
(this also applies on models equipped with
the optional Active Bi-Xenon
Ÿ headlights).
High beam flash1.
Turn the ignition key to position II.
2. Pull the turn signal lever to position (3). The
high beams will remain on until the lever is
released.Home safe lightingWhen you leave your vehicle at night, you can
make use of the home safe lighting function to
illuminate the area in front of the vehicle.
1. Remove the key from the ignition switch.
2. Pull the direction indicator lever as far as
possible towards the steering wheel (to
position 4) and release it.
3. Exit the vehicle and lock the doors.
The headlights and parking lights will illuminate
and remain on for 30
1, 60 or 90 seconds. The
1Factory setting

02 Instruments and controls
Left-side steering wheel lever
0267
time interval can be changed by a trained and
qualified Volvo service technician.

02 Instruments and controlsRight-side steering wheel lever
0268
Windshield wipers
G026953
Thumb wheelRain sensor on/off
Windshield wipers off
If the lever is in the 0 position and
you move it upwards, the wipers
will sweep one stroke at a time for
as long as you hold the lever up.
Single sweep position
Move the lever slightly upward
from the 0 position for one sweep
of the wipers. The lever returns
automatically to 0 when released.
Intermittent wiper function
With the lever in this position, you
can set the wiper interval by twist-
ing the control ring 1 upward to
increase wiper speed or down-
ward to decrease the speed.
Windshield washer/headlight washer
(certain models)When the lever is pulled to wash the wind-
shield, high pressure jets mounted in the
bumper will spray the headlights.
CAUTION
•
Use ample washer fluid when washing
the windshield to avoid scratching the
glass. The windshield should be thor-
oughly wet when the wipers are in oper-
ation.
•
Before using the wipers, ice and snow
should be removed from the wind-
shield/rear window. Be sure the wiper
blades are not frozen in place.
•
To conserve washer fluid in driving condi-
tions where the windshield washers are
used frequently, the headlights will only be
washed once for every five times the wind-
shield is washed within a 10-minute period.
•
A short pull on the lever will wash the wind-
shield only.
•
When approximately 1 US quart (1 liter)
remains in the washer fluid reservoir, the
headlights will not be washed when the
lever is pulled to conserve washer fluid for
the windshield.
Continuous wiper functionTop arrow: normal speed
Bottom arrows: higher speed

02 Instruments and controls
Right-side steering wheel lever
0269 Tailgate wiper/washer
G027127
Intermittent wiping: Press the upper
section of the switch Neutral position: The wiper is switched
off Normal (continuous) wiping: Press the
lower section of the switch
Move the lever forward to start the tailgate
washer. After washing the rear window, the
wiper will make several additional sweeps.
Tailgate wiper and reverse gearIf the front wipers are on and the transmission
is put into reverse gear, the tailgate wiper will
go into intermittent wiping function
1.
If the tailgate wiper is already in normal wiping
function, the normal wiping function will con-
tinue.
Rain sensor (option)The rain sensor automatically regulates wiper
speed according to the amount of water on the
windshield.
Thesensitivity of the sensor can be adjusted
by twisting ring 1 up (the wipers will sweep the
windshield more frequently) or down (the wip-
ers will sweep the windshield less frequently).Activating the rain sensor:1. Turn the ignition key to at least position I
and put the windshield wiper lever in posi-
tion0.
2. Press button (2).
> A light in the button will light up to indi-
cate that the rain sensor is active.Deactivating the rain sensor:•
Press button (2).
or
•
Move the windshield wiper lever down to
another position. Moving the lever up will
not deactivate the rain sensor. Doing so
will cause the wipers to sweep the wind-
shield until the lever is released, at which
time the wipers return to rain sensor mode.
The rain sensor is also deactivated when the
key is removed from the ignition.CAUTION
The rain sensor should be deactivated when
washing the vehicle in an automatic car
wash, etc. If the rain sensor function is left
on, the wipers will start inadvertently in the
car wash and could be damaged.
1Consult your Volvo retailer if you would like to have this function deactivated.

02 Instruments and controlsHazard warning flashers
0270
Hazard warning flashers
12
3
45
6
78
9 ABC
DEF
GHI
JKL
MNO
PQRS
TUVWXYZ
0*
#POWERVOLUMECDAM FM
G027096
The four-way flasher should be used to indi-
cate that the vehicle has become a traffic haz-
ard. To activate the flashers, press the triangu-
lar button in the center dash. Press the button
again to turn off the flashers.
NOTE
Regulations regarding the use of the hazard
warning flasher may vary, depending on
where you live.
Rear window and door mirror defroster
Press the switch to start heat-
ing the rear window and door
mirrors to remove ice or con-
densation. A light in the switch
will light up.
A timer automatically switches off the heating
after approximately 12 minutes. The LED will
go out correspondingly.

02 Instruments and controls
Trip computer
02``71 Trip computer (option)
G026956
READ (press to acknowledge/confirm/
erase a message)Thumb wheel (used to scroll among the trip
computer menus)RESET
The trip computer stores information gathered
from several systems in your vehicle and has
four menus that can be displayed in the text
window.
•
Driving distance on current fuel reserve
•
Average fuel consumption
•
Current fuel consumption
•
Average speed
•
Current speed in mph (Canadian models
only)
•
DSTC (see page 145 for detailed informa-
tion)NOTE
Warning messages from the vehicle's moni-
toring systems will override the trip com-
puter function. If a warning message is
displayed in the text window while you are
using the trip computer, you must acknowl-
edge the message by pressing button A.
Press button A again to return to the trip
computer function.1. Trip computer controls and functionsThe trip computer functions can be accessed
by twisting INFO (B) one step at a time in either
direction. Twisting a final time returns you to
the original function.
The trip computer can be reset (current data
will be erased from system memory) by press-
ing RESET (button C).2. Driving distance on current fuel
reserveThis function shows the approximate distance
that can be driven on the fuel remaining in the
tank. The calculation is based on average fuel
consumption during the last 20 miles (30 km)of driving and the amount of fuel remaining in
the tank when the reading was taken.
When
"----"
is displayed in the text window,
refuel as soon as possible.
3. Average fuel consumptionThis value indicates fuel consumption since the
last time the trip computer was reset (by press-
ingRESET, button C). When the engine is
switched off, information on fuel consumption
is stored and remains in system memory until
theRESET (button C) is pressed again.4. Current fuel consumptionThis value indicates the current fuel consump-
tion, based on readings taken once per sec-
ond. When the vehicle is not moving, "----" will
be displayed.5. Average speedThis value indicates average speed since the
last time the trip computer was reset (by press-
ingRESET, button C). When the engine is
switched off, information on average speed is
stored and remains in system memory until the
RESET (button C) is pressed again.

02 Instruments and controlsTrip computer
0272
6. Current speed in miles per hour
(Canadian models only)This function provides the driver with an instan-
taneous conversion of the vehicle's current
speed from km/h to mph.
NOTE
Trip computer readings may vary slightly
depending on the circumference of the tires
on the vehicle and driving style.
