2009 VOLVO S80 Owner´s Manual

02 Locks and alarm
Alarm
02``65 Disarming the alarm
±
Press the Unlock button on the remote key.
> Two short flashes from the car's direc-
tion indicators confirm that the alarm
has been deactivated and that all doors
are unlocked.Turning off (stopping) the alarmIf the alarm is sounding, it can be stopped by
pressing the Unlock button on the remote con-
trol or by inserting the remote key in the ignition
slot. Two short flashes from the car's direction
indicators confirm that the alarm has been
turned off.Other alarm-related functionsAutomatic re-armingIf the doors are unlocked, the locks will auto-
matically reengage (re-lock) and the alarm will
re-arm after 2 minutes unless a door or the
trunk has been opened.Audible/visual alarm signal•
An audible alarm signal is given by a bat-
tery powered siren. The alarm cycle lasts
for 30 seconds.
•
The visual alarm signal is given by flashing
all turn signals for approximately 5 minutes
or until the alarm is turned off.
Remote key not functioningIf the remote key is not functioning properly,
the alarm can be turned off and the vehicle can
be started as follows:
1. Open the driver's door with the key blade.
This will trigger the alarm.
2. Insert the remote key into the ignition slot.
This will turn off the alarm.Reduced alarm functionTurning off the accessory alarm sensors
G021360
Navigation (left/rght/up/down) buttonsENTERMENUEXITIn certain situations it may be desirable to turn
off the accessory inclination and movement
alarm sensors if, for example, you drive your
vehicle onto a ferry where the rocking of the
boat could trigger the alarm or if a pet is left in
the vehicle with the doors locked.
The vehicle's menu system is used for turning
off these sensors (see page 120 for a descrip-
tion of the menu system).
1.
Go into the menu under
Car settings
.
2.
Select
Reduced guard
(Press Enter to
choose).
3. Two alternatives are now available:
•Activate once
. If this alternative is
selected,
Reduced guard–see
manual will appear in the instrument
panel display and the accessory incli-
nation and movement alarm sensors will
be deactivated when the vehicle is
locked.
•Ask on exit
. If this alternative is
selected, the message
Press ENTER
to reduce guard until engine is
started—Press EXIT to cancel
will
appear in the center console display
each time the engine is turned off and
the accessory inclination and move-
ment alarm sensors will be deactivated
when the vehicle is locked.

02 Locks and alarmAlarm
0266
4.
PressENTER and lock the vehicle.
The next time the engine is started, the alarm
system will be reset and
Full guard
will appear
in the instrument panel display. The accessory
inclination and movement alarm sensors will be
reactivated.
In either of the alternatives, if you prefer not to
deactivate the accessory inclination and move-
ment alarm sensors, do not make a choice in
the menu or press EXIT and lock the vehicle.

02 Locks and alarm
0267

G020912
68
Instruments and controls........................................................................ 70
Ignition modes........................................................................................ 78
Seats....................................................................................................... 80
Seats¥S80 Executive ............................................................................. 85
Steering wheel........................................................................................ 87
Lighting................................................................................................... 88
Wipers and washers................................................................................ 94
Power windows....................................................................................... 96
Mirrors..................................................................................................... 98
Power moonroof................................................................................... 100
HomeLink® Wireless Control System (option).....................................102
Starting the engine................................................................................ 105
Transmission......................................................................................... 109
Brakes................................................................................................... 112
Parking brake........................................................................................ 114

03
YOUR DRIVING ENVIRONMENT

03 Your driving environmentInstruments and controls
0370
Instrument overview
G021107

03 Your driving environment
Instruments and controls
03``71
Function
Page
Menus and mes-
sages, turn signals,
high/low beams,
trip computer
120, 91,
88, 151
Cruise control
157
Horn, airbag
87, 18
Main instrument
panel
71
Menu system, audio
controls
131
Ignition slot
78
START/STOP
ENGINE button
78
Hazard warning
flashers
90
Door handle
–
In-door control pan-
els (power win-
dows, mirrors,
power child safety
locks, central lock-
ing button)
96, 98,
47, 61
Function
Page
Menu controls,
audio and climate
control systems
120, 134,
126
Center console but-
tons
120
Gear selector
109
Controls for active
chassis (Four-C)
156
Wipers and washers
94, 95
Steering wheel
adjustment
87
Parking brake
114
Hood opening con-
trol
215
Seat adjustment
controls
80
Lighting panel, but-
tons for opening
fuel filler door and
unlocking and
opening the trunk
88, 200,
62
Information displays
G010604
Information displays in the instrument panelThe information displays (1) show information
on some of the vehicle's functions, such as
cruise control, the trip computer and mes-
sages. The information is shown with text and
symbols.
More detailed information can be found in the
descriptions of the functions that use the infor-
mation displays.

03 Your driving environmentInstruments and controls
0372
Gauges
G010605
Gauges in the instrument panel
SpeedometerFuel gauge. Please note that the fuel level
indicator in the gauge moves from right to
left as the amount of fuel in the tank
decreases. See also the section on refuel-
ing beginning on page 198. See page
151 for more information on fuel level and
consumption.The tachometer shows engine speed in
thousands of revolutions per minute (rpm).
Do not drive continuously with the needle
in the red area of the gauge. The engine
management system will automatically
prevent excessively high engines speeds.
This will be noticeable as a pronounced
unevenness in engine speed.
Indicator, information, and warning
symbols
G010604
Indicator and warning symbols
Indicator and information symbolsIndicator and warning symbolsHigh beam and turn signal indicators
Function checkAll indicator and warning symbols light up in
ignition mode II or when the engine is started.
When the engine has started, all the symbols
should go out except the parking brake sym-
bol, which only goes out when the brake is
disengaged.
If the engine does not start or if the function
check is carried out in ignition mode II, all sym-
bols go out after 5 seconds except the symbolfor faults in the vehicle's emissions system and
the symbol for low oil pressure.
Certain symbols may not have their functions
illustrated, depending on the vehicle's equip-
ment.
Indicator and warning symbolsSymbol
DescriptionTrailer turn signal indicator
CHECK
ENGINE
Malfunction indicator lightAnti-lock brake system (ABS)Rear fog light onStability systemTire pressure monitoring sen-
sor (TPMS)Low fuel levelInformation symbol, see text
in information displayHigh beam indicator
