06 Maintenance and specifications
Fuses
06
241
Module B (white). Func-
tion
A
Front seat massage, arm rest
lights, refrigerator (option)
5
Control module Four C
(option)
15
Heated driver's seat (option)
15
Heated passenger's seat
(option)
15
Rear seat heater, passenger's
side (option)
15
AWD control module
10
Rear seat heater, driver's side
(option)
15
Folding head restraints
15
Power passenger's seat
(option)
25
Keyless drive (option)
20
Module B (white). Func-
tion
A
Electric parking brake – driv-
er's side (option)
30
Electric parking brake – pas-
senger's side (option)
30
Module D (blue). Func-
tion
A
Navigation system display
(option)
10
––SIRIUS satellite radio (option)
5
Audio amplifier
25
Audio system
15
–Reserve
–

06 Maintenance and specificationsWheels and tires
06242
IntroductionYour vehicle is equipped with tires according
to the vehicle's tire information placard on the
B-pillar (the structural member at the side of
the vehicle, at the rear of the driver's door
opening).
The tires have good road holding characteris-
tics and offer good handling on dry and wet
surfaces. It should be noted however that the
tires have been developed to give these fea-
tures on snow/ice-free surfaces.
Certain models are equipped with "all-season"
tires, which provide a somewhat higher degree
of road holding on slippery surfaces than tires
without the "all-season" rating. However, for
optimum road holding on icy or snow-covered
roads, we recommend suitable winter tires on
all four wheels.
CAUTION
Some Volvo models are equipped with an
Ultra High Performance tire and wheel com-
bination designed to provide maximum dry
pavement performance with consideration
for hydroplaning resistance. As such, they
may be more susceptible to road hazard
damage and, depending on driving condi-
tions, may achieve a tread life of less than
20,000 miles (30,000 km). Even if this vehi-
cle is equipped with Volvo’s advanced AWD
or DSTC system, these tires are not
designed for winter driving, and should be
replaced with winter tires when weather
conditions dictate.When replacing tires, be sure that the new tires
are the same size designation, type (radial) and
preferably from the same manufacturer, on all
four wheels. Otherwise there is a risk of altering
the car's roadholding and handling characte-
ristics.Storing wheels and tiresWhen storing complete wheels (tires mounted
on rims), they should be suspended off the
floor or placed on their sides on the floor.
Tires not mounted on rims should be stored on
their sides or standing upright, but should not
be suspended.
CAUTION
Tires should preferably be stored in a cool,
dry, dark place, and should never be stored
in close proximity to solvents, gasoline, oils,
etc.Tread wear indicator
G021829
Tread wear indicatorThe tires have wear indicator strips running
across or parallel to the tread. The letters TWI
are printed on the side of the tire. When
approximately 1/16 " (1.6 mm) is left on the
tread, these strips become visible and indicate
that the tire should be replaced. Tires with less
than 1/16 " (1.6 mm) tread offer very poor trac-
tion.

06 Maintenance and specifications
Wheels and tires
06``243
When replacing worn tires, it is recommended
that the tire be identical in type (radial) and size
as the one being replaced. Using a tire of the
same make (manufacturer) will prevent altera-
tion of the driving characteristics of the vehicle.
WARNING
•
The wheel and tire sizes for your Volvo
are specified to meet stringent stability
and handling requirements. Unap-
proved wheel/tire size combinations
can negatively affect your vehicle's sta-
bility and handling. Approved tire sizes
are shown in the Tire inflation pressure
tables.
•
Any damage caused by installation of
unapproved wheel/tire size combina-
tions will not be covered by your new
vehicle warranty. Volvo assumes no
responsibility for death, injury, or
expenses that may result from such
installations.
New tires
G021823
Remember that tires are perishable goods. As
of 2000, the manufacturing week and year
(Department of Transportation (DOT) stamp)
will be indicated with 4 digits (e.g. 1502 means
that the tire illustrated was manufactured dur-
ing week 15 of 2002).Tire age•
Tires degrade over time, even when they
are not being used. It is recommended that
tires generally be replaced after 6 years of
normal service. Heat caused by hot cli-
mates, frequent high loading conditions or
Ultra Violet (U.V.) exposure can accelerate
the aging process.
•
You should replace the spare tire when you
replace the other road tires due to the
aging of the spare.
•
A tire's age can be determined by the DOT
stamp on the sidewall (see the illustration).
•
A tire with e.g., visible cracks or discolor-
ation should be replaced immediately.
Improving tire economy•
Maintain correct tire pressure. See the tire
pressure tables on pages 246 and 247.
•
Drive smoothly: avoid fast starts, hard
braking and tire screeching.
•
Tire wear increases with speed.
•
Correct front wheel alignment is very
important.
•
Unbalanced wheels impair tire economy
and driving comfort.
•
Tires must maintain the same direction of
rotation throughout their lifetime.
•
When replacing tires, the tires with the
most tread should be mounted on the rear
wheels to reduce the chance of oversteer
during hard braking.
•
Hitting curbs or potholes can damage the
tires and/or wheels permanently.

06 Maintenance and specificationsWheels and tires
06244
Tire inflation
G032521
Tire inflation placard on U.S. modelsTire inflationCheck tire inflation pressure regularly.
Tables listing the recommended inflation pres-
sure for your vehicle can be found on pages
246 and 247. A tire inflation pressure placard
is also located on the driver's side B-pillar (the
structural member at the side of the vehicle, at
the rear of the driver's door opening). This plac-
ard indicates the designation of the factory-
mounted tires on your vehicle, as well as load
limits and inflation pressure.
NOTE
•
The placards shown indicate inflation
pressure for the tires installed on the
vehicle at the factory only.
•
A certain amount of air seepage from
the tires occurs naturally and tire pres-
sure fluctuates with seasonal changes
in temperature. Always check tire pres-
sure regularly.
•
Use a tire gauge to check the tire inflation
pressure, including the spare, at least once
a month and before long trips. You are
strongly urged to buy a reliable tire pres-
sure gauge, as automatic service station
gauges may be inaccurate.
•
Use the recommended cold inflation pres-
sure for optimum tire performance and
wear.
•
Under-inflation or over-inflation may cause
uneven treadwear patterns.NOTE
A certain amount of air seepage from the
tires occurs naturally and tire pressure fluc-
tuates with seasonal changes in tempera-
ture. Always check tire pressure regularly.
WARNING
•
Under-inflation is the most common
cause of tire failure and may result in
severe tire cracking, tread separation,
or "blow-out," with unexpected loss of
vehicle control and increased risk of
injury.
•
Under-inflated tires reduce the load car-
rying capacity of your vehicle.
G032522
Tire inflation placard on Canadian modelsWhen weather temperature changes occur, tire
inflation pressures also change. A 10-degree
temperature drop causes a corresponding
drop of 1 psi (7 kPa) in inflation pressure. Check
your tire pressures frequently and adjust them
to the proper pressure, which can be found on

06 Maintenance and specifications
Wheels and tires
06``245
the vehicle's tire information placard or certifi-
cation label.Checking tire pressure
Cold tiresInflation pressure should be checked when the
tires are cold.
The tires are considered to be cold when
they have the same temperature as the sur-
rounding (ambient) air.
This temperature is normally reached after the
vehicle has been parked for at least 3 hours.
After driving a distance of approximately
1 mile (1.6 km), the tires are considered to be
hot. If you have to drive farther than this dis-
tance to pump your tire(s), check and record
the tire pressure first and add the appropriate
air pressure when you get to the pump.
If checking tire pressure when the tire is hot,
never "bleed" or reduce air pressure. The tires
are hot from driving and it is normal for pres-
sures to increase above recommended cold
pressures. A hot tire at or below recommended
cold inflation pressure could be significantly
under-inflated.
To check inflation pressure:1. Remove the cap from the valve on one tire,
then firmly press the tire gauge onto the
valve.
2. Add air to reach the recommended air
pressure.
3. Replace the valve cap.
4. Repeat this procedure for each tire, includ-
ing the spare.
5. Visually inspect the tires to make sure there
are no nails or other objects embedded
that could puncture the tire and cause an
air leak.
6. Check the sidewalls to make sure there are
no gouges, cuts, bulges or other irregular-
ities.
NOTE
•
If you overfill the tire, release air by
pushing on the metal stem in the center
of the valve. Then recheck the pressure
with your tire gauge.
•
Some spare tires require higher inflation
pressure than the other tires. Consult
the tire inflation tables or see the infla-
tion pressure placard.
Tire specificationsSpeed ratingsThe speed ratings in the table translate as fol-
low:Speed ratingsM
81 mph (130 km/h)
Q
100 mph (160 km/h)
T
118 mph (190 km/h)
H
130 mph (210 km/h)
W
168 mph (270 km/h)
V
149 mph (240 km/h)
Y
186 mph (300 km/h)
Load ratingsThe speed ratings in the table translate as fol-
low:Load ratings91
1365 lbs (615 kg)
93
1433 lbs (650 kg)
99
1709 lbs (755 kg)

06 Maintenance and specificationsWheels and tires
06246
See also page 247 for an explanation of the designations on the sidewall of the tire.Tire inflation pressure table – U.S. modelsThe following tire pressures are recommended by Volvo for your vehicle. Refer to the tire inflation placard for information specific to the tires installed
on your vehicle at the factory.Tire size
Cold tire pressure for up to 5 personsFront
psi/kPa
Rear
psi/kPa
6-cylinder models
225/50 R 17
245/45 R 17
245/40 R18
35/240
35/240
V8 models
245/45 R 17
35/240
35/240
V8 models
245/40 R18
36/250
36/250
T 125/80 R 17
61/420
61/420

06 Maintenance and specifications
Wheels and tires
06``247 Tire inflation pressure table – Canadian models
The following tire pressures are recommended by Volvo for your vehicle. Refer to the tire inflation placard for information specific to the tires installed
on your vehicle at the factory.Tire size
Cold tire pressure for up to 5 persons
Optional tire pressure for up to 3 persons
Front
psi/kPa
Rear
psi/kPa
Front
psi/kPa
Rear
psi/kPa
6-cylinder models
225/50 R 17
245/45 R 17
38/260
38/260
32/220
32/220
6-cylinder models
245/40 R 18
38/260
38/260
33/230
33/230
V8 models
245/45 R 17
38/260
38/260
32/220
32/220
V8 models
38/260
38/260
35/240
35/240
T 125/80 R 17
61/420
61/420
61/420
61/420

06 Maintenance and specificationsWheels and tires
06248
Tire designations3
101112
45
6
7
8
9
21
G010753
Federal law mandates that tire manufacturers
place standardized information on the sidewall
of all tires (see the illustration).
The following information is listed on the tire
sidewall:
The tire designation (the following figures are
examples of a tire designation):
1.
215: the width of the tire (in millimeters)
from sidewall edge to sidewall edge. The
larger the number, the wider the tire.
2.
65: The ratio of the tire's height to its width.
3.
R: Radial tire.
4.
15: The diameter of the wheel rim (in
inches).5.
95: The tire's load index. In this example, a
load index of 95 equals a maximum load of
1521 lbs (690 kg).
6.
H: The tire's speed rating, or the maximum
speed at which the tire is designed to be
driven for extended periods of time, carry-
ing a permissible load for the vehicle, and
with correct inflation pressure. For exam-
ple, H indicates a speed rating of 130 mph
(210 km/h).
NOTE
This information may not appear on the tire
because it is not required by law.
7.
M+S or M/S = Mud and Snow, AT = All
Terrain,AS = All Season
8.
U.S. DOT Tire Identification Number
(TIN): This begins with the letters "DOT"
and indicates that the tire meets all federal
standards. The next two numbers or letters
are the plant code where it was manufac-
tured, the next two are the tire size code
and the last four numbers represent the
week and year the tire was built. For exam-
ple, the numbers 317 mean the 31st week
of 1997. After 2000 the numbers go to four
digits. For example, 2501 means the 25th
week of 2001. The numbers in between are
marketing codes used at the manufactur-
er's discretion. This information helps a tire
manufacturer identify a tire for safety recall
purposes.
9.
Tire Ply Composition and Material
Used: Indicates the number of plies indi-
cates or the number of layers of rubber-
coated fabric in the tire tread and sidewall.
Tire manufacturers also must indicate the
ply materials in the tire and the sidewall,
which include steel, nylon, polyester, and
others.
