2009 SATURN VUE HYBRID Owners Manual

Fuses Usage
ISRVMInside Rearview
Mirror
CLUSTERInstrument Panel
Cluster
AIR BAG Airbag System
OSRVMOutside Rearview
Mirror
KEY CAPKey Capture
Solenoid
WHL S/WSteering Wheel
Switch
F/DR LCKFront Driver Door
Lock
APO2Accessory Power
Outlet 2
BCM (VB3)Body Control
Module (BCM)
(VB3)
DR LCK Door Lock
BCM (VB6)Body Control
Module (VB6)
BCM (VB4)Body Control
Module (VB4)Fuses Usage
BCM (VB5)Body Control
Module (VB5)
TRL Trailer
AIRCON Air Conditioner
AUDIO Audio
BCM (VB7)Body Control
Module (VB7)
IGN SW Ignition Switch
AIR BAG Air Bag System
WASHER Washer Pump
APO1Accessory Power
Outlet 1
FSCMFuel Storage Control
Module
RR CLR Rear Closure
BCM (VB2)Body Control
Module (VB2)
DRLDaytime Running
Light
BCM (VB1)Body Control
Module (VB1)
ONSTAR OnStar
®
Relays Usage
RELAY
ACC/RAPAccessory, Retained
Accessory Power
(RAP) Relay
RELAY
RUN/C
RANKRun/Crank Relay
Underhood Fuse Block
The underhood fuse block is located
on the driver side of the engine
compartment, near the battery.
Notice:Spilling liquid on
any electrical components on the
vehicle may damage it. Always
keep the covers on any electrical
component.
Service and Appearance Care 5-77
ProCarManuals.com

FusesUsage
FAN MAIN Cooling Fan Main
REAR/WPR Rear Wiper Motor
FAN AUX Cooling Fan
AuxiliaryFuses
Usage
ECM/TCM/ SGCM Engine Control
Module/Transmission
Control
Module/Serial Data
Gateway
Communication
Module
Fuses
Usage
ECM Engine Control
Module
ENG-3 Engine 3
ENG-2 Engine 2
ENG-1 Engine 1
HYBRID BEC Hybrid BEC
RUN Run
S/ROOF Sunroof Module
HTD/SEAT Heated Seat Control
Module
BCM Body Control
Module
STRTR Starter Motor WPR Windshield Wiper
4WD/ESCM All-Wheel Drive
System
ABS Antilock Brake
System Module
A/C CLTCH Air Conditioning
Compressor
BLWR MTR Blower Motor
5-78 Service and Appearance Care
ProCarManuals.com

Fuses Usage
AMP Amplier
HORN Horn
ABSAntilock Brake
System Module
I/P BECInstrument Panel
Bussed Electrical
Center
FRT FOG Front Fog Lamps
I/P BECInstrument Panel
Bussed Electrical
Center
DRLDaytime Running
Light
T/LAMP RTRight Turn and
Parking Lamps
T/LAMP LTLeft Turn and
Parking Lamps
TRLR
T/LAMPTrailer Parking
Lamps
HDLPHILTPassenger Side
High-Beam
Headlamp
STOP LP Stoplamps
DEFOG Defroster FogFuses Usage
HDLP
LO RTDriver Side
Low-Beam
Headlamp
HDLP
LO LTPassenger Side
Low-Beam
Headlamp
HDLP
HI RTDriver Side
High-Beam
Headlamp
OSRVM
HTROutside Rearview
Mirror Heating
Relays Usage
FAN MAIN
RLYCooling Fan Main
Relay
FAN CTRL
RLYCooling Fan Control
Relay
FAN AUX
RLYCooling Fan
Auxiliary Relay
PWR/TRN
RLYEngine Control
Module/CAM,
Canister, Injectors,
Electronic Throttle
Control Relay
Relays Usage
STRTR
RLYStarter Relay
RUN RLY Run Relay
A/C CLTCH
RLYAir Conditioning
Compressor Relay
WPR SPD
RLYWindshield Wiper
Speed Relay
HORN RLY Horn Relay
WPR
CNTRL
RLYWindshield Wiper
Control Relay
T/LAMP
RLYParking Lamp Relay
HDLP
HI RLYHigh-Beam
Headlamp Relay
HDLP
LO RLYLow-Beam
Headlamp Relay
FRT FOG
RLYFront Foglamp
Relay
STOP
LP RLYStoplamp Relay
DEFOG
RLYDefogger Relay
Service and Appearance Care 5-79
ProCarManuals.com

Fuses Usage
HYBRID PUMPS Hybrid Pumps
HILL HOLD VLVS Hill Hold Valves
AUX
TRANSPUMP Auxiliary
Transmission
PumpRelays Usage
HILL HOLD VLVS Hill Hold Valves
AUX
TRANSPUMP Auxiliary
Transmission
Pump
5-80 Service and Appearance Care
ProCarManuals.com

Capacities and Specications
ApplicationCapacities
English Metric
Air Conditioning Refrigerant R134a For the air conditioning system refrigerant charge
amount, see the refrigerant caution label located under the hood. See your retailer for more information.
Cooling System 9.5 qt9.0 L
Engine Oil with Filter 5.0 qt4.7 L
Fuel Tank 18.0 gal68.1 L
Transmission (Bottom Pan Removal) 6.9 qt6.5 L
Wheel Nut Torque 100 ft lb140Y
All capacities are approximate. When adding, be sure to ll to the approximate level, as recommended in this
manual. Recheck uid level after lling.
Engine Specications
Engine VIN CodeTransmission Spark Plug Gap
2.4L L4 Engine ZAutomatic 0.040 in (1.01 mm)
Service and Appearance Care 5-81
ProCarManuals.com

✍NOTES
5-82 Service and Appearance Care
ProCarManuals.com

Maintenance
Schedule
Maintenance Schedule
Introduction.........................6-1
Maintenance
Requirements....................6-1
Your Vehicle and the
Environment......................6-2
Using the Maintenance
Schedule...........................6-2
Scheduled Maintenance......6-3
Additional Required
Services............................6-5
Maintenance Footnotes.......6-7
Owner Checks and
Services............................6-8
At Each Fuel Fill................6-8
At Least Once a Month......6-9
At Least Once a Year........6-9
Recommended Fluids
and Lubricants................6-11
Maintenance
Replacement Parts..........6-12
Engine Drive Belt
Routing...........................6-13
Maintenance Record.........6-14
Maintenance
Schedule
Introduction
Important: Keep engine oil at the
proper level and change as
recommended.
Maintenance
Requirements
Notice:Maintenance intervals,
checks, inspections, replacement
parts, and recommended uids
and lubricants as prescribed
in this manual are necessary to
keep this vehicle in good working
condition. Any damage caused
by failure to follow scheduled
maintenance might not be
covered by the vehicle warranty.
Maintenance Schedule 6-1
ProCarManuals.com

Your Vehicle and the
Environment
Proper vehicle maintenance not only
helps to keep the vehicle in good
working condition, but also helps the
environment. All recommended
maintenance is important. Improper
vehicle maintenance can even
affect the quality of the air we
breathe. Improper uid levels or the
wrong tire ination can increase
the level of emissions from the
vehicle. To help protect the
environment, and to keep the
vehicle in good condition, be sure to
maintain the vehicle properly.
Using the Maintenance
Schedule
We want to help keep this vehicle in
good working condition. But we
do not know exactly how you
will drive it. You might drive very
short distances only a few times a
week. Or you might drive long
distances all the time in very hot,
dusty weather. You might usethe vehicle in making deliveries. Or
you might drive it to work, to do
errands, or in many other ways.
Because of all the different
ways people use their vehicles,
maintenance needs vary. You might
need more frequent checks and
replacements. So please read the
following and note how you
drive. If you have any questions on
how to keep the vehicle in good
condition, see your dealer/retailer.
This schedule is for vehicles that:
carry passengers and cargo
within recommended limits on the
Tire and Loading Information
label. SeeLoading the Vehicle on
page 4-18.
are driven on reasonable road
surfaces within legal driving limits.
use the recommended fuel. See
Gasoline Octane on page 5-5.
The services inScheduled
Maintenance on page 6-3should be
performed when indicated. See
Additional Required Serviceson page 6-5andMaintenance
Footnotes on page 6-7for further
information.
{CAUTION
Performing maintenance work on
a vehicle can be dangerous. In
trying to do some jobs, you can
be seriously injured. Do your own
maintenance work only if you
have the required know-how and
the proper tools and equipment
for the job. If you have any doubt,
see your dealer/retailer to have a
qualied technician do the work.
SeeDoing Your Own Service
Work on page 5-4.
Some maintenance services can be
complex. So, unless you are
technically qualied and have the
necessary equipment, have
your dealer/retailer do these jobs.
6-2 Maintenance Schedule
