If the Off Indicator is Lit for an
Adult-Size Occupant
If a person of adult-size is sitting in
the right front passenger seat,
but the off indicator is lit, it could be
because that person is not sitting
properly in the seat.If this happens, use the following
steps to allow the system to detect
that person and enable the right
front passenger frontal airbag
and seat-mounted side impact
airbag:
1. Turn the vehicle off.
2. Remove any additional material
from the seat, such as blankets,
cushions, seat covers, seat
heaters, or seat massagers.
3. Place the seatback in the fully
upright position.
4. Have the person sit upright in the
seat, centered on the seat
cushion, with legs comfortably
extended.
5. Restart the vehicle and have the
person remain in this position for
two to three minutes after the
on indicator is lit.
Additional Factors Affecting
System Operation
Safety belts help keep the passenger
in position on the seat during vehicle
maneuvers and braking, which helps
the passenger sensing system
maintain the passenger airbag
status. See “Safety Belts” and “Child
Restraints” in the Index for additional
information about the importance of
proper restraint use.
Seats and Restraint System 1-53
ProCarManuals.com

A thick layer of additional material,
such as a blanket or cushion, or
aftermarket equipment such as seat
covers, seat heaters, and seat
massagers can affect how well the
passenger sensing system
operates. We recommend that you
not use seat covers or other
aftermarket equipment except when
approved by GM for your specic
vehicle. SeeAdding Equipment
to Your Airbag-Equipped Vehicle on
page 1-55for more information
about modications that can affect
how the system operates.
{CAUTION
Stowing of articles under the
passenger seat or between the
passenger seat cushion and
seatback may interfere with the
proper operation of the passenger
sensing system.
Servicing Your
Airbag-Equipped Vehicle
Airbags affect how the vehicle
should be serviced. There are parts
of the airbag system in several
places around the vehicle. Your
dealer/retailer and the service
manual have information about
servicing the vehicle and the airbag
system. To purchase a service
manual, seeService Publications
Ordering Information on page 7-13.
{CAUTION
For up to 10 seconds after the
ignition is turned off and the battery
is disconnected, an airbag can still
inate during improper service.
You can be injured if you are close
to an airbag when it inates. Avoid
yellow connectors. They are
probably part of the airbag system.
Be sure to follow proper service
procedures, and make sure the
person performing work for you is
qualied to do so.
1-54 Seats and Restraint System
ProCarManuals.com

Adding Equipment to
Your Airbag-Equipped
Vehicle
Q:Is there anything I might add
to or change about the
vehicle that could keep the
airbags from working
properly?
A:Yes. If you add things that
change the vehicle’s frame,
bumper system, height, front end
or side sheet metal, they may
keep the airbag system from
working properly. Changing or
moving any parts of the front
seats, safety belts, the airbag
sensing and diagnostic module,
steering wheel, instrument
panel, roof-rail airbag modules,
ceiling headliner or pillar
garnish trim, front sensors, side
impact sensors, rollover
sensor module, or airbag wiring
can affect the operation of
the airbag system.In addition, the vehicle has a
passenger sensing system for the
right front passenger position,
which includes sensors that are
part of the passenger seat. The
passenger sensing system may
not operate properly if the original
seat trim is replaced with non-GM
covers, upholstery or trim, or
with GM covers, upholstery or
trim designed for a different
vehicle. Any object, such as an
aftermarket seat heater or a
comfort enhancing pad or device,
installed under or on top of
the seat fabric, could also
interfere with the operation of
the passenger sensing system.
This could either prevent proper
deployment of the passenger
airbag(s) or prevent the
passenger sensing system from
properly turning off the passenger
airbag(s). SeePassenger
Sensing System on page 1-49.If you have questions, call
Customer Assistance. The phone
numbers and addresses for
Customer Assistance are in Step
Two of the Customer Satisfaction
Procedure in this manual. See
Customer Satisfaction Procedure
on page 7-1.
If the vehicle has rollover
roof-rail airbags, seeDifferent
Size Tires and Wheels on
page 5-53for additional
important information.
Seats and Restraint System 1-55
ProCarManuals.com

Q:Because I have a disability, I
have to get my vehicle
modied. How can I nd out
whether this will affect my
airbag system?
A:If you have questions, call
Customer Assistance. The phone
numbers and addresses for
Customer Assistance are in Step
Two of the Customer Satisfaction
Procedure in this manual. See
Customer Satisfaction Procedure
on page 7-1.
In addition, your dealer/retailer and
the service manual have information
about the location of the airbag
sensors, sensing and diagnostic
module and airbag wiring.
Restraint System
Check
Checking the Restraint
Systems
Safety Belts
Now and then, check that the safety
belt reminder light, safety belts,
buckles, latch plates, retractors, and
anchorages are all working properly.
Look for any other loose or
damaged safety belt system parts
that might keep a safety belt system
from doing its job. See your
dealer/retailer to have it repaired.
Torn or frayed safety belts may not
protect you in a crash. They can
rip apart under impact forces.
If a belt is torn or frayed, get a new
one right away.
Make sure the safety belt reminder
light is working. SeeSafety Belt
Reminders on page 3-24for more
information.Keep safety belts clean and dry.
SeeCare of Safety Belts on
page 5-69.
Airbags
The airbag system does not need
regularly scheduled maintenance or
replacement. Make sure the
airbag readiness light is working.
SeeAirbag Readiness Light
on page 3-25for more information.
Notice:If an airbag covering
is damaged, opened, or broken,
the airbag may not work properly.
Do not open or break the airbag
coverings. If there are any opened
or broken airbag covers, have
the airbag covering and/or airbag
module replaced. For the
location of the airbag modules,
seeWhat Makes an Airbag
Inflate? on page 1-47. See your
dealer/retailer for service.
1-56 Seats and Restraint System
ProCarManuals.com

Replacing Restraint
System Parts After a
Crash
{CAUTION
A crash can damage the restraint
systems in your vehicle. A
damaged restraint system may
not properly protect the person
using it, resulting in serious injury
or even death in a crash. To help
make sure your restraint systems
are working properly after a crash,
have them inspected and any
necessary replacements made as
soon as possible.
After a minor crash, replacement of
safety belts may not be necessary.
But the safety belt assemblies
that were used during any crash
may have been stressed or
damaged. See your dealer/retailer
to have the safety belt assemblies
inspected or replaced.If the vehicle has the LATCH
system and it was being used during
a crash, you may need new
LATCH system parts.
New parts and repairs may be
necessary even if the safety belt or
LATCH system (if equipped),
was not being used at the time of
the crash.
If an airbag inates, you will need to
replace airbag system parts. See
the part on the airbag system earlier
in this section.
Have the safety belt pretensioners
checked if the vehicle has been in a
crash, if the airbag readiness light
stays on after you start the vehicle,
or while you are driving. See
Airbag Readiness Light on
page 3-25.If an airbag inates or the vehicle
has been in a crash, the vehicle’s
sensing system may command
the automatic hybrid battery
disconnect to open. The battery will
disconnect. The hybrid battery
will be off and the vehicle will not
start. The airbag readiness light may
come on. SeeAirbag Readiness
Light on page 3-25for more
information. To operate the vehicle,
the automatic hybrid battery
disconnect must be reconnected by
a qualied service technician and
sensing system parts will need to be
replaced. Have the vehicle
serviced right away.
Seats and Restraint System 1-57
ProCarManuals.com

✍NOTES
1-58 Seats and Restraint System
ProCarManuals.com

Features and
Controls
Keys
Keys...................................2-2
Remote Keyless Entry
(RKE) System...................2-3
Remote Keyless Entry
(RKE) System Operation. . .2-4
Doors and Locks
Door Locks.........................2-6
Power Door Locks..............2-6
Delayed Locking.................2-6
Automatic Door Lock..........2-7
Automatic Door Unlock.......2-7
Rear Door Security
Locks................................2-7
Lockout Protection..............2-7
Liftgate...............................2-8
Windows
Windows.............................2-9
Power Windows..................2-9
Sun Visors........................2-10
Theft-Deterrent Systems
Theft-Deterrent Systems. . . .2-10
Content Theft-Deterrent.....2-10
PASS-Key®III+ Electronic
Immobilizer......................2-12
PASS-Key®III+ Electronic
Immobilizer Operation......2-12
Starting and Operating
Your Vehicle
New Vehicle Break-In.......2-14
Ignition Positions...............2-14
Retained Accessory
Power (RAP)...................2-15
Starting the Engine
(Automatic Engine
Start/Stop)
.......................2-15
Engine Coolant Heater......2-19
Automatic Transmission
Operation........................2-20
Parking Brake...................2-22
Regenerative Braking........2-23
Shifting Into Park..............2-23
Shifting Out of Park..........2-25
Parking Over Things
That Burn........................2-25
Engine Exhaust.................2-26
Running the Vehicle
While Parked..................2-26
Mirrors
Manual Rearview Mirror. . . .2-27
Automatic Dimming
Rearview Mirror...............2-27
Outside Power Mirrors......2-28
Outside Convex Mirror......2-28
Outside Heated Mirrors.....2-28
OnStar®System
OnStar®System................2-29
Universal Home Remote
System
Universal Home Remote
System............................2-32
Universal Home Remote
System Operation............2-33
Features and Controls 2-1
ProCarManuals.com

Storage Areas
Glove Box.........................2-37
Cupholders.......................2-37
Sunglasses Storage
Compartment...................2-37
Center Console Storage. . . .2-37
Driver Storage
Compartment...................2-38
Rear Seat Armrest............2-38
Convenience Net..............2-38
Cargo Cover.....................2-38
Cargo Tie Downs..............2-39
Cargo Management
System............................2-39
Keys
{CAUTION
Leaving children in a vehicle with
the ignition key is dangerous for
many reasons, children or others
could be badly injured or even
killed. They could operate the
power windows or other controls
or even make the vehicle move.
The windows will function with the
keys in the ignition and children
could be seriously injured or killed
if caught in the path of a closing
window. Do not leave the keys in
a vehicle with children.The two keys can be used for the
ignition and all locks.
The key code is stamped on the key
number plate and can be used to
make new keys at any dealer/
retailer. Store this information in a
safe place outside the vehicle.
2-2 Features and Controls
ProCarManuals.com
