2009 PONTIAC VIBE Owners Manual

Five things that do not indicate a
problem with the fuel gage:
At the gas station, the fuel pump
shuts off before the gage reads
F or full.
It takes a little more or less fuel
to ll up than the gage indicated.
For example, the gage may
have indicated the tank was half
full, but it actually took more
or less than half the tank’s
capacity to ll it.
It takes the gage several minutes
to read F or full after lling the
vehicle with fuel.
The gage moves a little when
you turn, stop or speed up.
The gage does not go back to
E or empty when you turn off
the ignition.
Low Fuel Warning Light
This light, on the fuel gage, comes
on when the fuel tank is low on
fuel. To turn if off, add fuel to the
fuel tank.
OnStar®System
OnStar uses several innovative
technologies and live advisors to
provide a wide range of safety,
security, information, and
convenience services. If the airbags
deploy, the system is designed to
make an automatic call to OnStar
Emergency advisors who can
request emergency services be
sent to your location. If the keys are
locked in the vehicle, call OnStar at
1-888-4-ONSTAR to have a signal
sent to unlock the doors. OnStar
Hands-Free Calling, including
30 trial minutes good for 60 days, is
available on most vehicles. Press the
OnStar button to have an OnStar
advisor contact Roadside Service. United States
Canada
Instruments and Controls 4-25
2009 - Pontiac Vibe Owner Manual

OnStar service is provided subject
to the OnStar Terms and Conditions
included in the OnStar Subscriber
glove box literature.
Some services such as Remote Door
Unlock or Stolen Vehicle Location
Assistance may not be available until
the owner of the vehicle registers
with OnStar. After the rst prepaid
year, contact OnStar to select a
monthly or annual subscription
payment plan. If a payment plan is
not selected, the OnStar system
and all services, including airbag
notication and emergency services,
may be deactivated and no longer
available. For more information
visit www.onstar.com (U.S.) or
www.onstar.ca (Canada), or press
the OnStar button to speak with an
advisor.
Not all OnStar services are available
on all vehicles. To check if this
vehicle is able to provide the
services described below, or for a
full description of OnStar servicesand system limitations, see the
OnStar Owner’s Guide in the
glove box or visit www.onstar.com
(U.S.) or www.onstar.ca (Canada),
contact OnStar at 1-888-4-ONSTAR
(1-888-466-7827) or TTY
1-877-248-2080, or press the
OnStar button to speak with an
OnStar advisor 24 hours a day,
7 days a week.
OnStar Services Available
with the Safe & Sound Plan

Automatic Notication of
Airbag Deployment
Link to Emergency Services
Roadside Assistance
Stolen Vehicle Location
Assistance
Remote Door Unlock/Vehicle
Alert
OnStar Hands-Free Calling with
30 trial minutes
OnStar Virtual Advisor (U.S. Only)
OnStar Services Included with
Directions & Connections Plan

All Safe and Sound Plan Services
Driving Directions - Advisor
Delivered
RideAssist
Information and Convenience
Services
OnStar Hands-Free Calling
OnStar Hands-Free Calling allows
eligible OnStar subscribers to make
and receive calls using voice
commands. Hands-Free Calling is
fully integrated into the vehicle, and
can be used with OnStar Pre-Paid
Minute Packages. Most vehicles
include 30 trial minutes good for
60 days. Hands-Free Calling can
also be linked to a Verizon Wireless
service plan in the U.S. or a Bell
Mobility service plan in Canada,
depending on eligibility.
4-26 Instruments and Controls
2009 - Pontiac Vibe Owner Manual

To nd out more, refer to the OnStar
Owner’s Guide in the vehicle’s glove
box, visit www.onstar.com or
www.onstar.ca, or speak with
an OnStar advisor by pressing
the OnStar button or calling
1-888-4-ONSTAR (1-888-466-7827).
OnStar Virtual Advisor
OnStar Virtual Advisor is a feature of
OnStar Hands-Free Calling that uses
minutes to access location-based
weather, local traffic reports, and
stock quotes. Press the phone
button and give a few simple voice
commands to browse through the
various topics. See the OnStar
Owner’s Guide for more information.
This feature is only available in the
continental U.S.
How OnStar Service Works
The OnStar system can record
and transmit vehicle information.
This information is automatically
sent to an OnStar Call Center when
the OnStar button is pressed, the
emergency button is pressed, or ifthe airbags deploy. This information
usually includes the vehicles GPS
location and, in the event of a crash,
additional information regarding the
crash that the vehicle was involved in
(e.g. the direction from which the
vehicle was hit). When the Virtual
Advisor feature of OnStar
Hands-Free Calling is used, the
vehicle also sends OnStar the
vehicles GPS location so they can
provide services where it is located.
OnStar service cannot work unless
the vehicle is in a place where
OnStar has an agreement with a
wireless service provider for service
in that area. OnStar service also
cannot work unless the vehicle is in
a place where the wireless service
provider OnStar has hired for that
area has coverage, network capacity
and reception when the service is
needed, and technology that is
compatible with the OnStar service.
Not all services are available
everywhere, particularly in remote
or enclosed areas, or at all times.Location information about the
vehicle is only available if the GPS
satellite signals are unobstructed
and available.
The vehicle must have a working
electrical system, including adequate
battery power, for the OnStar
equipment to operate. There are
other problems OnStar cannot
control that may prevent OnStar from
providing OnStar service at any
particular time or place. Some
examples are damage to important
parts of the vehicle in a crash, hills,
tall buildings, tunnels, weather or
wireless phone network congestion.
Your Responsibility
Increase the volume of the radio if
the OnStar advisor cannot be heard.
If the light next to the OnStar buttons
is red, the system may not be
functioning properly. If the light
appears clear (no light is appearing),
your OnStar subscription has
expired and all services have been
deactivated. Press the OnStar button
to conrm that the OnStar equipment
is active.
Instruments and Controls 4-27
2009 - Pontiac Vibe Owner Manual

✍NOTES
4-28 Instruments and Controls
2009 - Pontiac Vibe Owner Manual

Lighting
Lighting
Exterior Lamps Controls.....5-1
Daytime Running
Lamps (DRL)....................5-2
Automatic Headlamp
System.............................5-2
Fog Lamps.........................5-2
Instrument Panel
Brightness.........................5-3
Dome Lamp(s)....................5-3
Entry Lighting.....................5-3
Reading Lamps..................5-4
Battery Run-Down
Protection.........................5-4
Lighting
Exterior Lamps Controls
The lever on the left side of the
steering column operates the
exterior lamps.
P/;(Exterior Lamps):Turn the
outside band of the lever to operate
the lamps. For vehicles sold in the
U.S.,
Pappears on the instrument
panel cluster when the exterior
lamps are on. For vehicles rst
sold in Canada,
;appears in the
instrument panel cluster. SeeLights
On Reminder on page 4-23.The exterior lamp switch has three
positions:
((Off):Turns off all lamps, except
the Daytime Running Lamps (DRL).
;(Parking Lamps):Turns on
the parking lamps together with the
following:
Sidemarker Lamps
Taillamps
License Plate Lamp
Instrument Panel Lights
5(Headlamps):Turns on the
headlamps, together with the
previously listed lamps and lights.
Headlamps on Reminder
A tone sounds when the ignition is
turned to LOCK/OFF, the driver
door is opened and the key
is removed from the ignition while
the lamps are on.
Lighting 5-1
2009 - Pontiac Vibe Owner Manual

Daytime Running
Lamps (DRL)
Daytime Running Lamps (DRL) can
make it easier for others to see
the front of your vehicle during the
day. Fully functional DRL are
required on all vehicles rst sold
in Canada.
The DRL system makes the
headlamps come on at a reduced
brightness when the following
conditions are met:
The ignition is on with the
engine running.
The exterior lamps switch is off.
The parking brake is released.
When the exterior lamp switch
is turned to the headlamp position,
the DRL go off and the headlamps
come on. The other lamps that
come on with the headlamps also
come on.The headlamps automatically switch
from DRL to the regular headlamps
depending on the darkness of
the surroundings. See “Automatic
Headlamp System” following.
DRL also comes on if only the
parking lamps are being used.
Automatic Headlamp
System
When it is dark enough outside,
the automatic headlamp system
turns on the low-beam headlamps at
the normal brightness along with
other lamps such as the taillamps,
sidemarker, parking lamps and
instrument panel lights. An indicator
light on the instrument panel comes
on when the headlamps are on.
SeeInstrument Panel Cluster on
page 4-12.If the vehicle is driven through a
parking garage, overcast weather, or
a tunnel, the automatic headlamp
system may turn on. There is
a delay before the lights turn on
when starting the car at night.
Do not cover the automatic light
sensor, located on the top left corner
of the instrument panel. If the
sensor is covered the headlamps
will stay on continuously.
Fog Lamps
#
(Fog Lamps):For vehicles with
fog lamps, move the band on the turn
signal/multifunction lever to
#to turn
them on. The fog lamps only come
on when the headlamps are on
low beam.
Some localities have laws that
require the headlamps to be
on along with the fog lamps.
5-2 Lighting
2009 - Pontiac Vibe Owner Manual

Instrument Panel
Brightness
Use the trip odometer knob located
on the right side of the instrument
panel cluster to adjust the
instrument panel brightness.
Turn the knob clockwise or
counterclockwise to brighten
or dim the instrument panel.
The brightness of the instrument
panel lights decreases when
the headlamps are on.
Dome Lamp(s)
The interior lamps control is located
on the overhead lamp. To change
the interior lamps setting, slide
the switch to one of the following
positions:
OFF:Turns the lamp off.
ON:Keeps the lamp on all
the time.
Door:Turns the lamp on when
any door or the liftgate is opened.
The lamp goes off when all the side
doors and the liftgate are closed.
If the lamp switch is in the door
position and a door is left open,
the lamps will go off automatically
after 20 minutes.
Entry Lighting
After all the doors and liftgate
are closed, and the key is out of
the ignition, in LOCK/OFF or
ACC/ACCESSORY, the light
remains on for about 15 seconds
and then goes out, except under
the following conditions:
The ignition is turned to
ACC/ACCESSORY or ON/RUN
after all the doors and liftgate
are closed.
All the doors and the liftgate are
locked and the light is still on.
When any door is unlocked with the
key or Remote Keyless Entry (RKE)
system transmitter, the light comes
on for 15 seconds, even if the door is
not opened.
Lighting 5-3
2009 - Pontiac Vibe Owner Manual

Reading Lamps
For vehicles with a sunroof, there is
a reading lamp near the sunroof
switch.
OFF:Turns the lamp off.
ON:Keeps the lamp on all
the time.
Door:Turns the lamp on when
any door or the liftgate is opened.
The lamp goes off when all the side
doors and the liftgate are closed.
Battery Run-Down
Protection
The vehicle has a battery saver
feature designed to protect
the vehicle’s battery.
This feature will only work with the
dome lamp in the Door position.
When any interior lamp is left on
and the ignition is turned off,
the battery rundown protection
system automatically turns the lamp
off after 20 minutes. This prevents
draining of the battery.
5-4 Lighting
2009 - Pontiac Vibe Owner Manual
