2009 INFINITI QX56 display

DEF-6
< FUNCTION DIAGNOSIS >
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Function (BCM - COMMON ITEM)INFOID:0000000004223690
APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions for each system.
NOTE:
It can perform the diagnosis modes except the following for all sub system selection items.
REAR WINDOW DEFOGGER
Diagnosis mode Function Description
WORK SUPPORT Changes the setting for each system function.
SELF-DIAG RESULTS Displays the diagnosis results judged by BCM. Refer to BCS-51, "
DTCIndex".
CAN DIAG SUPPORT MNTR Monitors the reception status of CAN communication viewed from BCM.
DATA MONITOR The BCM input/output signals are displayed.
ACTIVE TEST The signals used to activate each device are forcibly supplied from BCM.
ECU IDENTIFICATION The BCM part number is displayed.
CONFIGURATION • Enables to read and save the vehicle specification.
• Enables to write the vehicle specification when replacing BCM.
System
Sub system selection item Diagnosis mode
WORK SUPPORT DATA MONITOR ACTIVE TEST
BCM BCM ×
Door lock DOOR LOCK ×××
Rear window defogger REAR DEFOGGER ×
Warning chime BUZZER ××
Interior room lamp timer INT LAMP ×××
Remote keyless entry system MULTI REMOTE ENT ××
Exterior lamp HEAD LAMP ×××
Wiper and washer WIPER ×××
Turn signal and hazard warning lamps FLASHER ××
Air conditioner AIR CONDITONER ×
Intelligent Key system INTELLIGENT KEY ×
Combination switch COMB SW ×
Immobilizer IMMU ××
Interior room lamp battery saver BATTERY SAVER ×××
Back door open TRUNK ××
RAP (retained accessory power) RETAINED PWR ×××
Signal buffer system SIGNAL BUFFER ××
TPMS (tire pressure monitoring sys-
tem) AIR PRESSURE MONITOR
×××
Vehicle security system PANIC ALARM ×
Revision: December 20092009 QX56

DIAGNOSIS SYSTEM (BCM)DEF-7
< FUNCTION DIAGNOSIS >
C
DE
F
G H
I
J
K
M A
B
DEF
N
O P
REAR WINDOW DEFOGGER : CONSULT-III Function (BCM - REAR DEFOGGER)
INFOID:0000000004223691
DATA MONITOR
Monitor Item [Unit] Description
IGN ON SW [ON/OFF] Indicates condition of ignition switch in ON position
IGN ACC SW [ON/OFF] Indicates condition of ignition switch in ACC position
REAR DEF SW [ON/OFF] Displays “Press (ON)/other (OFF)” status determin ed with the rear window defogger switch
Revision: December 20092009 QX56

BCM (BODY CONTROL MODULE)DEF-33
< ECU DIAGNOSIS >
C
DE
F
G H
I
J
K
M A
B
DEF
N
O P
DTC Inspection Priority ChartINFOID:0000000004223696
If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.
DTC IndexINFOID:0000000004223697
NOTE: Details of time display
• CRNT: Displays when there is a malfunction now or after returning to the normal condition until turning igni-
tion switch OFF → ON again.
• 1 - 39: Displayed if any previous ma lfunction is present when current conditi on is normal. It increases like 1
→ 2 → 3...38 → 39 after returning to the normal condition whenever ignition switch OFF → ON. The counter
remains at 39 even if the number of cycles exceeds it. It is counted from 1 again when turning ignition switch
OFF → ON after returning to the normal condi tion if the malfunction is detected again.
Display contents of CONSULT Fail-safe Cancellation
U1000: CAN COMM CIRCUIT I nhibit engine crankingWhen the BCM re-establishes communication with the other mod-
ules.
U1010: CONTROL UNIT (CAN) Inhibit engine cranking When the BCM re-start communicating with the other modules.
Priority DTC
1 • U1000: CAN COMM CIRCUIT
• U1010: CONTROL UNIT (CAN)
2 • B2190: NATS ANTENNA AMP
• B2191: DIFFERENCE OF KEY
• B2192: ID DISCORD BCM-ECM
• B2193: CHAIN OF BCM-ECM
• B2013: STRG COMM 1
• B2552: INTELLIGENT KEY
• B2590: NATS MALFUNCTION
3 • C1729: VHCL SPEED SIG ERR
• C1735: IGNITION SIGNAL
4 • C1704: LOW PRESSURE FL
• C1705: LOW PRESSURE FR
• C1706: LOW PRESSURE RR
• C1707: LOW PRESSURE RL
• C1708: [NO DATA] FL
• C1709: [NO DATA] FR
• C1710: [NO DATA] RR
• C1711: [NO DATA] RL
• C1712: [CHECKSUM ERR] FL
• C1713: [CHECKSUM ERR] FR
• C1714: [CHECKSUM ERR] RR
• C1715: [CHECKSUM ERR] RL
• C1716: [PRESSDATA ERR] FL
• C1717: [PRESSDATA ERR] FR
• C1718: [PRESSDATA ERR] RR
• C1719: [PRESSDATA ERR] RL
• C1720: [CODE ERR] FL
• C1721: [CODE ERR] FR
• C1722: [CODE ERR] RR
• C1723: [CODE ERR] RL
• C1724: [BATT VOLT LOW] FL
• C1725: [BATT VOLT LOW] FR
• C1726: [BATT VOLT LOW] RR
• C1727: [BATT VOLT LOW] RL
Revision: December 20092009 QX56

DEF-34
< ECU DIAGNOSIS >
BCM (BODY CONTROL MODULE)
CONSULT displayFail-safeIntelligent Key
warning lamp ON Tire pressure
monitor warning lamp ON Reference page
No DTC is detected.
further testing
may be required. ————
U1000: CAN COMM CIRCUIT ———BCS-30
U1010: CONTROL UNIT (CAN) ———BCS-31
B2190: NATS ANTENNA AMP ———SEC-27
B2191: DIFFERENCE OF KEY ———SEC-30
B2192: ID DISCORD BCM-ECM ———SEC-31
B2193: CHAIN OF BCM-ECM ———SEC-33
B2552: INTELLIGENT KEY ———SEC-35
B2590: NATS MALFUNCTION ———SEC-36
C1704: LOW PRESSURE FL ———WT-26
C1705: LOW PRESSURE FR ———WT-26
C1706: LOW PRESSURE RR ———WT-26
C1707: LOW PRESSURE RL ———WT-26
C1708: [NO DATA] FL ———WT-14
C1709: [NO DATA] FR ———WT-14
C1710: [NO DATA] RR ———WT-14
C1711: [NO DATA] RL ———WT-14
C1712: [CHECKSUM ERR] FL ———WT-16
C1713: [CHECKSUM ERR] FR ———WT-16
C1714: [CHECKSUM ERR] RR ———WT-16
C1715: [CHECKSUM ERR] RL ———WT-16
C1716: [PRESSDATA ERR] FL ———WT-18
C1717: [PRESSDATA ERR] FR ———WT-18
C1718: [PRESSDATA ERR] RR ———WT-18
C1719: [PRESSDATA ERR] RL ———WT-18
C1720: [CODE ERR] FL ———WT-16
C1721: [CODE ERR] FR ———WT-16
C1722: [CODE ERR] RR ———WT-16
C1723: [CODE ERR] RL ———WT-16
C1724: [BATT VOLT LOW] FL ———WT-16
C1725: [BATT VOLT LOW] FR ———WT-16
C1726: [BATT VOLT LOW] RR ———WT-16
C1727: [BATT VOLT LOW] RL ———WT-16
C1729: VHCL SPEED SIG ERR ———WT-19
C1735: IGNITION SIGNAL ————
Revision: December 20092009 QX56

DLK-3
C
DE
F
G H
I
J
L
M A
B
DLK
N
O P
PASSENGER SIDE : Diagnosis Procedure ........
....
87
REAR LH ............................................................... ....88
REAR LH : Description ............................................88
REAR LH : Component Function Check ...............88
REAR LH : Diagnosis Procedure ............................88
REAR RH ............................................................... ....89
REAR RH : Description ...........................................89
REAR RH : Component Function Check ...............90
REAR RH : Diagnosis Procedure ............................90
BACK DOOR ......................................................... ....91
BACK DOOR : Description ......................................91
GLASS HATCH LOCK ACTUATOR ..................92
Diagnosis Procedure ...............................................92
PASSENGER SELECT UNLOCK RELAY .........93
Description .......................................................... ....93
Component Function Check ....................................93
Diagnosis Procedure ...............................................93
INTELLIGENT KEY WARNING BUZZER ..........95
Description .......................................................... ....95
Component Function Check ..................................95
Diagnosis Procedure ...............................................95
Component Inspection ............................................96
OUTSIDE KEY ANTENNA .................................97
Description .......................................................... ....97
Component Function Check ..................................97
Diagnosis Procedure ...............................................97
STEERING LOCK UNIT .....................................99
Diagnosis Procedure ........................................... ....99
A/T SHIFT SELECTOR (PARK POSITION
SWITCH) ...........................................................
101
Diagnosis Procedure ........................................... ..101
REMOTE KEYLESS ENTRY RECEIVER ........103
Description .......................................................... ..103
Component Function Check ................................103
Diagnosis Procedure .............................................103
INTELLIGENT KEY BATTERY AND FUNC-
TION .................................................................
106
Description .......................................................... ..106
Component Function Check ................................106
Diagnosis Procedure .............................................106
HORN FUNCTION ............................................108
Description .......................................................... ..108
Component Function Check ................................108
Diagnosis Procedure ............................................108
COMBINATION METER DISPLAY FUNC-
TION .................................................................
110
Description .......................................................... ..110
Component Function Check ................................110
Diagnosis Procedure .............................................110
WARNING CHIME FUNCTION .......................111
Description ........................................................... ..111
Component Function Check ................................111
Diagnosis Procedure .............................................111
HAZARD FUNCTION ......................................112
Description .............................................................112
Component Function Check ................................112
Diagnosis Procedure .............................................112
KEY SWITCH (INTELLIGENT KEY UNIT IN-
PUT) ................................................................
113
Diagnosis Procedure .............................................113
KEY SWITCH (BCM INPUT) ...........................115
Diagnosis Procedure .............................................115
IGNITION KNOB SWITCH ..............................116
Ignition Knob Switch Check ...................................116
HEADLAMP FUNCTION .................................118
Diagnosis Procedure .............................................118
MAP LAMP AND IGNITION KEYHOLE ILLU-
MINATION FUNCTION ...................................
119
Diagnosis Procedure .............................................119
KEYFOB ID SET UP WITH CONSULT-III ......120
ID Code Entry Procedure ......................................120
KEYFOB ID SET UP WITHOUT CONSULT-III .121
ID Code Entry Procedure .................................... ..121
AUTOMATIC BACK DOOR SELF-DIAGNO-
SIS PROCEDURE ...........................................
123
Self-Diagnosis Procedure ......................................123
POWER LIFTGATE SWITCH FUNCTION ......125
Diagnosis Procedure ........................................... ..125
GLASS HATCH SWITCH ................................127
Diagnosis Procedure .............................................127
GLASS HATCH AJAR SWITCH .....................129
Diagnosis Procedure .............................................129
BACK DOOR CLOSE (CLOSE) SWITCH
SYSTEM ..........................................................
131
Diagnosis Procedure ........................................... ..131
BACK DOOR CLOSE (CANCEL) SWITCH
SYSTEM ..........................................................
132
Diagnosis Procedure ........................................... ..132
PINCH STRIP SYSTEM ..................................133
Diagnosis Procedure .............................................133
BACK DOOR WARNING CHIME SYSTEM ....134
Diagnosis Procedure .............................................134
HALF-LATCH SWITCH SYSTEM ...................135
Diagnosis Procedure .............................................135
Revision: December 20092009 QX56

DIAGNOSIS AND REPAIR WORKFLOWDLK-7
< BASIC INSPECTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
1.GET INFORMATION FOR SYMPTOM
Get the detailed information from the customer about the symptom (the condition and the environment when
the incident/malfunction occurred).
>> GO TO 2.
2.CHECK DTC
1. Check DTC.
2. Perform the following procedure if DTC is displayed.
- Record DTC and freeze frame data (Print them out with CONSULT-III.)
- Erase DTC.
- Study the relationship between the cause detected by DTC and the symptom described by the customer.
3. Check related service bulletins for information.
Is any symptom described and any DTC detected?
Symptom is described, DTC is displayed>>GO TO 3.
Symptom is described, DTC is not displayed>>GO TO 4.
Symptom is not described, DTC is displayed>>GO TO 5.
3.CONFIRM THE SYMPTOM
Confirm the symptom described by the customer.
Connect CONSULT-III to the vehicle in “DATA MONI TOR” mode and check real time diagnosis results.
Verify relation between the symptom and t he condition when the symptom is detected.
>> GO TO 5.
4.CONFIRM THE SYMPTOM
Confirm the symptom described by the customer.
Connect CONSULT-III to the vehicle in “DATA MONI TOR” mode and check real time diagnosis results.
Verify relation between the symptom and t he condition when the symptom is detected.
>> GO TO 6.
5.PERFORM DTC CONFIRMATION PROCEDURE
Perform DTC Confirmation Procedure for the display ed DTC, and then check that DTC is detected again.
At this time, always connect CONSULT-III to the vehicle, and check diagnostic results in real time.
If two or more DTCs are detected, refer to DLK-169, "
DTCInspectionPriorityChart" and determine trouble
diagnosis order.
NOTE:
• Freeze frame data is useful if the DTC is not detected.
• Perform Component Function Check if DTC Confirmation Procedure is not included in Service Manual. This
simplified check procedure is an effective alternat ive though DTC cannot be detected during this check.
If the result of Component Function Check is NG, it is the same as the detection of DTC by DTC Confirma-
tion Procedure.
Is DTC detected?
Yes >> GO TO 7.
No >> Refer to GI-38, "
Intermittent Incident".
6.DETECT MALFUNCTIONING SYST EM BY SYMPTOM DIAGNOSIS
Detect malfunctioning system according to SYMPTO M DIAGNOSIS based on the confirmed symptom in step
4, and determine the trouble diagnosis order based on possible causes and symptom.
>> GO TO 7.
7.DETECT MALFUNCTIONING PA RT BY DIAGNOSTIC PROCEDURE
Inspect according to Diagnostic Procedure of the system.
NOTE:
Revision: December 20092009 QX56

DLK-8
< BASIC INSPECTION >[WITH INTELLIGENT KEY SYSTEM]
DIAGNOSIS AND REPAIR WORKFLOW
The Diagnostic Procedure described based on open circuit inspection. A short circuit inspection is also
required for the circuit check in the Diagnostic Procedure.
Is malfunctioning part detected?
Ye s > > G O T O 8 .
No >> Check voltage of related BCM terminals using CONSULT-III.
8.REPAIR OR REPLACE THE MALFUNCTIONING PART
1. Repair or replace the malfunctioning part.
2. Reconnect parts or connectors disconnected during Diagnostic Procedure again after repair and replace- ment.
3. Check DTC. If DTC is displayed, erase it.
>> GO TO 9.
9.FINAL CHECK
When DTC was detected in step 2, perform DTC Confirmation Procedure or Component Function Check
again, and then check that the malfunction have been repaired securely.
When symptom was described from the customer, refer to confirmed symptom in step 3 or 4, and check that
the symptom is not detected.
Does the symptom reappear?
YES (DTC is detected)>>GO TO 7.
YES (Symptom remains)>>GO TO 6.
NO >> Inspection end
Revision: December 20092009 QX56

DLK-38
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
WARNING FUNCTION
WARNING FUNCTION
System DescriptionINFOID:0000000003775695
OPERATION DESCRIPTION
The warning functions are as follows and are given to the user as warning information and warnings using
combinations of Intelligent Key warning buzzer, KEY warning lamp and combination meter display in combina-
tion meter.
• Intelligent Key system malfunction
• OFF position warning
• P position warning
• Take away warning
• Door lock operation warning
• Key warning
• Intelligent Key insert information
• Engine start information
• Steering lock information
• Intelligent key low battery warning
• Key ID warning
OPERATION CONDITION
Once the following condition from below is established, alert or warning will be executed.
Warning/Information functions
Operation procedure
Intelligent Key system malfunction When a malfunction is detected on BCM, warning message will display.
OFF position warning For internal
• Ignition switch: ACC position.
• Door switch (driver side
): ON (Door is open).
For external OFF position warning (For internal) is in active mode, driver side door has
been closed.
NOTE:
OFF position (For external) active only when each of the sequence has oc-
curred as below: P position warning
→ ACC warning → OFF position warning
(For internal) → OFF position warning (For internal)
P position warning • Shift position: Except P position
• Engine is running to stopped (Ignition switch is ON to OFF)
Ta k e a w a y w a r n i n g Door is open to close
• Ignition switch: Except LOCK position.
• Door switch: ON to OFF (Door is open to close).
• Intelligent Key can not be detected inside the vehicle.
Door is open • Door switch: ON (Door is open)
• Key ID verification every 5 seconds when registered Intelligent Key can not
be detected inside the vehicle.
Take away through win-
dow • Engine is running.
• Key ID verification every 30 seconds when registered Intelligent Key can not
be detected inside the vehicle.
• After vehicle speed verification, the registered Intelligent Key can not be de- tect inside the vehicle.
Door lock operation warn-
ing Request switch operation
When request switch is pushed (lock operation) under the following conditions.
• Door switch: ON (Any door is open).
• Intelligent Key is inside vehicle.
Intelligent Key button op-
eration When Intelligent Key button is pushed (lock operation) under the following con-
ditions.
• Door switch: ON (Any door is open).
• Intelligent key is inside vehicle.
Key warning • Ignition switch is OFF position.
• Driver side door switch: ON (Driver side door is open).
• Keyfob is pressed inside the vehicle.
Intelligent Key insert information • Door switch: ON to OFF (Door is open to close).
• Ignition switch: OFF to ON position.
• Intelligent Key can not be detected inside the vehicle.
Revision: December 20092009 QX56
