P1808 VEHICLE SPEED SENSOR (ABS)
DescriptionINFOID:0000000003772090
The ABS actuator and electric unit (control unit) transmits a vehicle speed signal via CAN communication to
the transfer control unit. DTC P1808 sets when a malf unction is detected in the vehicle speed signal that is
output from the ABS actuator and electric unit (control unit) or an improper signal is input while driving.
DTC LogicINFOID:0000000003772091
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Perform self-diagnosis.
Is DTC P1808 displayed?
YES >> Perform diagnosis procedure. Refer to DLN-27, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000003772092
1.CHECK DTC WITH ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
Perform self-diagnosis with ABS actuator and electric unit (control unit). Refer to BRC-24, "CONSULT-III
Function (ABS)".
Is any malfunction detected by self-diagnosis?
YES >> Check the malfunctioning system.
NO >> GO TO 2.
2.CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to DLN-81, "Reference Value"
.
Are the inspection results normal?
YES >> GO TO 3.
NO >> Check transfer control unit pin terminals for damage or loose connection with harness connector.
If any items are damaged, repair or replace damaged parts.
3.CHECK DTC
Perform the self-diagnosis, after driving a vehicle for a while.
Are the inspection results normal?
YES >> Inspection End.
NO >> Perform self-diagnosis with ABS actuator and electric unit (control unit) again.
DTC CONSULT-III Diagnostic item is detected when... Reference
[P1808] VHCL SPEED SEN·ABS  Malfunction is detected in vehicle
speed signal that is output from ABS
actuator and electric unit (control unit)
through CAN communication.
 Improper signal is input while driving. Refer to
DLN-27
.
Revision: December 20092009 QX56

DLN-28
< COMPONENT DIAGNOSIS >[ATX14B]
P1810 NEUTRAL-4LO SWITCH
P1810 NEUTRAL-4LO SWITCH
DescriptionINFOID:0000000003772093
The neutral-4LO switch detects that the transfer case
is in neutral or 4LO range. DTC P1810 will set when an
improper signal from the neutral-4LO switch is input due to an open or short circuit.
DTC LogicINFOID:0000000003772094
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Perform self-diagnosis.
Is DTC P1810 displayed?
YES >> Perform diagnosis procedure. Refer to DLN-28, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000003772095
1.CHECK 4LO POSITION SWITCH SIGNAL
With CONSULT-III1. Start engine.
2. Select DATA MONITOR mode for A LL MODE AWD/4WD with CONSULT-III.
3. Read out the value of N POSI SW TF.
Without CONSULT-III
1. Start engine.
2. Check voltage between transfer control unit harness connector
terminal and ground.
DTC CONSULT-III Diagnostic item is detected when... Reference
[P1810] 4L POSI SW TF Improper signal from neutral-4LO switch
is input due to open or short circuit.Refer to
DLN-28
.
Condition Display value
 Vehicle stopped
 Engine running
 A/T selector lever N position
 Brake pedal depressed 4WD shift switch: 2WD,
AUTO or 4H
OFF
4WD shift switch: 4H to
4LO (While actuator mo-
tor is operating.) OFF
→ ON
4WD shift switch: 4LO to
4H (While actuator motor
is operating.) ON
→ OFF
4WD shift switch: 4LO ON
SDIA2693E
Revision: December 20092009 QX56

P1813 4WD SHIFT SWITCHDLN-31
< COMPONENT DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P1813 4WD SHIFT SWITCH
DescriptionINFOID:0000000003772097
The 4WD shift switch allows the driver to select AUTO, 2WD or 4WD and 4H or 4LO. DTC P1813 will set if
more than two switch inputs are simultaneously detected by the transfer control unit due to a short circuit in the
4WD shift switch.
DTC LogicINFOID:0000000003772098
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Perform self-diagnosis.
Is DTC P1813 displayed?
YES >> Perform diagnosis procedure. Refer to DLN-31, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000003772099
1.CHECK 4WD SHIFT SWITCH SIGNAL
With CONSULT-III
1. Turn ignition switch ON. (Do not start engine.)
2. Select DATA MONITOR mode for ALL MODE AWD/4WD with CONSULT-III.
3. Read out ON/OFF switching action of the 2WD SWITCH, AUTO SWITCH, LOCK SWITCH, 4L SW with
operating 4WD shift switch.
Without CONSULT-III
1. Turn ignition switch ON. (Do not start engine.)
2. Check voltage between transfer control unit harness connector
terminals and ground.
Are inspection results normal?
YES >> GO TO 5.
NO >> GO TO 2.
DTC CONSULT-III Diagnostic item is detected when... Reference
[P1813] 4WD MODE SW More than two switch inputs are simulta-
neously detected due to short circuit of
4WD shift switch.Refer to
DLN-31
.
Connector Terminal Condition Voltage (Ap-
prox.)
E142 9 - ground
4WD shift switch: 2WD Battery voltage
4WD shift switch: AUTO, 4H or 4LO 0V
18 - ground 4WD shift switch: 4H Battery voltage
4WD shift switch: 2WD, AUTO or
4LO
0V
23 - ground 4WD shift switch: 4LO Battery voltage
4WD shift switch: 2WD, AUTO or 4H 0V
24 - ground 4WD shift switch: AUTO Battery voltage
4WD shift switch: 2WD, 4H or 4LO 0V
WDIA0148E
Revision: December 20092009 QX56

P1814 WAIT DETECTION SWITCHDLN-35
< COMPONENT DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P1814 WAIT DETECTION SWITCH
DescriptionINFOID:0000000003772101
The wait detection switch detects if the transfer case is in 4WD. DTC P1814 will set if an improper signal from
the wait detection switch is input due to open or short circuit.
DTC LogicINFOID:0000000003772102
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Perform self-diagnosis.
Is DTC P1814 detected?
YES >> Perform diagnosis procedure. Refer to DLN-35, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000003772103
1.CHECK WAIT DETECTION SWITCH SIGNAL
With CONSULT-III
1. Start engine.
2. Select DATA MONITOR mode for ALL MODE AWD/4WD with CONSULT-III.
3. Read out the value of WAIT DETCT SW.
Without CONSULT-III
1. Start engine.
2. Check voltage between transfer control unit harness connector
terminal and ground.
DTC CONSULT-III Diagnostic item is detected when... Reference
[P1814] 4WD DETECT SWITCH Improper signal from wait detection
switch is input due to open or short cir-
cuit.
Refer to
DLN-35
.
Condition Display value
 Vehicle stopped
 Engine running
 A/T selector lever N position
 Brake pedal depressed 4WD shift switch: 2WD, AUTO
or 4H
OFF
4WD shift switch: 4H to 4LO
(While actuator motor is operat-
ing.) OFF
→ ON
4WD shift switch: 4LO to 4H
(While actuator motor is operat-
ing.) ON
→ OFF
4WD shift switch: 4LO ON
SDIA2701E
Revision: December 20092009 QX56

DLN-38
< COMPONENT DIAGNOSIS >[ATX14B]
P1816 TRANSMISSION RANGE SWITCH
P1816 TRANSMISSION RANGE SWITCH
DescriptionINFOID:0000000003772105
The transmission range switch transmits the A/T positi
on indicator signal (transmission range switch signal)
via CAN communication to the transfer control unit. DTC P1816 will set when the transmission range switch
signal is malfunctioning or there is a communication error.
DTC LogicINFOID:0000000003772106
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Perform self-diagnosis.
Is DTC P1816 displayed?
YES >> Perform diagnosis procedure. Refer to DLN-38, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000003772107
1.CHECK DTC WITH TCM
Perform self-diagnosis with TCM. Refer to TM-32, "CONSULT-III Function (TRANSMISSION)"
.
Is any malfunction detec ted by self-diagnosis?
YES >> Check the malfunctioning system.
NO >> GO TO 2.
2.CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to DLN-81, "Reference Value"
.
Are inspection results normal?
YES >> GO TO 3.
NO >> Check transfer control unit pin terminals fo r damage or loose connection with harness connector.
If any items are damaged, repair or replace damaged parts.
3.CHECK DTC
Drive the vehicle and then perform self-diagnosis.
Are inspection results normal?
YES >> Inspection End.
NO >> Perform self-diagnosis with TCM again.
DTC CONSULT-III Diagnostic item is detected when... Reference
[P1816] PNP SW/CIRC When transmission range switch signal
is malfunction or communication error
between the control units.Refer to
DLN-38
.
Revision: December 20092009 QX56

P1817 ACTUATOR MOTORDLN-39
< COMPONENT DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P1817 ACTUATOR MOTOR
DescriptionINFOID:0000000003772108
The actuator motor receives signals from the transfer c ontrol unit and controls shift rods which shift the trans-
fer case. DTC P1817 will set when any of the following occur:
 Motor does not operate properly due to open or short circuit in actuator motor.
 Malfunction is detected in the actuator motor. (W hen 4WD shift switch is operated and actuator motor does
not operate)
 Malfunction is detected in transfer shift high relay or transfer shift low relay.
DTC LogicINFOID:0000000003772109
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Perform self-diagnosis.
Is DTC P1817 detected?
YES >> Perform diagnosis procedure. Refer to DLN-39, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000003772110
1.CHECK ACTUATOR MOTOR SIGNAL
With CONSULT-III
1. Start engine.
2. Select DATA MONITOR mode for ALL MODE AWD/4WD with CONSULT-III.
3. Read out the value of SHIFT ACT1, SHIFT AC MON1, SHIFT ACT2 and SHIFT AC MON2.
DTC CONSULT-III Diagnostic item is detected when... Reference
[P1817] SHIFT ACTUATOR  Motor does not operate properly due
to open or short circuit in actuator mo-
tor.
 Malfunction is detected in the actuator motor. (When 4WD shift switch is op-
erated and actuator motor is not oper-
ated)
 Malfunction is detected in transfer shift
high relay and transfer shift low relay. Refer to
DLN-39
.
Monitored
item Condition Display
value
SHIFT ACT1  Vehicle stopped
 Engine running
 A/T selector lever N position
 Brake pedal depressed 4WD shift switch: 4H
to 4LO (Wait function
is operating.)
ON
Except the above OFF
SHIFT AC
MON1  Vehicle stopped
 Engine running
 A/T selector lever N position
 Brake pedal depressed 4WD shift switch: 4H
to 4LO (Wait function
is operating.)
ON
Except the above OFF
SHIFT ACT2  Vehicle stopped
 Engine running
 A/T selector lever N position
 Brake pedal depressed 4WD shift switch:
4LO to 4H (Wait func-
tion is operating.)
ON
Except the above OFF
Revision: December 20092009 QX56

DLN-40
< COMPONENT DIAGNOSIS >[ATX14B]
P1817 ACTUATOR MOTOR
Without CONSULT-III
1. Start engine.
2. Check voltage between transfer control unit harness connector
terminal and ground.
Are the inspection results normal?
YES >> GO TO 7.
NO >> GO TO 2.
2.CHECK ACTUATOR MOTOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Remove transfer shift high relay and transfer shift low relay.
3. Check voltage between transfer shift high relay harness connec- tor E46 terminal 5 (A), transfer shift low relay harness connector
E47 terminal 5 (B) and ground.
SHIFT AC
MON2  Vehicle stopped
 Engine running
 A/T selector lever N position
 Brake pedal depressed 4WD shift switch:
4LO to 4H (Wait func-
tion is operating.)
ON
Except the above OFF
Connector Terminal Condition Voltage
(Approx.)
E142 4 -
Ground  Vehicle stopped
 Engine running
 A/T selector lever
N position
 Brake pedal de-
pressed 4WD shift switch: 4H to
4LO (Wait function is
operating.)
Battery
voltage
Except the above 0V
13 -
Ground  Vehicle stopped
 Engine running
 A/T selector lever
N position
 Brake pedal de- pressed 4WD shift switch: 4LO
to 4H (Wait function is
operating.)
Battery
voltage
Except the above 0V
E143 33 -
Ground  Vehicle stopped
 Engine running
 A/T selector lever
N position
 Brake pedal de- pressed 4WD shift switch: 4H to
4LO (Wait function is
operating.)
Battery
voltage
Except the above 0V
42 -
Ground  Vehicle stopped
 Engine running
 A/T selector lever
N position
 Brake pedal de-
pressed 4WD shift switch: 4LO
to 4H (Wait function is
operating.)
Battery
voltage
Except the above 0V
Monitored
item Condition Display
value
SDIA2705E
Connector Terminal Voltage (Approx.)
A: E46 5 - Ground Battery voltage
B: E47 5 - Ground
WDIA0310E
Revision: December 20092009 QX56

P1818 ACTUATOR POSITION SWITCHDLN-45
< COMPONENT DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P1818 ACTUATOR POSITION SWITCH
DescriptionINFOID:0000000003772112
The actuator position switch detects the current actuator motor range. DT C P1818 will set if either of the fol-
lowing occur:
 Improper signal from actuator position s witch is input due to open or short circuit.
 Malfunction is detected in actuator position switch.
DTC LogicINFOID:0000000003772113
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Perform self-diagnosis.
Is DTC P1818 detected?
YES >> Perform diagnosis procedure. Refer to DLN-45, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000003772114
1.CHECK ACTUATOR POSITION SWITCH SIGNAL
With CONSULT-III
1. Start engine.
2. Select DATA MONITOR mode for ALL MODE AWD/4WD with CONSULT-III.
3. Read out the value of SHIFT POS SW1 and SHIFT POS SW2.
Without CONSULT-III
1. Start engine.
DTC CONSULT-III Diagnostic item is detected when... Reference
[P1818] SHIFT ACT POSI SW  Improper signal from actuator position
switch is input due to open or short cir-
cuit.
 Malfunction is detected in the actuator
position switch. Refer to
DLN-45
.
Monitored item Condition Display value
SHIFT POS SW1  Vehicle stopped
 Engine running
 A/T selector lever
N position
 Brake pedal de-
pressed 4WD shift switch: 4LO ON
4WD shift switch:
2WD, AUTO or 4H
OFF
SHIFT POS SW2  Vehicle stopped
 Engine running
 A/T selector lever
N position
 Brake pedal de- pressed 4WD shift switch: 4H,
AUTO or 2WD
ON
4WD shift switch: 4LO OFF
Revision: December 20092009 QX56
