panel forward onto the horizontal panel, then grasp both
panels and lift them to the forward, upright position in
the trunk.
NOTE:The convertible top will NOT operate with the
Cargo Shield in the stowed position.Power Convertible Top Controls
The power top switch is located on the instrument panel
to the left of the steering column.
Stowed Cargo ShieldPower Top Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87
3

There is also a power top button on the Remote Keyless
Entry (RKE) transmitter for remotely lowering the power
convertible top.Lowering the Power Convertible Top
Using the Power Top Switch
NOTE:The power top switch will operate when the
ignition switch is turned to the ON or ACC position and
when in the power accessory delay.
There are two Top Down switch positions.
Press the switch to the first detent and release
it. The system will lower all fully raised win-
dows approximately 0.5 in (10 mm), lower the
top to its fully retracted position, and then raise the
windows. Press the switch to the second detent and
release it. The system will lower all four windows and the
top to their fully retracted positions.
Power Top Button
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Using the Remote Keyless Entry (RKE) Transmitter
NOTE:Steps1–3must be performed within five
seconds.
1. Press and release the UNLOCK button on the RKE
transmitter.
2. Press and release the POWER TOP button
on the RKE transmitter.
3. Press and hold the POWER TOP button until the
Power Top and All Windows Down feature is complete.
Raising the Power Convertible Top
Using the Power Top Switch
NOTE:The power top switch will operate when the
ignition switch is turned to the ON or ACC position and
when in the power accessory delay.Press and hold the switch in the Top Up
position until the operation of raising the top
and latching it is complete, which is indicated
by the system raising the windows and dis-
playing “TOP DONE” in the odometer or “CONVERT-
IBLE TOP COMPLETE” in the EVIC (if equipped).
Using the Remote Keyless Entry (RKE) Transmitter
You cannot use the power top button on the RKE
transmitter to raise the power convertible top. You must
use the power top switch inside the vehicle to perform
this operation.
Manually
Closing the power convertible top manually is a compli-
cated and physically demanding procedure, and it re-
quires a special tool to do so. In the event that you
experience a malfunction when operating the power
convertible top:
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89
3

1. Read all of the Notes, Cautions, and Warning found
under “Power Convertible Top Usage Precautions” to
verify all operating conditions are met.
2. Check for Operation and Warning Messages as de-
scribed under “Power Convertible Top Operation &
Warning Messages.” If applicable, perform the related
action to correct the condition present.
3. If Steps 1 and 2 do not resolve the problem, see
“Manual Bypass Mode” Section.
Manual Bypass Mode
In case of an unresponsive power top system, there is a
customer Manual Bypass Mode. If the power top mal-
functions mid-cycle, press the interior POWER TOP
switch in the Top Up direction five times within two
seconds. This mode will allow the top to close with
failures. Once the top is closed, please see your autho-
rized dealer.NOTE:This process may take a more significant
amount of time to fully close the power top. It’s not
uncommon to see 30 second delays before operation
begins.
Wind Stop — If Equipped
The Wind Stop installs in the backseat area of the vehicle.
The Wind Stop will not interfere with power top opera-
tion. Therefore, it can remain installed when the top is up.
However, when not in use, the Wind Stop folds to allow
for convenient storage underneath the cargo shield in the
trunk.
NOTE:It is recommended that you lower the convert-
ible top before installing or removing the Wind Stop.
Installing the Wind Stop
1. Remove the Wind Stop from the trunk.
2. Unfold the Wind Stop framework.
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3. Lay the small frame (1) flat on top of the large frame
(2) and snap the two frames together by engaging the
frame lock (3).
NOTE:The frames must lie flat on each other in order to
snap them together.4. Pivot the small frame (1) away from the large frame (2)
until the pivot lock (3) engages to lock the two frames in
an L shape.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91
3

5. Unfold both stems at the rear of the large frame. 6. Align and insert the stems into the slot in each trim
panel.
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

7. Align the pins at the front of the large frame with the
hole in each trim panel. Slide the pins outward until fully
extended into each hole.Removing and Storing the Wind Stop
Reverse the installation procedure to remove, fold, and
store the Wind Stop. However, note the following before
doing so:
•Disengage the pivot lock (1) to fold the small frame flat
onto the large frame. Disengage the frame lock (2) to
disconnect the small frame from the large frame.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93
3

Power Convertible Top Operation and Warning
Messages
When the appropriate conditions exist, the PTCM dis-
plays various power convertible top operation and warn-
ing messages in the Electronic Vehicle Information Center(EVIC) – if equipped, or in the Odometer for vehicles not
equipped with the EVIC. Refer to the following chart for
message related information:
EVIC
MessageEVIC
Message
Display
TimeOdometer
Message
(< 5 mph
[8 km/h])
Odometer
Message
Display
TimeOdometer
Message
(> 5 mph
[8 km/h])
Odometer
Message
Display
TimeChime Condition Operator
Action
Required
CONVERT-
IBLE TOP
IN OPERA-
TIONUntil Op-
eration is
CompleteTOP Until Op-
eration is
Complete— — — The System
is Lowering
or Raising
the Top—
CONVERT-
IBLE TOP
COM-
PLETE9 Seconds TOP DONE Display
Scrolls for 6
Seconds— — Single
ChimeThe System
Completes
Operation of
Lowering or
Raising the
To p—
