Instrument Panel Overview
3-4

The main components of the instrument panel are the following:
A.Headlamps on page 3-13.
B. Air Outlets. SeeOutlet Adjustment on page 3-26.
C.Turn Signal/Multifunction Lever on page 3-7.
D. OnStar
®andAudio Steering Wheel Controls on
page 3-109(If Equipped).
E.Instrument Panel Cluster on page 3-29.
F.Ignition Positions on page 2-22.
G.Audio Steering Wheel Controls on page 3-109
(If Equipped).
H. Transfer Case Controls. See “Automatic Transfer
Case” underFour-Wheel Drive on page 2-30.
I. Rear Window Washer/Wiper. SeeWindshield
Washer on page 3-9.
J.Audio System(s) on page 3-62.
K.Dual Climate Control System on page 3-20.
L.Dome Lamp Override on page 3-17.
M.Fog Lamps on page 3-16(If Equipped).
Instrument Panel Brightness on page 3-16.N.Hood Release on page 5-11.
O. Driver Information Center (DIC) Steering Wheel
Controls (If Equipped). SeeDriver Information
Center (DIC) on page 3-47.
P. Ashtray. SeeAshtray(s) and Cigarette Lighter on
page 3-19.
Q. Shift Lever and StabiliTrak
®Button. SeeShifting
Into Park on page 2-35andStabiliTrak®System
on page 4-6.
R. Lighter. SeeAshtray(s) and Cigarette Lighter on
page 3-19.
S.Accessory Power Outlet(s) on page 3-19.
T. Rear Window Defogger. See “Rear Window
Defogger” underDual Climate Control System on
page 3-20andDual Automatic Climate Control
System on page 3-22.
U.Glove Box on page 2-53.
3-5

Hazard Warning Flashers
|(Hazard Warning Flasher):Press this button
located on top of the steering column, to make the front
and rear turn signal lamps ash on and off. This warns
others that you are having trouble. Press again to turn
the ashers off.
When the hazard warning ashers are on, the vehicle’s
turn signals will not work.
Horn
To sound the horn, press the horn symbols on the
steering wheel pad.
Tilt Wheel
The tilt lever is on the
outboard side of the
steering column, under
the turn signal lever.
Hold the steering wheel and pull the lever toward you to
change the position, then release the lever to lock.
Do not adjust the steering wheel while driving.
3-6

Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes the following:
GTurn and Lane Change Signals
23Headlamp High/Low-Beam Changer
Flash-to-Pass Feature
NWindshield Wipers
JWindshield Washer
ICruise Control
Turn and Lane-Change Signals
An arrow on the instrument
panel cluster ashes in the
direction of the turn or
lane change.
Move the lever all the way up or down to signal a turn.
Raise or lower the lever until the arrow starts to ash
to signal a lane change. Hold it there until the lane
change is complete.
The lever returns to its starting position when it is
released.
If after signaling a turn or lane change the arrows
ash rapidly or do not come on, a signal bulb could be
burned out.
Have the bulbs replaced. If the bulb is not burned out,
check the fuse. SeeFuses and Circuit Breakers on
page 5-119.
If the vehicle has a trailer towing option with added
wiring for the trailer lamps, a turn signal asher is used.
With this asher installed, the signal indicator ashes
even if a turn signal bulb is burned out. Check the front
and rear turn signal lamps regularly to make sure they
are working.
3-7

Turn Signal On Chime
A chime sounds if the turn signal has been on
3/4 of a mile (1.2 km). Move the turn signal lever to off.
Headlamp High/Low-Beam Changer
To change the headlamps from low to high beam,
push the lever toward the instrument panel. To return
to low-beam headlamps, pull the multifunction lever
toward you. Then release it.
When the high beams are
on, this indicator light on
the instrument panel cluster
will also be on.
Flash-to-Pass
This feature lets high-beam headlamps be used to
signal to a driver in front of you that you want to pass.
It works even if the headlamps are in the automatic
position.
To use it, pull the turn signal lever toward you, then
release it.
If the headlamps are in the automatic position or on
low beam, the high-beam headlamps turn on. They
will stay on as long as the lever is held toward you.
The high-beam indicator on the instrument panel
cluster comes on. Release the lever to return to
normal operation.
3-8

Windshield Wipers
8(Mist):Turn the band to mist, for a single wiping
cycle. Hold it there until the wipers start, then release it.
The wipers will stop after one wipe. Hold the band on
mist longer if more wipe cycles are needed.
9(Off):Turns the wipers off.
N(Windshield Wipers):Turn the band to control the
windshield wipers.
6: Turn the band to set the wiper speed for a long or
short delay between wipes. The closer to the top of the
lever, the shorter the delay time.
For steady wiping at low speed, turn the band away
from you to the rst solid band past the delay settings.
For high-speed wiping, turn the band further, to the
second solid band past the delay settings.
Be sure to clear ice and snow from the wiper blades
before using them. If they are frozen to the windshield,
gently loosen or thaw them. If they become worn or
damaged, get new blades or blade inserts.
Windshield Washer
L(Windshield Washer):Press the windshield
washer paddle to spray washer uid on the windshield.
The wipers will clear the window and then either
stop or return to the preset speed.
{CAUTION:
In freezing weather, do not use your washer until
the windshield is warmed. Otherwise the washer
uid can form ice on the windshield, blocking your
vision.
3-9

Rear Window Wiper/Washer
{CAUTION:
In freezing weather, do not use your washer until
the windshield is warmed. Otherwise the washer
uid can form ice on the windshield, blocking
your vision.
The rear wiper/washer
button is located to the
right of the steering wheel
on the instrument panel.To turn the rear wiper on, turn the control to either 1, 2,
or 3. For delayed wiping, turn the control to 1 or 2.
For steady wiping, turn the control to 3. To turn the
wiper off, turn the control to 0.
To wash the rear window, press
=located in the
center of the control.
The rear window washer uses the same uid bottle as
the windshield washer. However, the rear window washer
will run out of uid before the windshield washer. If the
windshield can be washed, but not the rear window,
check the uid level.
Cruise Control
With cruise control, a speed of about 25 mph (40 km/h)
or more can be maintained without keeping your foot
on the accelerator. Cruise control does not work
at speeds below about 25 mph (40 km/h).
If you apply the brakes, the cruise control shuts off.
