2008 TOYOTA 4RUNNER audio

xi
1 OPERATION OF INSTRUMENTS AND CONTROLSPage
1 Overview of instruments and controls
1
. . . . . . . . . . . . . . . . . . . . . . . . . .
2 Keys and Doors11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
3 Occupant restraint systems41
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Steering wheel and Mirrors11 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Lights, Wipers and Defogger129
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 Gauges, Meters and Service reminder indicators145
. . . . . . . . . . . . . .
7 Engine (ignit ion) swit c h, Trans mis s ion and Par k ing br ak e161
. . . . . . .
8 Audio system 207
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
9 Air conditioning system289
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10 Other equipment303
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . .
2 INFORMATION BEFORE DRIVING YOUR TOYOTA 337 . . . . . . . . . .
3 STARTING AND DRIVING 369 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 IN CASE OF AN EMERGENCY 389 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 CORROSION PREVENTION AND APPEARANCE CARE 413 . . . . .
6 VEHICLE MAINTENANCE AND CARE 421 . . . . . . . . . . . . . . . . . . . . . . .
7 DO−IT−YOURSELF MAINTENANCE
1 Introduction427
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
2 Engine and Chassis435
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
3 Electrical components449
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

8 SPECIFICATIONS 461 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . .
9 FOR OWNERS 471 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
1 0 INDEX 475 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . .
Table of contents

4
1. Driving position memory switches
2. Headlight, turn signal and front foglight switches
3. Wiper and washer switches
4. Power back window switch
5. Audio system/rear view monitor system and navigation system including audio
system (For the navigation system, see
the separate Navigation System
Owner ’s Manual".)
6. Front passenger ’s seat belt reminder light
7. Engine immobilizer/theft deterrent system indicator light
8. Front passenger occupant classification indicator light
9. Multi−information display
10. Emergency flasher switch
11. Air conditioning controls
12. Auxiliary box
13. Back window and outside rear view mirror defogger switch
14. Four−wheel drive control switch knob (full−time four−wheel drive models) or
multi−mode control switch knob
(multi−mode four−wheel drive models)
CY11068

5
15. Engine switch
16. Cruise control switch
17. Hood lock release lever
18. Fuel filler door opener
19. Roll sensing of curtain shield airbags off switch
20. VSC OFF" switch
21. Center differential lock switch
22. Power outlet main switch
23. Instrument panel light control dial
CY11065
1. Volume control switches for audio system/hands−free system (For the
hands−free system, see the separate
Navigation System Owner ’s Manual".)
2.  " switch
3. MODE" switch
4. Telephone switches (See the separate Navigation System Owner ’s Manual".)
5. Speech command switch (See the separate Navigation System Owner ’s
Manual".)

Steering switches

207
OPERATION OF INSTRUMENTS AND
CONTROLS
Audio system
Reference208
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . .
Using your audio system 209
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Audio remote controls 238
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
AUX adapter 239
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
Rear seat entertainment system 240
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio/video system operating hints 280
. . . . . . . . . . . . . . . . . . . . . . . . . . .
For vehicle equipped with Navigation system, please refer to the
separate Navigation System Owner’s Manual".
SECTION 1− 8

209
This section describes some of the basic
features on Toyota audio systems. Some
information may not pertain to your sys-
tem.
Your audio system works when the engine
switch is in the ACC" or ON" position.
NOTICE
To prevent the battery from being dis-
charged, do not leave the audio sys-
tem on longer than necessary when
the engine is not running.
CAUTION
For vehicle sold in U.S.A. and
Canadas:
Part 15 of the FCC Rules
FCC Warning:
Any unauthorized changes or modifi-
cations to this equipment will void
the user’s authority to operate this
device.
Laser products
Do not take this unit apart or at-
tempt to make any changes your-
self. This is an intricate unit that
uses a laser pickup to retrieve
information from the surface of
compact discs. The laser is care-
fully shielded so that its rays re-
main inside the cabinet. There-
fore, never try to disassemble the
player or alter any of its parts
since you may be exposed to la-
ser rays and dangerous voltages.
This product ut ilizes a laser. Use
of controls or adjustments or per-
formance of procedures other
than those specified herein may
result in hazardous radiation ex-
posure.
Using your audio system
Some basics

210
TURNING THE SYSTEM ON AND OFF
Push PWR·VOL" to turn the audio system
on and off.
Push AM", FM1", FM2", FM",
AM·SAT"∗
or DISC·AUX" to turn on that function
without pushing PWR·VOL".
You can turn on the compact disc player
by inserting a compact disc.
You can turn off the compact disc player
by ejecting the compact disc. If the audio
system was previously off, then the entire
audio system will be turned off when you
eject the compact disc.
∗: Use of satellite radio requires XM
tuner and service. Contact your Toyota
dealer for details.
SWITCHING BETWEEN FUNCTIONS
Push AM", FM1", FM2", FM",
AM·SAT"∗
or DISC·AUX" if the system is already on
but you want to switch from one function
to another.
∗: Use of satellite radio r equires XM
tuner and service. Contact your Toyota
dealer for details. LISTENING TO THE XM
 SATELLITE
RADIO BROADCAST∗ (type 2 and 3)
To listen to a satellite radio br oadcast in
your vehicle, an additional genuine Toyota
satellite receiver and ant enna (or equiva-
lents) must be purchased and installed. A
subscription to the XM
 Satellite Radio
service is also necessary.
How to subscribe to an XM
 Satellite
Radio
An XM
 Satellite Radio is a t uner de-
signed exclusively to receive broadcasts
provided under a separate subscription.
Availability is limited to the 48 conti guous
U.S. states and 10 Canadian provinces. How to subscribe:
You must enter into a separate service
agreement with the XM
 Satellite Radio in
order to receive satellite br oadcast pro-
gramming in the vehicle. Additional activa-
tion and service subscription fees apply
that are not included in the purchase price
of the vehicle and optional digital sate llite
tuner. For complete information on sub-
scription rates and terms, or to subscribe
to the XM
 Satellite Radio,
U.S.A.
Visit on the web at www.xmradio.com
or
call 1−800−967−2346.
Canada
Visit on the web at www.xmradio.ca
or call
1−877−438−9677.
The XM
 Satellite Radio is solely respon-
sible for the quality, availability and con-
tent of the satellite radio services pro-
vided, which are subject to the terms and
conditions of the XM
 Satellite Radio cus-
tomer service agreement.
Customers should have their radio ID
ready; the radio ID can be found by tun-
ing to channel 000" on the radio. For
details, see Displaying the radio ID" be-
low.

211
All fees and programming are the respon-
sibility of the XM
 Satellite Radio and are
subject to change.
Satellite t uner technology notice:
Toyota’s satellite radio t uners are awarded
Type Approval Certificates from XM
 Sat-
ellite Radio Inc. as proof of compatibility
with the services offered by the XM
 Sat-
ellite Radio.
Displaying the radio ID
Each XM
 tuner is identified with a unique
radio ID. You will need the radio ID when
activating XM
 service or when reporting
a problem.
If you select the CH 000" using the
TUNE" knob, the ID code of 8 alphanu-
meric characters appears. If you select
another channel, display of the ID code is
canceled. The channel (000) alternates the
display between the radio ID and the spe-
cific radio ID code.
∗: Use of satellite radio r equires XM
tuner and service. Contact your Toyota
dealer for details. TONE AND BALANCE
For details about your system’s tone and
balance controls, see the description of
your own system.
Type 1 and 2 audio systems utilize SRS
FOCUS
 and SRS TruBass  audio
enhancement technologies, under license
from SRS Labs, Inc., in all modes except
AM radio mode.
FOCUS , TruB as s , SRS and symbols are
trademarks of SRS Labs, Inc.
FOCUS and TruBass technologies are incorporated under
license from SRS Labs, Inc.
Tone
How good an audio program sounds to
you is largely determined by the mix of
the treble, midrange and bass levels. In
fact, different kinds of music and vocal
programs usually sound better with differ-
ent mixes of treble, midrange and bass. Balance
A good balance of the left and right stereo
channels and of the front and rear sound
levels is also important.
Keep in mind that if you are listening to
a stereo recording or broadcast, changing
the right/left balance will increase the vol-
ume of one group of sounds while de-
creasing the volume of another.
YOUR RADIO ANTENNA
Your vehicle has an antenna printed on
the inside of the rear quarter window.
NOTICE
Putting a film (especially a conductive
or metallic film) on the rear quarter
window will noticeably reduce the
sensitivity of the radio.

214
Details of specific buttons, controls and
features are described in the alphabetical
list that follows.1 2 3 4 5 6 (Preset buttons)
These buttons are used to preset and
tune in radio stations.
To preset a station to a button: Tune in
the desired station. (See TUNE·FILE" or
SEEK/TRACK".) Push and hold down the
button until you hear a beepthis will set
the station to the button. The preset but-
ton number will appear on the display.
To recall a preset station: Push the button
for the station you want. The preset but-
ton number and station frequency will ap-
pear on the display.
These systems can store one AM and two
FM stations for each button. (The display
will show AM", FM1" or FM2" when you
push AM", FM1" or FM2" button.)
(Eject button)
Push the compact disc eject button to
eject a compact disc.
(Reverse/Fast−forward button)
Push and hold
" (preset button 6) or

" (preset button 5) to fast−forward or
reverse within a compact disc. When you
release the button, the compact disc play-
er will resume playing.
AM
Push the AM" button to turn on the radio
and select the AM band. AM" will appear
on the display.
AUDIO CONT (Tone and sound balance
controls)
Each time you push the AUDIO CONT"
knob, the mode changes. To adjust the
tone and balance, turn the knob.
BAS: Adjusts low−pitched tones. The dis-
play ranges from −5 to 5.
TRE: Adjusts high−pitched tones. The dis-
play ranges from −5 to 5.
FAD: Adjusts the sound balance between
the front and rear speakers. The display
ranges from F7 to R7.
BAL: Adjusts the sound balance between
the right and left speakers. The display
ranges from L7 to R7.
