2008 TOYOTA 4RUNNER jacking

194
CY16015
(d) Turning off the rear height controlair suspension
To turn off the rear height control air
suspension with the vehicle stopped,
push the HEIGHT CONTROL OFF"
switch. The height control OFF" indi-
cator light comes on and the vehicle
height is fixed in the same mode as the
height control switch is pushed.
This status is memorized in the system
even after the engine is stopped.
If you push the switch again, the height
control OFF" indicator light goes out and
the rear height control air suspension is
turned on.
Even after the rear height control air sus-
pension is turned off with the HEIGHT
CONTROL OFF" switch, if the vehicle
speed exceeds 30 km/h (19 mph), the
rear height control air suspension automat-
ically selects the N" mode.CAUTION
If you drive through deep water over
about 700 mm (28 in.) in depth, put
the vehicle height in the HI" mode
with the height select switch and then
turn off the rear height control air
suspension by pushing the HEIGHT
CONTROL OFF" switch.
NOTICE
 When jacking up or installing tire
chains, be sure to turn off the rear
height control air suspension by
pushing the HEIGHT CONTROL
OFF" switch and stop the engine.
Otherwise, the vehicle height may
change because of the automatic
leveling function, resulting in an un-
expected accident.
 If your vehicle must be towed, put
the vehicle height in the N" mode
and turn off the rear height control
air suspension. Otherwise, the ve-
hicle height may change because of
the automatic leveling function, re-
sulting in an unexpected accident.

395
CAUTION
Do not attempt to remove the radiator
cap when the engine and radiator are
hot. Serious injury could result from
scalding hot fluid and steam blown
out under pressure.
7. After the engine coolant temperaturehas cooled to normal, again check the
coolant level in the reservoir. If neces-
sary, bring it up to half full again. Seri-
ous coolant loss indicates a leak in the
system. You s hould have it checked as
soon as possible at your Toyota dealer.
1. Reduce your speed gradually, keeping a straight line. Move cau-
tiously off the road to a safe place
well away from the traffic. Avoid
stopping on the center divider of
a highway. Park on a level spot
with firm ground.
2. Stop the engine and turn on your emergency flashers.
3. Firmly set the parking brake and put the transmission in P".
4. Have everyone get out of the ve- hicle on the side away from traffic.
5. Read the following instructions thoroughly.CAUTION
When jacking, be sure to observe
the following to reduce the possi-
bility of death or serious injury:
Follow jacking instructions.
 Do not put any part of your
body under the vehicle sup-
ported by the jack. Otherwise,
personal injury may occur.
 Do not start or run the engine
while your vehicle is supported
by the jack.
 S t o p th e veh i cl e on a level fi rm
ground, firmly set the parking
brake and put the transmission
in P". Block the wheel diago-
nally opposite to the one being
changed if necessary.
If you have a flat tire

396
Make sure to set the jack prop-
erly in the jack point. Raising
the vehicle with jack improper-
ly positioned will damage the
vehicle or may allow the ve-
hicle to fall off the jack and
cause death or serious injury.
 Never get under the vehicle
when the vehicle is supported
by the jack alone.
 Use the jack only for lifting
your vehicle during wheel
changing.
 Do not raise the vehicle with
someone in the vehicle.
 When raising the vehicle, do
not place any objects on top
of or underneath the jack.
 Raise the vehicle only high
enough to remove and change
the tire.
NOTICE
 Do not continue driving with
a deflated tire. Driving even a
short distance can damage a
tire and wheel beyond repair.
 Vehicles with rear height con-
trol air suspension: When
jacking up or installing the
tire chains, be sure to turn
off the rear height control
and stop the engine. Other-
wise, the vehicle height may
change in the automatic lev-
eling function, resulting in
accident.
CY40055
1. G et th e req u i red to o l s an d
spare tire.
1. Tool bag
2. Jack
To prepare yourself for an emergency,
you should familiarize yourself with
the use of the jack, each of the tools
and their storage locations.
When storing the tool bag, make sure
it is securely held by the tightening
strap.
Required tools and spare
tire

478
EngineBefore starting the engine 370 . . . . . . . . . . .
Checking the coolant level 438 . . . . . . . . . .
Emission control device 342 . . . . . . . . . . . . .
Engine compartment 428 . . . . . . . . . . . . . . .
Exhaust gas caution 343 . . . . . . . . . . . . . . . .
Hood release 34 . . . . . . . . . . . . . . . . . . . . . . .
Identification number 350 . . . . . . . . . . . . . . .
Oil consumption 344 . . . . . . . . . . . . . . . . . . . .
Oil level 436 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overheating 394 . . . . . . . . . . . . . . . . . . . . . . .
Starting procedure 370 . . . . . . . . . . . . . . . . .
Three−way catalytic converters 342 . . . . . .
Engine coolant
Temperature gauge 146 . . . . . . . . . . . . . . . . .
Winter driving tips 375 . . . . . . . . . . . . . . . . . .
Engine coolant temperature gauge 146 . . . . .
Engine immobilizer system 14 . . . . . . . . . . . . .
Engine oil
Winter driving tips 375 . . . . . . . . . . . . . . . . . .
Engine oil replacement reminder light 149 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine switch 162 . . . . . . . . . . . . . . . . . . . . . . . .
Engine switch light 139 . . . . . . . . . . . . . . . . . . .
Exhaust gas caution 343 . . . . . . . . . . . . . . . . . .
F
Facts about engine oil
consumption 344 . . . . . . . . . . . . . . . . . . . . . . .
Flasher, Headlight 130,132 . . . . . . . . . . . . . . . .
Flat tire
After changing wheels 404 . . . . . . . . . . . . . .
Changing tire 401 . . . . . . . . . . . . . . . . . . . . . . If you have a flat tire 395
. . . . . . . . . . . . . . . .
Jack point 399 . . . . . . . . . . . . . . . . . . . . . . . . .
Jacking precautions 395 . . . . . . . . . . . . . . . .
Jacking up 400 . . . . . . . . . . . . . . . . . . . . . . . .
Loosening wheel nuts 399 . . . . . . . . . . . . . . .
Lowering vehicle 403 . . . . . . . . . . . . . . . . . . .
Reinstalling w heel ornament 403 . . . . . . . . .
Removing wheel ornament 398 . . . . . . . . . .
Wheel block 398 . . . . . . . . . . . . . . . . . . . . . . .
Wheel nuts 402 . . . . . . . . . . . . . . . . . . . . . . . .
Floor mat 336 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid level
Brake 439 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power steering 440 . . . . . . . . . . . . . . . . . . . . .
Washer fluid 453 . . . . . . . . . . . . . . . . . . . . . . .
Fog light switch, Front 136 . . . . . . . . . . . . . . . .
Foreign countries, Operation in 341 . . . . . . . .
Four−wheel drive
Operating the four−wheel drive system 168,171 . . . . . . . . . . . . . . . . . . . . . .
Front cup holder 327 . . . . . . . . . . . . . . . . . . . . .
Front fog light switch 136 . . . . . . . . . . . . . . . . .
Front passenger occupant classification system 91 . . . . . . . . . . . . . . . .
Front passenger ’s seat belt reminder light 149 . . . . . . . . . . . . . . . . . . . . . .
Front seat
Driving position memory system 48 . . . . . .
Seatback flattening 46,47 . . . . . . . . . . . . . . .
Front seats 43,44,45 . . . . . . . . . . . . . . . . . . . . . .
Fuel
Filler door o pener 37. . . . . . . . . . . . . . . . . . .
Fuel economy 386 . . . . . . . . . . . . . . . . . . . . .
Fuel pump shut off system 341 . . . . . . . . . . Gauge 146
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation in foreign countries 341 . . . . . . .
Tank cap 37 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel information 339 . . . . . . . . . . . . . . . . . . . . .
Fuel pump shut off system 341 . . . . . . . . . . . .
Fuse
Fuse box 452 . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse locations 430 . . . . . . . . . . . . . . . . . . . . . . .
G
Garage door opener 318
. . . . . . . . . . . . . . . . . .
Gauge
Engine coolant temperature 146
. . . . . . . . .
Fuel 146
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glove box 317
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Good driving practice 163
. . . . . . . . . . . . . . . . .
Grocery bag hooks 331
. . . . . . . . . . . . . . . . . . .
H
Hazard switch 135
. . . . . . . . . . . . . . . . . . . . . . .
Head restraints 62
. . . . . . . . . . . . . . . . . . . . . . .
Headlight switch 130,132
. . . . . . . . . . . . . . . . .
Height control
Rear height control air suspension 191
. . . . . . . . . . . . . . . . . . . . . .
High speed operation
During break−in 339
. . . . . . . . . . . . . . . . . . . .
Hill−start assist control system 189 . . . . . . . .
Hood release, Engine 34
. . . . . . . . . . . . . . . . . .
How to start the engine 370
. . . . . . . . . . . . . . .
