2008 NISSAN TEANA sensor

POWER DOOR LOCK SYSTEM
DLK-11
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
FUNCTION DIAGNOSIS
POWER DOOR LOCK SYSTEM
System DiagramINFOID:0000000003794734
System DescriptionINFOID:0000000003794735
DOOR LOCK FUNCTION
 The door lock and unlock switch (driver side) are build into power window main switch.
 Interlocked with the locking operation of door lock and unlock switch, door lock actuators of all doors are
locked.
 Interlocked with the unlocking operation of door lock and unlock switch, door lock actuators of all doors and
are unlocked.
 When ignition switch is ON and BCM receives air bag deployment signal, it operates automatically to unlock
all doors. Air bag diagnosis sensor unit sends the air bag deployment signal to BCM.
Door Key Cylinder
 With the door key inserted in the door key cylinder on driver side, turning the door key cylinder to “LOCK”,
locks door lock actuator of driver side door.
 With the door key inserted in the door key cylinder on driver side, turning the door key cylinder to “UNLOCK”,
unlocks door lock actuator of driver side door.
JMKIA2372GB

POWER DOOR LOCK SYSTEM
DLK-13
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
Front door lock assembly (unlock sensor) Detects door lock condition of driver door.
Door switch Inputs door open/close condition to BCM.
Key slot Inputs key insert/remove signal to BCM.
Combination meter Receives buzzer signal from BCM via CAN communication line, and sounds the buzzer.
 Transmits vehicle speed signal to CAN communication line.
TCM Transmits shift position signal to BCM via CAN communication line.Item Function

DLK-16
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY SYSTEM
INTELLIGENT KEY SYSTEM : Component Description
INFOID:0000000003794741
DOOR LOCK FUNCTION
10. Inside key antenna (instrument cen-
ter) M10511. Inside key antenna (trunk room) B86 12. Outside key antenna (rear bumper)
D85
13. Front outside handle LH (request
switch) D1114. Front outside handle LH
(outside key antenna) D1215. Trunk lid lock assembly
(trunk lid opener actuator) T5
16. Front door switch (driver side) B34
A. Behind the combination meter B. Engine room (LH) C. Behind the instrument lower panel
RH
D. Behind the center console E. Behind the audio unit F. View with rear bumper removed
1. Front door lock assembly (driver
side) D92. Rear door lock assembly LH D85 3. Trunk lid opener request switch T6
A. View with front door finisher removed B. View with rear door finisher removed C. View with trunk lid
JMKIA2376ZZ
Item Function
BCM Controls the Intelligent Key system.
Front door lock assembly (door lock
actuator)Outputs lock/unlock signal from BCM and locks/unlocks each door.
Front door lock assembly (unlock
sensor)Detects door lock condition of driver door.
Door switch Inputs door open/close condition to BCM.
Remote keyless entry receiver Receives lock/unlock signal from the Intelligent Key, and then transmits to BCM.
Request switch Inputs lock/unlock operation to BCM.
Intelligent Key Transmits button operation to remote keyless entry receiver.
Outside key antenna Detects if Intelligent Key is outside the vehicle.
Inside key antenna Detects if Intelligent Key is inside the vehicle.
Intelligent Key warning buzzer Warns the user of the lock/unlock condition and inappropriate operations with the buzzer sound.

DLK-20
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY SYSTEM
DOOR LOCK FUNCTION : Component Description
INFOID:0000000003794745
TRUNK OPEN FUNCTION
10. Inside key antenna (instrument cen-
ter) M10511. Inside key antenna (trunk room) B86 12. Outside key antenna (rear bumper)
D85
13. Front outside handle LH (request
switch) D1114. Front outside handle LH
(outside key antenna) D1215. Trunk lid lock assembly
(trunk lid opener actuator) T5
16. Front door switch (driver side) B34
A. Behind the combination meter B. Engine room (LH) C. Behind the instrument lower panel
RH
D. Behind the center console E. Behind the audio unit F. View with rear bumper removed
1. Front door lock assembly (driver
side) D92. Rear door lock assembly LH D85 3. Trunk lid opener request switch T6
A. View with front door finisher removed B. View with rear door finisher removed C. View with trunk lid
JMKIA2376ZZ
Item Function
BCM Controls the door lock function.
Front door lock assembly (door lock
actuator)Output lock/unlock signal from BCM and locks/unlocks each door.
Front door lock assembly (unlock
sensor)Detects door lock condition of driver door.
Door switch Input door open/close condition to BCM.
Remote keyless entry receiver Receives lock/unlock signal from the Intelligent Key, and then transmits to BCM.
Request switch Input lock/unlock operation to BCM.
Intelligent Key Transmits button operation to remote keyless entry receiver.
Outside key antenna Detects if Intelligent Key is outside the vehicle.
Inside key antenna Detects if Intelligent Key is inside the vehicle.
Combination meter Receives hazard warning lamp signal from BCM and blinks turn signal indicators.
Intelligent Key warning buzzer Warns the user of the lock/unlock condition and inappropriate operations with the buzzer sound.

DLK-78
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
UNLOCK SENSOR
UNLOCK SENSOR
DescriptionINFOID:0000000003794882
Detects door lock condition of driver door.
Component Function CheckINFOID:0000000003794883
1.CHECK FUNCTION
Check unlock sensor (“DOOR STAT-DR”) in “Data Monitor” mode.
Is the inspection result normal?
YES >> Unlock sensor is OK.
NO >> Refer to DLK-78, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003794884
1.CHECK BCM OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect front door lock assembly (driver side) (unlock sensor) connector.
3. Check signal between front door lock assembly (driver side) (unlock sensor) harness connector and
ground with oscilloscope.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK UNLOCK SENSOR CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between BCM harness connector and front door lock assembly (driver side) (unlock sen-
sor) harness connector.
3. Check continuity between BCM harness connector and ground.
Monitor item Condition
DOOR STAT-DRFront door lock (driver side) LOCK: OFF
Front door lock (driver side) UNLOCK: ON
(+)
(–)Signal
(Reference value) Front door lock assembly (driver side) (unlock sensor)
Connector Terminal
D9 3 Ground
JPMIA0012GB
BCMFront door lock assembly
(driver side) (unlock sensor)
Continuity
Connector Terminal Connector Terminal
M123 119 D9 3 Existed
BCM
GroundContinuity
Connector Terminal
M123 119 Not existed

UNLOCK SENSOR
DLK-79
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-78, "Removal and Installation".
NO >> Repair or replace harness.
3.CHECK UNLOCK SENSOR GROUND CIRCUIT
Check continuity between front door lock assembly (driver side) (unlock sensor) harness connector and
ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK UNLOCK SENSOR
Refer to DLK-79, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace front door lock assembly (driver side). Refer to DLK-214, "
TRUNK LID ASSEMBLY :
Removal and Installation".
5.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000003794885
1.CHECK UNLOCK SENSOR
1. Turn ignition switch OFF.
2. Disconnect front door lock assembly (driver side) (unlock sensor).
3. Check front door lock assembly (driver side) (unlock sensor) terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace front door lock assembly (driver side). Refer to DLK-202, "
DOOR ASSEMBLY : Removal
and Installation".
Front door lock assembly (driver side) (unlock sensor)
GroundContinuity
Connector Terminal
D9 4 Existed
Front door lock assembly
(driver side) (unlock sensor)
Condition Continuity
Te r m i n a l
34Front door lock assembly
(driver side) (unlock sensor) Unlock Existed
Lock Not existed

DLK-122
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
BCM (BODY CONTROL MODULE)
DOOR SW-RLRear LH door closed Off
Rear LH door opened On
DOOR SW-BKNOTE:
The item is indicated, but not monitored. Off
CDL LOCK SWOther than power door lock switch LOCK Off
Power door lock switch LOCK On
CDL UNLOCK SWOther than power door lock switch UNLOCK Off
Power door lock switch UNLOCK On
KEY CYL LK-SWNOTE:
The item is indicated, but not monitored. Off
KEY CYL UN-SWNOTE:
The item is indicated, but not monitored. Off
KEY CYL SW-TRNOTE:
The item is indicated, but not monitored. Off
HAZARD SWHazard switch is OFF Off
Hazard switch is ON On
REAR DEF SW
NOTE:
At model with BOSE au-
dio system this item is in-
dicated, but is not
monitored.Rear window defogger switch is OFF Off
Rear window defogger switch is ON On
TR CANCEL SWNOTE:
The item is indicated, but not monitored. Off
TR/BD OPEN SWTrunk lid opener switch OFF Off
While the trunk lid opener switch is turned ON On
TRNK/HAT MNTRTrunk lid closed Off
Trunk lid opened On
RKE-LOCKLOCK button of the key is not pressed Off
LOCK button of the key is pressed On
RKE-UNLOCKUNLOCK button of the key is not pressed Off
UNLOCK button of the key is pressed On
RKE-TR/BDTRUNK OPEN button of the key is not pressed Off
TRUNK OPEN button of the key is pressed On
RKE-PANICNOTE:
The item is indicated, but not monitored. Off
RKE-P/W OPENNOTE:
The item is indicated, but not monitored. Off
RKE-MODE CHGLOCK/UNLOCK button of the key is not pressed and held simulta-
neouslyOff
LOCK/UNLOCK button of the key is pressed and held simulta-
neouslyOn
OPTICAL SENSORBright outside of the vehicle Close to 5 V
Dark outside of the vehicle Close to 0 V
REQ SW -DRDriver door request switch is not pressed Off
Driver door request switch is pressed On
REQ SW -ASPassenger door request switch is not pressed Off
Passenger door request switch is pressed On Monitor Item Condition Value/Status

DLK-140
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
BCM (BODY CONTROL MODULE)
111
(L/Y)GroundSteering lock unit
communicationInput/
OutputSteering lockLOCK status Battery voltage
LOCK or UNLOCK
For 15 seconds after UN-
LOCKBattery voltage
15 seconds or later after
UNLOCK0 V
11 3
(P/B)Ground Optical sensor InputIgnition switch
ONWhen bright outside of
the vehicleClose to 5 V
When dark outside of the
vehicleClose to 0 V
11 5
(L)Ground Shock sensor Input Ignition switchOFF 0 V
ACC 5.0 V
ON
2.5 V
11 6
(R/W)GroundFuse check (Stop
lamp switch)Input — Battery voltage
11 8
(O/L)Ground Stop lamp switch Input Stop lamp switchOFF (Brake pedal is not
depressed)0 V
ON (Brake pedal is de-
pressed)Battery voltage
11 9
(G/W)GroundFront door lock as-
sembly driver side
(unlock sensor)Input Driver doorLOCK status (unlock sen-
sor switch OFF)
1.1 V
UNLOCK status (unlock
sensor switch ON)0 V
121
(Y)Ground Key slot switch InputWhen the key is inserted into key slot Battery voltage
When the key is not inserted into key slot 0 V
122
(V/R)Ground ACC feedback Input Ignition switchOFF 0 V
ACC or ON Battery voltage
123
(G/W)Ground IGN feedback Input Ignition switchOFF or ACC 0 V
ON Battery voltage Te r m i n a l N o .
(Wire color)Description
ConditionVa l u e
(Approx.)
Signal nameInput/
Output +–
JMKIA0066GB
JPMIA1034GB
JPMIA0012GB
