B2192 ID DISCORD, IMMU-ECM
DescriptionINFOID:0000000003814948
BCM performs the ID verification with ECM that allows the engine to start. Start the engine if the ID is OK.
ECM prevents the engine from starting if the ID is not registered. BCM starts the communication with ECM if
ignition switch is turned ON.
DTC LogicINFOID:0000000003814949
DTC DETECTION LOGIC
NOTE:
 If DTC B2192 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic".
 If DTC B2192 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON under the following conditions.
- Selector lever is in the P or N position.
- Do not depress brake pedal.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-43, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814950
1.PERFORM INITIALIZATION
Perform initialization with CONSULT-III. Reregister all Intelligent Keys.
For initialization and registration of Intelligent Key. Refer to “CONSULT-III Operation Manual NATS-IVIS/
NVIS”.
Can the system be initialized and can the engine be started with reregistered Intelligent Key?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE BCM
1. Replace BCM. Refer to BCS-78, "
Removal and Installation".
2. Perform initialization with CONSULT-III.
For initialization, refer to “CONSULT-III Operation Manual NATS-IVIS/NVIS”.
Can the system be initialized and can the engine be started with reregistered Intelligent Key?
YES >> INSPECTION END
NO >> GO TO 3.
3.REPLACE ECM
1. Replace ECM. Refer to EC-14, "
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Descrip-
tion".
2. Perform initialization with CONSULT-III.
Can the system be initialized and can the engine be started with reregistered Intelligent Key?
YES >> INSPECTION END
NO >> GO TO 4.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2192ID DISCORD, IMMU-
ECMThe ID verification result between BCM and ECM is
NG. The registration is necessary.BCM
ECM

B2193 CHAIN OF ECM-IMMU
SEC-45
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2193 CHAIN OF ECM-IMMU
DescriptionINFOID:0000000003814951
BCM performs the ID verification with ECM that allows the engine to start. Start the engine if the ID is OK.
ECM prevents the engine from starting if the ID is not registered. BCM starts the communication with ECM if
ignition switch is turned ON.
DTC LogicINFOID:0000000003814952
DTC DETECTION LOGIC
NOTE:
 If DTC B2193 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic".
 If DTC B2193 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON under the following conditions.
- Selector lever is in the P or N position.
- Do not depress brake pedal.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-45, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814953
1.REPLACE BCM
1. Replace BCM. Refer to BCS-78, "
Removal and Installation".
2. Perform initialization with CONSULT-III.
For initialization, refer to “CONSULT-III Operation Manual NATS-IVIS/NVIS”.
Does the engine start?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE ECM
Replace ECM. Refer to EC-14, "
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Description".
>> INSPECTION END
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2193CHAIN OF ECM-
IMMUInactive communication between ECM and BCM Harness or connectors
(The CAN communication line is
open or shorted)
BCM
ECM

SEC-50
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B2555 STOP LAMP
B2555 STOP LAMP
DescriptionINFOID:0000000003814960
BCM detects the stop lamp status and confirms the stop lamp switch ON/OFF status. BCM confirms the
engine start condition according to the stop lamp switch ON/OFF status.
DTC LogicINFOID:0000000003814961
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Depress the brake pedal and wait for at least 1 second.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-50, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814962
1.CHECK STOP LAMP SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check voltage between BCM harness connector and ground.
Is the inspection normal?
YES >> GO TO 2.
NO >> Check the following.
 10A fuse [No. 7, located in the fuse block (J/B)]
 Harness for open or short between BCM and fuse.
2.CHECK STOP LAMP SWITCH POWER SUPPLY CIRCUIT
1. Disconnect stop lamp switch connector.
2. Check voltage between stop lamp harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check harness for open or short between stop lamp switch and fuse.
DTC No.Trouble diagno-
sis nameDTC detecting condition Possible cause
B2555 STOP LAMPBCM makes a comparison between the
upper voltage and lower voltage of stop
lamp switch. It judges from their values to
detect the malfunctioning circuit. Harness or connectors
(Stop lamp switch circuit is open or shorted)
 Stop lamp switch
Fuse
(+)
(–)Voltage (V)
(Approx.) BCM
Connector Terminal
M123 116 Ground Battery voltage
(+)
(–)Voltage (V)
(Approx.) Stop lamp switch
Connector Terminal
E115 1 Ground Battery voltage

SEC-52
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B2556 PUSH-BUTTON IGNITION SWITCH
B2556 PUSH-BUTTON IGNITION SWITCH
DescriptionINFOID:0000000003814964
The switch that changes the power supply position. BCM maintains the power supply position status. BCM
changes the power supply position with the operation of the push-button ignition switch.
DTC LogicINFOID:0000000003814965
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine and wait for at least 100 seconds.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-52, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814966
1.CHECK PUSH-BUTTON IGNITION SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect push-button ignition switch connector.
3. Check voltage between push-button ignition switch harness connector and ground.
Is the inspection normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK PUSH-BUTTON IGNITION SWITCH CIRCUIT
1. Disconnect BCM connector and IPDM E/R connector.
2. Check continuity between push-button ignition switch harness connector and BCM harness connector.
3. Check continuity between push-button ignition switch harness connector and ground.
Is the inspection normal?
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2556PUSH-BUTTON IG-
NITION SWITCHBCM detects the push-button ignition
switch stuck at ON for 100 seconds or
more Harness or connectors
(Push-button ignition switch circuit is shorted.)
 Push-button ignition switch
BCM
(+)
(–)Voltage (V)
(Approx.) Push-button ignition switch
Connector Terminal
M101 4 Ground Battery voltage
Push-button ignition switch BCM
Continuity
Connector Terminal Connector Terminal
M101 4 M122 89 Existed
Push-button ignition switch
GroundContinuity
Connector Terminal
M101 4 Not existed

B2602 SHIFT POSITION
SEC-59
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2602 SHIFT POSITION
DescriptionINFOID:0000000003814978
BCM confirms the shift position with the following 4 signals.
 Selector lever
 P/N position switch
 P position signal from IPDM E/R (CAN)
 P position signal from TCM (CAN)
DTC LogicINFOID:0000000003814979
DTC DETECTION LOGIC
NOTE:
 If DTC B2602 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic".
 If DTC B2602 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine under the following conditions and wait for at least 10 seconds.
- Selector lever is in the P or N position.
- Depress the brake pedal.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-59, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814980
1.CHECK DTC WITH “ABS ACTUATOR AND ELECTRIC UNIT”
Check “Self diagnostic result” with CONSULT-III. Refer to BRC-48, "
DTC No. Index".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK CONTROL DEVICE POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect control device (detention switch) connector.
3. Check voltage between control device (detention switch) harness connector and ground.
Is the inspection result normal?
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2602 SHIFT POSITIONBCM detects the following status for 10 seconds.
 Shift position is in the P position
 Vehicle speed is 4 km/h (2.5 MPH) or more
 Ignition switch is in the ON position Harness or connectors
(Control device circuit is open or
shorted)
 Control device (detention switch)
 ABS actuator and electric unit
(control unit)
BCM
(+)
(–)Voltage (V)
(Approx.) Control device (detention switch)
Connector Terminal
M57 8 Ground Battery voltage

B2603 SHIFT POSITION STATUS
SEC-61
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2603 SHIFT POSITION STATUS
DescriptionINFOID:0000000003814981
BCM confirms the shift position with the following 4 signals.
 Selector lever
 P/N position switch
 P position signal from IPDM E/R (CAN)
 P position signal from TCM (CAN)
DTC LogicINFOID:0000000003814982
DTC DETECTION LOGIC
NOTE:
 If DTC B2603 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic".
 If DTC B2603 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
 If DTC B2603 is displayed with DTC B210F for IPDM E/R, first perform the trouble diagnosis for DTC B210F.
Refer to SEC-107, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine under the following conditions and wait for at least 1 second.
- Selector lever is in the P position.
- Do not depress the brake pedal.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-61, "VQ35DE MODELS : Diagnosis Procedure" (VQ35DE) or SEC-62, "VQ25DE
MODELS : Diagnosis Procedure" (VQ25DE).
NO >> INSPECTION END
VQ35DE MODELS
VQ35DE MODELS : Diagnosis ProcedureINFOID:0000000003814983
1.CHECK DTC WITH IPDM E/R
Check “Self diagnostic result” with CONSULT-III for IPDM E/R.
Is DTC B210F detected?
YES >> Refer to SEC-107, "DTC Logic".
NO >> GO TO 2.
2.CHECK TCM CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector and IPDM E/R connector.
3. Check continuity between TCM harness connector and IPDM E/R harness connector.
DTC Self-diagnosis name DTC detecting condition Possible causes
B2603SHIFT POSITION
STATUSBCM detects the followings status for 500 ms or
more when shift is in P position, and ignition switch
is in the ON position.
 Park/neutral position (PNP) switch: approx. 0 V
 Control device (detention switch): approx. 0 V Harness or connector
(Control device circuit is open or short-
ed)
 Harness or connectors
[Park/neutral position (PNP) switch
circuit is open or shorted]
 Park/neutral position (PNP) switch
BCM

SEC-64
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B2604 PNP SWITCH
B2604 PNP SWITCH
DescriptionINFOID:0000000003814984
BCM confirms the shift position with the following 4 signals.
 Selector lever
 P/N position switch
 P position signal from IPDM E/R (CAN)
 P position signal from TCM (CAN)
DTC LogicINFOID:0000000003814985
DTC DETECTION LOGIC
NOTE:
 If DTC B2604 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic".
 If DTC B2604 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
 If DTC B2604 is displayed with DTC B210F for IPDM E/R, first perform the trouble diagnosis for DTC B210F.
Refer to SEC-107, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine under the following conditions and wait for at least 1 second.
- Selector lever is in the P or N position
- Do not depress the brake pedal
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-64, "VQ35DE MODELS : Diagnosis Procedure" (VQ35DE) or SEC-65, "VQ25DE
MODELS : Diagnosis Procedure" (VQ25DE).
NO >> INSPECTION END
VQ35DE MODELS
VQ35DE MODELS : Diagnosis ProcedureINFOID:0000000003814986
1.CHECK DTC WITH IPDM E/R
Check “Self diagnostic result” with CONSULT-III for IPDM E/R.
Is DTC B210F detected?
YES >> Refer to SEC-107, "DTC Logic".
NO >> GO TO 2.
2.CHECK TCM CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector and IPDM E/R connector.
3. Check continuity between TCM harness connector and IPDM E/R harness connector.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2604 PNP SWITCHBCM detects the following status for 500 ms or
more when the ignition switch is in the ON position.
 N position input signal exists. Shift position signal
from TCM does not exist.
 N position input signal does not exist. Shift posi-
tion signal from TCM exists. Harness or connectors
[Park/neutral position (PNP) switch
circuit is open or shorted]
 Park/ neutral position (PNP) switch

B260F ENGINE STATUS
SEC-81
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B260F ENGINE STATUS
DescriptionINFOID:0000000003815011
BCM receives the engine status signal from ECM via CAN communication.
DTC LogicINFOID:0000000003815012
DTC DETECTION LOGIC
NOTE:
 If DTC B260F is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic".
 If DTC B260F is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON under the following conditions.
- Selector lever is in the P or N position.
- Do not depress brake pedal.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-81, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003815013
1.INSPECTION START
1. Turn ignition switch ON.
2. Check “Self diagnostic result” with CONSULT-III.
3. Touch “ERASE”.
4.Perform DTC Confirmation Procedure.
See SEC-81, "
DTC Logic".
Is the DTC B260F displayed again?
YES >> GO TO 2.
NO >> GO TO 3.
2.REPLACE ECM
Replace ECM. Refer to EC-14, "
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Description".
>> INSPECTION END
3.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B260F INTERRUPTION OF ENGINE STATUS SIGNALBCM has not yet received the engine status sig-
nal from ECM when ignition switch is in the ON
positionECM
