B1148 CURTAIN MODULE RH
SRC-109
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
NO >> Replace wiring harness.
3.REPLACE SIDE CURTAIN AIR BAG MODULE
1. Replace RH side curtain air bag module. Refer to SR-14, "
Exploded View"
2. Perform DTC confirmation procedure. Refer to SRC-108, "DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-108, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
Page 4353 of 5121

SRC-110
< COMPONENT DIAGNOSIS >
B1150 CURTAIN MODULE LH
B1150 CURTAIN MODULE LH
DescriptionINFOID:0000000003814068
For LH side curtain air bag module, crash is judged by main “G” sensor output signal (left side: LH satellite
sensor, right side: RH satellite sensor) and safing algorithm (left and right GP in air bag diagnosis sensor unit).
OPERATION
In case of frontal collision whose acceleration exceeds the specified level, the ignition materials are ignited by
electric ignition system. The system burns the gas generating materials resulting in a chemical reaction. This
generates hot gases that flow into the air bag through a filter and expand the bag.
STRUCTURE
LH side curtain air bag module mainly consists of air bag and inflator which inflates air bag.
INSTALLATION
LH side curtain air bag module is installed on the roof side with fixed bolts.
DTC LogicINFOID:0000000003814069
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-110, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814070
WARNING:
Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1150 CURTAIN MODULE LH
[OPEN]LH side curtain air bag module circuit is
open Disconnection of wiring harness and
open
Malfunction in LH side curtain air bag
module
Malfunction in air bag diagnosis sen-
sor unit
Page 4354 of 5121
B1150 CURTAIN MODULE LH
SRC-111
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
NO >> Replace wiring harness.
3.REPLACE SIDE CURTAIN AIR BAG MODULE
1. Replace LH side curtain air bag module. Refer to SR-14, "
Exploded View"
2. Perform DTC confirmation procedure. Refer to SRC-110, "DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-110, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
Page 4355 of 5121

SRC-112
< COMPONENT DIAGNOSIS >
B1151 CURTAIN MODULE LH
B1151 CURTAIN MODULE LH
DescriptionINFOID:0000000003814071
For LH side curtain air bag module, crash is judged by main “G” sensor output signal (left side: LH satellite
sensor, right side: RH satellite sensor) and safing algorithm (left and right GP in air bag diagnosis sensor unit).
OPERATION
In case of frontal collision whose acceleration exceeds the specified level, the ignition materials are ignited by
electric ignition system. The system burns the gas generating materials resulting in a chemical reaction. This
generates hot gases that flow into the air bag through a filter and expand the bag.
STRUCTURE
LH side curtain air bag module mainly consists of air bag and inflator which inflates air bag.
INSTALLATION
LH side curtain air bag module is installed on the roof side with fixed bolts.
DTC LogicINFOID:0000000003814072
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-112, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814073
WARNING:
Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1151 CURTAIN MODULE LH
[VB-SHORT]LH side curtain air bag module circuit is
shorted to some power supply circuit Disconnection of wiring harness and
short
Malfunction in LH side curtain air bag
module
Malfunction in air bag diagnosis sen-
sor unit
Page 4356 of 5121
B1151 CURTAIN MODULE LH
SRC-113
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
NO >> Replace wiring harness.
3.REPLACE SIDE CURTAIN AIR BAG MODULE
1. Replace LH side curtain air bag module. Refer to SR-14, "
Exploded View"
2. Perform DTC confirmation procedure. Refer to SRC-112, "DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-112, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
Page 4357 of 5121

SRC-114
< COMPONENT DIAGNOSIS >
B1152 CURTAIN MODULE LH
B1152 CURTAIN MODULE LH
DescriptionINFOID:0000000003814074
For LH side curtain air bag module, crash is judged by main “G” sensor output signal (left side: LH satellite
sensor, right side: RH satellite sensor) and safing algorithm (left and right GP in air bag diagnosis sensor unit).
OPERATION
In case of frontal collision whose acceleration exceeds the specified level, the ignition materials are ignited by
electric ignition system. The system burns the gas generating materials resulting in a chemical reaction. This
generates hot gases that flow into the air bag through a filter and expand the bag.
STRUCTURE
LH side curtain air bag module mainly consists of air bag and inflator which inflates air bag.
INSTALLATION
LH side curtain air bag module is installed on the roof side with fixed bolts.
DTC LogicINFOID:0000000003814075
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-114, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814076
WARNING:
Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1152 CURTAIN MODULE LH
[GND-SHORT]LH side curtain air bag module circuit is
shorted to ground Disconnection of wiring harness and
short
Malfunction in LH side curtain air bag
module
Malfunction in air bag diagnosis sen-
sor unit
Page 4358 of 5121
B1152 CURTAIN MODULE LH
SRC-115
< COMPONENT DIAGNOSIS >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
NO >> Replace wiring harness.
3.REPLACE SIDE CURTAIN AIR BAG MODULE
1. Replace LH side curtain air bag module. Refer to SR-14, "
Exploded View"
2. Perform DTC confirmation procedure. Refer to SRC-114, "DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-22, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-114, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
Page 4359 of 5121

SRC-116
< COMPONENT DIAGNOSIS >
B1153 CURTAIN MODULE LH
B1153 CURTAIN MODULE LH
DescriptionINFOID:0000000003814077
For LH side curtain air bag module, crash is judged by main “G” sensor output signal (left side: LH satellite
sensor, right side: RH satellite sensor) and safing algorithm (left and right GP in air bag diagnosis sensor unit).
OPERATION
In case of frontal collision whose acceleration exceeds the specified level, the ignition materials are ignited by
electric ignition system. The system burns the gas generating materials resulting in a chemical reaction. This
generates hot gases that flow into the air bag through a filter and expand the bag.
STRUCTURE
LH side curtain air bag module mainly consists of air bag and inflator which inflates air bag.
INSTALLATION
LH side curtain air bag module is installed on the roof side with fixed bolts.
DTC LogicINFOID:0000000003814078
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-10, "
Air Bag Warning Lamp Diagnosis".
NOTE:
SRS does not enter Diagnosis mode if no malfunction is detected in User mode.
Is malfunctioning part detected?
YES >> Refer to SRC-116, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814079
WARNING:
Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1153 CURTAIN MODULE LH
[SHORT]LH side curtain air bag module circuit
are shorted to each other Disconnection of wiring harness and
short
Malfunction in LH side curtain air bag
module
Malfunction in air bag diagnosis sen-
sor unit
