2008 MERCEDES-BENZ GL450 Owner's Manual

568 Technical data
Fuels, coolants, lubricants
Anticorrosion/antifreeze
Your vehicle contains a number of
aluminum parts. The use of aluminum
components in motor vehicle engines
necessitates that anticorrosion/antifreeze
coolant used in such engines be
specifically formulated to protect the aluminum parts. Failure to use such
anticorrosion/antifreeze coolant will result
in a significantly shortened service life.
Therefore, the following product is strongly
recommended for use in your vehicle:
MB 325.0 Anticorrosion/Antifreeze agent.Before the start of the winter season (or
once a year in hot southern regions), you
should have the anticorrosion/antifreeze
concentration checked. The coolant is also
regularly checked each time you bring your
vehicle to an authorized Mercedes-Benz
Light Truck Center for service.
Anticorrosion/antifreeze quantity
Approximate freeze protection
Model-35°F (-37°C)-49°F (-45°C)
GL 320 CDI5.0 US qt (4.75 l)5.5 US qt (5.2 l)
GL 4505.3 US qt (5.0 l)5.8 US qt (5.5 l)
GL 5501
1Data preliminary.
5.6 US qt (5.25 l)6.1 US qt (5.8 l)
164.boo Seite 568 Freitag, 30. März 2007 12:54 12

569 Technical data
Fuels, coolants, lubricants
Windshield washer system and
headlamp cleaning system*
Both the windshield washer system and
headlamp cleaning system* are supplied
from the windshield washer reservoir.
The windshield washer reservoir has a ca-
pacity of approximately 8.1 US qt (7.7 l).
Refill the reservoir with MB Windshield
Washer Concentrate and water (or con-
centrate and commercially available
premixed windshield washer sol-
vent/antifreeze, depending on ambient
temperatures).Windshield and headlamp washer fluid
mixing ration
For temperatures above freezing point, use
MB Windshield Washer Concentrate
“MB SummerFit” and water:

1 part “MB SummerFit” to 100 parts
water
(1.34 fl oz [40 ml] “MB SummerFit” to
1gal [4.0l] water)
For temperatures below freezing point, use
MB Windshield Washer Concentrate
“MB SummerFit ” and commercially avail-
able premixed windshield washer
solvent/antifreeze:

1 part “MB SummerFit” to 100 parts
solvent
(1.34 fl oz [40 ml] “MB SummerFit” to
1 gal [4.0 l] solvent)Warning!G
Washer solvent/antifreeze is highly flamma-
ble. Do not spill washer solvent/antifreeze
on hot engine parts, because it may ignite
and burn. You could be seriously burned.
164.boo Seite 569 Freitag, 30. März 2007 12:54 12

570
164.boo Seite 570 Freitag, 30. März 2007 12:54 12

571 Index
A
ABS 101
Indicator lamp 436
Off-road - ABS 102
ABS, ESP
®
Messages in the multifunction
display 451
Accelerator position, automatic
transmission 195
Accessory weight 415
Accident 66
Active head restraint 90, 133, 499
Adaptive Damping System (ADS)* 278
Air bags 76
Children 77, 91
Front passenger front air bag off
indicator lamp 31, 32, 85
Front, Driver 79
Front, Passenger 79
Occupant Classification System
(OCS) 81
Safety guidelines 78
Side impact (front and rear*) 80
Window curtain 80Air conditioning refrigerant 564
Air conditioning system see
Climate control or
Automatic climate control (3-zone)*
Air conditioning, Cooling 224, 239
Air distribution, Front 219, 234
Air distribution, Rear 227, 243
Air pressure see Tire inflation pressure
Air recirculation mode 222, 237
Air suspension program 278
Adaptive Damping System
(ADS)* 278
Messages in the multifunction
display 486
Vehicle level control 279
Air vents 227
Air vents*, Rear 245
Air vents, Front 220, 234
Air volume 220, 235
Alarm system see Anti-theft systems
Alignment bolt (vehicle tool kit) 492, 524
Anticorrosion/antifreeze 563, 568
Antiglare, Interior rear view mirror 208Antiglare, Rear view mirrors* 208
Antilock Brake System see ABS
Anti-theft systems 110
Anti-theft alarm system 109, 110
Immobilizer 109
Aquaplaning see Hydroplaning
Armrest storage/telephone*
compartment
Front 317
Ashtrays (Depending on
vehicle configuration) 321
Aspect ratio 415
ATF 381
Attaching a trailer 366
AUDIO menu 164
Audio menu
CD operation 165
Radio operation 164
Satellite radio* operation 164
Auto-dimming*, Rear view mirrors 208
Automatic central locking,
Control system 180
164.boo Seite 571 Freitag, 30. März 2007 12:54 12

572 Index
Automatic climate control (3-zone)* 228
Air conditioning refrigerant 563
Air conditioning, Cooling 239, 240
Air distribution, Front 234
Air distribution, Rear 243
Air recirculation mode 237
Air vents*, second-row seats 245
Air vents*, third-row seats 245
Air vents, Front 234
Air volume 235
Control panel, Front 230
Control panel, Rear 241
Deactivating system 232
Defogging 235
Defrosting 235
Maximum cooling, MAXCOOL 237
Rear passenger compartment 241
Rear window defroster 212
Residual engine heat (REST) 241
Using driver-side settings for
all temperature zones 240Automatic headlamp mode 144
Automatic lighting control, Interior
lighting 150
Automatic locking when driving 128
Automatic transmission 56
Accelerator position 195
Emergency operation
(limp-home mode) 200
Gear ranges 197
Gear selector lever 56, 189
Gear selector lever position 192
Gear shifting malfunctions 200
Hill start assist system 196
Kickdown 196
Shifting procedure 192
Starting the engine 56
Steering wheel gearshift control 198
Towing a trailer 197
Transmission fluid level 381
Transmission positions 193
Automatic Transmission Fluid see ATFB
Backrest
Seat 46
Seat, Lumbar support 137
Seat, Multicontour* 138
Backup lamps
Messages in the multifunction
display 477
Replacing bulbs 511
Bar 416
BAS 103
Lamps in instrument cluster 436
Messages in the multifunction
display 451
Batteries, SmartKey
Check lamp 112, 115
Checking battery condition 120
Messages in the multifunction
display 466
Replacing 502
164.boo Seite 572 Freitag, 30. März 2007 12:54 12

573 Index
Battery, Vehicle 528
Charging 535
Disconnecting and connecting 530
Jump starting 536
Removing and installing 530
Bead 416
Beverage holder see Cup holder
Bi-Xenon headlamps* see headlamps
Bolts, Spare wheel 494
Brake fluid 564
Checking 376
Messages in the multifunction
display 469
Brake lamp
Cleaning lenses 429
Messages in the multifunction
display 477
Replacing bulbs 511
Brake pads 348
Messages in the multifunction
display 467
Brakes 348
Warning lamp 437
Break-in period 346
Bulbs, replacing see Replacing bulbsButton for Voice control* system 30,
156
C
California retail buyers and lessees,
Important notice for 11
Camera see Rear view camera*
Can holder see Cup holder
Capacities and recommended
fuel/lubricants 562
Card holder 33, 37, 320
Cargo compartment cover blind 310
Cargo net* 312
Cargo tie-down rings 302
Carpets, Cleaning 433
Carriers* 295
Catalytic converter
(gasoline engine) 371
CD changer 165, 315
CD player 165
Center console
Lower part 33
Upper part (Vehicles with
enhanced off-road package*) 32
Upper part (Vehicles without
enhanced off-road package*) 31Central locking
Automatic 128
Locking/unlocking from the
inside 128
Switch 128
Certification label 550
CHECK ENGINE malfunction indicator
lamp 439, 440
Checking tire pressure electronically with
the Advanced Tire Pressure Monitoring
System (Advanced TPMS)*,
(Canada only) 401
Checking tire pressure electronically with
the Tire Pressure Monitoring System
(TPMS), (USA only) 398
Checklist
Off-road driving 357
Returning from off-road driving 363
164.boo Seite 573 Freitag, 30. März 2007 12:54 12

574 Index
Children in the vehicle 91
Air bags 77, 91
Blocking rear door window
operation 98
Indicator lamp, Front passenger front
air bag 85
Infant and child restraint systems 86,
92
LATCH-type child seat anchors 95
Occupant Classification System
(OCS) 81
Cigarette lighter
(Depending on vehicle
configuration) 323
Climate control 214
Air conditioning refrigerant 563
Air conditioning, Cooling 224, 225
Air distribution, Front 219
Air distribution, rear 227
Air recirculation mode 222
Air vents*, second-row seats 220
Air vents, Front 220
Air volume 220
Control panel*, Rear 226
Control panel, Front 216
Deactivating system 218Defogging 222
Defrosting 221
Rear window defroster 212
Residual engine heat (REST) 225
Clock 27, 174
Cloth upholstery, Cleaning and
care of 434
Cockpit 24
Cockpit Management and Data System
see COMAND System
Cold tire inflation pressure 416
Collapsible wheel chock 494
COMAND System see separate operating
instructions
Combination switch 61, 62, 64, 147
Compass 344
Adjustment 178
Calibration 179
Calling up the compass 344
Control and operation of radio
transmitters 370
Control system 155
Multifunction display 155
Multifunction steering wheel 156
Resetting to factory default 169Control system menus 155
AUDIO 164
DISTRONIC* (Canada only) 167
NAV* 166
Off-road 166
Settings 168
Standard display 162
TEL* 186
Trip computer 184
Vehicle configuration 182
Vehicle status message memory 167
Control system submenus 159, 161, 171
Comfort* 181
Instrument cluster 172, 173
Lighting 175
Time/Date 174
Vehicle 178
Coolant 381, 567
Anticorrosion/antifreeze mixing ratio
and quantity 568
Capacities 562
Checking coolant level 376, 381
Messages in the multifunction
display 470, 472
Temperature 372
Temperature display 162
164.boo Seite 574 Freitag, 30. März 2007 12:54 12

575 Index
Corner-illuminating front fog lamps* 147
Messages in the multifunction
display 478
Replacing bulbs 510
Crossbars* 295
Crossing obstacles 361
Cruise control 255
Activating 257
Messages in the multifunction
display 452
Cup holders 320
Cleaning 321
Front center console 321
Front center console,
Removing/Installing 321
Rear armrest 320
Curb weight 416
D
Date display, Setting 174
Daytime running lamp mode 145
Setting 175
Deep water see Standing water
Defogging windshield 221, 235
Defrosting, Front 221, 235
Defrosting, Rear 212Delayed shut-off
Exterior lamps 176
Interior lighting 177
Department of Transportation see DOT
Diesel engine
Preglow indicator lamp 29
Differential locks* 204
A few words about 204
Messages in the multifunction
display 488
Switching 205
Difficulties
While driving 65
While starting 59
Digital clock see Clock
Digital speedometer 155, 163
Dimensions, Vehicle 560
Direction of rotation (tires) 387
Displays
Digital speedometer 155, 163
Distronic* 263
Maintenance service indicator 422
Messages in the multifunction
display 449
Multifunction display 155Outside temperature 155, 163
Selecting 173
Symbol messages 466
Text messages 451
Vehicle status message 168, 449
Vehicle system settings, Control
system 159, 161, 168
Distance to empty (range), Trip
Computer 184
Distronic* 260
Activating 266
Cleaning system sensor 430
Control system 264
Deactivating 268
Distance warning function* 272
Distance warning function*
activating/deactivating 183
Driving hints 270
Messages in the multifunction
display 453
Sensor cover 430
Warning and indicator lamps 263
164.boo Seite 575 Freitag, 30. März 2007 12:54 12
