2008 MERCEDES-BENZ GL450 Owner's Manual

304 Controls in detail
Loading
Hooks
Two hooks are located on the rear com-
partment trim panels, one on each side.
1Hook
Use the hooks to secure light weight items
only. The maximum permissible weight per
hook is 9lb(4kg).Expanding cargo compartment
You can separately fold the left and right
rear seat backrests to expand the cargo
compartment.
Warning!G
When expanding the cargo compartment,
always fully fold the corresponding seats
and, if so equipped, always use the
cargo net* (
page 312) when transporting
cargo.
Unless you are transporting cargo, the back-
rests must remain properly locked in the up-
right position.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle, and can cause
injury to vehicle occupants unless the items
are securely fastened in the vehicle.
Always use the cargo tie down rings
(
page 302).
Warning!G
Never drive the vehicle with the tailgate
open. Deadly carbon monoxide (CO) gases
may enter vehicle interior resulting in un-
consciousness and death.
!When the second-row seats are folded for-
ward, the front seats may not be moved to the
rearmost position. Otherwise you could damage
the front and second-row seats.
164.boo Seite 304 Freitag, 30. März 2007 12:54 12

305 Controls in detail
Loading
Expanding cargo compartment in part
Folding third-row seats, electrically
There are several ways to fold the third-row
seats.Two buttons are located on the right side
trim of the third-row seats.
Example, button for the left third-row seat
1Button for returning third-row seats to
upright position
2Button for folding the third-row seatsTwo buttons are located on the
passenger-side in the cargo compartment
Example, button for the right third-row seat
1Button for returning third-row seats to
upright position
2Button for folding the third-row seats
Push in the head restraints of the
third-row seats all the way
(
page 135).
Remove cargo compartment cover
blind (
page 311).
iUse the left button, indicated byL, to fold
down the left third-row seat.
Use the right button, indicated byR, to fold down
the right third-row seat.
iIt is only possible to fold the third-row seats
down when the rear right door is open.iIt is only possible to fold the third-row seats
down when the tailgate is open.

164.boo Seite 305 Freitag, 30. März 2007 12:54 12

306 Controls in detail
Loading
Press and hold button2 for each side
until the third-row seats are fully fold-
ed.
If a third-row seat is not engaged properly,
for example, the message
3rd Row Of
Seats – Right Not Locked
appears in the
multifunction display (
page 155).
Press and hold button2 again, until
the message disappears.Expanding cargo compartment fully
Folding second-row seats
Push in the head restraints of the
second-row seats all the way
(
page 135).
Warning!G
Folded second-row seats are intended to
serve as a cargo compartment expansion in
conjunction with folded third-row seats only.
Do not fold the second-row seats and allow
third-row seat occupants to use folded sec-
ond-row seats as a footrest while driving.
Third-row seat occupants must, like all vehi-
cle occupants, keep both feet on the floor in
front of their seat. Otherwise, occupants
could slide under their seat belt in a colli-
sion. If occupants slide under the belt, it
would apply force at the abdomen or neck.
That could cause serious or even fatal inju-
ries. Do not fold the second-row seats and
allow third-row seat occupants to use folded
second-row seats as a table while driving.
Objects placed on folded second-row seats
may come loose during braking, vehicle ma-
neuvers, or an accident and be thrown
around the vehicle interior. Objects thrown
around the vehicle interior may cause an ac-
cident and/or serious personal injury.
!When the second-row seats are folded for-
ward, the front seats may not be moved to the re-
armost position. Otherwise you could damage
the front and second-row seats.

164.boo Seite 306 Freitag, 30. März 2007 12:54 12

307 Controls in detail
Loading
1Strap
2Seat cushion
Pull strap1 in direction of arrow.
Fold seat cushion2 forward.3Lever
Pull and hold lever3 in direction of
arrow at resistance point.
The seat backrest folds down.
Check for secure locking by pushing
and pulling on the seat backrest.
164.boo Seite 307 Freitag, 30. März 2007 12:54 12

308 Controls in detail
Loading
Folding third-row seats, electrically
There are several ways to fold the third-row
seats.
Two buttons are located on the right side
trim of the third-row seats.
Example, button for the left third-row seat
1Button for returning third-row seats to
upright position
2Button for folding the third-row seatsTwo buttons are located on the
passenger-side in the cargo compartment
Example, button for the right third-row seat
1Button for returning third-row seats to
upright position
2Button for folding the third-row seats
Push in the head restraints of the
third-row seats all the way
(
page 135).
Remove cargo compartment cover
blind (
page 311).
Press and hold button2 for each side
until the third-row seats are fully fold-
ed.
The cargo compartment is fully extend-
ed.
If a third-row seat is not engaged properly,
for example, the message
3rd Row Of
Seats – Right Not Locked
appears in the
multifunction display (
page 155).
Press and hold button2 again, until
the message disappears.
iUse the left button, indicated byL, to fold
down the left third-row seat.
Use the right button, indicated byR, to fold down
the right third-row seat.
iIt is only possible to fold the third-row seats
down when the rear right door is open.
iIt is only possible to fold the third-row seats
down when the tailgate is open.
164.boo Seite 308 Freitag, 30. März 2007 12:54 12

309 Controls in detail
Loading
Returning seats to their original positionStep 1:
Return third-row seats to its original
position (
page 308).
Step 2:
1Seat backrest
2Lever
Pull and hold lever2 in direction of
arrow at resistance point.
Fold seat backrest1 rearward until it
engages.
Check for secure locking by pushing
and pulling on seat backrest1.3Seat cushion
Fold seat cushion3 rearward until it
locks into position.
Warning!G
Make sure all seats are properly locked in
position before driving off. Do not drive with
seats not properly locked.
Never ride in a moving vehicle with the seat
not properly locked as this can be danger-
ous. The seat could move forward and the
seat backrest could fold. You could slide un-
der the seat belt during braking, vehicle ma-
neuvers, or in an accident. If you slide under
it, the belt would apply force at the abdomen
or neck. That could cause serious or even fa-
tal injuries.
The seat backrest and seat belt provide the
best restraint when the wearer is in a nearly
upright position and the belt is properly po-
sitioned on the body.
164.boo Seite 309 Freitag, 30. März 2007 12:54 12

310 Controls in detail
Loading
Cargo compartment cover blind
The cargo compartment cover blind can be
installed behind the third-row seats or the
second-row seats.
Blind installed behind third-row seats
1Handle
2MountRolling out blind
Pull blind on handle1 across the car-
go compartment.
Guide blind into mounts2 and re-
lease.
Rolling up blind
Disengage blind and guide retraction
by its handle1.Installing blind
Cover from the mounts behind second-row
seats
3Cover
Press on cover3 at its upper edge as
indicated by arrow.
!With the cargo compartment cover blind in-
stalled, do not pile luggage higher than the lower
edges of the rear side windows.
iBefore installing cargo compartment cover
blind behind the second-row seats, fold the
third-row seats forward (
page 305).
iBefore installing cargo compartment cover
blind behind the third-row seats, fold the left or
right third-row seat forward (
page 305). After-
wards, return the left or right third-row seat into
its original position.
164.boo Seite 310 Freitag, 30. März 2007 12:54 12

311 Controls in detail
Loading
Remove cover3 by pulling its lower
edge out of the side trim.
Place left side of blind2 (page 311)
in left mount.
Position right side of blind2 over right
mount.
Press release button1 (page 311)
and guide cover2 into mount.
Make sure the cargo compartment
cover blind is securely fastened.Removing blind
Blind installed behind second-row seats
1Release button
2Blind
Roll the blind up.
Push release button1.
Pull blind2 to the left against the
spring pressure until the spring in the
cover audibly engages.
Remove the blind.
iTo avoid loss of the mount covers, insert the
mount covers into the mounts currently not in
use.
iBefore removing cargo compartment cover
blind behind the third-row seats, fold the left or
right third-row seat forward (
page 305). After-
wards, return the left or right third-row seat into
its original position.
