2008 KIA Amanti Owner's Manual

315
Knowing your vehicle
Window opening and closing
The driver’s door has a master power
window switch that controls all the win-
dows in the vehicle. To open or close a
window, press down or pull up the front
portion of the corresponding switch.
Automatic power window
Depressing or pulling up the power win-
dow switch momentarily to the second
detent position (
➅) completely lowers or
lifts the window even when the switch is
released. To stop the window at the
desired position while the window is in
operation, pull up or depress the switch
momentarily to the opposite direction of
the window movement.
If the battery has been discharged or
disconnected, the automatic power win-
dow system must be reset as follows:
1. Turn the ignition key to ON position.
2. Close each window and continue pulling up on each power window
switch for at least 0.5 second after the
window is completely closed. Automatic window reversal (When win-
dow is closed by the automatic power
window)
If the upward movement of the window is
blocked by an object or part of the body,
the window will detect the resistance
and will stop upward movement. The
window will then lower approximately
150 mm (5.9 inches) to allow the object
to be cleared.
1GHA2301A1GHA2300A

Knowing your vehicle
163
Power window lock switch
• The driver can disable the power win-
dow switches on a passenger door by
depressing the power window lock
switch located on the driver’s door to
LOCK (pressed).
• When the power window lock switch is ON, the driver’s master control cannot
operate the passenger door power
windows either.
Power window timer (if equipped)
The power windows can be operated for
approximately 30 seconds after the igni-
tion key is removed or turned to the ACC
or LOCK position. However, if the front
doors are opened, the power windows
cannot be operated even within 30 sec-
onds after the ignition key is removed.
WARNING
• The automatic window rever sal
feature (window lower s 150 mm
[5.9 inches] when a resistance is
detected) will only operate when
the automatic power window up
operation feature is used.
Automatic window rever sal will
not operate if the window is
raised using the fir st detent posi-
tion (
➄) on the power window
s witch. Always double check to
make sure all faces, arms, hands
and other obstructions are safely
out of the way before operating
the power window.
• If an object less than 4 mm (0.16 inch) in diameter is caught
between the window gla ss and
the upper window channel, the
automatic rever sal may not detect
the resistance and will not oper-
ate. Therefore, always check for
any obstructions before raising
any window.

317
Knowing your vehicle
Driver’s seat
➀
Seat adjustment, forward / back-
ward/height
➁Seatback recliner
➂Seat heater / ventilator switch*
➃Lumbar support
➄Driver position memory system*
■ Headrest adjustment (headrest
cannot be adjusted by a switch)
Front passenger seat
➅
Seat adjustment, forward / backward
\bSeatback recliner
➇Seat heater / ventilator switch*
■ Headrest adjustment (headrest
cannot be adjusted by a switch)
Rear seat
➈
Seat heater switch (left)*
\fSeat heater switch (right)*
* : if equipped
SEATS
STOPSTOP
OGH026012N

Knowing your vehicle
183
For a seating position more comfortable
to the driver and front passenger, adjust
the seat forward, backward, up and
down.
WARNING
• Loose objects in the driver’s foot
area could interfere with the oper-
ation of the foot pedal s,possibly
caus ing an accident. Loos e
objects might interfere with the
s eat slide mechanis m. Do not
place anything under the front
seats.
• The power s eats are operable
with the ignition OFF.
Therefore, children should never
be left unattended in the car.
WARNING- Driver’ s seat
• Never attempt to adjus t the seat
while the vehicle is moving. This
could res ult in loss of control, and
an accident caus ing death,seri-
ous injury, or property damage.
• Do not allow anything to interfere with the normal pos ition of the
s eatback. Storing items against a
s eatback or in any other way inter-
fering with proper locking of a
s eatback could res ult in serious
or fatal injury in a s udden stop or
collis ion.
(Continued)
(Continued)
• Always drive and ride with yourseatback upright and the lap por-
tion of the safety belt, or lap belt,
snug and low across the hips.
This pos ition puts your safety
belts in the best position to pro-
tect you in case of an accident.
• In order to avoid unnece ssary air
bag injuries including the po ssi-
bility of severe injury or death,
always sit as far back as possible
from the steering wheel while still
being able to maintain comfort-
able control of your vehicle.
• The Canadian Motor Vehicle Safety Standards (CMVSS) rec-
ommends that the driver sit at
least 250 mm (10 inches) away
from the steering wheel to avoid
the risk of serious injury or death
due to the deployment of the dri-
ver’ s air bag.
CAUTION
• Power seats are driven by electric
motor. Stop operating when the adjustment is completed.
Excessive operation may damagethe electrical equipment.
• When in operation, the power seats consume large amounts ofelectrical power. To preventunnecessary charging s ystem
drain, don’t adjus t the power
s eats longer than necessary
while the engine is not running.
• Do not operate two or more power seat control buttons at the sametime. Doing so may res ult in
power seat motor or electrical
component malfunction.

319
Knowing your vehicle
Driver’s seat adjustment
Forward/backward position and
height adjustment
Adjusting the seat forward and backward
Push the control button forward or back-
ward to move the seat to the desired
position. Release the knob and the seat
will lock in the selected position.
Adjust the seat before driving, and make
sure the seat is locked securely by trying
to move forward and backward without
using the control knob. If the seat moves,
it is not locked properly. Adjusting front height of seat cushion
Move the front portion of the control knob
up to raise or down to lower the front part
of the seat cushion.
Adjusting rear height of seat cushion
Move the rear portion of the control knob
up to raise or down to lower the rear part
of the seat cushion.
5GHA22385GHA22395GHA2240

Knowing your vehicle
203
WARNING
Driving or riding in a vehicle with a
front seatback reclined could lead
to serious or fatal injury in an acci-
dent. If a front seat is reclined dur-
ing an accident, the occupant’ s hips
may slide under the lap portion of
the safety belt applying great force
to the unprotected abdomen or
neck or a passenger may be ejected
in a rollover. Serious or fatal inter-
nal injuries could result. Keep the
seatbacks in a comfortably upright
position whenever the vehicle i s in
motion.
Adjusting the height of seat cushion
To raise or lower the seat cushion, pull up
or push down on the center of the corre-
sponding switch. Release the knob once
the seat reaches the desired position.Adjusting the driver’ s seatback
recliner
Move the lever forward or backward to
the desired angle and release the lever. If
the lever is released, seatback will lock in
place. After adjustment, make sure that
the lever has returned to its original
locked position.
5GHA22415GHA2242

321
Knowing your vehicle
Lumbar support
The lumbar support can be adjusted by
pressing the lumbar support switch on
the side of the driver’s seat. Press the
front portion of the switch (
➀) to increase
support, or the rear portion of the switch
(
➁), to decrease support.
Move the support position up and down
by pressing the switch (
➂) or (➃).
Driver position memory system (if equipped)
A driver position memory system is pro-
vided to store and recall the seat and
outside mirror positions with a simple
button operation. By saving the desired
positions into the system memory, differ-
ent drivers can reposition the seat and
outside mirror based upon their driving
preference.
See page 3-28 for detail information.
Adjusting the front passenger
seat
Forward/backward position adjust-
ment
Push the control knob forward or back-
ward to move the seat to the desired
position. Release the knob and the seat
will lock in the selected position.
Adjust the seat before driving, and make
sure the seat is locked securely by trying
to move forward and backward without
using the control knob. If the seat moves,
it is not locked properly.
OGH026014
STOPSTOP
OGH036900N5GHA2248

Knowing your vehicle
223
Adjusting seatback recliner
Move the lever forward or backward to
the desired angle and release the lever. If
the lever is released, seatback will lock in
place. After adjustment, make sure that
the lever has returned to its original
locked position.
WARNING
In order to avoid unnecessary air
bag injuries including the po ssibili-
ty of severe injury or death, alway s
sit as far back as possible by mov-
ing the seat far back, while still
maintaining good vehicle control.
Serious injury or death may be
caused due to the deployment of
the passenger’ s air bag.
5GHA2249
WARNING
Riding in a vehicle with a front seat-
back reclined could lead to serious
or fatal injury in an accident. If a
front seat is reclined, the occu-
pant’ s hips may slide under the lap
portion of the safety belt applying
great force to the unprotected
abdomen or neck or a passenger
may be ejected in a rollover. Serious
or fatal internal injuries could
res ult. Keep the s eatbacks in a
comfortably upright po sition when-
ever the vehicle i s in motion.
