2008 KIA Amanti Owner's Manual

23
Your vehicle at a glance
INSTRUMENT PANEL OVERVIEW
1. Driver’s Air Bag ...................................3-57
2. Light control / Turn signals..........4-34/4-36
3. Instrument cluster ...............................4-25
4. Wiper/Washer .....................................4-38
5. Ignition switch .......................................4-2
6. Seat warmer .......................................3-23
7. Front passenger’s air bag off indicator ..3-59
8. Hazard .........................................4-42, 6-2
9. Rear climate control selection button ..4-52
10. Climate control system .....................4-43
11. Shift lever ............................................4-5
12. Passenger’s airbag ...........................3-58
13. Glove box ..........................................3-90
14. Trunk lid control button......................3-77
15. Audio controls*..................................3-99
16. Auto cruise controls* .........................4-19
17. Electronic stability control*................4-22
18. Trip computer* .................................3-117
*: if equipped
OGH006001N

Your vehicle at a glance
42
ENGINE COMPARTMENT
OGH057001N
1. Windshield washer fluid reservoir .......7-18
2. Power steering fluid reservoir .............7-15
3. Engine oil filler cap .............................7-11
4. Auto transaxle oil dipstick ...................7-16
5. Air cleaner...........................................7-19
6. Brake fluid reservoir ............................7-14
7. Engine oil dipstick ...............................7-11
8. Radiator cap .......................................7-13
9. Positive battery terminal ..............6-4, 7-22
10. Engine coolant reservoir ...................7-12
11. Negative battery terminal ..........6-4, 7-22

3
Keys / 3-2
Remote keyless entry / 3-4
Immobilizer system / 3-7
Door locks / 3-9
Windows / 3-13
Seats / 3-17
Driver position memory system / 3-28
Safety belts / 3-30
Air bags-advanced supplemental restraint system / 3-52
Trunk / 3-76
Hood / 3-80
Fuel filler lid / 3-81
Mirrors / 3-84
Interior lights / 3-88
Storage compartments / 3-89
Interior features / 3-91
Sunroof / 3-96
Antenna / 3-98
Audio remote control / 3-99
Audio systems / 3-100
Knowing your vehicle

Knowing your vehicle
23
The key code number is stamped on the
plate attached to the key set. Should you
lose your keys, this number will enable
an authorized Kia Dealer to duplicate the
keys easily. Remove the plate and store it
in a safe place. Also, record the code
number and keep it in a safe and handy
place, but not in the vehicle.Key operations
➀Master key
Used to start the engine, lock and unlock the doors, lock and unlock the
glove box, and open the trunk.
➁Sub key
Used only to start the engine and lock
and unlock the door.
➂Transmitter
Used to lock and unlock the doors
and trunk (trunk can only be opened
with the transmitter when the trunk lid
control button located in the glove
compartment is turned on. See page
3-3).
KEYS
OGH036001NOGH036002N
WARNING- Ignition key
Leaving children unattended in a
vehicle with the ignition key i s dan-
gerou s even if the key is not in the
ignition. Children copy adult s and
they could place the key in the igni-
tion. The ignition key would enable
children to operate power window s
or other control s, or even make the
vehicle move, which could re sult in
serious bodily injury or even death.
Never leave the keys in your vehicle
with unsupervised children.
➀
➁
➂

33
Knowing your vehicle
Restrictions in handling keys
When leaving keys with parking lot and
valet attendants, the following proce-
dures will ensure that your vehicle’s trunk
and glove box compartment cannot be
opened in your absence.1. Unlock the glove box with the master
key and open it.
2. Set the trunk lid control button in the glove box compartment to OFF (not
depressed). In the OFF position, the
trunk cannot be unlocked with either
the trunk release lever inside the car or
trunk open button of transmitter.
3. Close the glove box, and lock the glove box using the master key.
4. Leave the sub key with the attendant. The trunk and glove box are secured
because the sub key only allows the
engine to start and locks and unlocks
the door.
1GHA2004
WARNING
Use only Kia original part s for the
ignition key in your vehicle. If an
aftermarket key i s used, the ignition
s witch may not return to ON after
START. If this happens, the starter
will continue to operate caus ing
damage to the starter motor and
possible fire due to excessive cur-
rent in the wiring.

Knowing your vehicle
43
➀Lock button
➁ Unlock button
➂ Trunk lid open button
➃ Alarm button
➀Lock ( )
All doors are locked and the hazard
lamp will flash once if the lock button
is pressed. Also, the trunk is locked
and cannot be opened with the out-
side handle.
➁Unlock ( )
Driver’s door is unlocked and the haz-
ard lamp will flash twice if the unlock
button is pressed once. Also, the trunk
is unlocked and can be opened with
the outside handle. All doors are
unlocked if the unlock button is
pressed twice within 3 seconds.
After depressing this button, the
doors will be locked automatically
unless you open them within 30 sec-
onds.
➂ Trunk lid open ( )
The trunk lid opens if this button is
pressed. If this button is pressed while
all the doors are locked, the trunk will
open, however it will remain locked
when closed.
If any door is unlocked, the trunk will
remain unlocked when closed.
When the trunk lid control button in
the glove box is OFF, the trunk will not
open or unlock even when the button
on the transmitter is pressed.
➃ Alarm ( )
The horn sounds and hazard lamp
will flash for about 27 seconds if this
button is pressed.
REMOTE KEYLESS ENTRY (IF EQUIPPED)
2GHN3330A
➀
➂
➁➃

35
Knowing your vehicle
✽NOTICE
The transmitter will not work if any of
the following occur:
- The ignition key is in the ignition
switch.
- You exceed the operating distance limit (10 m [393.7 inches]).
- The battery in the transmitter is weak.
- Other vehicles or objects may be blocking the signal.
- The weather is extremely cold.
- The transmitter is close to a radio transmitter such as a radio station or
an airport which can interfere with
normal operation of the transmitter.
When the transmitter does not work
correctly, open and close the door with
the ignition key. If you have a problem
with the transmitter, contact an author-
ized Kia Dealer.
✽ NOTICE
Keep the transmitter away from water
or any liquid. If the keyless entry system
is inoperative due to exposure to water
or liquids, it will not be covered by your
manufacturer vehicle warranty.
Operational distance may vary depend-
ing upon the area the transmitter is used
in. For example, if the vehicle is parked
near police stations, government and
public offices, broadcasting stations, mil-
itary installations, airports, or transmit-
ting towers, etc., operational distance
may be lessened. This device complie
s with Industry
Canada Standard RSS-210.
Operation is subject to the following two
conditions:
1. This device may not cause interfer- ence, and
2. This device must accept any interfer- ence, including interference that may
cause undesired operation of the
device.
WARNING
Changes or modifications not
expressly approved by the party
responsible for compliance could
void the user’ s authority to operate
the equipment.

Knowing your vehicle
63
Battery replacement
Transmitter uses a 3 volt lithium battery
which will normally last for several years.
When replacement is necessary, use the
following procedure.
1. Insert a slim tool into the slot and gen-tly pry open the transmitter’s center
cover (
➀).
2. Replace the battery with a new one. When replacing the battery, make sure
the battery’s positive “+” symbol faces
up as indicated in the illustration.
3. Install the battery in the reverse order of removal.
✽NOTICE
The keyless entry system transmitter is
designed to give you years of troublefree
use, however it can malfunction if
exposed to moisture or static electricity.
If you are unsure how to use your trans-
mitter or replace the battery, contact an
authorized Kia dealer.
For replacement of transmitters, see an
Authorized Kia Dealer for reprogram-
ming.
2GHN3101
CAUTION
•U sing the wrong battery can
cause the transmitter to malfunc- tion. Be sure to use the correct
battery.
• To avoid damaging the tran smit-
ter, don't drop it, get it wet, or expose it to heat or sunlight.
➀
