143
Lights up in red:
Engine overheating Carefully bring the car to a stop, switch
off the engine and allow it to cool down.
Do not open the hood, otherwise there
would be a risk of injury by scalding.
Contact your BMW center.
Lights up in yellow:
Engine too hot Continue driving at more moderate
speed so that the engine can cool
down. Have the engine checked with-
out delay if the situation reoccurs.
Lights up in red:
Battery is no longer being charged.
Alternator malfunctionSwitch off all unnecessary electrical
consumers. Have the power supply
system checked without delay.
Lights up in yellow:
Battery charge level very low, battery
aged or not securely connectedHave the battery checked as soon as
possible.
Indication in US models
Parking brake applied
Indication in Canadian models
Parking brake applied
Indication in US models
Lights up in red:
Brake fluid level too low If brake pedal travel is considerably
longer than usual, stop immediately.
Contact your BMW center.
Lights up in yellow:
Drive-off assistant has failed. The car
will not be held in place after the brake
is releasedHave the system checked as soon as
possible.
Indication in Canadian models
Lights up in red:
Brake fluid level too low If brake pedal travel is considerably
longer than usual, stop immediately.
Contact your BMW center.
Lights up in yellow:
Drive-off assistant has failed. The car
will not be held in place after the brake
is releasedHave the system checked as soon as
possible.
12Cause What to do

Indicator and warning lamps
144Indication in US models
Brake pads worn Have the condition of the brake pads
checked without delay.
Indication in Canadian models
Brake pads worn Have the condition of the brake pads
checked without delay.
Indication in US models
Vehicle electronics failed You cannot continue your journey. Con-
tact your BMW center.
Indication
* in Canadian models
Vehicle electronics failed You cannot continue your journey. Con-
tact your BMW center.
Indication
* in Canadian models
Vehicle electronics failed You cannot continue your journey. Con-
tact your BMW center.
Lights up in red: Have the system in question checked
without delay.
>Starter failed or The engine cannot be restarted.
>ignition malfunctioning. Engine
restart only possible when brake is
depressed or
>lighting system failed. Low beams/
tail lamps and brake lamps still
operational. All other lamps failedDepress the brake to restart the engine.
Lights up in yellow:
>Control of the brake lamps failed or
>fuel supply malfunctioningYou can continue your journey, but
moderate your speed and exercise due
caution. Have the system in question
checked without delay.
>Drive malfunctioning Transmission limp-home program
active with reduced acceleration. You
can continue your journey, but moder-
ate your speed and exercise due cau-
tion. Have the system checked immedi-
ately.
12Cause What to do

Reference
At a glance
Controls
Driving tips
Mobility
145
Flashing:
Dynamic Stability Control DSC is regu-
lating the drive and braking forces, refer
also to page68
Dynamic Stability Control DSC is deac-
tivated, refer also to page68Driving stability limited during accelera-
tion and cornering.
Driving style must be readjusted.
Suspension control system failed, refer
also to page68Driving stability limited during accelera-
tion and cornering.
You can continue your journey, but
moderate your speed and exercise due
caution. Have the system checked as
soon as possible.
Indication in US models
The driving stability control systems,
including ABS and the Tire Pressure
Monitor, have failed, refer also to
page67You can continue your journey.
Reduced braking and driving stability.
Drive at moderate speeds, avoiding
abrupt braking maneuvers. Have the
system checked as soon as possible.
Indication
* in Canadian models
The driving stability control systems,
including ABS and the Flat Tire Monitor
or Tire Pressure Monitor
*, have failed,
refer also to page67You can continue your journey.
Reduced braking and driving stability.
Drive at moderate speeds, avoiding
abrupt braking maneuvers. Have the
system checked as soon as possible.
Indication
* in Canadian models
The driving stability control systems,
including ABS and the Flat Tire Monitor
or Tire Pressure Monitor
*, have failed,
refer also to page67You can continue your journey.
Reduced braking and driving stability.
Drive at moderate speeds, avoiding
abrupt braking maneuvers. Have the
system checked as soon as possible.
Vehicles with Flat Tire Monitor
*
Light up in yellow and red:
>Tire is deflated Carefully bring the car to a stop. Comply
with the additional information starting
on page69.
>Flat Tire Monitor not initialized Initialize Flat Tire Monitor, refer to
page69.
Light up in yellow:
Flat Tire Monitor failed. Punctures are
not indicatedHave the system checked.
12Cause What to do

Indicator and warning lamps
146Vehicles with Tire Pressure Monitor
*
Light up in yellow and red:
There is a flat tire or substantial loss of
tire pressureCarefully bring the car to a stop. Comply
with the additional information starting
on page70.
Light up in yellow:
Tire Pressure Monitor not initialized Check the inflation pressure and reset
the system, refer to page70.
The small lamp flashes in yellow and
then lights up continuously; the larger
lamp comes on in yellow:
Tire Pressure Monitor has failed. Punc-
tures are not indicatedHave the system checked. Comply with
the additional information starting on
page71.
Lights up in red:
>Transmission limp-home program
active with restricted range of
gears, possibly with reduced accel-
eration.You can continue your journey, but
moderate your speed and exercise due
caution. It may not be possible to con-
tinue the trip after stopping. Have the
system checked without delay.
Gears can be engaged without
depressing the brakeAlways depress the brake to engage a
gear.
Lights up in yellow:
>Transmission limp-home program
active with reduced range of gearsYou can continue your journey, but
moderate your speed and exercise due
caution. Have the system checked
without delay.
>Transmission position P malfunc-
tioning:
Selector lever locked in position P
with engine running or ignition
switched on and brake depressedRelease transmission lock, refer to
page51. Have the system checked as
soon as possible.
>Brake signal malfunctioning: gear
can be engaged without depress-
ing the brakeTo engage a gear while the vehicle is at
a standstill, always step on the brake.
Before leaving the vehicle, switch off
the engine. Have the system checked
as soon as possible.
12Cause What to do

Reference
At a glance
Controls
Driving tips
Mobility
147
Lights up in red:
Transmission overheating Stop the car and switch off the engine.
Allow the transmission to cool down.
You can continue your journey, but
moderate your speed and exercise due
caution. Have the system checked if the
situation reoccurs.
Lights up in yellow:
Transmission too hot Avoid high engine loads. You can con-
tinue your journey, but moderate your
speed and exercise due caution.
P is not engaged. Vehicle not pre-
vented from rolling
Selector lever malfunctioning You can continue your journey. Shift
into the desired position again, if neces-
sary. Have the system checked if the
situation reoccurs.
Brake signal malfunctioning: gear can
be engaged without depressing the
brakeTo engage a gear while the vehicle is at
a standstill, always step on the brake.
Before leaving the vehicle, switch off
the engine. Have the system checked
as soon as possible.
Pinch protection system of the power
windows malfunctioningHave the system checked.
Pinch protection system of the electric
glass roof malfunctioningHave the system checked.
Cruise control system failed You can continue your journey. Have
the system checked.
Park Distance Control failed Have the system checked.
Bulb of exterior lighting system failed Have the exterior lighting checked as
soon as possible.
Low-beam headlamp failed Have the low beams checked as soon
as possible.
High-beam headlamp failed Have the high-beam headlamps
checked.
Adaptive Head Light failed
12Cause What to do

Indicator and warning lamps
148Coolant level too low Add coolant immediately, refer to
page119.
Engine oil pressure too low Stop immediately and switch off the
engine. You cannot continue your jour-
ney. Contact your BMW center.
Engine oil level too low Add engine oil immediately; refer to
page117 for more information.
Lights up in red:
Service appointment overdue Arrange a service appointment.
Check service requirements, refer to
page63.
Lights up in yellow:
Service due Arrange a service appointment.
Check service requirements, refer to
page63.
No service due Check service requirements, refer to
page63.
Time and date no longer correct Set the time and date, refer to page64.
12Cause What to do
