2008 AUDI A4 Infotainment MMI Operating Manual

Speech dialogue system175
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
Playing an audio CD
Applies to vehicles: with multi-function steering wheel and speech dialogue system
Activating CD mode
Important: The MMI system must be switched on

page 40.
– Switch on the speech dialogue system
page 170.
– Say the command CD. CD mode will be activated. The
speech dialogue system will remain activated for approx-
imately five seconds so that you can say another
command.
Applies to vehicles: with multi-function steering wheel and speech dialogue system
Selecting an audio CD
Important: CD mode must be activated
page 175.
– Briefly press the talk button . The tone will
sound.
– To select a CD, say the command CD NUMBER (ONE TO
SIX).
– To select the next/previous CD, say the command NEXT
CD / PREVIOUS CD.
– To play a CD via a recorded name tag
page 172, say the
command CD (NAME TAG), e.g. CD “BEST OF BEATLES”.
– To select a CD that is currently being played
page 173,
briefly press the talk button and give the command
PLAY.
Applies to vehicles: with multi-function steering wheel and speech dialogue system
Selecting a track
Important: CD mode must be activated
page 175.
– Briefly press the talk button . The tone will
sound.
– To select a track, say the command TRACK NUMBER (1 TO
99).
– To select the next/previous track, say the command NEXT
TRACK / PREVIOUS TRACK.
Applies to vehicles: with multi-function steering wheel and speech dialogue system
Other commands in CD mode
Important: CD mode must be activated
page 175.
– To delete a name tag that is currently being read out,
briefly press the talk button and say the command
DELETE.
– To change a name tag that is currently being read out,
briefly press the talk button and say the command
RENAME.
Using the directory
Applies to vehicles: with multi-function steering wheel and speech dialogue system
Opening the directory
Important: The MMI system must be switched on

page 40.
– Switch on the speech dialogue system
page 170.















Speech dialogue system 176
– Say the command DIRECTORY. The directory will open.
The speech dialogue system will remain activated for
approximately five seconds so that you can say another
command.
Applies to vehicles: with multi-function steering wheel and speech dialogue system
Using a directory entry
Important: The directory must first be opened
page 175.
– Briefly press the talk button . The tone will
sound.
– To call a phone number stored in the directory via a
recorded name tag
page 172, say the command CALL
(NAME TAG), e.g. CALL “PETER MILLER”.
– You can call a phone number stored in a directory entry
that is currently being read out
page 173 by briefly
pressing the talk button and giving the command
CALL.
– To set a navigation destination stored to a directory entry
via a recorded name tag
page 172, say the command
NAVIGATE TO (NAME TAG), e.g. NAVIGATE TO “PETER
MILLER”. The navigation destination will be loaded into
the navigation system and displayed on the MMI system.
– To navigate to a directory entry that is currently being
read out
page 173, briefly press the talk button and
say the command NAVIGATE TO.
If a directory entry contains more than one phone number, you can
specify the desired number by saying “business land line”, “busi-
ness mobile”, “private land line” or “private mobile”, e.g. CALL
PETER MILLER PRIVATE MOBILE.If a directory entry contains two navigation destinations, you can
specify the desired destination by adding “business” or “private”,
e.g. NAVIGATE TO PETER MILLER PRIVATE.
Applies to vehicles: with multi-function steering wheel and speech dialogue system
Other commands for the directory
Important: The directory must first be opened
page 175.
– To change a name tag that is currently being read out,
briefly press the talk button and say the command
RENAME.
– To delete a name tag that is currently being read out,
briefly press the talk button and say the command
DELETE.
The address card and all its information will remain unchanged in
the MMI.
Using the telephone
Applies to vehicles: with multi-function steering wheel, speech dialogue system and
Bluetooth car telephone kit or phone pre-installation
Activating the telephone
Important: The MMI system must be switched on

page 40.
– Switch on the speech dialogue system
page 170.
– Say the command TELEPHONE. The telephone will be
activated. The speech dialogue system will remain acti-
vated for approximately five seconds so that you can say
another command.










!




Speech dialogue system177
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
Applies to vehicles: with multi-function steering wheel, speech dialogue system and
Bluetooth car telephone kit or phone pre-installation
Dialling a telephone number
Important: The telephone mode must be activated

page 176.
– Briefly press the talk button . The tone will
sound.
– Say the command DIAL NUMBER.
– Say the desired digits individually or in groups. The
system will repeat the spoken digits to confirm them,
and they will then appear on the MMI display.
– To delete the last digit or group of digits, say the
command DELETE.
– To dial the number, give the command DIAL.
Applies to vehicles: with multi-function steering wheel, speech dialogue system and
Bluetooth car telephone kit or phone pre-installation
Redialling
Important: The telephone mode must be activated

page 176.
– Briefly press the talk button . The tone will
sound.
– Say the command REDIAL.
Applies to vehicles: with multi-function steering wheel, speech dialogue system and
Bluetooth car telephone kit or phone pre-installation
Calling a name tag
Important: The telephone must be activated
page 176, or
the directory must be open
page 175.
– Briefly press the talk button . The tone will
sound.
– To call a phone number stored for a recorded name tag

page 172, say the command CALL (NAME TAG), e.g.
CALL “PETER MILLER”.
– After the speech dialogue system has given you the cue
, say the command YES. The tele-
phone number will be dialled.
If a directory entry contains more than one phone number, you can
specify the desired number by saying “business land line”, “busi-
ness mobile”, “private land line” or “private mobile”, e.g. CALL
PETER MILLER PRIVATE MOBILE.
Applies to vehicles: with multi-function steering wheel, speech dialogue system and
Bluetooth car telephone kit or phone pre-installation
Other commands for using the telephone
Important: The telephone must be activated
page 176, or
the directory must be open
page 175.
Call (name tag) business
– Briefly press the talk button . The tone will
sound.
– To call a business number stored for a recorded name tag

page 172, say the command CALL (NAME TAG) BUSI-
NESS, e.g. CALL “PETER MILLER” BUSINESS.














Speech dialogue system 178
– After the speech dialogue system has given you the cue
, say the command YES. The tele-
phone number will be dialled.
Call (name tag) private
– Briefly press the talk button . The tone will
sound.
– To call a private number stored for a recorded name tag

page 172, say the command CALL (NAME TAG)
PRIVATE, e.g. CALL “PETER MILLER” PRIVATE.
– After the speech dialogue system has given you the cue
, say the command YES. The tele-
phone number will be dialled.
Entering PIN code
– Briefly press the talk button . The tone will
sound.
– Give the command ENTER PIN NUMBER or ENTER PIN
CODE.
– Say your PIN code.
Navigation
Applies to vehicles: with multi-function steering wheel, speech dialogue system and
navigation system
Activating navigation mode
Important: The MMI system must be switched on

page 40.
– Switch on the speech dialogue system
page 170.– Say the command NAVIGATION. The navigation mode
will be activated. The speech dialogue system will remain
activated for approximately five seconds so that you can
say another command.
Applies to vehicles: with multi-function steering wheel, speech dialogue system and
navigation system
Entering a destination
Important: The navigation mode must be activated

page 178.
– Briefly press the talk button . The tone will
sound.
– To enter a destination country, give the command
SPECIFY COUNTRY and say the name of the country you
wish to enter.
– To enter a destination town, give the command SPECIFY
TOWN and spell out the letters of the town you wish to
enter.
– You can also enter the post code for a destination by
giving the command SPECIFY POST CODE
27).
– To enter a destination street, give the command SPECIFY
STREET NAME and spell out the letters of the street you
wish to enter.
– To navigate to the destination you have entered, give the
command START ROUTE GUIDANCE.
Searching for towns can take several seconds. A list of town names
will appear in the MMI display when the search is finished. Select
the desired town by specifying the number of the town in the list,


27)Function is not available for all countries.











Speech dialogue system179
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control e.g. NUMBER FOUR. Give the commands NEXT PAGE and PREVIOUS
PA G E to scroll up and down the list of town names.
It is possible that a one or more towns share a name (e.g.
Newcastle). Therefore, you must specify more exactly which desti-
nation you want by selecting the number of the town in the list once
again.
Always spell out the town and street names clearly, without pausing
and without using special characters (e.g. a dash). When entering a
street name, you will also be asked whether you want to specify an
intersection or house number.
If you want to be directed to the town centre, you can say TOWN
CENTRE instead of specifying a street.
Note
For more information on the navigation functions, please refer to

page 104.
Applies to vehicles: with multi-function steering wheel, speech dialogue system and
navigation system
Other commands in the navigation mode
Important: The navigation mode must be activated

page 178 or
page 105.
– Briefly press the talk button . The tone will
sound.
– To stop the route guidance, say the command STOP
ROUTE GUIDANCE.
– You can load a special destination such as a petrol
station
page 116 by giving the command SPECIAL
DESTINATION.– To load a last destination as the navigation destination

page 114 say the command LAST DESTINATIONS.
– To load a top destination as the navigation destination

page 116 say the command TOP DESTINATIONS.
– You can have the system repeat the last voice guidance
cue
page 119 by giving the command LAST INSTRUC-
TION.
– Switch the dynamic navigation function on and off

page 117 by saying the command DYNAMIC NAVIGA-
TION ON/OFF.
– If you would like to switch the display of the map on the
MMI display on or off, say the command MAP ON/OFF.
– To switch the intersection zoom on and off, give the
command INTERSECTION ZOOM ON/OFF.
– You can change the map type
page 119 by giving the
command OVERVIEW MAP, DESTINATION MAP or
CURRENT POSITION MAP.
– To display the current location of your vehicle at a scale
of 1 km, say the command DETAIL MAP. This function can
only be used in conjunction with the speech dialogue
system.
– You can change the scale of the map by saying SCALE
and the desired scale. You can choose any of the
following scales: 100 m, 200 m, 500 m, 1 km, 2 km, 5 km,
10 km, 20 km, 50 km, 100 km, 200 km and 500 km.
– To change the map display, say the command ZOOM
IN/OUT.
– To repeat the last recorded traffic report, say the
command REPEAT TRAFFIC REPORT.











Speech dialogue system 180
– You can set a navigation destination that has been stored
in a directory entry via a name tag
page 172 by saying
NAVIGATE TO (NAME TAG), e.g. NAVIGATE TO “PETER
MILLER”. The navigation destination will be loaded into
the navigation system.
If a directory entry contains two navigation destinations, you can
specify the desired destination by adding “business” or “private”,
e.g. NAVIGATE TO PETER MILLER PRIVATE.
Note
To switch back to the previous map display, say the corresponding
command (e.g. CURRENT POSITION MAP). The system remembers
the previous map scale and resets it automatically.










Speech dialogue system181
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control










182
