2007 VOLVO C70 CONVERTIBLE Owner´s Manual

2007 Volvo C70
risk of condensation forming on the insides of the windows, especially i\
n winter.
Timer
The timer function minimizes the risk of fogging, or stale air when the \
recirculation function is selected.
See
page 73 for information on setting the recirculation timer.
NOTE
Recirculation is always disengaged if the defroster button is engaged to\
clear ice or condensation from
the side windows.
4. Defroster
Directs airflow to the windshield and side windows and increases blower \
speed.
When the defroster is activated:
l Air flows to the windows at high blower speed.
l The LED in the defroster button lights up when this function is activate\
d. The air conditioning system
is controlled to provide maximum air dehumidification.
l The air conditioning is automatically switched on (can be switched off \
by pressing button 5).
The air is not recirculated.
5. Airflow controls
Press one of the three buttons in the illustration to activate the selec\
ted airflow. A symbol
in the display above the climate control panel and a lit LED in the sele\
cted button indicate that the manual
function has been selected. With manually selected airflow both warm and\
cool air can be selected. See
also the table on
page 85.
6. Air conditioning On/Off
file:///K|/delme/2007_C70/07c70_03.htm (6 of 10)12/22/2006 9:15:43 PM

2007 Volvo C70
ON: The air conditioning system is engaged when the ON light is lit and is\
controlled
automatically by the system to maintain the selected temperature.
OFF: The system is disengaged when the OFF lights up
When OFF is selected and the OFF LED is lit, the air conditioning system\
is deactivated.
84 03 Climate
Electronic Climate Control (ECC)
Other functions are still controlled automatically.
When Defroster (4) is selected, the air conditioning system is activat\
ed for maximum dehumidifying.
7 and 8. Heated front seats (option)
Maximum heating: Press the button once - both LEDs light up.
Reduced heating: Press the button a second time - one LED lights up.
Seat heating off: Press the button a third time - no LEDs are lit.
9. Rear window and door mirror defrosters
Press to defrost the rear window and door mirrors.
The rear window and door mirrors are defrosted simultaneously if the swi\
tch is pressed once. The
function is active if one LED is lit in the switch. The door mirrors are\
deactivated automatically after
file:///K|/delme/2007_C70/07c70_03.htm (7 of 10)12/22/2006 9:15:43 PM

2007 Volvo C70
approximately 6 minutes. The rear windscreen is deactivated after approx\
imately 12 minutes.
NOTE
This function is automatically switched off when the power retractable h\
ard top is
down.
10. Temperature selector
The temperatures on the driver's and passenger's sides can be set separa\
tely using the knob
(with the thermometer in it). The temperature can be set for both side\
s of the car when the ignition is
switched on (both LEDs will be on), which means that a temperature set\
ting will apply to both sides of the
car.
To set the temperature on one side of the car:
l Press the knob once. The LED for one side of the car will light up. Turn\
the knob to adjust the
temperature.
l Press the knob a second time to set the temperature on the opposite side\
of the car.
l Press the knob a third time to set the temperature on both sides of the \
car at the same time.
NOTE
Selecting a temperature that is higher or lower than necessary will not \
heat or cool the passenger
compartment faster.
85 03 Climate
Air distribution
file:///K|/delme/2007_C70/07c70_03.htm (8 of 10)12/22/2006 9:15:43 PM

2007 Volvo C70



file:///K|/delme/2007_C70/07c70_03.htm (9 of 10)12/22/2006 9:15:43 PM

2007 Volvo C70

Contents | Top of Page
file:///K|/delme/2007_C70/07c70_03.htm (10 of 10)12/22/2006 9:15:43 PM\

2007 Volvo C70
2 0 0 7
VOLVO C70
86 04 Interior
Front seats
88
Power retractable hard top
92
Interior lighting
98
Storage compartments
100
87 04 Interior
88 04 Interior
Front seats
Manual seat adjustment
file:///K|/delme/2007_C70/07c70_04.htm (1 of 27)12/22/2006 9:15:45 PM

2007 Volvo C70
The driver's and passenger's seats can be adjusted in a number of ways t\
o provide a comfortable driving
and sitting position.
1. Forward-rearward: Pull the lever up and slide the seat to the positio\
n of your choice.
2. Use this control to raise or lower the front edge of the seat cushion\
.
3. Use this control to raise or lower the rear edge of the seat cushion.\
4. Turn this knob (option on some passenger's seats) to adjust the fir\
mness of the lumbar support
1.
5. Turn this knob to adjust the backrest tilt.
6. Control panel for power seats.
WARNING
l Do not adjust the seat while driving.
l The seat should be adjusted so that the brake pedal can be depressed
fully.
l Position the seat as far rearward as comfort and control allow.
1Also applies to the optional power seat.
89 04 Interior
Front seats
file:///K|/delme/2007_C70/07c70_04.htm (2 of 27)12/22/2006 9:15:45 PM

2007 Volvo C70
Accessing the rear seat-Easy Entry
Move the seat belt from the guide before entering the rear seat. See page 15.
Manual seat
Moving the seat forward:
1. Pull up control 1 (see the illustration above) to release the backr\
est.
2. Tilt the backrest forward and slide the seat forward.
Moving the seat rearward:
1. With the backrest tilted forward, move the seat rearward to the desir\
ed position.
2. Pull up control 1 and return the backrest to the upright position.
Power seats
Easy entry is only intended to be used when the front seat in unoccupied\
.
Moving the seat forward:
1. Pull up control 1 (see the illustration above) to release the backr\
est.
2. Tilt the backrest forward.
3. Press and hold down button 2 (see the illustration above) to move t\
he seat forward.
file:///K|/delme/2007_C70/07c70_04.htm (3 of 27)12/22/2006 9:15:45 PM
