2007 Volvo C70
time of publication. Please note that some vehicles may be equipped diff\
erently, depending on special legal requirements. Optional
equipment described in this manual may not be available in all markets. \
l Volvo reserves the right to make model changes at any time, or to change\
specifications or design without notice and without incurring
obligation.
WARNING
If your vehicle is involved in an accident, unseen damage may affect its\
drivability and
safety.
WARNING
CALIFORNIA proposition 65
Engine exhaust, some of its constituents, and certain vehicle components\
contain or emit chemicals known to the state of California to
cause cancer, and birth defects or other reproductive harm. In addition,\
certain fluids contained in vehicles and certain products of
component wear contain or emit chemicals known to the State of Californi\
a to cause cancer, and birth defects or other reproductive
harm.
7 Introduction
Volvo and the environment
Volvo is committed to the well being of its customers. As a natural part\
of this commitment, we care about the environment in which we
all live. Caring for the environment means an everyday involvement in re\
ducing our environmental impact. Volvo's environmental
activities are based on a holistic view, which means we consider the ove\
rall environmental impact of a product throughout its complete
life cycle. In this context, design, production, product use, and recycl\
ing are all important considerations. In production, Volvo has partly
or completely phased out several chemicals including CFCs, lead chromate\
s, asbestos, and cadmium; and reduced the number of
chemicals used in our plants 50% since 1991.
Volvo was the first in the world to introduce into production a three-wa\
y catalytic converter with a Lambda sond, now called the heated
oxygen sensor, in 1976. The current version of this highly efficient sys\
tem reduces emissions of harmful substances (CO, HC, NOx) from
the exhaust pipe by approximately 95-99% and the search to eliminate the\
remaining emissions continues. Volvo is the only automobile
manufacturer to offer CFC-free retrofit kits for the air conditioning sy\
stem of all models as far back as the 1975 model 240. Advanced
electronic engine controls and cleaner fuels are bringing us closer to o\
ur goal. After Volvo vehicles and parts have fulfilled their use,
recycling is the next critical step in completing the life cycle. The me\
tal content is about 75% of the total weight of a vehicle, which makes
the vehicle among the most recycled industrial products. In order to hav\
e efficient and well controlled recycling, all Volvo variants have
printed dismantling manuals, indicating the weight and material of indiv\
idual components. For Volvo, all homogeneous plastic parts
weighing more than 3.4 oz. (100 grams) are marked with international s\
ymbols that indicate how the component is to be sorted for
recycling. In addition to continuous environmental refinement of convent\
ional gasoline-powered internal combustion engines, Volvo is
actively looking at advanced technology alternative-fuel vehicles.
When you drive a Volvo, you become our partner in the work to lessen the\
car's impact on the environment. To reduce your vehicle's
environmental impact, you can:
l Maintain proper air pressure in your tires. Tests have shown decreased f\
uel economy with improperly inflated tires.
l Follow the recommended maintenance schedule in your Warranty and Service\
Records Information booklet.
l Drive at a constant speed whenever possible.
l See a trained and qualified Volvo service technician as soon as possible\
for inspection if the check engine (malfunction indicator) light
illuminates, or stays on after the vehicle has started.
l Properly dispose of any vehicle-related waste such as used motor oil, us\
ed batteries, brake pads, etc.
l When cleaning your vehicle, please use genuine Volvo car care products. \
All Volvo car care products are formulated to be
environmentally friendly.
For additional information regarding the environmental activities in whi\
ch Volvo Cars of North America, LLC and Volvo Car Corporation
file:///K|/delme/2007_C70/07c70_00.htm (5 of 7)12/22/2006 9:15:34 PM

2007 Volvo C70
Check seat belt mechanism function as follows: attach the seat belt and \
pull rapidly on the strap.
17 01 Safety
Supplemental Restraint System
Supplemental Restraint System (SRS)
As an enhancement to the three-point seat belts, your Volvo is equipped \
with a Supplemental Restraint
System (SRS). Volvo's SRS consists of seat belt tensioners, front airb\
ags, side impact airbags, the
occupant weight sensor, and inflatable curtains. All of these systems ar\
e monitored by the SRS control
module. An SRS warning light in the instrument panel (see the illustrat\
ion above) illuminates when the
ignition key is turned to position I, II, or III, and will normally go o\
ut after approximately 7 seconds if no
faults are detected in the system.
Where applicable, a text message will also be displayed when the SRS war\
ning light illuminates. If this
warning symbol is not functioning properly, the general warning symbol
illuminates and either SRS
AIRBAG SERVICE URGENT or SRS AIRBAG SERVICE REQUIRED will be displayed.
WARNING
l If the SRS warning light stays on after the engine has started or if it \
illuminates while you are driving,
have the vehicle inspected by a trained and qualified Volvo service tech\
nician as soon as possible.
l Never try to repair any component or part of the SRS yourself. Any inter\
ference in the system could
cause malfunction and serious injury. All work on these systems should b\
e performed by a trained and
qualified Volvo service technician.
file:///K|/delme/2007_C70/07c70_01.htm (9 of 41)12/22/2006 9:15:37 PM

2007 Volvo C70
The gauge indicates the temperature of the engine cooling system. If the\
temperature is abnormally high and the
needle enters the red zone, a message is shown in the display. Bear in m\
ind that auxiliary lamps in front of the air
intake reduce the cooling capacity at high outside temperatures and high\
engine loads.
15.Indicator and warning symbols
Function check
The indicator and warning symbols
1 light up when you turn the ignition key to the driving position (posit\
ion II)
before starting. This shows that the symbols are functioning.

When the engine starts, all symbols go out. If the engine is not started\
within 5 seconds, all of the symbols except
CHECK ENGINE and will go out. Certain symbols may not have their functio\
ns illustrated, depending on the car's
equipment.
The PARK BRAKE symbol will not go out until the parking brake has been r\
eleased.
Symbols in the center of the instrument panel
Warning symbol
The red warning symbol lights up to indicate a fault that could affect t\
he car's drivability. A text explaining the nature
of the fault will also be shown in the information display. The symbol a\
nd accompanying text will remain on until the
fault has been corrected. This symbol may also light up in combination w\
ith other indicator or warning symbols.
1On certain engines, the symbol for low oil pressure is not used. Instead\
, a text warning is provided in the information display,
see also
page 192.
file:///K|/delme/2007_C70/07c70_02.htm (6 of 43)12/22/2006 9:15:42 PM

2007 Volvo C70
1. Malfunction indicator light

As you drive, a computer called On-Board Diagnostics II (OBDII) monito\
rs your car's engine, transmission, electrical
and emission systems.
The CHECK ENGINE light will light up if the computer senses a condition that potentially\
may need correcting.
When this happens, please have your car checked by a trained and qualifi\
ed Volvo service technician as soon as
possible.
A CHECK ENGINE light may have many causes. Sometimes, you may not notice a change in y\
our car's behavior.
Even so, an uncorrected condition could hurt fuel economy, emission cont\
rols, and drivability. Extended driving
without correcting the cause could even damage other components in your \
car.
NOTE
Canadian models are equipped with the second
symbol.
2. Anti-lock Brake system (ABS)

If the warning light comes on, there is a malfunction of the ABS system \
(the standard braking system will still
function).
file:///K|/delme/2007_C70/07c70_02.htm (8 of 43)12/22/2006 9:15:42 PM

2007 Volvo C70
4. Oil pressure warning light1

If the light comes on while driving, stop the car, stop the engine immed\
iately, and check the engine oil level. If the oil
level is normal and the light stays on after restart, have the car towed\
to the nearest trained and qualified Volvo
service technician. After hard driving, the light may come on occasional\
ly when the engine is idling. This is normal,
provided it goes off when the engine speed is increased.
5. Seat belt reminder
See page 16 for detailed information.
6. Generator warning light

If the light comes on while the engine is running, have the charging sys\
tem checked by a trained and qualified Volvo
service technician.
7. Brake failure warning light

If this light comes on while driving or braking, stop the car as quickly\
as possible in a safe place, open the hood, and
check
1 On certain engines, this symbol is not used to indicate low oil pressur\
e. Instead, a text warning is provided in the information
display, see also
page 192.
52 02 Instruments and controls
Symbols - instrument panel
the brake fluid level in the reservoir. See page 190 for the location of the reservoir.
file:///K|/delme/2007_C70/07c70_02.htm (11 of 43)12/22/2006 9:15:42 PM\

2007 Volvo C70
NOTE
Canadian models are equipped with the second
symbol.
WARNING
If the fluid level is below the MIN mark in the reservoir or if a "Brake failure - Service urgent" message \
is
displayed in the information display: DO NOT DRIVE. Have the car towed to a trained and qualified Volvo service
technician and have the brake system inspected.
If the fluid level is below the MIN mark in the reservoir or if a "BRAKE FAILURE - SERVICE URGENT" message
is displayed in the information display: DO NOT DRIVE. Have the car towed to a trained and qualified Volvo service
technician and have the brake system inspected.

If the BRAKE and ABS warning lights come on at the same time, this could\
indicate a fault in the brake
system. In this case:
1. Stop the car in a suitable place and switch off the engine.
2. Restart the engine.
3. If both warning lights go off, no further action is required and the \
car can be driven.
4. If both lights remain on after the engine has been restarted, switch \
off the engine again and check the brake fluid
level. See
page 190 for the location of the reservoir.
Door open warning
The driver will be alerted if either door, the hood, or the trunk lid ar\
e open or ajar.
At low speeds

If the car is moving at a speed of less than approximately 4 m.p.h. (7 \
km/h), the Information symbol in the instrument
panel will light up and a message will be shown in the information displ\
ay indicating which door(s), etc is not
completely closed.
file:///K|/delme/2007_C70/07c70_02.htm (12 of 43)12/22/2006 9:15:42 PM\

2007 Volvo C70
NOTE
If a message is displayed when e.g. you are using the trip computer, thi\
s message must be read before you can
access the trip computer
54 02 Instruments and controls
Information display
Message Meaning
STOP SAFELY Stop the car in a safe place and switch off the engine to help prevent t\
he risk of
serious damage.
STOP ENGINE Stop the car in a safe place and switch off the engine to help prevent t\
he risk of
serious damage.
SERVICE URGENT Take your car to a trained and qualified Volvo service technician for in\
spection
immediately.
SEE MANUAL Refer to your owner's manual. For additional information, please contact\
a
trained and qualified Volvo service technician.
SERVICE REQUIRED Take your car to a trained and qualified Volvo service technician for in\
spection
as soon as possible (but preferably before the next scheduled maintenan\
ce
service).
TIME FOR REGULAR
SERVICE This message is affected by the number of miles/km driven, by the number\
of
months, or by the number of engine hours since the service reminder was \
reset
at the most recent regularly scheduled service.
REMINDER CHECK OIL
LEVEL Check the oil level when this message is displayed. See
page 191.
DSTC SPIN CONTROL OFF The stability system's spin control function has been turned off. See
page 138
for details.
55 02 Instruments and controls
Lighting panel
file:///K|/delme/2007_C70/07c70_02.htm (14 of 43)12/22/2006 9:15:42 PM\

2007 Volvo C70
122 06 Starting and driving
General information
Economical driving conserves natural resources
Better driving economy may be obtained by thinking ahead, avoiding rapid\
starts and stops and adjusting
the speed of your vehicle to immediate traffic conditions.
Observe the following rules:
l Bring the engine to normal operating temperature as soon as possible by \
driving with a light foot on the
accelerator pedal for the first few minutes of operation. A cold engine \
uses more fuel and is subject to
increased wear.
l Whenever possible, avoid using the vehicle for driving short distances. \
This does not allow the engine
to reach normal operating temperature.
l Drive carefully and avoid rapid acceleration and hard braking.
l Use the transmission's Drive (D) position as often as possible and avo\
id using kickdown.
l Do not exceed posted speed limits.
l Avoid carrying unnecessary items (extra load) in the vehicle.
l Maintain correct tire pressure. Check tire pressure regularly (when tir\
es are cold).
l Remove snow tires when threat of snow or ice has ended.
l At highway driving speeds, fuel consumption will be lower with the air c\
onditioning on and the
windows closed than with the air conditioning off and the windows open. \
l Using the onboard trip computer's fuel consumption modes can help you le\
arn how to drive more
economically.
Other factors that decrease gas mileage are:
l Dirty air cleaner
l Dirty engine oil and clogged oil filter
l Dragging brakes
l Incorrect front end alignment
Some of the above mentioned items and others are checked at the standard\
maintenance intervals.
Avoid overheating the engine
Do not drive at engine speeds above 4,500 rpm if you tow a trailer in hi\
lly areas. This could cause the
engine oil to overheat.
file:///K|/delme/2007_C70/07c70_06.htm (2 of 18)12/22/2006 9:15:48 PM
