2007 SATURN ION Owners Manual

Driver Seat Height Adjuster
If your vehicle has a driver’s seat height adjuster
it, is located on the outboard side of the seat.
To raise the seat, move the lever upward
repeatedly until the seat is at the desired height.
To lower the seat, move the lever downward
repeatedly until the seat is at the desired height.
Manual Lumbar
If your vehicle has this
feature, the knob is
located on the front
of the driver seat
lower cushion on the
inboard side.
Turn the knob clockwise or counterclockwise to
increase or decrease the lumbar support.
9
ProCarManuals.com

Reclining Seatbacks
{CAUTION:
You can lose control of the vehicle if you
try to adjust a manual driver’s seat while
the vehicle is moving. The sudden
movement could startle and confuse you,
or make you push a pedal when you do
not want to. Adjust the driver’s seat only
when the vehicle is not moving.
{CAUTION:
If the seatback is not locked, it could
move forward in a sudden stop or crash.
That could cause injury to the person
sitting there. Always push and pull on the
seatback to be sure it is locked.
Your seats have manual reclining seatbacks. The
lever used to operate them is located on the
outboard side of the seats.
10
ProCarManuals.com

To recline the seatback, do the following:
1. Lift the recline lever.
2. Move the seatback to the desired position,
then release the lever to lock the seatback
in place.
3. Push and pull on the seatback to make sure it
is locked.To return the seatback to an upright position, do
the following:
1. Lift the lever fully without applying pressure to
the seatback and the seatback will return to
the upright position.
2. Push and pull on the seatback to make sure it
is locked.
11
ProCarManuals.com

{CAUTION:
Sitting in a reclined position when your
vehicle is in motion can be dangerous.
Even if you buckle up, your safety belts
cannot do their job when you are reclined
like this.
The shoulder belt cannot do its job
because it will not be against your body.
Instead, it will be in front of you. In a crash,
you could go into it, receiving neck or other
injuries.
CAUTION: (Continued)
12
ProCarManuals.com

CAUTION: (Continued)
The lap belt cannot do its job either. In a
crash, the belt could go up over your
abdomen. The belt forces would be there,
not at your pelvic bones. This could cause
serious internal injuries.
For proper protection when the vehicle is
in motion, have the seatback upright. Then
sit well back in the seat and wear your
safety belt properly.
Do not have a seatback reclined if your vehicle is
moving.
Head Restraints
Adjust the head restraint so that the top of the
restraint is at the same height as the top of
the occupant’s head. This position reduces the
chance of a neck injury in a crash.
13
ProCarManuals.com

Pull the head restraint
up to raise it. To lower
the head restraint,
press the button,
located on the top of the
seatback, and push
the restraint down.
Passenger Folding Seatback
Your vehicle may have a passenger seat that
folds at.
{CAUTION:
If you fold the seatback forward to carry
longer objects, such as skis, be sure any
such cargo is not near an airbag. In a
crash, an inating airbag might force that
object toward a person. This could cause
severe injury or even death. Secure
objects away from the area in which an
airbag would inate. For more
information, seeWhere Are the Airbags?
on page 71andLoading Your Vehicle on
page 250.
{CAUTION:
Things you put on this seatback can
strike and injure people in a sudden stop
or turn, or in a crash. Remove or secure
all items before driving.
14
ProCarManuals.com

To fold the seatback at, do the following:
1. Lift the bar under the seat to unlock it.
2. Slide the seat as far back as it will go and
release the bar. Try to move the seat with
your body to make sure it is locked into place.
3. Lift the recliner lever, located on the outboard
side of the seat, and fold the seat forward
until the seatback disengages.4. Release the recliner lever and fold the seat
forward until it locks in the folded position.
Pull up on the seatback to be sure it is locked.
15
ProCarManuals.com

To raise the seatback to an upright position, do
the following:
1. Lift the recliner lever, located on the outboard
side of the seat, and lift the seatback.
2. Push the seatback until it re-engages.
{CAUTION:
If the seatback is not locked, it could
move forward in a sudden stop or crash.
That could cause injury to the person
sitting there. Always push and pull on the
seatback to be sure it is locked.
3. Push and pull on the seatback to make sure it
is locked in place.
Rear Seats
Split Folding Rear Seat
You can fold either side of the rear seatback down
for more cargo space.
To lower the rear seatback, follow these steps:
1. Open the trunk and pull one or both of the small
handles located in the center of the trunk.
16
