2007 PONTIAC TORRENT Owners Manual

When your vehicle has a at tire, use the following
example as a guide to assist you in the placement
of wheel blocks.
The following information will tell you next how to
use the jack and change a tire.Removing the Spare Tire and Tools
If your vehicle has the rear compartment storage
panel/cover, you will have to remove it to access
the load oor. SeeRear Compartment Storage
Panel/Cover on page 140for more information.
To access the spare tire and tools, do the
following:
1. Lift the load oor up and pull it out of the
vehicle and set it aside.
409

2. Remove the nut retaining the spare tire.
3. Remove the compact spare tire. SeeCompact
Spare Tire on page 420for more information.
4. Locate the jack and wheel wrench, which are
located on the driver’s side of the rear cargo
area, behind an access door. Pull out the
access door to reach them.5. Remove the
wing-bolt holding the
jack and then
remove it.
6. Remove the hook and loop fastener straps
holding the bag containing the wheel wrench.
Remove the wheel wrench from the bag.
7. Extend the socket portion of the wrench from
the handle.
410

Removing the Flat Tire and
Installing the Spare Tire
You must take off the wheel cover or center cap, if
the vehicle has one, to reach the wheel bolts.
1. Loosen all ve
plastic caps by
turning the wheel
wrench
counterclockwise.
Do not try to remove
plastic caps from
the cover or
center cap.
2. Pull the cover or center cap away from the
wheel.
3. Use the wheel wrench to loosen all the wheel
nuts. Do not remove them yet.4. Attach the wheel wrench to the jack bolt head
and turn the wheel wrench clockwise. That
will raise the lift head a little.
5. Place the jack near the at tire.
Notice:Make sure that the jack lift head is in
the correct position or you may damage
your vehicle. The repairs would not be covered
by your warranty.
411

6. Find the arrow on the plastic lower body
panel. Position the jack head under the
metal jacking ange and not the plastic lower
body panel.With the jack head positioned correctly on the
metal jacking ange, it should look like this
from underneath.
412

Do not lift the vehicle using the plastic lower
body panel.
7. Put the compact spare tire near you.
{CAUTION:
Getting under a vehicle when it is jacked
up is dangerous. If the vehicle slips off
the jack you could be badly injured or
killed. Never get under a vehicle when it is
supported only by a jack.
{CAUTION:
Raising your vehicle with the jack
improperly positioned can damage the
vehicle and even make the vehicle fall. To
help avoid personal injury and vehicle
damage, be sure to t the jack lift head
into the proper location before raising the
vehicle.
413

{CAUTION:
Lifting a vehicle and getting under it to do
maintenance or repairs is dangerous
without the appropriate safety equipment
and training. The jack provided with your
vehicle is designed only for changing a
at tire. If it is used for anything else, you
or others could be badly injured or killed
if the vehicle slips off the jack. Use the
jack provided with your vehicle only for
changing a at tire.
8. Raise the vehicle by turning the jack handle
clockwise. Raise the vehicle far enough off
the ground so there is enough room for
the road tire to clear the ground.
414

9. Remove all of the
wheel nuts.
10. Remove the at tire.
{CAUTION:
Rust or dirt on the wheel, or on the parts
to which it is fastened, can make the
wheel nuts become loose after time. The
wheel could come off and cause an
accident. When you change a wheel,
CAUTION: (Continued)
CAUTION: (Continued)
remove any rust or dirt from the places
where the wheel attaches to the vehicle. In
an emergency, you can use a cloth or a
paper towel to do this; but be sure to use
a scraper or wire brush later, if needed, to
get all the rust or dirt off.
11. Remove any rust or
dirt from the wheel
bolts, mounting
surfaces, and spare
wheel.
415

12. Place the compact spare tire on the
wheel-mounting surface.
{CAUTION:
Never use oil or grease on studs or nuts.
If you do, the nuts might come loose.
Your wheel could fall off, causing a
serious accident.
13. Reinstall the wheel nuts. Tighten each nut by
hand until the wheel is held against the hub.
14. Lower the vehicle by turning the jack handle
counterclockwise.
416
