Changes or modications to this system by other
than an authorized service facility could void
authorization to use this equipment.
At times you may notice a decrease in range. This
is normal for any remote keyless entry system.
If the transmitter does not work or if you have to
stand closer to your vehicle for the transmitter
to work, try this:
Check the distance. You may be too far from
your vehicle. You may need to stand closer
during rainy or snowy weather.
Check the location. Other vehicles or objects
may be blocking the signal. Take a few steps
to the left or right, hold the transmitter
higher, and try again.
Check to determine if battery replacement or
resynchronization is necessary. See “Battery
Replacement” and “Resynchronization”
underRemote Keyless Entry (RKE) System
Operation on page 97.
If you are still having trouble, see your dealer
or a qualied technician for service.
Remote Keyless Entry (RKE)
System Operation
The vehicle’s doors can be locked and unlocked
from about 3 feet (1 m) up to 65 feet (20 m)
away with the Remote Keyless Entry (RKE)
transmitter.
If your vehicle has the remote start feature you
can also start your vehicle with the RKE
transmitter. Your RKE transmitter, with the remote
start button, provides an increased range of
195 feet (60 m) away. However, the range may be
less while the vehicle is running. As a result,
you may need to be closer to your vehicle to turn
it off than you were to turn it on.
There are other conditions which can affect the
performance of the transmitter. SeeRemote
Keyless Entry (RKE) System on page 96.
97

L(Vehicle Locator/Panic Alarm):Press and
release this button to locate your vehicle. The turn
signal lamps will ash and the horn will sound
three times. Press and hold this button for more
than two seconds to activate the panic alarm. The
turn signal lamps will ash and the horn will
sound repeatedly for 30 seconds. The alarm will
turn off when the ignition is moved to RUN or
the alarm button is pressed again. The ignition
must be in LOCK for the panic alarm to work.
The RKE transmitter is used to arm/disarm
the content theft-deterrent system. Your vehicle’s
theft-deterrent system can be programmed to
three different modes. SeeContent Theft-Deterrent
on page 111
If you accidentally set off the alarm when entering
or exiting the vehicle, you can shut it off by
pressing the lock or unlock button once or the
panic alarm button twice.Matching Transmitter(s) to Your
Vehicle
Each RKE transmitter is coded to prevent another
transmitter from unlocking your vehicle. If a
transmitter is lost or stolen, a replacement can be
purchased through your dealer. Remember to bring
any additional transmitters so they can also be
re-coded to match the new transmitter. Once your
dealer has coded the new transmitter, the lost
transmitter will not unlock your vehicle. The vehicle
can have a maximum of four transmitters matched
to it. Or, see “Relearn Remote Key” underDIC
Operation and Displays on page 195for
instructions on how to match RKE transmitters to
your vehicle.
99

Remote Vehicle Start
Your vehicle may have the remote start feature.
This feature allows you to start the engine
from outside the vehicle. See “REMOTE START”
underDIC Vehicle Personalization on page 210
for instructions on how to enable and disable this
feature.
During a remote start, the climate control system
will turn on at the fan, temperature, and mode
settings the vehicle was set to when the vehicle
was last turned off and will also turn on the
rear window defogger.
Laws in some local communities may restrict the
use of remote starters. For example, some
laws may require a person using remote start to
have the vehicle in view when doing so. Check
local regulations for any requirements on remote
starting of vehicles.
/(Remote Vehicle Start):Press and release
the lock button and then press and hold the remote
vehicle start button to start the vehicle.
Your RKE transmitter, with the remote start button,
provides an increased range of operation.
However, the range may be less while the vehicle
is running. As a result, you may need to be
closer to your vehicle to turn it off, than you were
to turn it on.
If your vehicle is low on fuel, do not use the remote
start feature. The vehicle may run out of fuel.
To start the engine using the remote start feature,
do the following:
1. Aim the RKE transmitter, that has a remote
vehicle start button, at the vehicle.
2. Press and release the transmitter’s lock
button, then immediately press and hold
the remote vehicle start button until the
vehicle’s turn signal lamps ash, or for at
least four seconds, if the vehicle’s lights are
not visible. The vehicle’s doors will be locked.
Pressing the remote start button again after the
vehicle has started will turn off the ignition.
101

Visor Vanity Mirrors
Your vehicle has covered visor vanity mirrors on
both the driver’s and passenger’s side.
Theft-Deterrent Systems
Vehicle theft is big business, especially in some
cities. Although your vehicle has a number of
theft-deterrent features, we know that nothing we
put on it can make it impossible to steal.
Content Theft-Deterrent
To activate the theft-deterrent system:
1. Open the door.
2. Lock the door with the power door lock
switch or the remote keyless entry transmitter.
If you are using the remote keyless entry
transmitter, the door does not need to
be open.
3. Close all doors.Once armed, the alarm will go off if someone tries
to enter the vehicle without using the remote
keyless entry transmitter or a key or turns
the ignition on with an incorrect key. The horn will
sound and the turn signal lamps will ash for
approximately two minutes.
When the alarm is armed, the trunk may be
opened with the remote keyless entry transmitter.
The power door lock switches are disabled
and the doors remain locked. You must use your
remote keyless entry transmitter or your key to
unlock the doors when the system is armed.Arming with the Power Lock Switch
The alarm system will arm when you use either
power lock switch to lock the doors while any door
or the trunk is open and the key is removed
from the ignition.
Arming with the Remote Keyless Entry
Transmitter
The alarm system will arm when you use your
remote keyless entry transmitter to lock the doors,
if the key is not in the ignition.
111

Instrument Panel Overview........................ 148
Hazard Warning Flashers.......................... 150
Other Warning Devices............................. 150
Horn.......................................................... 150
Tilt Wheel.................................................. 151
Turn Signal/Multifunction Lever.................. 151
Turn and Lane-Change Signals................. 152
Headlamp High/Low-Beam Changer.......... 152
Flash-to-Pass............................................ 153
Windshield Wipers..................................... 153
Windshield Washer.................................... 154
Rear Window Wiper/Washer...................... 155
Cruise Control........................................... 155
Headlamps................................................ 159
Headlamps on Reminder........................... 159
Daytime Running Lamps (DRL)................. 160
Automatic Headlamp System..................... 160
Fog Lamps................................................ 161
Instrument Panel Brightness...................... 161
Dome Lamp.............................................. 162
Entry Lighting............................................ 162
Map Lamps............................................... 162
Cargo Lamp.............................................. 162
Electric Power Management...................... 163Battery Run-Down Protection..................... 164
Accessory Power Outlet(s)........................ 164
Ashtray(s) and Cigarette Lighter................ 165
Climate Controls......................................... 166
Climate Control System............................. 166
Outlet Adjustment...................................... 170
Passenger Compartment Air Filter............. 170
Warning Lights, Gages, and Indicators..... 172
Instrument Panel Cluster........................... 173
Speedometer and Odometer...................... 174
Trip Odometer........................................... 174
Tachometer............................................... 174
Safety Belt Reminder Light........................ 175
Passenger Safety Belt Reminder Light....... 175
Airbag Readiness Light............................. 176
Passenger Airbag Status Indicator............. 177
Battery Warning Light................................ 179
Brake System Warning Light..................... 180
Anti-Lock Brake System Warning Light...... 181
Traction Control System (TCS)
Warning Light........................................ 182
Engine Coolant Temperature
Warning Light........................................ 182
Section 3 Instrument Panel
145

The main components of your instrument panel are the following:
A. Air Outlets. SeeOutlet Adjustment on page 170.
B. Turn Signal/Multifunction Lever. SeeTurn
Signal/Multifunction Lever on page 151.
C. Instrument Panel Cluster. SeeInstrument Panel
Cluster on page 173.
D. Windshield Wiper/Washer Lever. See
Windshield Wipers on page 153.
E. Driver Information Center Controls. SeeDIC
Operation and Displays on page 195.
F. Hazard Warning Flashers. SeeHazard Warning
Flashers on page 150.
G. Passenger Airbag Status Indicator. See
Passenger Airbag Status Indicator on page 177.
H. Rear Window Wiper/Washer Buttons. See
Rear Window Wiper/Washer on page 155. Fog
Lamps Button. SeeFog Lamps on page 161.
I. Power Mirror Control. SeeOutside Power
Mirrors on page 132.
J. Instrument Panel Brightness Control. See
Instrument Panel Brightness on page 161.K. Cruise Controls. SeeCruise Control on
page 155.
L. Tilt Wheel. SeeTilt Wheel on page 151.
M. Horn. SeeHorn on page 150.
N. Audio Steering Wheel Controls. SeeAudio
Steering Wheel Controls on page 285.
O. Audio System. SeeAudio System(s) on
page 218.
P. Shift Lever. SeeShifting Into Park (P) on
page 123.
Q. Traction Control System (TCS) Button. See
Traction Control System (TCS) on page 297.
R. Power Window Switches. SeePower Windows
on page 110.
S. Climate Control System. SeeClimate Control
System on page 166. Heated Seat Buttons
(If Equipped). SeeHeated Seats on page 11.
T. Glove Box. SeeGlove Box on page 137.
149

Hazard Warning Flashers
Your hazard warning ashers let you warn others.
They also let police know you have a problem.
Your front and rear turn signal lamps will ash on
and off.
The hazard warning
asher button is located
in the center of the
instrument panel.
Your hazard warning ashers work no matter what
position your key is in, and even if the key is
not in the ignition switch.
Press the button to make the front and rear turn
signal lamps ash on and off. Press the button
again to turn the ashers off.
When the hazard warning ashers are on, your
turn signals will not work.
Other Warning Devices
If you carry reective triangles, you can set them up
at the side of the road about 300 feet (100 m)
behind your vehicle.
Horn
Press near or on the horn symbols on your
steering wheel pad to sound the horn.
150

Tilt Wheel
Your vehicle has a tilt wheel that allows you to
adjust the steering wheel.
The lever to tilt the steering wheel is located on
the left side of the steering column.
To tilt the wheel, hold the steering wheel and push
the lever down. Then, move the steering wheel
to a comfortable position and pull the lever
up rmly to lock the column in place.
Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes the following:
GTurn and Lane-Change Signals. See
Turn and Lane-Change Signals on page 152.
23Headlamp High/Low-Beam Changer.
SeeHeadlamp High/Low-Beam Changer on
page 152.
Flash-to-Pass. SeeFlash-to-Pass on page 153.
OExterior Lamp Control. SeeHeadlamps on
page 159.
151
