DIAGNOSIS SYSTEM (TCM)
TM-351
< FUNCTION DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
2. Move selector lever to “P” position.
3. Turn ignition switch OFF. Wait at least 5 seconds.
4. Turn ignition switch ON. (Do not start engine.)
Does OD OFF indicator lamp come on about 2 seconds?
YES >> GO TO 2.
NO >> Stop procedure. Perform XX-XX, "*****"
before proceed-
ing.
2.JUDGEMENT PROCEDURE STEP 1
1. Turn ignition switch OFF.
2. Keep pressing shift lock release button.
3. Move selector lever from “P” to “D” position.
4. Turn ignition switch ON. (Do not start engine.)
5. Keep pressing overdrive control switch while OD OFF indicator lamp is lighting up for 2 seconds. (OD
OFF indicator lamp is on.)
6. Keep pressing overdrive control switch and shift selector lever to the “2” position. (OD OFF indicator lamp
is on.)
7. Stop pressing overdrive control switch. (OD OFF indicator lamp is on.)
8. Shift selector lever to the “1” position. (OD OFF indicator lamp is on.)
9. Keep pressing overdrive control switch. (OD OFF indicator lamp is off.)
10. Depress accelerator pedal fully while pressing overdrive control switch.
>> GO TO 3.
3.CHECK SELF-DIAGNOSIS CODE
Check OD OFF indicator lamp. Refer to "Judgement of Self-diagnosis Code".
>>DIAGNOSIS END
Judgement of Self-diagnosis Code
SCIA5472E
SCIA7140E

TM-420
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
A/T SHIFT LOCK SYSTEM
Data are reference values.
Diagnosis ProcedureINFOID:0000000001731062
SYMPTOM 1:
Selector lever cannot be moved from “P” position with ignition switch in ON position and brake
pedal depressed.
Selector lever can be moved from “P” position with ignition key in ON position and brake pedal
released.
Selector lever can be moved from “P” position when ignition switch is removed from key cylinder.
SYMPTOM 2:
Ignition key cannot be removed when selector lever is set to “P” position.
Ignition key can be removed when selector lever is set to any position except “P” position.
1.CHECK KEY INTERLOCK CABLE
Check key interlock cable for damage.
OK or NG
OK >> GO TO 2.
NG >> Repair key interlock cable. Refer to XX-XX, "*****"
.
2.CHECK A/T POSITION
Check A/T position. Refer to XX-XX, "*****"
.
OK or NG
OK >> GO TO 3.
NG >> Adjust control cable. Refer to XX-XX, "*****"
.
3.CHECK SHIFT LOCK SOLENOID AND PARK POSITION SWITCH
1. Turn ignition switch ON. (Do not start engine.)
2. Selector lever is set in “P” position.
3. Check operation sound.
OK or NG
OK >>INSPECTION END
NG >> GO TO 4.
4.CHECK POWER SOURCE
1. Turn ignition switch ON. (Do not start engine.)
TER-
MINAL
NO.WIRE
COLORITEM CONDITIONVOLTAGE
(Approx.)
1 P O/D switchIgnition switch: “ON” Battery voltage
Ignition switch: “OFF” 0V
2 B Ground Always 0V
3 L IlluminationParking lamps: “ON” Battery voltage
Parking lamps: “OFF” 0V
4 B Ground Always 0V
5 LG Shift lock solenoidWhen ignition switch is "ON", brake pedal is depressed and se-
lector lever is set in "P" position.Battery voltage
Except above. 0V
6 B Ground Always 0V
Condition Brake pedal Operation sound
When ignition switch is turned to ON position and selector lever is set in
“P” position.Depressed Yes
Released No

SYSTEM SYMPTOM
TM-429
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
SYMPTOM DIAGNOSIS
SYSTEM SYMPTOM
Symptom ChartINFOID:0000000001714345
Numbers are arranged in order of inspection.
Perform inspections starting with number one and work up.
Items Symptom Condition Diagnostic item Reference page
No Lock-up Engage-
ment/TCC InoperativeTorque converter is
not locked up.ON vehicle1. Accelerator pedal position sensorEC-583
2. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTRXX-XX, "*****"
and XX-XX,
"*****"
3. Engine speed signalXX-XX, "*****"
4. A/T fluid temperature sensorXX-XX, "*****"
5. Line pressure testXX-XX, "*****"
6. Torque converter clutch solenoid valveXX-XX, "*****"
7. Control valve assemblyXX-XX, "*****"
OFF vehicle 8. Torque converterXX-XX, "*****"
Torque converter
clutch piston slip.ON vehicle1. A/T fluid levelXX-XX, "*****"
2. Accelerator pedal position sensorEC-583
3. Line pressure testTM-178
4. Torque converter clutch solenoid valveXX-XX, "*****"
5. Line pressure solenoid valveXX-XX, "*****"
6. Control valve assemblyXX-XX, "*****"
OFF vehicle 7. Torque converterXX-XX, "*****"
Lock-up point is ex-
tremely high or low.ON vehicle1. Accelerator pedal position sensorEC-5832. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTRXX-XX, "*****"
and XX-XX,
"*****"
3. Torque converter clutch solenoid valveXX-XX, "*****"
4. Control valve assemblyXX-XX, "*****"

TM-430
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
Shift ShockSharp shock in shift-
ing from “N” to “D” po-
sition.ON vehicle1. Engine idling speedXX-XX, "*****"

(Type 1), XX-XX,
"*****" (Type 2)
2. Accelerator pedal position sensorEC-297
(Type 1),
EC-583
(Type 2)
3. Line pressure testTM-178
4. A/T fluid temperature sensorTM-48
(Type 1),
XX-XX, "*****"

(Type 2)
5. Engine speed signalTM-56
(Type 1),
XX-XX, "*****"

(Type 2)
6. Line pressure solenoid valveTM-81
(Type 1),
XX-XX, "*****"

(Type 2)
7. Control valve assemblyXX-XX, "*****"
8. Accumulator N-DXX-XX, "*****"
OFF vehicle 9. Forward clutchXX-XX, "*****"
Too sharp a shock in
changing from D
1 to
D
2.ON vehicle1. Accelerator pedal position sensorEC-297
(Type 1),
EC-583
(Type 2)
2. Line pressure testTM-178
3. Accumulator servo releaseXX-XX, "*****"
4. Control valve assemblyXX-XX, "*****"
5. A/T fluid temperature sensorTM-48
(Type 1),
XX-XX, "*****"

(Type 2)
OFF vehicle 6. Brake bandXX-XX, "*****"
Too sharp a shock in
changing from D
2 to
D
3.ON vehicle1. Accelerator pedal position sensorEC-297
(Type 1),
EC-583
(Type 2)
2. Line pressure testTM-178
3. Control valve assemblyXX-XX, "*****"
OFF vehicle4. High clutchXX-XX, "*****"5. Brake bandXX-XX, "*****"
Too sharp a shock in
changing from D
3 to
D
4.ON vehicle1. Accelerator pedal position sensorEC-297
(Type 1),
EC-583
(Type 2)
2. Line pressure testTM-178
3. Control valve assemblyXX-XX, "*****"
OFF vehicle4. Brake bandXX-XX, "*****"5. Overrun clutchXX-XX, "*****"
6. Forward one-way clutchXX-XX, "*****"
Gear change shock
during deceleration by
releasing accelerator
pedal.ON vehicle1. Accelerator pedal position sensorEC-297
(Type 1),
EC-583
(Type 2)
2. Line pressure testTM-178
3. Overrun clutch solenoid valveTM-93
(Type 1),
XX-XX, "*****"

(Type 2)
4. Control valve assemblyXX-XX, "*****"
Large shock in chang-
ing from 1
2 to 11 in “1”
position.ON vehicle 1. Control valve assemblyXX-XX, "*****"OFF vehicle 2. Low & reverse brakeXX-XX, "*****"
Items Symptom Condition Diagnostic item Reference page

SYSTEM SYMPTOM
TM-431
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Improper Shift TimingToo high a gear
change point from D
1
to D
2, from D2 to D3,
from D
3 to D4.ON vehicle1. Accelerator pedal position sensorEC-583
2. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTRXX-XX, "*****"
and XX-XX,
"*****"
3. Shift solenoid valve AXX-XX, "*****"
4. Shift solenoid valve BXX-XX, "*****"
Gear change directly
from D
1 to D3 occurs.ON vehicle1. A/T fluid levelXX-XX, "*****"2. Accumulator servo releaseXX-XX, "*****"
OFF vehicle 3. Brake bandXX-XX, "*****"
Too high a change
point from D
4 to D3,
from D
3 to D 2, from
D
2 to D1.ON vehicle1. Accelerator pedal position sensorEC-583
2. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTRXX-XX, "*****"
and XX-XX,
"*****"
Kickdown does not
operate when de-
pressing accelerator
pedal in D
4 within
kickdown vehicle
speed.ON vehicle1. Accelerator pedal position sensorEC-583
2. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTRXX-XX, "*****"
and XX-XX,
"*****"
3. Shift solenoid valve AXX-XX, "*****"
4. Shift solenoid valve BXX-XX, "*****"
Kickdown operates or
engine overruns when
depressing accelera-
tor pedal in D
4 beyond
kickdown vehicle
speed limit.ON vehicle1. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTRXX-XX, "*****"

and XX-XX,
"*****"
2. Accelerator pedal position sensorEC-583
3. Shift solenoid valve AXX-XX, "*****"
4. Shift solenoid valve BXX-XX, "*****"
Gear change from 22
to 2
3 in “2” position.ON vehicle1. PNP switch adjustmentXX-XX, "*****"2. Control cable adjustmentXX-XX, "*****"
Gear change from 11
to 1
2 in “1” position.ON vehicle1. PNP switch adjustmentXX-XX, "*****"2. Control cable adjustmentXX-XX, "*****"
Items Symptom Condition Diagnostic item Reference page

SYSTEM SYMPTOM
TM-437
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Slips/Will Not EngageRaces extremely fast
or slips in changing
from D
3 to D2 when
depressing accelera-
tor pedal. ON vehicle1. A/T fluid levelXX-XX, "*****"
2. Accelerator pedal position sensor EC-583
3. Line pressure testTM-178
4. Line pressure solenoid valveXX-XX, "*****"
5. Shift solenoid valve BXX-XX, "*****"
6. Control valve assemblyXX-XX, "*****"
OFF vehicle7. Brake bandXX-XX, "*****"8. High clutchXX-XX, "*****"
Races extremely fast
or slips in changing
from D
4 or D3 to D 1
when depressing ac-
celerator pedal.ON vehicle1. A/T fluid levelXX-XX, "*****"
2. Accelerator pedal position sensorEC-583
3. Line pressure testTM-178
4. Line pressure solenoid valveXX-XX, "*****"
5. Shift solenoid valve AXX-XX, "*****"
6. Shift solenoid valve BXX-XX, "*****"
7. Control valve assemblyXX-XX, "*****"
OFF vehicle8. Forward clutchXX-XX, "*****"9. Forward one-way clutchXX-XX, "*****"
10. Low one-way clutchXX-XX, "*****"
Vehicle will not run in
any position.ON vehicle1. A/T fluid levelXX-XX, "*****"
2. Control cable adjustmentXX-XX, "*****"
3. Line pressure testTM-178
4. Line pressure solenoid valveXX-XX, "*****"
OFF vehicle5. Oil pumpXX-XX, "*****"
6. High clutchXX-XX, "*****"
7. Brake bandXX-XX, "*****"
8. Low & reverse brakeXX-XX, "*****"
9. Torque converterXX-XX, "*****"
10. Parking componentsXX-XX, "*****"
OthersEngine cannot be
started in “P” and “N”
positions.
XX-XX, "*****"
ON vehicle1. Ignition switch and starterXX-XX, "*****"
,
XX-XX, "*****"
2. Control cable adjustmentXX-XX, "*****"
3. PNP switch adjustmentXX-XX, "*****"
Engine starts in posi-
tions other than “P”
and “N”.ON vehicle1. Control cable adjustmentXX-XX, "*****"
2. PNP switch adjustmentXX-XX, "*****"
Items Symptom Condition Diagnostic item Reference page

TM-438
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
OthersTransaxle noise in“ P”
and “N” positions.ON vehicle1. A/T fluid levelXX-XX, "*****"
2. Line pressure testTM-178
3. Accelerator pedal position sensorEC-583
4. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTRXX-XX, "*****"
and XX-XX,
"*****"
OFF vehicle5. Oil pumpXX-XX, "*****"6. Torque converterXX-XX, "*****"
Vehicle moves when
changing into “P” po-
sition or parking gear
does not disengage
when shifted out of “P”
position.ON vehicle 1. Control cable adjustmentXX-XX, "*****"
OFF vehicle 2. Parking componentsXX-XX, "*****"
Vehicle runs in “N” po-
sition.
XX-XX, "*****"
ON vehicle 1. Control cable adjustmentXX-XX, "*****"
OFF vehicle2. Forward clutchXX-XX, "*****"3. Reverse clutchXX-XX, "*****"
4. Overrun clutchXX-XX, "*****"
Vehicle braked when
shifting into “R” posi-
tion.ON vehicle1. A/T fluid levelXX-XX, "*****"
2. Control cable adjustmentXX-XX, "*****"
3. Line pressure testTM-178
4. Line pressure solenoid valveXX-XX, "*****"
5. Control valve assemblyXX-XX, "*****"
OFF vehicle6. High clutchXX-XX, "*****"7. Brake band XX-XX, "*****"
8. Forward clutchXX-XX, "*****"
9. Overrun clutchXX-XX, "*****"
Excessive creep. ON vehicle 1. Engine idling speedEC-389
Engine stops when
shifting lever into “R”,
“D”, “2” and “1” posi-
tions.ON vehicle1. Engine idling speedEC-3892. A/T fluid levelXX-XX, "*****"
3. Torque converter clutch solenoid valveXX-XX, "*****"
4. Control valve assemblyXX-XX, "*****"
OFF vehicle 5. Torque converterXX-XX, "*****"
Vehicle braked by
gear change from D
1
to D
2.ON vehicle 1. A/T fluid levelXX-XX, "*****"OFF vehicle2. Reverse clutchXX-XX, "*****"3. Low & reverse brakeXX-XX, "*****"
4. High clutchXX-XX, "*****"
5. Low one-way clutchXX-XX, "*****"
Vehicle braked by
gear change from D
2
to D
3.ON vehicle 1. A/T fluid levelXX-XX, "*****"OFF vehicle 2. Brake bandXX-XX, "*****"
Items Symptom Condition Diagnostic item Reference page

SYSTEM SYMPTOM
TM-439
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
OthersVehicle braked by
gear change from D
3
to D
4.ON vehicle 1. A/T fluid levelXX-XX, "*****"OFF vehicle2. Overrun clutchXX-XX, "*****"3. Forward one-way clutchXX-XX, "*****"
4. Reverse clutchXX-XX, "*****"
Maximum speed not
attained. Poor accel-
eration.ON vehicle1. A/T fluid levelXX-XX, "*****"
2. PNP switch adjustmentXX-XX, "*****"
3. Overdrive control switchXX-XX, "*****"
4. Accelerator pedal position sensorEC-583
5. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTRXX-XX, "*****"
and XX-XX,
"*****"
6. Shift solenoid valve AXX-XX, "*****"
7. Shift solenoid valve BXX-XX, "*****"
8. Control valve assemblyXX-XX, "*****"
OFF vehicle9. Reverse clutchXX-XX, "*****"
10. High clutchXX-XX, "*****"
11. Brake bandXX-XX, "*****"
12. Low & reverse brakeXX-XX, "*****"
13. Oil pumpXX-XX, "*****"
14. Torque converterXX-XX, "*****"
Transaxle noise in
“D”, “2”, “1” and “R”
positions.ON vehicle 1. A/T fluid levelXX-XX, "*****"
OFF vehicle 2. Torque converterXX-XX, "*****"
Engine brake does
not operate in “1” po-
sition.ON vehicle1. PNP switch adjustmentXX-XX, "*****"
2. Control cable adjustmentXX-XX, "*****"
3. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTRXX-XX, "*****"
and XX-XX,
"*****"
4. Control valve assemblyXX-XX, "*****"
5. Overrun clutch solenoid valveXX-XX, "*****"
OFF vehicle6. Overrun clutchXX-XX, "*****"7. Low & reverse brakeXX-XX, "*****"
Items Symptom Condition Diagnostic item Reference page
