2007 NISSAN TIIDA EC Engine Control System

TM-128
< SYMPTOM DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
SYSTEM SYMPTOM
Shift ShockSharp shock in shift-
ing from “N” to “D” po-
sition.ON vehicle1. Engine idling speedEC-26
2. Accelerator pedal position sensorEC-297
3. Line pressure testTM-178
4. A/T fluid temperature sensorTM-48
5. Engine speed signalTM-56
6. Line pressure solenoid valveTM-81
7. Control valve assemblyTM-191
8. Accumulator N-DTM-191
OFF vehicle 9. Forward clutchTM-267
Too sharp a shock in
changing from D
1 to
D
2.ON vehicle1. Accelerator pedal position sensorEC-297
2. Line pressure testTM-178
3. Accumulator servo releaseTM-191
4. Control valve assemblyTM-191
5. A/T fluid temperature sensorTM-48
OFF vehicle 6. Brake bandTM-287
Too sharp a shock in
changing from D
2 to
D
3.ON vehicle1. Accelerator pedal position sensorEC-297
2. Line pressure testTM-178
3. Control valve assemblyTM-191
OFF vehicle4. High clutchTM-2625. Brake bandTM-287
Too sharp a shock in
changing from D
3 to
D
4.ON vehicle1. Accelerator pedal position sensorEC-297
2. Line pressure testTM-178
3. Control valve assemblyTM-191
OFF vehicle4. Brake bandTM-2875. Overrun clutchTM-267
6. Forward one-way clutchTM-278
Gear change shock
during deceleration by
releasing accelerator
pedal.ON vehicle1. Accelerator pedal position sensorEC-2972. Line pressure testTM-178
3. Overrun clutch solenoid valveTM-93
4. Control valve assemblyTM-191
Large shock in chang-
ing from 1
2 to 11 in “1”
position.ON vehicle 1. Control valve assemblyTM-191OFF vehicle 2. Low & reverse brakeTM-273
Items Symptom Condition Diagnostic item Reference page

SYSTEM SYMPTOM
TM-129
< SYMPTOM DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Improper Shift TimingToo high a gear
change point from D
1
to D
2, from D2 to D3,
from D
3 to D4.ON vehicle1. Accelerator pedal position sensorEC-297
2. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTRTM-52 and TM-97
3. Shift solenoid valve ATM-85
4. Shift solenoid valve BTM-89
Gear change directly
from D
1 to D3 occurs.ON vehicle1. A/T fluid levelTM-1712. Accumulator servo releaseTM-191
OFF vehicle 3. Brake bandTM-287
Too high a change
point from D
4 to D3,
from D
3 to D 2, from
D
2 to D1.ON vehicle1. Accelerator pedal position sensorEC-297
2. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTRTM-52 and TM-97
Kickdown does not
operate when de-
pressing accelerator
pedal in D
4 within
kickdown vehicle
speed.ON vehicle1. Accelerator pedal position sensorEC-297
2. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTRTM-52 and TM-97
3. Shift solenoid valve ATM-85
4. Shift solenoid valve BTM-89
Kickdown operates or
engine overruns when
depressing accelera-
tor pedal in D
4 beyond
kickdown vehicle
speed limit.ON vehicle1. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTRTM-52
and TM-97
2. Accelerator pedal position sensorEC-297
3. Shift solenoid valve ATM-85
4. Shift solenoid valve BTM-89
Gear change from 22
to 2
3 in “2” position.ON vehicle1. PNP switch adjustmentTM-1952. Control cable adjustmentTM-204
Gear change from 11
to 1
2 in “1” position.ON vehicle1. PNP switch adjustmentTM-1952. Control cable adjustmentTM-204
Items Symptom Condition Diagnostic item Reference page

SYSTEM SYMPTOM
TM-135
< SYMPTOM DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Slips/Will Not EngageRaces extremely fast
or slips in changing
from D
3 to D2 when
depressing accelera-
tor pedal. ON vehicle1. A/T fluid levelTM-171
2. Accelerator pedal position sensor EC-297
3. Line pressure testTM-178
4. Line pressure solenoid valveTM-81
5. Shift solenoid valve BTM-89
6. Control valve assemblyTM-191
OFF vehicle7. Brake bandTM-2878. High clutchTM-262
Races extremely fast
or slips in changing
from D
4 or D3 to D 1
when depressing ac-
celerator pedal.ON vehicle1. A/T fluid levelTM-171
2. Accelerator pedal position sensorEC-297
3. Line pressure testTM-178
4. Line pressure solenoid valveTM-81
5. Shift solenoid valve ATM-85
6. Shift solenoid valve BTM-89
7. Control valve assemblyTM-191
OFF vehicle8. Forward clutchTM-2679. Forward one-way clutchTM-278
10. Low one-way clutchTM-222
Vehicle will not run in
any position.ON vehicle1. A/T fluid levelTM-171
2. Control cable adjustmentTM-204
3. Line pressure testTM-178
4. Line pressure solenoid valveTM-81
OFF vehicle5. Oil pumpTM-240
6. High clutchTM-262
7. Brake bandTM-287
8. Low & reverse brakeTM-273
9. Torque converterTM-222
10. Parking componentsTM-213
OthersEngine cannot be
started in “P” and “N”
positions.
TM-140
ON vehicle1. Ignition switch and starterSTR-62. Control cable adjustmentTM-204
3. PNP switch adjustmentTM-195
Engine starts in posi-
tions other than “P”
and “N”.ON vehicle1. Control cable adjustmentTM-204
2. PNP switch adjustmentTM-195
Items Symptom Condition Diagnostic item Reference page

TM-136
< SYMPTOM DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
SYSTEM SYMPTOM
OthersTransaxle noise in“ P”
and “N” positions.ON vehicle1. A/T fluid levelTM-171
2. Line pressure testTM-178
3. Accelerator pedal position sensorEC-297
4. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTRTM-52 and TM-97
OFF vehicle5. Oil pumpTM-2406. Torque converterTM-222
Vehicle moves when
changing into “P” po-
sition or parking gear
does not disengage
when shifted out of “P”
position.ON vehicle 1. Control cable adjustmentTM-204
OFF vehicle 2. Parking componentsTM-213
Vehicle runs in “N” po-
sition.
TM-141
ON vehicle 1. Control cable adjustmentTM-204
OFF vehicle2. Forward clutchTM-2673. Reverse clutchTM-258
4. Overrun clutchTM-267
Vehicle braked when
shifting into “R” posi-
tion.ON vehicle1. A/T fluid levelTM-171
2. Control cable adjustmentTM-204
3. Line pressure testTM-178
4. Line pressure solenoid valveTM-81
5. Control valve assemblyTM-191
OFF vehicle6. High clutchTM-2627. Brake band TM-287
8. Forward clutchTM-267
9. Overrun clutchTM-267
Excessive creep. ON vehicle 1. Engine idling speedEC-26
Engine stops when
shifting lever into “R”,
“D”, “2” and “1” posi-
tions.ON vehicle1. Engine idling speedEC-262. A/T fluid levelTM-171
3. Torque converter clutch solenoid valveTM-73
4. Control valve assemblyTM-191
OFF vehicle 5. Torque converterTM-222
Vehicle braked by
gear change from D
1
to D
2.ON vehicle 1. A/T fluid levelTM-171OFF vehicle2. Reverse clutchTM-2583. Low & reverse brakeTM-273
4. High clutchTM-262
5. Low one-way clutchTM-222
Vehicle braked by
gear change from D
2
to D
3.ON vehicle 1. A/T fluid levelTM-171OFF vehicle 2. Brake bandTM-287
Items Symptom Condition Diagnostic item Reference page

SYSTEM SYMPTOM
TM-137
< SYMPTOM DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
OthersVehicle braked by
gear change from D
3
to D
4.ON vehicle 1. A/T fluid levelTM-171OFF vehicle2. Overrun clutchTM-2673. Forward one-way clutchTM-278
4. Reverse clutchTM-258
Maximum speed not
attained. Poor accel-
eration.ON vehicle1. A/T fluid levelTM-171
2. PNP switch adjustmentTM-195
3. Overdrive control switchT M - 111
4. Accelerator pedal position sensorEC-297
5. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTRTM-52 and TM-97
6. Shift solenoid valve ATM-85
7. Shift solenoid valve BTM-89
8. Control valve assemblyTM-191
OFF vehicle9. Reverse clutchTM-258
10. High clutchTM-262
11. Brake bandTM-287
12. Low & reverse brakeTM-273
13. Oil pumpTM-240
14. Torque converterTM-222
Transaxle noise in
“D”, “2”, “1” and “R”
positions.ON vehicle 1. A/T fluid levelTM-171
OFF vehicle 2. Torque converterTM-222
Engine brake does
not operate in “1” po-
sition.ON vehicle1. PNP switch adjustmentTM-195
2. Control cable adjustmentTM-204
3. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTRTM-52 and TM-97
4. Control valve assemblyTM-191
5. Overrun clutch solenoid valveTM-93
OFF vehicle6. Overrun clutchTM-2677. Low & reverse brakeTM-273
Items Symptom Condition Diagnostic item Reference page

TM-138
< SYMPTOM DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
SYSTEM SYMPTOM
OD OFF Indicator Lamp Does Not Come On
INFOID:0000000001696242
SYMPTOM:
OD OFF indicator lamp does not come on for about 2 seconds when turning ignition switch to ON.
1.CHECK CAN COMMUNICATION LINE
Perform self-diagnosis. Refer to TM-35, "
CONSULT-III Function (TRANSMISSION)" or TM-350, "Diagnosis
Procedure without CONSULT-III".
Is a malfunction in CAN communication indicated in the results?
YES >> Check CAN communication line. Refer to TM-43, "Description" (type 1) or TM-391, "Description"
(type 2).
NO >> GO TO 2.
2.CHECK TCM POWER SOURCE
1. Turn ignition switch ON. (Do not start engine.)
2. Check voltage between TCM connector terminals and ground.
OthersTransaxle overheats.ON vehicle1. A/T fluid levelTM-171
2. Engine idling speedEC-26
3. Accelerator pedal position sensorEC-297
4. Line pressure testTM-178
5. Line pressure solenoid valveTM-81
6. Control valve assemblyTM-191
OFF vehicle7. Oil pumpTM-240
8. Reverse clutchTM-258
9. High clutchTM-262
10. Brake bandTM-287
11. Forward clutchTM-267
12. Overrun clutchTM-267
13. Low & reverse brakeTM-273
14. Torque converterTM-222
ATF shoots out during
operation.
White smoke emitted
from exhaust pipe
during operation.ON vehicle 1. A/T fluid levelTM-171
OFF vehicle2. Reverse clutchTM-258
3. High clutchTM-262
4. Brake bandTM-287
5. Forward clutchTM-267
6. Overrun clutchTM-267
7. Low & reverse brakeTM-273
Unusual smell at A/T
fluid charging pipe.ON vehicle 1. A/T fluid levelTM-171
OFF vehicle2. Torque converterTM-222
3. Oil pumpTM-240
4. Reverse clutchTM-258
5. High clutchTM-262
6. Brake bandTM-287
7. Forward clutchTM-267
8. Overrun clutchTM-267
9. Low & reverse brakeTM-273
Items Symptom Condition Diagnostic item Reference page

TM-140
< SYMPTOM DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
SYSTEM SYMPTOM
Check again. Refer to TM-180, "Check Before Engine Is Started".
OK or NG
OK >>INSPECTION END
NG >> GO TO 7.
7.CHECK TCM
1. Check TCM input/output. Refer to TM-119, "
Reference Value" (Type 1) or TM-422, "Reference Value"
(Type 2).
2. If NG, recheck TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
Engine Cannot Be Started in "P" and "N" PositionINFOID:0000000001696243
SYMPTOM:
Engine cannot be started with selector lever in “P” or “N” position.
Engine can be started with selector lever in “D”, “2”, “1” or “R” position.
1.CHECK SELF-DIAGNOSIS RESULTS
Perform self-diagnosis. Refer to TM-35, "
CONSULT-III Function (TRANSMISSION)" or TM-38, "Diagnosis
Procedure without CONSULT-III".
Is any malfunction detected by self-diagnostic results?
YES >> Check the malfunctioning system. Refer to TM-35, "CONSULT-III Function (TRANSMISSION)" or
TM-38, "
Diagnosis Procedure without CONSULT-III".
NO >> GO TO 2.
2.CHECK PNP SWITCH
Check continuity between PNP switch harness connector terminals.
OK or NG
OK >> GO TO 4.
NG >> GO TO 3.
3.CHECK CONTROL CABLE ADJUSTMENT
Check PNP switch again with control cable disconnected from manual shaft of A/T assembly. Refer to test
group 2.
OK or NG
OK >> Adjust control cable. Refer to TM-204, "Adjustment of A/T Position".
NG >> 1. Check PNP switch (Refer to test group 2.) again after adjusting PNP switch (Refer to TM-46
).
- If OK, INSPECTION END
- If NG, repair or replace PNP switch. Refer to TM-195, "
Park/Neutral Position (PNP) Switch".
4.CHECK STARTING SYSTEM
Check starting system. Refer to STR-6, "
System Description".
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
In "P" Position, Vehicle Moves Forward or Backward When PushedINFOID:0000000001696244
SYMPTOM:
Vehicle moves when it is pushed forward or backward with selector lever in “P” position.
Selector lever position Connector terminal Continuity
“P”, “N”
F25 1 - 2Ye s
Other positions No
SCIA5606E

SYSTEM SYMPTOM
TM-153
< SYMPTOM DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Check again. Refer to TM-183, "Cruise Test - Part 1".
OK or NG
OK >>INSPECTION END
NG >> GO TO 3.
3.CHECK TCM
1. Check TCM input/output signals. Refer to TM-22, "
Input/Output Signal of TCM".
2. If NG, recheck TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
Engine Speed Does Not Return to Idle (Light Braking D4→ D3)INFOID:0000000001696256
SYMPTOM:
Engine speed does not smoothly return to idle when A/T shifts from D
4 to D3 on “Cruise Test — Part
1”.
1.CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis. Refer to XX-XX, "*****"
or TM-38, "Diagnosis Procedure without CONSULT-III".
Is any malfunction detected by self-diagnostic results?
YES >> Check the malfunctioning system. Refer to XX-XX, "*****" or XX-XX, "*****".
NO >> GO TO 2.
2.CHECK ACCELERATOR PEDAL POSITION SENSOR
Check accelerator pedal position sensor. Refer to EC-297, "
Description" (type 1) or EC-583, "Description"
(type 2).
OK or NG
OK >> GO TO 3.
NG >> Repair or replace accelerator pedal position sensor.
3.CHECK A/T FLUID CONDITION
1. Remove oil pan. Refer to TM-213, "
Component".
2. Check A/T fluid condition. Refer to TM-171, "
Checking A/T Fluid".
OK or NG
OK >> GO TO 5.
NG >> GO TO 4.
4.DETECT MALFUNCTIONING ITEM
1. Remove control valve assembly. Refer to TM-191, "
Control Valve Assembly and Accumulators".
2. Check the following items:
- Overrun clutch control valve
- Overrun clutch reducing valve
- Overrun clutch solenoid valve
3. Disassemble A/T. Refer to TM-222, "
Disassembly".
4. Check the following items:
- Overrun clutch assembly. Refer to TM-267, "
Forward and Overrun Clutches".
OK or NG
OK >> GO TO 6.
NG >> Repair or replace damaged parts.
5.DETECT MALFUNCTIONING ITEM
1. Remove control valve assembly. Refer to TM-191, "
Control Valve Assembly and Accumulators".
2. Check the following items:
- Overrun clutch control valve
- Overrun clutch reducing valve
- Overrun clutch solenoid valve
OK or NG
