2007 NISSAN TIIDA length

REPAIR FOR COMPONENT PARTS
TM-563
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
 Measure thickness (t) of dish plate. Replace if damaged, deformed
or worn.
Forward Clutch and Overrun Clutch Spring Retainer Assembly
Check length (L) of spring retainer assembly. Replace if damaged,
deformed or worn.
CAUTION:
Do not remove return springs (A) from spring retainer (B)
Forward Clutch Drum
 Make sure that check balls do not stick.
 Apply compressed air to check ball oil hole from outside of forward
clutch drum. Make sure air leaks past ball.
 Apply compressed air to oil hole from inside of forward clutch
drum. Make sure there is no air leakage.
Overrun Clutch Piston
 Make sure that check balls do not stick.
 Apply compressed air to check ball oil hole opposite return spring.
Make sure there is no air leakage.
 Apply compressed air to oil hole on return spring side. Make sure
that air leaks through ball hole.
ASSEMBLY
Thickness of dish plate (t)
Forward clutch: 2.5 mm (0.098 in)
Overrun clutch: 2.15 mm (0.0846 in)
SAT163D
Length (L): 27.7 mm (0.1091 in)
SCIA7025J
SAT213D
SAT212D

REPAIR FOR COMPONENT PARTS
TM-569
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
 Measure thickness (t) of dish plate. Replace if damaged, deformed
or worn.
Low & Reverse Brake Spring Retainer Assembly
Check length (L) of spring retainer assembly. Replace if damaged,
deformed or worn.
CAUTION:
Do not remove return springs (A) from spring retainer (B)
ASSEMBLY
1. Install seal ring (1) and D-ring (2) on low & reverse brake piston
(3).
2. Install low & reverse brake piston in transaxle case while turning
it.
CAUTION:
Apply ATF to inner surface of transaxle case.Thickness of dish plate (t): 2.93 mm (0.1154 in)
SAT163D
Length (L): 26.3 mm (1.035 in)
SCIA7025J
SCIA6516J
SAT239D

REPAIR FOR COMPONENT PARTS
TM-583
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
INSPECTION
Pistons, Retainers and Piston Stem
Check the sliding surfaces for damage or excessive wear. Replace if necessary.
Return Springs
 Check each return spring for damage or deformation. Also mea-
sure free length. Refer to TM-323, "
Band Servo".
 Replace springs if deformed or fatigued.
ASSEMBLY
1. Install D-rings to band servo piston.
2. Install band servo thrust washer (4), band servo piston (3), OD
servo return spring (2) and spring retainer (1) to band servo pis-
ton stem (5).
3. Place band servo piston stem (1) on a wooden block, and install
E-ring (2) to band servo piston stem (1) while pressing spring
retainer (3) downward.
SAT138D
SCIA3688E
SCIA7054E
SCIA7056E

TM-608
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
ASSEMBLY
Completely remove all moisture, oil and old sealant, etc. from the transaxle case and converter
housing mating surfaces.
22. Install converter housing on transaxle case.
23. Install bracket on converter housing.
24. Tighten converter housing bolts (1), (2) and (3) to the specified
torque.
*: Tighten with bracket.
25. Install O-ring to plug.
CAUTION:
 Do not reuse O-ring.
 Apply ATF to O-ring.
26. Install plug to converter housing.
27. Tighten plug fitting bolt to the specified torque.
28. Install accumulator pistons.
a. Install O-rings (1) on servo release accumulator piston (2) and
N-D accumulator piston (3). Refer to TM-321, "
Accumulator".
b. Install return springs (1), servo release accumulator piston (2)
and N-D accumulator piston (3) into transaxle case (4). Refer to
TM-321, "
Accumulator".
29. Install lip seals (1) for band servo oil holes on transaxle case.
Bolt 1 2 3*
Bolt length
[mm (in)]30 (1.18) 40 (1.57)
Number of bolts 10 9 1
SCIA6956E
SCIA6033J
SCIA6042J
SCIA5895J

ASSEMBLY
TM-609
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
30. Install control valve assembly on transaxle case.
a. Install O-ring on terminal body.
CAUTION:
 Do not reuse O-ring.
 Apply ATF to O-ring.
b. Insert manual valve into control valve assembly.
CAUTION:
Do not drop manual valve.
c. Set manual shaft in “N” position.
d. Install control valve assembly on transaxle case while aligning
manual valve (2) with manual plate (1).
e. Install terminal body (2) into transaxle case by pushing it.
f. Install snap ring (1) to terminal body (2).
g. Tighten bolts (A), (B) and (C) to the specified torque.
Bolt length, number and location:
31. Install oil pan.
a. Attach magnets on oil pan.
SCIA3999E
SCIA7090E
SCIA6030J
Bolt symbol A B C
Bolt length “ ” [mm (in)]
40.0 mm
(1.575 in)33.0 mm
(1.299 in)43.5 mm
(1.713 in)
Number of bolts 5 6 2
SCIA5911J

TM-614
< SERVICE DATA AND SPECIFICATIONS (SDS) [TYPE 2 (4AT: RE4F03B)]
SERVICE DATA AND SPECIFICATIONS (SDS)
Control Valves
INFOID:0000000001731459
CONTROL VALVE SPRINGS
Unit: mm (in)
AccumulatorINFOID:0000000001731460
RETURN SPRINGS
Unit: mm (in)
Unit: mm (in)
O-RINGS
Unit: mm (in)
Clutches and BrakesINFOID:0000000001731461
REVERSE CLUTCH
Location spring designation Free length (l) Outer diameter (D)
Upper bodyL14 Pilot valve spring 38.98 (1.5346) 8.9 (0.350)
L151–2 accumulator valve spring 20.5 (0.807) 6.95 (0.2737)
1–2 accumulator piston spring 55.66 (2.1913) 19.5 (0.768)
L16 1st reducing valve spring 27.0 (1.063) 7.0 (0.276)
L17 3–2 timing valve spring 23.0 (0.906) 6.65 (0.2618)
L18 Overrun clutch reducing valve spring 37.5 (1.476) 7.0 (0.276)
L19 Torque converter relief valve spring 33.3 (1.311) 9.0 (0.354)
L20 Torque converter clutch control valve spring 53.01 (2.0870) 6.5 (0.256)
L21 Cooler check valve spring 28.04 (1.1039) 7.15 (0.2815)
Lower bodyL3 Pressure regulator valve spring 45.0 (1.772) 15.0 (0.591)
L4 Overrun clutch control valve spring 21.7 (0.854) 7.0 (0.276)
L5 Accumulator control valve spring 22.0 (0.866) 6.5 (0.256)
L6 Shift valve A spring 21.7 (0.854) 7.0 (0.276)
L7 Shuttle valve spring 51.0 (2.008) 5.65 (0.2224)
L12 Shift valve B spring 21.7 (0.854) 7.0 (0.276)
L13Pressure modifier valve spring 32.0 (1.260) 6.9 (0.272)
Pressure modifier piston spring 30.5 (1.201) 9.8 (0.386)
— Line pressure relief valve spring 17.02 (0.6701) 8.0 (0.315)
— Torque converter pressure holding spring 9.0 (0.354) 7.3 (0.287)
Location Free length (L1)
Servo release accumulator 62.8 (2.472)
Location Length (L2)
N-D accumulator46.5 (1.831)
Location Inner diameter (Small) Inner diameter (Large)
Servo release accumulator 26.9 (1.059) 44.2 (1.740)
N-D accumulator 34.6 (1.362) 39.4 (1.551)
Number of drive plates2
Number of driven plates2
Drive plate thickness [mm (in)]Standard 2.0 (0.079)
Allowable limit 1.8 (0.070)

TM-616
< SERVICE DATA AND SPECIFICATIONS (SDS) [TYPE 2 (4AT: RE4F03B)]
SERVICE DATA AND SPECIFICATIONS (SDS)
Final Drive
INFOID:0000000001731462
DIFFERENTIAL SIDE GEAR CLEARANCE
DIFFERENTIAL SIDE BEARING END PLAY
Planetary CarrierINFOID:0000000001731463
Oil PumpINFOID:0000000001731464
Input ShaftINFOID:0000000001731465
SEAL RING CLEARANCE
SEAL RING
Unit: mm (in)
Reduction Pinion GearINFOID:0000000001731466
TURNING TORQUE
Band ServoINFOID:0000000001731467
RETURN SPRINGS
Unit: mm (in)
Output ShaftINFOID:0000000001731468
SEAL RING CLEARANCE
Clearance between side gear and differential case with washer [mm (in)] 0.1 - 0.2 (0.004 - 0.008)
Differential side bearing end play [mm (in)] 0 - 0.15 (0 - 0.0059)
Clearance between planetary carrier and pinion washer [mm (in)]Standard 0.15 - 0.70 (0.0059 - 0.0276)
Allowable limit 0.80 (0.0315)
Oil pump side clearance0.02 - 0.04 (0.0008 - 0.0016)
Clearance between oil pump housing and outer gear [mm (in]Standard 0.08 - 0.15 (0.0031 - 0.0059)
Allowable limit 0.15 (0.0059)
Oil pump cover seal ring clearance [mm (in)]Standard 0.10 - 0.25 (0.0039 - 0.0098)
Allowable limit 0.25 (0.0098)
Input shaft seal ring clearance [mm (in)]Standard 0.10 - 0.25 (0.0039 - 0.0098)
Allowable limit 0.25 (0.098)
Outer diameter Inner diameter Width
24 (0.94) 20.4 (0.803) 1.97 (0.0776)
Turning torque of reduction pinion gear [N·m (kg-m, in-lb)] 0.11 - 0.69 (0.02 - 0.07, 1 - 6)
Return spring Free length
2nd servo return spring 32.5 (1.280)
OD servo return spring 38.52 (1.5165)

TM-634
< REMOVAL AND INSTALLATION >[5MT: RS5F91R]
TRANSAXLE ASSEMBLY
8. Remove engine undercover.
9. Remove front drive shafts. Refer to FAX-10, "
Removal and Installation (Left Side)" and FAX-11, "Removal
and Installation (Right Side)".
NOTE:
Insert a suitable plug into side oil seal after removing front drive shaft.
10. Remove heat insulator and exhaust front tube. Refer to EX-5, "
Removal and Installation".
11. Disconnect position switch harness connector and then disconnect clip from rear housing.
12. Drain gear oil. Refer to TM-628, "
Draining".
13. Disconnect select cable and shift cable from transaxle assembly. Refer to TM-630, "
Removal and Installa-
tion".
14. Support engine assembly and transaxle assembly with a jack.
CAUTION:
When setting a jack, be careful not to bring it into contact with switch.
15. Remove engine mount through bolt-securing nut. Refer to EM-89, "
Exploded View".
16. Remove LH engine mount bracket (transaxle side) bolts.
17. Remove rear engine mount bracket and rear torque rod.
18. Remove transaxle assembly to engine assembly bolts.
19. Remove transaxle assembly from the vehicle.
CAUTION:
Secure transaxle assembly to a jack while removing it.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
When installing transaxle assembly, be careful not to bring transaxle input shaft into contact with
clutch cover.
 If transaxle is removed from the vehicle, always replace CSC. Refer to CL-11, "
Removal and Installation".
 When installing the transaxle assembly to the engine, install the
bolts following the standard below.
(A): M/T to engine
(B): Engine to M/T
 Bleed the air from the clutch hydraulic system. Refer to CL-8, "
Air Bleeding Procedure".
 After installation, check oil level, and check for leaks and loose mechanisms. Refer to TM-628, "
Inspection".
SCIA7084E
Bolt No. 1234
Quantity 2213
Bolt length “ ”
mm (in)55
(2.17)49
(1.93)69
(2.72)55
(2.17)
Tightening torque
N·m (kg-m, ft-lb)48.0
(4.9, 35)
PCIB1517E
