2007 NISSAN 350Z Owner´s Manual

Without satellite radio:
AM, FM1, FM2 and CD or CD changer
With satellite radio:
AM, FM1, FM2, SAT1, SAT2 and CD changerVOLUME control switchesPush up or down the VOLUME control switch to
increase or decrease the volume.
Tuning switch
Memory change (radio):
Push up or down the tuning switch for less than
1.5 seconds to change the radio frequency.
SEEK tuning (radio):
Push up or down the tuning switch for more than
1.5 seconds to seek the next or previous radio
station.
APS (Automatic Program Search) FF,
APS REW (CD or CD changer):
Push up or down the tuning switch for less than
1.5 seconds to return to the beginning of the
present program or skip to the next program.
Push several times to skip back or skip through
programs.
This system searches for the blank intervals
between selections. If there is a blank intervalwithin one program or there is no interval be-
tween programs, the system may not stop in the
desired or expected location.
FOLDER change (CD changer/CD with
MP3 or WMA):
Push up or down the tuning switch for more than
1.5 seconds to change the folders (if there are
any folders).
DISC change (CD changer/CD without
MP3 or WMA):
Push up or down the tuning switch for more than
1.5 seconds to change the playing disc up or
down.
ANTENNAThe antenna is located at the rear of the vehicle.
To remove the antenna, turn it counterclockwise.
To reinstall it, screw it securely into the base.
CAUTION
Be sure to remove the antenna before
entering a low-roof garage or an auto-
matic car wash. Otherwise the antenna
may be damaged.
SAA0606
4-30
Display screen, heater, air conditioner and audio systems


07.2.9/Z33-D/V5.0


When installing a CB, ham radio or car phone in
your NISSAN vehicle, be sure to observe the
following cautions, otherwise the new equip-
ment may adversely affect the Engine Control
system and other electronic parts.
WARNING

A cellular telephone should not be
used while driving so full attention
may be given to vehicle operation.
Some jurisdictions prohibit the use
of cellular telephones while driving.

If you must make a call while your
vehicle is in motion, the hands free
cellular phone operational mode (if
so equipped) is highly recommended.
Exercise extreme caution at all times
so full attention may be given to
vehicle operation.

If a conversation in a moving vehicle
requires you to take notes, pull off
the road to a safe location and stop
your vehicle before doing so.
CAUTION

Keep the antenna as far away as
possible from the electronic control
modules.

Keep the antenna wire more than 8 in
(20 cm) away from the electronic con-
trol system harnesses. Do not route
the antenna wire next to any harness.

Adjust the antenna standing-wave
ratio as recommended by the manu-
facturer.

Connect the ground wire from the CB
radio chassis to the body.

For details, consult a NISSAN dealer.
WARNING

Use a phone after stopping your ve-
hicle in a safe location. If you have to
use a phone while driving, exercise
extreme caution at all times so full
attention may be given to vehicle
operation.

If a conversation in a moving vehicle
requires you to take notes, pull off
the road to a safe location and stop
your vehicle before doing so.
CAUTION
To avoid draining the vehicle battery,
use a phone after starting the engine.
CAR PHONE OR CB RADIOBLUETOOTH
HANDS-FREE
PHONE SYSTEM WITH NISSAN
VOICE RECOGNITION (if so
equipped)
Display screen, heater, air conditioner and audio systems
4-31


07.2.9/Z33-D/V5.0


1. Volume control switch −/+
2. PHONE SEND
button
3. PHONE ENDbutton
4. Indicator light
5. Microphone
Your vehicle is equipped with the Bluetooth
Hands-Free Phone System. If you are an owner
of a Bluetooth
enabled cellular phone, you can
set up the wireless connection between your
cellular phone and the in-vehicle phone module.
With Bluetoothwireless technology, you can
make or receive a hands-free telephone call with
your cellular phone in the vehicle.Once your cellular phone is paired to the in-
vehicle phone module, no other phone connect-
ing procedure is required. Your phone is auto-
matically connected with the in-vehicle phone
module when the ignition switch is turned to the
ON position with the paired cellular phone
turned on and carried in the vehicle.
You can register up to 5 different Bluetooth
cellular phones to the in-vehicle phone module.
However, you can talk on only one cellular phone
at a time.
Before using the Bluetooth
Hands-Free Phone
System, refer to the following notes.

Set up the wireless connection between acellular phone and the in-vehicle phone mod-
ule before using the Bluetooth
Hands-Free
Phone System.

Some Bluetooth
enabled cellular phones
may not be recognized by the in-vehicle
phone module. Please visit
www.nissanusa.com/bluetooth for a recom-
mended phone list.

You will not be able to use a hands-free
phone under the following conditions:
— Your vehicle is outside of the telephone
service area.
— Your vehicle is in an area where it is
difficult to receive radio waves; such as in
a tunnel, in an underground parking ga-
rage, near a tall building or in a mountain-
ous area.
— Your cellular phone is locked to prevent it
from being dialed.
When the radio wave condition is not ideal or
ambient sound is too loud, it may be difficult to
hear the other person’s voice during a call.
Do not place the cellular phone in an area
surrounded by metal or far away from the in-
vehicle phone module to prevent tone quality
degradation and wireless connection disruption.
While a cellular phone is connected through the
SAA1699
4-32
Display screen, heater, air conditioner and audio systems


07.2.9/Z33-D/V5.0


Bluetooth
wireless connection, the battery
power of the cellular phone may discharge
quicker than usual. The Bluetooth
Hands-Free
Phone System cannot charge cellular phones.
If the Bluetooth
Hands-Free Phone System
seems to be malfunctioning, please refer to
“Troubleshooting guide” later in this section. You
can also visit www.nissanusa.com/bluetooth for
troubleshooting help.
Refer to the cellular phone Owner’s Manual
regarding the telephone charges, cellular phone
antenna and body, etc.
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This equipment should be installed
and operated with minimum distance 8 in (20
cm) between the radiator and your body. This
Transmitter must not be co-located or operating
in conjunction with any other antenna or trans-
mitter.
USING THE SYSTEMThe NISSAN Voice Recognition system allows
hands-free operation of the Bluetooth
Hands-
Free Phone System.
If the vehicle is in motion, some commands may
not be available so full attention may be given to
vehicle operation.
InitializationWhen the ignition switch is turned to the ON
position, NISSAN Voice Recognition is initial-
ized, which takes a few seconds. When com-
pleted, the amber light on the overhead console
illuminates and the system is ready to accept
voice commands. If the
button is pushed
before the initialization completes, the system
will announce “Hands-free phone system not
ready” and will not react to voice commands.
Operating tipsTo get the best performance out of the NISSAN
Voice Recognition system, observe the follow-
ing:

Keep the interior of the vehicle as quiet as
possible. Close the windows to eliminate
surrounding noises (traffic noises, vibration
sounds, etc.), which may prevent the system
from recognizing voice commands correctly.

Wait until the tone sounds before speaking a
command. Otherwise, the command will not be
received properly.

Start speaking a command within 5 seconds
after the tone sounds.

Speak in a natural voice without pausing
between words.Giving voice commandsTo operate NISSAN Voice Recognition, push
and release the
button located on the
steering wheel. The light on the overhead con-
sole flashes to signal you have entered a voice
recognition (VR) session. After the tone sounds,
speak a command.
The command given is picked up by the micro-
phone, and voice feedback is given when the
command is accepted.

If you need to hear the available commands
for the current menu again, say “Help” and
the system will repeat them.

If a command is not recognized, the system
announces, “Command not recognized.
Please try again.” Repeat the command in a
clear voice.

If you want to go back to the previous
command, you can say “Go back” or “Cor-
Display screen, heater, air conditioner and audio systems
4-33


07.2.9/Z33-D/V5.0


rection” anytime the system is waiting for a
response.

You can cancel a command when the system
is waiting for a response by saying, “Cancel”
or “Quit.” The system announces “Cancel”
and ends the VR session. You can also push
the
button on the steering wheel at any
time. Whenever the VR session is cancelled,
a double beep is played to indicate you have
exited the system.

If you want to adjust the volume of the voice
feedback, push the volume control switch (+
or −) on the steering wheel while being
provided with feedback. You can also use the
radio volume control knob.
How to say numbers
NISSAN Voice Recognition requires a certain
way to speak numbers in voice commands. Refer
to the rules and examples below.

Either “zero” or “oh” can be used for “0”.
Example: 1-800-662-6200
— “One eight oh oh six six two six two oh
oh”, or
— “One eight zero zero six six two six two oh
oh”
Words can be used for the first 4 digits
places only.
Example: 1-800-662-6200
— “One eight hundred six six two six two oh
oh”,
— NOT “One eight hundred six six two sixty
two hundred, and
— NOT “One eight oh oh six six two sixty two
hundred.

Numbers can be spoken in small groups. The
system will prompt you to continuing entering
digits, if desired.
Example: 1-800-662-6200
— “One eight oh oh”
The system repeats the numbers and
prompts you to enter more.
— “six six two”
The system repeats the numbers and
prompts you to enter more.
— “six two oh oh”

You can say “Star” for * and “Pound” for # at
anytime in any position of the phone number.
Example: 1-555-1212 *123— “One five five five one two one two star
one two three”
NOTE:
For best results, say phone numbers as
single digits.
4-34
Display screen, heater, air conditioner and audio systems


07.2.9/Z33-D/V5.0


CONTROL BUTTONSThe control buttons for the Bluetooth
Hands-
Free Phone System are located on the steering
wheel.
TALK/PHONE SEND
Push the
button to initiate a VR session
or answer an incoming call.
You can also use the
button to skip
through system feedback and to enter com-
mands during a call. See “List of voice com-
mands” and “During a call” later in this sec-
tion for more information.
MODE/PHONE END
Push the
button to cancel a VR session
or end a call.
GETTING STARTEDThe following procedures will help you get
started using the Bluetooth
Hands-Free Phone
System with NISSAN Voice Recognition. For
additional command options, refer to “List of
voice commands” later in this section.
Choosing a languageYou can interact with the Bluetooth
Hands-
Free Phone System using English, Spanish or
French.
To change the language, perform the following.
1. Press and hold the
button for more
than 5 seconds.
2. The system announces: “Press the PHONE
SEND (
) button for the hands-free
phone system to enter the speaker adapta-
tion mode or press the PHONE END
(
) button to select a different lan-
guage.”
3. Press the
button.
For information on speaker adaptation, see“Speaker adaptation (SA) mode” later in this
section.
4. The system announces the current language
and gives you the option to change the
language to Spanish (in Spanish) or French
(in French). Use the following chart to select
the language.
NOTE:
You must press the
button or the
button within 5 seconds to change
the language.Current
languagePress
(TALK/PHONE
SEND)
to selectPress
(MODE/PHONE
END)
to select
English Spanish French
Spanish English French
French English Spanish
5. If you decide not to change the language, do
not press either button. After 5 seconds, the
VR session will end, and the language will not
be changed.
SAA1700
Display screen, heater, air conditioner and audio systems
4-35


07.2.9/Z33-D/V5.0


Pairing procedure1. Push the
button on the steering wheel.
The system announces the available com-
mands.
2. Say: “Setup”A. The system acknowledges
the command and announces the next set of
available commands.
3. Say: “Pair phone”B. The system acknowl-
edges the command and announces the next
set of available commands.
4. Say: “New phone”C. The system acknowl-
edges the command and asks you to initiate
pairing from the phone handset
D.
When you are asked to enter a PIN code for
pairing your Bluetooth
cellular phone, oper-
ate it to enter the code “1234”.The code is always “1234” regardless of the
number of phones paired.
The pairing procedure of the cellular phone
varies according to each cellular phone. See
the cellular phone Owner’s Manual for de-
tails. You can also visit www.nissanusa.com/
bluetooth for instructions on pairing NISSAN
recommended cellular phones.
5. The system asks you to say a name for the
phone
E.
If the name is too long or too short, the
system tells you, then prompts you for a name
again.
Also, if more than one phone is paired and
the name sounds too much like a name
already used, the system tells you, then
prompts you for a name again.
6. The system asks you to assign a priority level
F. The priority level determines which phone
is active when more than one paired
Bluetooth
phone is in the vehicle. Follow the
instructions provided by the system or refer
to “Setup” later in this section for more
information on changing priorities.
7. The system will ask if you would like to select
a custom ring tone
G. Follow the instruc-
tions provided by the system or refer to
“Setup” later in this section for more informa-tion on selecting ringtones.
Making a call by entering a phone
number1. Push the
button on steering wheel. A
tone will sound.
2. Say: “Call”
A. The system acknowledges
the command and announces the next set of
available commands.
3. Say the number you wish to call
B. For
example, 555-1212 can be said as “five five
five one two one two.” See “How to say
numbers” earlier in this section for more
information.
4. When you have finished speaking the phone
number, the system repeats it back and
announces the available commands.
5. Say: “Dial”
C. The system acknowledges the
command and makes the call.
For additional command options, see “List of
voice commands” later in this section.
4-36
Display screen, heater, air conditioner and audio systems


07.2.9/Z33-D/V5.0


Receiving a callWhen you hear the ring tone, press the
button on the steering wheel.
Once the call has ended, press the
button
on the steering wheel.
NOTE:
If you do not wish to take the call when you
hear the ring tone, press thebutton
on the steering wheel to reject the call.
For additional command options, see “List of
voice commands” later in this section.
LIST OF VOICE COMMANDSWhen you push and release the
button on
the steering wheel, you can choose from the
commands on the Main Menu. The following
pages describe these commands and the com-
mands in each sub-menu.
Remember to wait for the tone before
speaking.You can say “Help” to hear the list of commands
currently available anytime the system is waiting
for a response.
If you want to end an action without completing
it, you can say “Cancel” or “Quit” at anytime the
system is waiting for a response. The system will
end the VR session. Whenever the VR session is
cancelled, a double beep is played to indicate
you have exited the system.
If you want to go back to the previous command,
you can say “Go back” or “Correction” anytime
the system is waiting for a response.
When you get used to the menus in the system,
you can talk ahead by saying more than one
command at a time. For example, say, “Call five
five five one two one two” or “Memo pad record.”
Also, when you get used to the system re-
sponses, you can skip ahead to the tone by
pressing the
button on the steering wheel.
However, if you press the
button when the
system is waiting for a response from you it will
end the VR session.
“Call”Name (speak name)
A
If you have stored entries in the Phone Book, you
can dial a number associated with a name and
location.
See “Phone book” later in this section to learn
how to store entries.
When prompted by the system, say the name of
the phone book entry you wish to call. The
system acknowledges the name.
If there are multiple locations associated with the
name, the system asks you to choose the loca-
tion.
Once you have confirmed the name and loca-
tion, the system begins the call.
Number (speak digits)
B
When prompted by the system, say the number
Display screen, heater, air conditioner and audio systems
4-37


07.2.9/Z33-D/V5.0
