2007 NISSAN 350Z Maintenance Workshop Manual

MA-1
MAINTENANCE
L MAINTENANCE
CONTENTS
C
D
E
F
G
H
I
J
K
M
SECTION MA
A
B
MA
Revision: 2006 November2007 350Z
MAINTENANCE
PRECAUTIONS .......................................................... 3
Precautions for Battery Service ................................ 3
PREPARATION ........................................................... 4
Special Service Tools ............................................... 4
Commercial Service Tools ........................................ 4
GENERAL MAINTENANCE ....................................... 5
Explanation of General Maintenance ....................... 5
PERIODIC MAINTENANCE ....................................... 7
Introduction of Periodic Maintenance ....................... 7
Schedule 1 ............................................................... 8
EMISSION CONTROL SYSTEM MAINTE-
NANCE .................................................................. 8
CHASSIS AND BODY MAINTENANCE ............... 9
Schedule 2 ............................................................. 10
EMISSION CONTROL SYSTEM MAINTE-
NANCE ................................................................ 10
CHASSIS AND BODY MAINTENANCE ............. 10
RECOMMENDED FLUIDS AND LUBRICANTS .......11
Fluids and Lubricants .............................................. 11
Engine Oil Recommendation ................................. 12
ANTI-FREEZE COOLANT MIXTURE RATIO ..... 12
ENGINE MAINTENANCE ......................................... 13
Checking Drive Belts .............................................. 13
Tension Adjustment ................................................ 13
Changing Engine Coolant ...................................... 13
DRAINING ENGINE COOLANT ......................... 13
REFILLING ENGINE COOLANT ........................ 14
FLUSHING COOLING SYSTEM ......................... 15
Checking Fuel Lines ............................................... 16
Changing Air Cleaner Filter .................................... 16
VISCOUS PAPER TYPE ..................................... 16
Changing Engine Oil .............................................. 16
Changing Oil Filter ................................................. 17
REMOVAL ........................................................... 17
INSTALLATION ................................................... 17
INSPECTION AFTER INSTALLATION ............... 18
Changing Spark Plugs (Iridium-Tipped Type) ........ 18
REMOVAL ........................................................... 18
INSPECTION AFTER REMOVAL ....................... 18INSTALLATION ................................................... 19
Checking EVAP Vapor Lines .................................. 19
CHASSIS AND BODY MAINTENANCE ................... 20
Checking Exhaust System ...................................... 20
Checking Clutch Fluid Level and Leaks ................. 20
Checking M/T Oil .................................................... 20
Changing M/T Oil .................................................... 20
Checking A/T Fluid ................................................. 20
Changing A/T Fluid ................................................. 22
Checking Differential Gear Oil ................................ 23
Changing Differential Gear Oil ................................ 23
Balancing Wheels (Bonding Weight Type) ............. 23
REMOVAL ........................................................... 23
WHEEL BALANCE ADJUSTMENT ..................... 23
Tire Rotation ........................................................... 25
Checking Brake Fluid Level and Leaks .................. 25
Checking Brake Lines and Cables ......................... 25
Changing Brake Fluid ............................................. 25
Checking Disc Brake .............................................. 25
ROTOR ................................................................ 25
CALIPER ............................................................. 26
PAD ..................................................................... 26
Checking Steering Gear and Linkage ..................... 26
STEERING GEAR ............................................... 26
STEERING LINKAGE ......................................... 26
Checking Power Steering Fluid and Lines .............. 27
Axle and Suspension Parts .................................... 27
Lubricating Locks, Hinges and Hood Latch (Coupe) ... 28
Lubricating Locks, Hinges and Hood Latch (Road-
ster) ........................................................................ 28
Checking Seat Belt, Buckles, Retractors, Anchors
and Adjusters .......................................................... 29
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 30
Standard and Limit .................................................. 30
BELT DEFLECTION AND TENSION .................. 30
ENGINE COOLANT CAPACITY (APPROXI-
MATE) .................................................................. 30
ENGINE OIL CAPACITY (APPROXIMATE) ........ 30
SPARK PLUG (IRIDIUM-TIPPED TYPE) ............ 30

MA-2Revision: 2006 November2007 350Z WHEEL BALANCE .............................................. 30
Tightening Torque ................................................... 30

PRECAUTIONS
MA-3
C
D
E
F
G
H
I
J
K
MA
B
MA
Revision: 2006 November2007 350Z
PRECAUTIONSPFP:00001
Precautions for Battery ServiceNLS00001
Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interfer-
ence between the window edge and the vehicle when the door is opened/closed. During normal operation, the
window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic
window function will not work with the battery disconnected.

MA-4
PREPARATION
Revision: 2006 November2007 350Z
PREPARATIONPFP:00002
Special Service ToolsNLS00002
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Commercial Service ToolsNLS00003
Tool number
(Kent-Moore No.)
Tool nameDescription
KV10115801
(J38956)
Oil filter wrenchRemoving and installing oil filter
a: 64.3 mm (2.531 in)
S-NT375
(Kent-Moore No.)
Tool nameDescription
Power toolLoosening bolts and nuts
Spark plug wrench Removing and installing spark plug
PBIC0190E
PBIC3874E

GENERAL MAINTENANCE
MA-5
C
D
E
F
G
H
I
J
K
MA
B
MA
Revision: 2006 November2007 350Z
GENERAL MAINTENANCEPFP:00000
Explanation of General MaintenanceNLS00004
General maintenance includes those items which should be checked during the normal day-to-day operation
of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform
checks and inspections themselves or have their NISSAN dealers do them.
OUTSIDE THE VEHICLE
The maintenance items listed here should be performed from time to time, unless otherwise specified.
INSIDE THE VEHICLE
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the
vehicle, etc.ItemReference page
TiresCheck the pressure with a gauge, including the spare, at least once a month
and always prior to a long distance trips. Adjust to the specified pressure if nec-
essary. Check carefully for damage, cuts or excessive wear.—
Wheel nutsWhen checking the tires, make sure no nuts are missing, and check for any
loose nuts. Tighten if necessary.—
WindshieldClean the windshield on a regular basis. Check the windshield at least every six
months for cracks or other damage. Repair as necessary.—
Tire rotationTires cannot be rotated in this vehicle, as front tires are different size from rear
tires and the direction of wheel rotation is fixed in each tire.MA-25
Transmitter compo-
nents in tire pressure
monitoring system
(TPMS)Replace grommet seal, valve core and cap of the transmitter in TPMS every tire
replacement by reaching wear limit of tire.WT-10
Wheel alignment and
balanceIf the vehicle pulls to either side while driving on a straight and level road, or if
you detect uneven or abnormal tire wear, there may be a need for wheel align-
ment. If the steering wheel or seat vibrates at normal highway speeds, wheel
balancing may be needed.MA-23
, FSU-6
Windshield wiper
bladesCheck for cracks or wear if they do not wipe properly. —
Doors and engine
hoodCheck that all doors and the engine hood operate smoothly as well as the trunk
lid and back hatch. Also make sure that all latches lock securely. Lubricate if
necessary. Make sure that the secondary latch keeps the hood from opening
when the primary latch is released.
When driving in areas using road salt or other corrosive materials, check lubri-
cation frequently.MA-28
LampsMake sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and
other lamps are all operating properly and installed securely. Also check head-
lamp aim. Clean the headlamps on a regular basis. —
ItemReference page
Warning lamps and
chimesMake sure that all warning lamps and chimes are operating properly. —
Windshield wiper and
washerCheck that the wipers and washer operate properly and that the wipers do not
streak.—
Windshield defrosterCheck that the air comes out of the defroster outlets properly and in sufficient
quantity when operating the heater or air conditioner.—
Steering wheelCheck that it has the specified play. Be sure to check for changes in the steering
condition, such as excessive play, hard steering or strange noises.
Free play: Less than 35 mm (1.38 in)—
SeatsCheck seat position controls such as seat adjusters, seatback recliner, etc. to
make sure they operate smoothly and that all latches lock securely in every
position. Check that the head restrains move up and down smoothly and that
the locks (if equipped) hold securely in all latched positions. Check that the
latches lock securely for folding-down rear seatbacks.—

MA-6
GENERAL MAINTENANCE
Revision: 2006 November2007 350Z
UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).Seat beltsCheck that all parts of the seat belt system (e.g. buckles, anchors, adjusters and
retractors) operate properly and smoothly, and are installed securely. Check the
belt webbing for cuts, fraying, wear or damage.MA-29
Accelerator pedalCheck the pedal for smooth operation and make sure the pedal does not catch
or require uneven effort. Keep the floor mats away from the pedal.—
Clutch PedalMake sure the pedal operates smoothly and check it has the proper free play. —
BrakesCheck that the brake does not pull the vehicle to one side when applied. —
Brake pedal and
boosterCheck the pedal for smooth operation and make sure it has the proper distance
under it when depressed fully. Check the brake booster function. Be sure to
keep the floor mats away from the pedal.BR-7
, BR-23
Parking brakeCheck that the lever has the proper travel and make sure that the vehicle is held
securely on a fairly steep hill when only the parking brake is applied.PB-3
Automatic transmis-
sion “Park” mecha-
nismCheck that the lock release button on the selector lever operates properly and
smoothly. On a fairly steep hill check that the vehicle is held securely with the
selector lever in the “P” position without applying any brakes.— ItemReference page
ItemReference page
Windshield washer
fluidCheck that there is adequate fluid in the tank. —
Engine coolant levelCheck the coolant level when the engine is cold.MA-13
Radiator and hosesCheck the front of the radiator and clean off any dirt, insects, leaves, etc., that
may have accumulated. Make sure the hoses have no cracks, deformation,
deterioration or loose connections.—
Brake and clutch fluid
levelsMake sure that the brake and clutch fluid levels are between the “MAX” and
“MIN” lines on the reservoirs.MA-25
, MA-20
BatteryCheck the fluid level in each cell. It should be between the “MAX” and “MIN”
lines. Vehicles operated in high temperatures or under severe conditions require
frequent checks of the battery fluid level.—
Engine drive beltsMake sure that no belt is frayed, worn, cracked or oily.MA-13
Engine oil levelCheck the level on oil level gauge after parking the vehicle on a level spot and
turning off the engine.MA-16
Power steering fluid
level and linesCheck the level on the dipstick with the engine off. Check the lines for improper
attachment, leaks, cracks, etc.MA-27
Exhaust systemMake sure there are no loose supports, cracks or holes. If the sound of the
exhaust seems unusual or there is a smell of exhaust fumes, immediately locate
the trouble and correct it.MA-20
UnderbodyThe underbody is frequently exposed to corrosive substances such as those
used on icy roads or to control dust. It is very important to remove these sub-
stances, otherwise rust will form on the floor pan, frame, fuel lines and around
the exhaust system. At the end of winter, the underbody should be thoroughly
flushed with plain water, being careful to clean those areas where mud and dirt
can easily accumulate.—
Fluid leaksCheck under the vehicle for fuel, oil, water or other fluid leaks after the vehicle
has been parked for a while. Water dripping from the air conditioner after use is
normal. If you should notice any leaks or gasoline fumes are evident, check for
the cause and correct it immediately.—

PERIODIC MAINTENANCE
MA-7
C
D
E
F
G
H
I
J
K
MA
B
MA
Revision: 2006 November2007 350Z
PERIODIC MAINTENANCEPFP:00026
Introduction of Periodic MaintenanceNLS00005
Two different maintenance schedules are provided, and should be used, depending upon the conditions in
which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic
maintenance at the same mileage/time intervals.
Schedule 1Follow Periodic Maintenance Schedule 1 if the driving habits frequently include
one or more of the following driving conditions:

Repeated short trips of less than 5 miles (8 km).

Repeated short trips of less than 10 miles (16 km) with outside temperatures
remaining below freezing.

Operating in hot weather in stop-and-go “rush hour” traffic.

Extensive idling and/or low speed driving for long distances, such as police,
taxi or door-to-door delivery use.

Driving in dusty conditions.

Driving on rough, muddy, or salt spread roads.

Towing a trailer, using a camper or a car-top carrier.Emission Control Sys-
tem Maintenance
MA-8
Chassis and Body
Maintenance
MA-9
Schedule 2Follow Periodic Maintenance Schedule 2 if none of driving conditions shown in
Schedule 1 apply to the driving habits.Emission Control Sys-
tem MaintenanceMA-10Chassis and Body
MaintenanceMA-10

MA-8
PERIODIC MAINTENANCE
Revision: 2006 November2007 350Z
Schedule 1NLS00006
EMISSION CONTROL SYSTEM MAINTENANCE
Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. [ ]: At the mileage intervals only
NOTE:
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found
damaged or if auto belt tensioner reading reaches maximum limit.
(2) If operating mainly in dusty conditions, more frequent maintenance may be required.
(3) Maintenance-free item. For service procedures, refer to FL section.
(4) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(5) If valve noise increases, inspect valve clearance.
* Maintenance items and intervals with “*” are recommended by NISSAN for reliable vehicle operation. The owner need not perform
such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are
required.MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference
Section -
Page or -
Content Title Perform at number of miles,
kilometers or months, which-
ever comes first.Miles x 1,000
(km x 1,000)
Months3.75
(6)
37.50
(12)
611 . 2 5
(18)
915
(24)
1218.75
(30)
1522.5
(36)
1826.25
(42)
2130
(48)
24
Drive belts NOTE (1)MA-13
Air cleaner filter NOTE (2) [R]MA-16
EVAP vapor linesI*MA-19
Fuel linesI*MA-16
Fuel filter NOTE (3)-
Engine coolant NOTE (4)MA-13
Engine oil R R RRRRR RMA-16
Engine oil filter (Use part No.
15208 65F01 or equivalent.)R R RRRRR RMA-17
Spark plugs (Iridium-tipped
type)Replace every 105,000 miles (169,000 km).MA-18
Intake & exhaust valve clear-
ance*NOTE (5)EM-80
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference
Section -
Page or -
Content Title Perform at number of miles,
kilometers or months, which-
ever comes first.Miles x 1,000
(km x 1,000)
Months33.75
(54)
2737.5
(60)
3041.25
(66)
3345
(72)
3648.75
(78)
3952.5
(84)
4256.25
(90)
4560
(96)
48
Drive belts NOTE (1) I*MA-13
Air cleaner filter NOTE (2) [R]MA-16
EVAP vapor linesI*MA-19
Fuel linesI*MA-16
Fuel filter NOTE (3)-
Engine coolant NOTE (4) R*MA-13
Engine oil R R R R R R R RMA-16
Engine oil filter (Use part No.
15208 65F01 or equivalent.)R R RRRRRRMA-17
Spark plugs (Iridium-tipped
type)Replace every 105,000 miles (169,000 km).MA-18
Intake & exhaust valve clear-
ance*NOTE (5)EM-80
