Page 25 of 30
CHASSIS AND BODY MAINTENANCE
MA-25
C
D
E
F
G
H
I
J
K
MA
B
MA
Revision: 2006 November2007 350Z
Tire RotationNLS0000S
CAUTION:
Do not include the T-type spare tire when rotating the tires.
Use NISSAN genuine wheel nuts for aluminum wheels.
NOTE:
Tire cannot be rotated in vehicle, as front tire are different size from rear tire and the direction of wheel rotation
is fixed in each tire.
Checking Brake Fluid Level and LeaksNLS0000T
If fluid level is extremely low, check brake system for leaks.
Checking Brake Lines and CablesNLS0000U
Check brake fluid lines and parking brake cables for improper
attachment, leaks, chafing, abrasions, deterioration, etc.
Changing Brake FluidNLS0000V
1. Drain brake fluid from each bleed valve.
2. Refill until new brake fluid comes out from each bleed valve.
Use same procedure as in bleeding hydraulic system to refill
brake fluid.
Refer to BR-10, "
BRAKE FLUID" .
Refill with recommended Genuine Brake Fluid or equivalent
DOT 3 (US FMVSS No. 116).
Refer to MA-11, "
RECOMMENDED FLUIDS AND LUBRI-
CANTS" .
Never reuse drained brake fluid.
Be careful not to splash brake fluid on painted areas.
Checking Disc BrakeNLS0000W
ROTOR
Check condition, wear, and damage.
SBR451D
SBR389C
SBR419C
Front Rear
Brake model Other than brembo With brembo Other than brembo With brembo
Standard thickness (new) 28.0 mm (1.102 in) 30.0 mm (1.181 in) 16.0 mm (0.630 in) 22.0 mm (0.866 in)
Runout limit (with it attached to
the vehicle)0.035 mm (0.0014 in) 0.040 mm (0.0016 in) 0.055 mm (0.0022 in) 0.07 mm (0.0028 in)
Repair limit thickness 26.0 mm (1.024 in) 28.4 mm (1.118 in) 14.0 mm (0.551 in) 20.2 mm (0.795 in)
Page 26 of 30
MA-26
CHASSIS AND BODY MAINTENANCE
Revision: 2006 November2007 350Z
CALIPER
Check for leakage.
PA D
Check for wear or damage.
Checking Steering Gear and LinkageNLS0000X
STEERING GEAR
Check gear housing and boots for looseness, damage and
grease leakage.
Check connection with steering column for looseness.
STEERING LINKAGE
Check ball joint, dust cover and other component parts for looseness, wear, damage and grease leakage.
SMA922A
BRA0010D
Front Rear
Brake model Other than brembo With brembo Other than brembo With brembo
Standard thickness (new) 11.0 mm (0.433 in) 9.3 mm (0.366 in) 8.5 mm (0.335 in) 9.1 mm (0.358 in)
Repair limit thickness 2.0 mm (0.079 in) 2.0 mm (0.079 in) 2.0 mm (0.079 in) 2.0 mm (0.079 in)
SLIA0014E
Page 27 of 30
CHASSIS AND BODY MAINTENANCE
MA-27
C
D
E
F
G
H
I
J
K
MA
B
MA
Revision: 2006 November2007 350Z
Checking Power Steering Fluid and LinesNLS0000Y
Check fluid level in reservoir tank with engine off.
Use “HOT” range at fluid temperatures of 50 to 80°C (122 to 176°F)
or “COLD” range at fluid temperatures of 0 to 30°C (32 to 86°F).
CAUTION:
Do not overfill.
Recommended fluid is Genuine NISSAN PSF or equivalent.
Refer to MA-11, "
RECOMMENDED FLUIDS AND LUBRI-
CANTS"
Check lines for improper attachment, leaks, cracks, dam-
age, loose connections, chafing and deterioration.
Check rack boots for accumulation of power steering fluid.
Axle and Suspension PartsNLS0000Z
Check front and rear axle and suspension parts for excessive play,
cracks, wear or other damage.
Shake each wheel to check for excessive play.
Check wheel bearings for smooth operation.
Check axle and suspension nuts and bolts for looseness.
Check strut (shock absorber) for oil leakage or other damage.
Check suspension ball joint for grease leakage and ball joint
dust cover for cracks or other damage.
SST850C
SST851C
SMA525A
SFA392B
Page 28 of 30
MA-28
CHASSIS AND BODY MAINTENANCE
Revision: 2006 November2007 350Z
Lubricating Locks, Hinges and Hood Latch (Coupe)NLS00010
Lubricating Locks, Hinges and Hood Latch (Roadster)NLS00011
PIIA2512E
PIIA7636E
Page 29 of 30
CHASSIS AND BODY MAINTENANCE
MA-29
C
D
E
F
G
H
I
J
K
MA
B
MA
Revision: 2006 November2007 350Z
Checking Seat Belt, Buckles, Retractors, Anchors and AdjustersNLS0005L
CAUTION:
After any collision, inspect all seat belt assemblies, including retractors and other attached hard-
wares (I.e. anchor bolt, guide rail set). Nissan recommends to replace all seat belt assemblies in
use during a collision, unless not damaged and properly operating after minor collision.
Also inspect seat belt assemblies not in use during a collision, and replace if damaged or improp-
erly operating.
Seat belt pre-tensioner should be replaced even if the seat belts are not in use during a frontal col-
lision where the driver and passenger air bags are deployed.
If any component of seat belt assembly is questionable, do not repair.
Replace as seat belt assembly.
If webbing is cut, frayed, or damaged, replace belt assembly.
Never oil tongue and buckle.
Use a genuine NISSAN seat belt assembly.
For details, refer to Refer to Service Manual in SB section.
Check anchors for loose mounting
Check belts for damage
Check retractor for smooth operation
Check function of buckles and tongues when buckled and released
PIIB7159E
Page 30 of 30
MA-30
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2006 November2007 350Z
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Standard and LimitNLS00014
BELT DEFLECTION AND TENSION
ENGINE COOLANT CAPACITY (APPROXIMATE)
Unit: (US qt, lmp qt)
ENGINE OIL CAPACITY (APPROXIMATE)
Unit: (US qt, lmp qt)
SPARK PLUG (IRIDIUM-TIPPED TYPE)
WHEEL BALANCE
Tightening TorqueNLS00015
Unit: N·m (kg-m, ft-lb),
Unit: N·m (kg-m, in-lb)* Tension of drive belts Auto adjustment by auto tensioner
Engine coolant capacity (With reservoir tank at “MAX” level) 9.0 (9-1/2, 7-7/8)
Reservoir tank engine coolant capacity (at MAX level) 0.8 (7/8, 3/4)
Drain and refill With oil filter change 4.9 (5-1/8, 4-1/4)
Without oil filter change 4.6 (4-7/8, 4)
Dry engine (Overhaul)5.5 (5-3/4, 4-7/8)
MakeDENSO
Standard typeFXE22HR-11
Gap (Nominal)1.1 mm (0.043 in)
Maximum allowable unbalanceDynamic (At rim flange) Less than 5 g (0.17 oz) (one side)
Static (At rim flange) Less than 10 g (0.35 oz)
Radiator drain plug1.2 (0.12, 11)*
Air relief plug1.2 (0.12, 11)*
Oil pan drain plug34.3 (3.5, 25)
Oil filter17.7 (1.8, 13)
Spark plug19.6 (2.0, 14)
