PRECAUTIONS PFP:00011
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
NKS0005P
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Battery ServiceNKS0005Q
Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interfer-
ence between the window edge and the vehicle when the door is opened/closed. During normal operation, the
window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic
window function will not work with the battery disconnected.

DI-44
UNIFIED METER AND A/C AMP
Revision: 2006 November2007 350Z
UNIFIED METER AND A/C AMPPFP:27760
System DescriptionNKS0006X
DESCRIPTION

For the unified meter and A/C amp., the signal required for con-
trolling the combination meter and triple meter are integrated in
the A/C auto amp.

Unified meter and A/C amp. corresponds a CONSULT-III func-
tion (self-diagnosis results, CAN diagnosis support monitor and
data monitor).
COMBINATION METER CONTROL FUNCTION

Unified meter and A/C amp. receives necessary information for combination meter from each unit.

Unified meter and A/C amp. converses with the combination meter transmits a signal through with com-
munication line (TX, RX) between unified meter and A/C amp. and combination meter.
Input/output signals between unified meter and A/C amp. and combination meter.
NOTE:
Combination meter performs fail-safe operation when unified meter and A/C amp. communication is malfunctioning. Refer to DI-7,
"FAIL-SAFE" .
SKIB0018E
Unit Input Output
Unified meter and A/C amp.

Seat belt buckle switch signal (Driver's side)

Trip computer mode switch signal

Trip computer setting switch signal

Illumination control nighttime required signal

Refuel status signal

Vehicle speed signal

Low-fuel warning lamp condition signal

Self-diagnosis condition signal

Odo/trip switch signal

Delivery destination data signal

Combination meter receive error signal

Combination meter specifications signal

Triple meter specifications signal

Engine speed signal

Engine coolant temperature signal

Fuel level sensor signal (resistance value)

Malfunction indicator lamp signal

ABS warning lamp signal

Tire pressure warning lamp signal

Brake warning lamp signal

Oil pressure warning lamp signal

Turn indicator signal

High beam request signal

VDC OFF indicator lamp signal

TCS OFF indicator lamp signal

SLIP indicator lamp signal

CRUISE indicator lamp signal

SET indicator lamp signal

A/T CHECK indicator lamp signal

A/T position indicator signal

Manual mode indicator signal

Manual mode gear position signal

Shift-up indicator setting signal

CAN communication condition signal of A/T

Door switch signal

Position lights request signal

Buzzer output signal

WARNING CHIME
DI-71
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2006 November2007 350Z
WARNING CHIMEPFP:24814
System DescriptionNKS00266

The buzzer for warning chime system is installed in the combination meter.

The buzzer sounds when the combination meter receives buzzer output signal from each unit through uni-
fied meter and A/C amp.
IGNITION KEY WARNING CHIME
With the key inserted into the key switch, and the ignition switch in OFF or ACC position, when driver's door is
open, the ignition key warning chime sounds.

BCM detects key inserted into the key switch, ignition switch in OFF or ACC position, and driver side door
switch ON. And then, BCM transmits buzzer output signal (ignition key warning chime) to unified meter
and A/C amp. with CAN communication.

Unified meter and A/C amp. transmits buzzer output signal (ignition key warning chime) to combination
meter with communication line.

When combination meter receives buzzer output signal (ignition key warning chime), it sounds the buzzer.
LIGHT WARNING CHIME
With ignition switch in OFF or ACC position, drivers door open, and lighting switch in 1ST or 2ND position, the
light warning chime will sounds.

BCM detects ignition switch in OFF or ACC position, driver side door switch ON, and lighting switch in
1ST or 2ND position. And then, BCM transmits buzzer output signal (light warning chime) to unified meter
and A/C amp. with CAN communication line.

Unified meter and A/C amp. transmits buzzer output signal (light warning chime) to combination meter
with communication line.

When combination meter receives buzzer output signal (light warning chime), it sounds the buzzer.
NOTE:
For further details of combination switch, refer to LT- 8 7 , "
Combination Switch Reading Function" .
PKIC4374E
PKIC4375E

WARNING CHIME
DI-77
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2006 November2007 350Z
Terminals and Reference Value for BCMNKS0007K
CAUTION:

Check combination switch system terminal waveform under the loaded condition with lighting
switch, turn signal switch and wiper switch OFF not to be fluctuated by overloaded.

Turn wiper dial position to 4 except when checking waveform or voltage of wiper dial position.
Wiper dial position can be confirmed on CONSULT-III. Refer to LT- 9 1 , "
DATA MONITOR" .
Terminal
No.Wire
colorSignal nameMeasuring condition
Reference value
(Approx.) Igni-
tion
switchOperation or condition
2GYCombination
switch input 5ONLighting,
turn, wiper
switch
(Wiper
intermit-
tent dial
position 4)OFF 0 V
Any of the conditions below

Lighting switch 1ST

Lighting switch HIGH beam
(Operates only HIGH beam
switch)

Turn signal switch to right
1.0 V
Lighting switch 2ND
2.0 V
3L/WCombination
switch input 4ONLighting,
turn, wiper
switch
(Wiper
intermit-
tent dial
position 4)OFF 0 V
Any of the conditions below

Lighting switch 2ND

Lighting switch PASSING
(Operates only PASSING switch)

Turn signal switch to left
1.0 V
4PU/WCombination
switch input 3ONLighting,
turn, wiper
switch
(Wiper
intermit-
tent dial
position 4)OFF 0 V
Any of the conditions below

Front wiper switch MIST

Front wiper switch INT

Front wiper switch LO
1.0 V
PKIB4959J
PKIB4953J
PKIB4959J
PKIB4959J

DI-78
WARNING CHIME
Revision: 2006 November2007 350Z
5Y/RCombination
switch input 2ONLighting,
turn, wiper
switchOFF
(Wiper intermittent dial position 4)0 V
Any of the conditions below

Front washer switch

Rear washer switch

Wiper intermittent dial position 1

Wiper intermittent dial position 5

Wiper intermittent dial position 6
1.0 V
Rear wiper switch ON
(Wiper intermittent dial position 4)
0.8 v
6Y/GCombination
switch input 1ONLighting,
turn, wiper
switchOFF
(Wiper intermittent dial position 4)0 V
Any of the conditions below

Front wiper switch HI

Rear wiper switch INT

Wiper intermittent dial position 3
1.0 V
Any of the conditions below

Wiper intermittent dial position 1

Wiper intermittent dial position 2
1.7 V
Any of the conditions below

Wiper intermittent dial position 6

Wiper intermittent dial position 7
0.8 V Te r m i n a l
No.Wire
colorSignal nameMeasuring condition
Reference value
(Approx.) Igni-
tion
switchOperation or condition
PKIB4959J
PKIB4955J
PKIB4959J
PKIB4952J
PKIB4955J

WARNING CHIME
DI-79
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2006 November2007 350Z
18 BRemote key-
less entry
receiver
(Ground)
——Refer to WT-20, "
Control Unit
Input/Output Signal Standard" . 19 YRemote key-
less entry
receiver
(Power sup-
ply)
20 LRemote key-
less entry
receiver (Sig-
nal)
32 G/BCombination
switch output
5ONLighting,
turn, wiper
switchOFF
(Wiper intermittent dial position 4)
7.2 V
Any of the conditions below

Wiper intermittent dial position 1

Wiper intermittent dial position 2

Wiper intermittent dial position 6

Wiper intermittent dial position 7
1.0 V
33 GCombination
switch output
4ONLighting,
turn, wiper
switchOFF
(Wiper intermittent dial position 4)
7.2 V
Any of the conditions below

Lighting switch 1ST (The same
result with lighting switch 2ND)

Rear wiper switch INT

Wiper intermittent dial position 1

Wiper intermittent dial position 5

Wiper intermittent dial position 6
1.2 V Terminal
No.Wire
colorSignal nameMeasuring condition
Reference value
(Approx.) Igni-
tion
switchOperation or condition
PKIB4960J
PKIB4956J
PKIB4960J
PKIB4958J

DI-80
WARNING CHIME
Revision: 2006 November2007 350Z
34 W/LCombination
switch output
3ONLighting,
turn, wiper
switchOFF
(Wiper intermittent dial position 4)
7.2 V
Any of the conditions below

Lighting switch 2ND

Lighting switch HI beam
(Operates only HI beam switch)

Rear washer switch

Wiper intermittent dial position 1

Wiper intermittent dial position 2

Wiper intermittent dial position 31.2 V
35 W/GCombination
switch output
2ONLighting,
turn, wiper
switch
(Wiper
intermit-
tent dial
position 4)OFF
7.2 V
Any of the conditions below

Lighting switch 2ND

Lighting switch PASSING
(Operates only PASSING switch)

Front wiper switch INT

Front wiper switch HI
1.2 V
36 W/RCombination
switch output
1ONLighting,
turn, wiper
switch
(Wiper
intermit-
tent dial
position 4)OFF
7.2 V
Any of the conditions below

Turn signal switch to right

Turn signal switch to left

Front wiper switch MIST

Front wiper switch LO

Front washer switch
1.2 V Te r m i n a l
No.Wire
colorSignal nameMeasuring condition
Reference value
(Approx.) Igni-
tion
switchOperation or condition
PKIB4960J
PKIB4958J
PKIB4960J
PKIB4958J
PKIB4960J
PKIB4958J
