DRIVER INFORMATION SYSTEM
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions for Battery Service ................................ 3
COMBINATION METERS ........................................... 4
System Description .................................................. 4
UNIFIED METER CONTROL UNIT ...................... 4
UNIFIED METER AND A/C AMP. ......................... 4
POWER SUPPLY AND GROUND CIRCUIT ........ 4
SPEEDOMETER ................................................... 4
TACHOMETER ..................................................... 5
WATER TEMPERATURE GAUGE ........................ 5
FUEL GAUGE ....................................................... 5
ODO/TRIP METER ............................................... 5
ILLUMINATION CONTROL ................................... 6
SHIFT-UP INDICATOR ......................................... 7
FAIL-SAFE ............................................................ 7
Component Parts and Harness Connector Location ..... 8
Arrangement of Combination Meter ......................... 9
Schematic .............................................................. 10
Wiring Diagram — METER — ................................. 11
Terminals and Reference Value for Combination
Meter ...................................................................... 13
Terminals and Reference Value for Unified Meter
and A/C Amp. ......................................................... 14
Self-Diagnosis Mode of Combination Meter ........... 15
SELF-DIAGNOSIS FUNCTION .......................... 15
OPERATION PROCEDURE ............................... 15
CONSULT-III Function (METER A/C AMP) ............ 15
Trouble Diagnosis .................................................. 16
HOW TO PERFORM TROUBLE DIAGNOSIS ... 16
PRELIMINARY CHECK ...................................... 16
Symptom Chart ...................................................... 16
Power Supply and Ground Circuit Inspection ........ 17
Vehicle Speed Signal Inspection ............................ 18
Engine Speed Signal Inspection ............................ 19
Engine Coolant Temperature Signal Inspection ..... 19
Fuel Level Sensor Signal Inspection ...................... 19
Illumination Control Switch Inspection ................... 21Fuel Gauge Pointer Fluctuates, Indicator Wrong
Value or Varies ....................................................... 22
Fuel Gauge Does Not Move to FULL Position ....... 22
Electrical Components Inspection .......................... 23
FUEL LEVEL SENSOR UNIT ............................. 23
Removal and Installation for Combination Meter .... 24
REMOVAL ........................................................... 24
INSTALLATION ................................................... 24
Disassembly and Assembly for Combination Meter ... 24
DISASSEMBLY ................................................... 24
ASSEMBLY ......................................................... 25
TRIPLE METERS ...................................................... 26
System Description ................................................. 26
TRIPLE METER .................................................. 26
UNIFIED METER AND A/C AMP. ........................ 26
POWER SUPPLY AND GROUND CIRCUIT ....... 26
VOLTMETER ....................................................... 26
OIL PRESSURE GAUGE .................................... 26
TRIP COMPUTER ............................................... 27
FAIL-SAFE .......................................................... 29
Schematic ............................................................... 30
Wiring Diagram — 3METER — .............................. 31
Terminals and Reference Value for Triple Meter .... 35
Terminals and Reference Value for Unified Meter
and A/C Amp. ......................................................... 36
Terminals and Reference Value for Combination
Meter ...................................................................... 37
Self-Diagnosis Mode of Triple Meter ...................... 38
SELF-DIAGNOSIS FUNCTION ........................... 38
OPERATION PROCEDURE ................................ 38
CONSULT-III Function (METER A/C AMP) ............ 38
Trouble Diagnosis ................................................... 39
HOW TO PERFORM TROUBLE DIAGNOSIS .... 39
PRELIMINARY CHECK ....................................... 39
Symptom Chart ....................................................... 39
Vehicle Speed Signal Inspection ............................ 40
Fuel Consumption Monitor Signal Inspection ......... 40
Oil Pressure Sensor Signal Inspection ................... 40
Trip Computer Switch Inspection ............................ 42
Removal and Installation of Triple Meters .............. 42

COMBINATION METERS
DI-7
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2006 November2007 350Z
SHIFT-UP INDICATOR

Shift-up indicator can be used when shifting up at a constant
engine speed from any gear while driving. It becomes a guide
for shift-up timing.

Shift-up indicator flashes approximately 500 rpm before reach-
ing the engine speed set. It illuminates when reaching the
engine speed set.
Shift-up engine speed can be set by the shift-up indicator setting
mode on trip computer. Refer to DI-29, "
Shift-up Indicator Setting
Mode" .
NOTE:

There may be a time lag between the shift-up indicator illumina-
tion and the tachometer indication.

If the battery cable is disconnected, the set engine speed becomes 7,000 rpm.
FA I L - S A F E
Combination meter performs fail-safe operation when unified meter and A/C amp. communication is malunc-
tion.
PKIA2097E
Function Fail-safe operation
Speedometer Return to zero
Tachometer
Reset to zero Fuel gauge
Water temperature gauge
Illumination control Combination meter illumination Change to nighttime mode
Odo/trip meter Integrate in response to 8-pulse input
A/T indicator The display turns OFF
Meter buzzer The meter buzzer turns OFF
Warning lamp/indicator lampABS warning lamp
The lamp turns ON VDC OFF indicator lamp
TCS OFF indicator lamp
SLIP indicator lamp
Brake warning lamp
Tire pressure warning lamp
A/T CHECK lamp
The lamp turns OFF Oil pressure warning lamp
Door warning lamp
High beam indicator lamp
Turn signal indicator lamp
Malfunction indicator lamp
CRUISE indicator lamp
SET indicator lamp

DI-16
COMBINATION METERS
Revision: 2006 November2007 350Z
Trouble DiagnosisNKS00061
HOW TO PERFORM TROUBLE DIAGNOSIS
1. Confirm the symptom or customer complaint.
2. Perform preliminary check. Refer to DI-16, "
PRELIMINARY CHECK" .
3. According to the symptom chart, make sure of the symptom cause and repair or replace applicable parts.
4. Does the meter operate normally? If so, GO TO 5. If not, GO TO 2.
5. INSPECTION END
PRELIMINARY CHECK
1. CHECK OPERATION OF SELF-DIAGNOSIS MODE (COMBINATION METER)
Perform self-diagnosis mode of combination meter. Refer to DI-15, "
SELF-DIAGNOSIS FUNCTION" .
Does self-diagnosis mode operation normally?
YES >> GO TO 2.
NO >> GO TO 3.
2. CHECK UNIFIED METER AND A/C AMP. (CONSULT-III)
Perform self-diagnosis of unified meter and A/C amp. Refer to DI-47, "
CONSULT-III Function (METER A/C
AMP)" .
Self-diagnostic results
No malfunction detected >> INSPECTION END
Malfunction detected >> Check applicable parts, and repair or replace corresponding parts.
3. CHECK POWER SUPPLY AND GROUND CIRCUIT OF COMBINATION METER
Check power supply and ground circuit of combination meter. Refer to DI-17, "
Power Supply and Ground Cir-
cuit Inspection" .
OK or NG
OK >> Replace combination meter.
NG >> Repair power supply and ground circuit of combination meter.
Symptom ChartNKS00062
Symptom Possible cause
Speedometer and odo/trip meter indication is malfunction. Refer to DI-18, "
Vehicle Speed Signal Inspection" .
Tachometer indication is malfunction. Refer to DI-19, "
Engine Speed Signal Inspection" .
Water temperature gauge indication is malfunction. Refer to DI-19, "
Engine Coolant Temperature Signal Inspection" .
Fuel gauge indication is malfunction.
Refer to DI-19, "
Fuel Level Sensor Signal Inspection" .
Low-fuel warning lamp indication is irregular.
A/T position indicator is malfunction. Refer to DI-70, "
A/T Indicator Is Malfunction" .
Illumination control does not operate. Refer to DI-21, "
Illumination Control Switch Inspection" .

DI-18
COMBINATION METERS
Revision: 2006 November2007 350Z
Vehicle Speed Signal InspectionNKS00065
Symptom: Indication is irregular for the Speedometer and odo/trip meter.
1. CHECK VDC/TCS/ABS CONTROL UNIT OR ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)
Perform the following units self-diagnosis.

VDC/TCS/ABS control unit [with VDC]. Refer to BRC-96, "CONSULT-III Functions (ABS)" .

ABS actuator and electric unit (control unit) [without VDC (with TCS)]. Refer to BRC-52, "CONSULT-III
MAIN FUNCTION" .

ABS actuator and electric unit (control unit) [without VDC (without TCS)]. Refer to BRC-19, "CONSULT-III
MAIN FUNCTION" .
Self
-diagnostic results
No malfunction detected >> GO TO 2.
Malfunction detected >> Check applicable parts, and repair or replace corresponding parts.
2. CHECK UNIFIED METER AND A/C AMP. OUTPUT SIGNAL
1. Start engine and drive vehicle at approximately 40 km/h (25 MPH).
2. Check voltage signal between unified meter and A/C amp. har-
ness connector M49 terminal 26 and ground.
OK or NG
OK >> GO TO 3.
NG >>

If monitor indicates “0 V” constantly, repair or replace malfunctioning parts after checking each
unit inputting vehicle speed signal (8 pulse), harness and connector between each unit and uni-
fied meter and A/C amp.

If monitor indicates “5 V” or “12 V” constantly, replace unified meter and A/C amp.
3. CHECK CONTINUITY BETWEEN COMBINATION METER AND UNIFIED METER AND A/C AMP.
1. Turn ignition switch OFF.
2. Disconnect combination meter connector and unified meter and A/C amp. connector.
3. Check continuity between combination meter harness connector
M19 terminal 20 and unified meter and A/C amp. harness con-
nector M49 terminal 26.
OK or NG
OK >> Replace combination meter.
NG >> Repair harness or connector.26 – Ground:NOTE:
Maximum voltage may
be 5 V due to specifica-
tions (connected units).
SKIB0338E
PKIA1935E
20 – 26 : Continuity should exist.
SKIB0339E

COMBINATION METERS
DI-19
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2006 November2007 350Z
Engine Speed Signal InspectionNKS00066
Symptom: Tachometer indication is malfunction.
1. CHECK UNIFIED METER AND A/C AMP. OUTPUT SIGNAL
1. Start engine and select “METER A/C AMP” on CONSULT-III.
2. Using “TACHO METER” on “DATA MONITOR”, compare the value of “DATA MONITOR” with tachometer
pointer of combination meter.
OK or NG
OK >> GO TO 2.
NG >> Replace combination meter.
2. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
1. Select “ENGINE” on CONSULT-III.
2. Using “ENG SPEED” on “DATA MONITOR”, check the CONSULT-III screen when the engine is idling.
3. Select “METER A/C AMP” on CONSULT-III.
4. Using “TACHO METER” on “DATA MONITOR”, compare the value of “DATA MONITOR” of the idling
speed with that of the “ENG SPEED”.
OK or NG
OK >> Perform ECM self-diagnosis. Refer to EC-116, "CONSULT-III Function (ENGINE)" .
NG >> Replace unified meter and A/C amp.
Engine Coolant Temperature Signal InspectionNKS00067
Symptom: Water temperature gauge indication is malfunction.
1. CHECK UNIFIED METER AND A/C AMP. OUTPUT SIGNAL
1. Start engine and select “METER A/C AMP” on CONSULT-III.
2. Using “W TEMP METER” on the “DATA MONITOR”, compare the value of “DATA MONITOR” with water
temperature gauge pointer of combination meter.
OK or NG
OK >> GO TO 2.
NG >> Replace combination meter.
2. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
1. Select “ENGINE” on CONSULT-III.
2. Using “COOLAN TEMP/S” on “DATA MONITOR”, check the CONSULT-III screen.
3. Select “METER A/C AMP” on CONSULT-III.
4. Using “W TEMP METER” on, compare the value of “DATA MONITOR” with that of the “COOLAN TEMP/
S”.
OK or NG
OK >> Perform ECM self-diagnosis. Refer to EC-116, "CONSULT-III Function (ENGINE)" .
NG >> Replace unified meter and A/C amp.
Fuel Level Sensor Signal InspectionNKS00068
Symptom:

Fuel gauge indication is malfunction.

Low-fuel warning lamp indication is irregular.
Water temperature gauge pointer Reference value of data monitor [°C (°F)]
Hot Approx. 130 (266)
Middle Approx. 70 - 105 (158 - 221)
Cold Approx. 50 (122)

DI-40
TRIPLE METERS
Revision: 2006 November2007 350Z
Vehicle Speed Signal InspectionNKS0006R
Symptom: Speed indication is not displayed properly.
1. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
1. Start engine and select “METER A/C AMP” on CONSULT-III.
2. Using “SPEED METER” on the “DATA MONITOR”, compare the value of data monitor with speed indica-
tion of trip computer.
OK or NG
OK >> Refer to DI-18, "Vehicle Speed Signal Inspection" of “COMBINATION METERS”.
NG >> Replace triple meter.
Fuel Consumption Monitor Signal InspectionNKS0006S
Symptom:

DTE (distance to empty) indication is not displayed properly.

Average fuel consumption indication is not displayed properly.
1. CHECK ECM (CONSULT-III)
Perform self-diagnosis of ECM. Refer to EC-116, "
CONSULT-III Function (ENGINE)" .
Self
-diagnostic results
No malfunction detected>>Replace unified meter and A/C amp.
Malfunction detected>>Check applicable parts, and repair or replace corresponding parts.
Oil Pressure Sensor Signal InspectionNKS0006T
Symptom: Indication is malfunction of oil pressure gauge.
1. CHECK OIL PRESSURE SENSOR SIGNAL INPUT
1. Turn ignition switch ON.
2. Check voltage between triple meter harness connector M44 ter-
minal 8 and ground.
OK or NG
OK >> Replace triple meter.
NG >> GO TO 2.
Average vehicle speed indication is not indicated properly.
Replace triple meter. Trip distance indication is not indicated properly.
Trip time indication is not indicated properly.
Stopwatch indication is not displayed properly.
Indication is malfunction of voltmeter.
Indication is malfunction of oil pressure gauge. Refer to DI-40, "
Oil Pressure Sensor Signal Inspection" .
Trip computer switch is not operate. Refer to DI-42, "
Trip Computer Switch Inspection" . Trouble phenomenon Possible cause
8 – Ground
When ignition switch is in ON
position (Engine stopped.): Approx. 1 V
Engine running [When the oil
pressure is 80 psi (500 kPa)]: Approx. 3 V
SKIB1167E

DI-44
UNIFIED METER AND A/C AMP
Revision: 2006 November2007 350Z
UNIFIED METER AND A/C AMPPFP:27760
System DescriptionNKS0006X
DESCRIPTION

For the unified meter and A/C amp., the signal required for con-
trolling the combination meter and triple meter are integrated in
the A/C auto amp.

Unified meter and A/C amp. corresponds a CONSULT-III func-
tion (self-diagnosis results, CAN diagnosis support monitor and
data monitor).
COMBINATION METER CONTROL FUNCTION

Unified meter and A/C amp. receives necessary information for combination meter from each unit.

Unified meter and A/C amp. converses with the combination meter transmits a signal through with com-
munication line (TX, RX) between unified meter and A/C amp. and combination meter.
Input/output signals between unified meter and A/C amp. and combination meter.
NOTE:
Combination meter performs fail-safe operation when unified meter and A/C amp. communication is malfunctioning. Refer to DI-7,
"FAIL-SAFE" .
SKIB0018E
Unit Input Output
Unified meter and A/C amp.

Seat belt buckle switch signal (Driver's side)

Trip computer mode switch signal

Trip computer setting switch signal

Illumination control nighttime required signal

Refuel status signal

Vehicle speed signal

Low-fuel warning lamp condition signal

Self-diagnosis condition signal

Odo/trip switch signal

Delivery destination data signal

Combination meter receive error signal

Combination meter specifications signal

Triple meter specifications signal

Engine speed signal

Engine coolant temperature signal

Fuel level sensor signal (resistance value)

Malfunction indicator lamp signal

ABS warning lamp signal

Tire pressure warning lamp signal

Brake warning lamp signal

Oil pressure warning lamp signal

Turn indicator signal

High beam request signal

VDC OFF indicator lamp signal

TCS OFF indicator lamp signal

SLIP indicator lamp signal

CRUISE indicator lamp signal

SET indicator lamp signal

A/T CHECK indicator lamp signal

A/T position indicator signal

Manual mode indicator signal

Manual mode gear position signal

Shift-up indicator setting signal

CAN communication condition signal of A/T

Door switch signal

Position lights request signal

Buzzer output signal

UNIFIED METER AND A/C AMP
DI-47
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2006 November2007 350Z
CONSULT-III Function (METER A/C AMP)NKS00071
CONSULT-III can display each diagnostic item using the diagnostic test modes shown following.
SELF-DIAGNOSTIC RESULTS
Display Item List
NOTE:
“TIME” means the following.

0: Means detected malfunction at present.

1-63: Means detected malfunction in past. (Displays number of ignition switch OFF → ON after detecting
malfunction. “Self-diagnosis result” is erased when exceeding “63”.)
DATA MONITOR
Display Item List
System Diagnosis mode Description
METER A/C AMPSELF-DIAG RESULTSUnified meter and A/C amp. check the conditions and displays memo-
rized erro.
DATA MONOTOR Displays unified meter and A/C amp. input data in real time.
Display item [Code] Malfunction is detected when...Reference
page
CAN COMM CIRC [U1000]When unifield meter and A/C amp. is not transmitting or receiving CAN communica-
tion signal for 2 seconds or less.DI-50
T/METER COMM CIRC [B2201]Malfunction is detected in communication of between triple meter and unified meter
and A/C amp.DI-50
METER COMM CIRC [B2202]Malfunction is detected in communication of between combination meter and unified
meter and A/C amp.DI-52
VEHICLE SPEED CIRC [B2205]When an erroneous signal is input.
CAUTION:
Even when there is no malfunction on speed signal system, malfunction may be
misinterpreted when battery has low voltage (when maintaining 7 - 8 V for about
2 seconds). DI-55
Monitor item [Unit] MAIN SIGNALSSELECTION
FROM MENUContents
SPEED METER [km/h] or [mph] X XThis is the angle correction value after the speed signal
from the VDC/TCS/ABS control unit [with VDC system] or
ABS actuator and electric unit (control unit) [without VDC
system] is converted into the vehicle speed.
SPEED OUTPUT [km/h] or [mph] X XThis is the angle correction value before the speed signal
from the VDC/TCS/ABS control unit [with VDC system] or
ABS actuator and electric unit (control unit) [without VDC
system] is converted into the vehicle speed.
TACHO METER [rpm] X XThis is the converted value for the engine speed signal
from the ECM.
W TEMP METER [°C] or [°F] X XThis is the converted value for the engine coolant tempera-
ture signal from the ECM.
FUEL METER [lit.] X XThis is the processed value for the signal (resistance
value) from the fuel gauge.
DISTANCE [km] or [mile] X XThis is the calculated value for the speed signal from the
VDC/TCS/ABS control unit [with VDC system] or ABS
actuator and electric unit (control unit) [without VDC sys-
tem] and the signal (resistance signal) from the fuel gauge.
FUEL W/L [ON/OFF] X X Indicates [ON/OFF] condition of low-fuel warning lamp.
MIL [ON/OFF] XIndicates [ON/OFF] condition of malfunction indicator
lamp.
