VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: 2006 November2007 350Z
When the key is used to unlock a door, BCM terminal 22 receives signal

from terminal 12 of the power window main switch (door lock and unlock switch).
When the BCM receives either above signal or unlock signal from key fob, the vehicle security system is deac-
tivated. (Disarmed phase)
PANIC ALARM OPERATION
Remote keyless entry system may or may not operate vehicle security system (horn and headlamps) as
required.
When the panic alarm button on the keyfob is triggered, ground is supplied intermittently to both headlamp
relay and horn relay.
When both headlamp relay (with built-in IPDM E/R) and horn relay are energized and then power is supplied
to headlamps (high beam and low beam) and horns (HIGH and LOW).
The headlamp flashes and the horn sounds intermittently.
The alarm automatically turns off after 25 seconds or when BCM receives any signal from key fob.
CAN Communication System DescriptionNIS0002U
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN Communication UnitNIS0002V
Refer to LAN-4, "CAN Communication System" .

BL-138
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: 2006 November2007 350Z
CONSULT-III Function (IPDM E/R)NIS00031
CONSULT-III APPLICATION ITEM
Data Monitor
Active Test
Trouble DiagnosisNIS00032
WORK FLOW

“POWER DOOR LOCK SYSTEM” Diagnosis; refer to BL-35, "Work Flow" .
HORNThis test is able to check vehicle security horn (horn alarm) operation. The horns will be activated
for 0.5 seconds after “ON” on CONSULT-III screen is touched.
HEAD LAMPThis test is able to check vehicle security lamp (headlamp alarm) operation. The headlamps will
be activated for 0.5 seconds after “ON” on CONSULT-III screen is touched. Test Item Description
Monitored Item Description
HL LO REQ Indicates [ON/OFF] condition of headlamp low beam.
HL HI REQ Indicates [ON/OFF] condition of headlamp high beam.
HOOD SW Indicates [ON/OFF] condition of hood switch.
THFT HRN REQ Indicates [ON/OFF] condition of horn relay.
Test Item Description
LAMPSThis test is able to check theft warning lamp (headlamp alarm) operation. The headlamps will be
activated for 0.5 seconds after “ON” on CONSULT-III screen is touched.
HORNThis test is able to check theft warning horn (horn alarm) operation. The horns will be activated for
0.5 seconds after “ON” on CONSULT-III screen is touched.
LIIA0123E

BL-140
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: 2006 November2007 350Z
Symptom ChartNIS00034
*1: Make sure the system is in the armed phase.PROCEDURE
Diagnostic procedure Reference page
SYMPTOM
1Vehicle secu-
rity system
cannot be set
by ····Door switchDiagnostic Procedure 1 (Check door, hood, back door switch or
trunk room lamp switch)BL-141
Lock/unlock switch Diagnostic Procedure 6 (Check door lock/unlock switch)BL-149
Door outside key Diagnostic Procedure 3 (Check door key cylinder switch)BL-147
Key fob Check remote keyless entry system function.BL-61
BCM If the above systems are “OK”, replace BCM.BCS-17
Security indicator does not turn “ON”.Diagnostic Procedure 2 (Check security indicator lamp)BL-146If the above systems are “OK”, replace BCM.BCS-17
2*1 Vehicle
security sys-
tem does not
alarm when
····Any door is opened.Diagnostic Procedure 1 (Check door, hood and trunk room lamp
switch)BL-141
If the above systems are “OK”, replace BCM.BCS-17
3Vehicle secu-
rity alarm
does not acti-
vate.Horn alarmDiagnostic Procedure 4 (Check vehicle security horn alarm)BL-148If the above systems are “OK”, replace BCM.BCS-17
Headlamp alarmDiagnostic Procedure 5 (Check vehicle security headlamp alarm)BL-148If the above systems are “OK”, replace BCM.BCS-17
4Vehicle secu-
rity system
cannot be
canceled by
····Door outside key Diagnostic Procedure 3 (Check door key cylinder switch)BL-147Key fobCheck remote keyless entry system function.BL-61If the above systems are “OK”, replace BCM.BCS-17

BL-148
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: 2006 November2007 350Z
Diagnostic Procedure 4NIS00038
CHECK VEHICLE SECURITY HORN ALARM
First perform the “SELF-DIAG RESULTS” of “BCM” with CONSULT-III, then perform the trouble diag-
nosis of malfunction system indicated in “SELF-DIAG RESULTS” of “BCM”. Refer to BCS-16, "
CAN
Communication Inspection Using CONSULT-III (Self-Diagnosis)" .
1. CHECK HORN OPERATION
Check if horn sounds with horn switch.
Does horn operate?
YES >> GO TO 2.
NO >> Check horn circuit. Refer to WW-53, "
HORN" .
2. CHECK IPDM E/R INPUT SIGNAL
Check voltage between IPDM E/R connector E9 terminal 51 and ground.
OK or NG
OK >> Replace IPDM E/R.
NG >> GO TO 3.
3. CHECK HORN RERAY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R and horn relay connector.
3. Check continuity between IPDM E/R harness connector E9 terminal 51 and horn relay harness connector
E21 terminal 1.
OK or NG
OK >> Horn circuit is OK.
NG >> Repair or replace harness.
Diagnostic Procedure 5NIS00039
CHECK VEHICLE SECURITY HEADLAMP ALARM
1. CHECK HEAD LAMP OPERATION
Does headlamp come on when turning lighting switch “ON”?
YES or NO
YES >> Headlamp alarm circuit is OK.
NO >> Check headlamp system. Refer to,,, LT- 3 2 , "
HEADLAMP (FOR CANADA) - DAYTIME LIGHT
SYSTEM -"LT- 5 , "HEADLAMP (FOR USA)" . 51 (G/B) – Ground : Battery voltage.
PIIA6403E
1 (G/B) - 51(G/B) : Continuity should exist.
PIIA6404E
