RADIATOR CORE SUPPORT
BL-19
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
RADIATOR CORE SUPPORTPFP:62500
Removal and InstallationNIS0000E
REMOVAL
1. Remove hood assembly. Refer to BL-15, "Removal and Installation of Hood Assembly" .
2. Remove front bumper. Refer to EI-14, "
Removal and Installation" .
3. Remove head lamp (LH/RH). Refer to LT- 2 9 , "
Removal and Installation" .
4. Remove hood lock assembly, and then hood lock cable. Refer to BL-16, "
Removal and Installation of
Hood Lock Control" .
5. Remove washer tank. Refer to WW-34, "
Removal and Installation of Washer Tank" .
6. Remove crash zone sensor. Refer to SRS-48, "
Removal and Installation" .
7. Remove washer tank inlet clip. Refer to WW-34, "
Removal and Installation of Washer Tank" .
8. Remove the oil cooler. Refer to PS-33, "
HYDRAULIC LINE" .
9. Remove ambient sensor. Refer to ATC-104, "
Removal and Installation" .
PIIB9262E
1. Radiator core support side stay (RH) 2. Radiator core support side (RH) 3. Hood stay
4. Bumper retainer (RH) 5. Grommet 6. Horn (High)
7. Air guide (RH) 8.Bumper fascia stay radiator core
support center (LH)9. Horn (Low)
10. Radiator core support center 11. Air duct 12. Air guide (LH)
13. Bumper retainer (LH) 14. Radiator core support side (LH) 15. Radiator core support side stay (LH)
16. Radiator upper bracket 17. Hood rod clamp 18. Radiator core support bar
19.Bumper fascia stay radiator core
support center (RH)
TRUNK LID OPENER
BL-115
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
through driver side door lock actuator (unlock sensor) terminals 2 and 4,
through grounds M30 and M66.
And power is supplied
to BCM terminal 68
through trunk lid lock assembly (trunk lid opener actuator) terminals 2 and 1
through grounds B5, B6 and T14.
Then trunk lid lock assembly (trunk lid opener actuator) opens trunk.
TRUNK LID OPENER CANCEL OPERATION
When trunk lid opener cancel switch is OFF (CANCEL), it cannot open trunk with trunk lid opener switch.
TRUNK OPENER OPERATION WITH KEY FOB
Open the trunk with key fob. Refer to BL-63, "Trunk Opener Operation/For Roadster" .
