2007 NISSAN 350Z relay

BL-72
REMOTE KEYLESS ENTRY SYSTEM
Revision: 2006 November2007 350Z
Terminals and Reference Value for IPDM E/RNIS0001C
*: In the state that horn reminder operates.
CONSULT-III Function (BCM)NIS0001D

CONSULT-III can display each diagnostic item using the diagnostic test modes shown following.
*:Refer to BCS-16, "CAN Communication Inspection Using CONSULT-III (Self-Diagnosis)" . Te r m i -
nal Wire
colorItemSignal
input/out-
putConditionVoltage (V)
(Approx.)
38 B Ground — — 0
48 L CAN – HInput/
Output—0
49 P CAN – LInput/
Output—0
51 G/B Horn relay InputWhen door lock is operated using
key fob*
(ON → OFF)Battery voltage → 0
60 B Ground — — 0
BCM diagnosis
positionInspection items and diagnosis mode Description
MULTI REMOTE
ENTData monitorDisplays the input remote keyless entry system data to
BCM on real–time basis.
Active test Sends a drive signal to check the operation.
Work support Changes the setting for each function.

REMOTE KEYLESS ENTRY SYSTEM
BL-85
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
Check IPDM E/R Operation NIS0001P
1. CHECK IPDM E/R INPUT SIGNAL
Check voltage between IPDM E/R connector E9 terminal 51 and ground.
OK or NG
OK >> Replace IPDM E/R.
NG >> GO TO 2.
2. CHECK IPDM E/R CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R and horn relay connector.
3. Check continuity between IPDM E/R harness connector E9 terminal 51 and horn relay harness connector
E21 terminal 1.
OK or NG
OK >> Check harness connection.
NG >> Repair or replace harness.
Check Remote Keyless Entry Receiver NIS0001Q
1. CHECK MULTI-REMOTE CONTROL RECEIVER INPUT VOLTAGE
1. Remove key from ignition key cylinder.
2. Check signal between remote keyless entry receiver connector and ground with oscilloscope.
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.51 (G/B) – Ground : Battery voltage
PIIA6403E
1 (G/B) - 51(G/B) : Continuity should exist.
PIIA6404E
Con-
nectorTerminal
(Wire color)
Condition Signal
(Reference value)
(+) (–)
M78 4 (Y)Grou
ndKey is inserted in
IGN key cylinder 0
All door closed
PIIA2835E
OCC3881D

VEHICLE SECURITY (THEFT WARNING) SYSTEM
BL-127
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
2. Disconnecting and connecting the battery connector before canceling armed phase.
POWER SUPPLY AND GROUND
Power is supplied at all times

through 10A fuse [No.19, located in the fuse block (J/B)]

to security indicator lamp terminal 1.
Power is supplied at all times

through 40A fusible link (letter F , located in the fuse and fusible link box)

to BCM terminal 55

through 10A fuse [No.18, located in the fuse block (J/B)]

to BCM terminal 42.
With the ignition switch in the ACC or ON position, power is supplied

through 10A fuse [No. 6, located in the fuse block (J/B)]

to BCM terminal 11.
Ground is supplied.

to BCM terminal 52

through body grounds M30 and M66.
INITIAL CONDITION TO ACTIVATE THE SYSTEM
The operation of the vehicle security system is controlled by the doors and trunk (for Roadster).
To activate the vehicle security system, BCM must receive signals indicating the doors and trunk (for Road-
ster) are closed and the doors are locked by key or key fob.
When a door is open, BCM terminals 12, 65 receives a ground signal from each door switch.
When driver side door is unlocked by power window main switch (door lock and unlock switch), BCM terminal
22 receives a signal from terminal 12 of power window main switch.
When passenger side door is unlocked by power window sub-switch (door lock and unlock switch), BCM ter-
minal 22 receives a signal from terminal 16 of power window sub-switch.
The IPDM E/R then sends a signal to the BCM via CAN communication line.
When the back door (for Coupe) or trunk (for Roadster) is open, BCM terminal 57 (for Roadster) or 58 (for
Coupe) receives a ground signal

from terminal 1 of the back door switch (for Coupe) or terminal 3 of trunk lid lock assembly (trunk room
lamp switch) (for Roadster)

through body grounds B5, B6,T14, D105 (for Coupe) or B5, B6, T14 (for Roadster).
VEHICLE SECURITY SYSTEM ALARM OPERATION
The vehicle security system is triggered by

opening a driver or passenger side door

opening the back door (for Coupe)

opening the trunk (for Roadster)

detection of battery disconnect and connect.
The vehicle security system will be triggered once the system is in armed phase,
When BCM receives a ground signal at terminals 12, 62 (door switch), 57 (trunk room lamp switch) or 58 (back
door switch).
Power is supplied at all times

to horn relay terminal 2

through 15A fuse (No. 35, located in the fuse and fusible link box).
When the vehicle security system is triggered, ground is supplied intermittently to both headlamp relay and
horn relay.
When both headlamp relay (with built-in IPDM E/R) and horn relay are energized and then power is supplied
to headlamps (high beam and low beam) and horns (HIGH and LOW).
The headlamps flash and the horn sounds intermittently.
The alarm automatically turns off after 50 seconds, but will reactivate if the vehicle is tampered with again.
VEHICLE SECURITY SYSTEM DEACTIVATION
To deactivate the vehicle security system, a door must be unlocked or back door (for Coupe) or trunk (for
Roadster) must be opened with the key or key fob.

BL-128
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: 2006 November2007 350Z
When the key is used to unlock a door, BCM terminal 22 receives signal

from terminal 12 of the power window main switch (door lock and unlock switch).
When the BCM receives either above signal or unlock signal from key fob, the vehicle security system is deac-
tivated. (Disarmed phase)
PANIC ALARM OPERATION
Remote keyless entry system may or may not operate vehicle security system (horn and headlamps) as
required.
When the panic alarm button on the keyfob is triggered, ground is supplied intermittently to both headlamp
relay and horn relay.
When both headlamp relay (with built-in IPDM E/R) and horn relay are energized and then power is supplied
to headlamps (high beam and low beam) and horns (HIGH and LOW).
The headlamp flashes and the horn sounds intermittently.
The alarm automatically turns off after 25 seconds or when BCM receives any signal from key fob.
CAN Communication System DescriptionNIS0002U
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN Communication UnitNIS0002V
Refer to LAN-4, "CAN Communication System" .

VEHICLE SECURITY (THEFT WARNING) SYSTEM
BL-137
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
Terminals and Reference Value for IPDM E/RNIS0002Z
CONSULT-III Function (BCM)NIS00030
CONSULT-III APPLICATION ITEM
Work Support
Data Monitor
Active Test
Terminal Wire
colorItemSignal
Input/
OutputConditionVoltage [V]
(Approx.)
38 B Ground — — 0
48 L CAN-HInput/
Output——
49 P CAN-LInput/
Output——
51 G/B Horn relay Output ON → OFF 0 → Battery voltage
60 B Ground — — 0
Test Item Description
SECURITY ALARM SET This mode is able to confirm and change security alarm ON-OFF setting.
THEFT ALM TRGThe switch which triggered vehicle security alarm is recorded. This mode is able to confirm and
erase the record of vehicle security alarm. The trigger data can be erased by touching “CLEAR”
on CONSULT-III screen.
Monitored Item Description
IGN ON SW Indicates [ON/OFF] condition of ignition switch.
ACC ON SW Indicates [ON/OFF] condition of ignition switch in ACC position.
KEY CYL LK SW Indicates [ON/OFF] condition of lock signal from key cylinder switch.
KEY CYL UN SW Indicates [ON/OFF] condition of unlock signal from key cylinder switch.
DOOR SW-DR Indicates [ON/OFF] condition of driver side door switch.
DOOR SW-AS Indicates [ON/OFF] condition of passenger side door switch.
BACK DOOR SW Indicates [ON/OFF] condition of back door switch.
TRUNK OPNR SW Indicates [ON/OFF] condition of trunk room lamp switch. (Roadster models)
TRUNK OPN MNTRThis is displayed even when it is not equipped.
Indicates [ON/OFF] condition of trunk lid opener switch. (Roadster models)
TRUNK KEY SW This is displayed even when it is not equipped.
DOOR SW-RR This is displayed even when it is not equipped.
HOOD SW Indicates [ON/OFF] condition of hood switch.
LOCK SW DR/ASIndicates [ON/OFF] condition of lock signal from driver and passenger side door lock/unlock
switch.
UNLK SW DR/ASIndicates [ON/OFF] condition of unlock signal from driver and passenger side door lock/unlock
switch.
LK BUTTON/SIG Indicates [ON/OFF] condition of lock signal from key fob.
UN BUTTON/SIG Indicates [ON/OFF] condition of unlock signal from key fob.
TRUNK BTN/SIGIndicate [ON/OFF] condition of back door open signal from key fob (for Coupe).
Indicates [ON/OFF] condition of trunk open signal from key fob (for Roadster).
Test Item Description
THEFT INDThis test is able to check security indicator lamp operation. The lamp will be turned on when “ON”
on CONSULT-III screen is touched.

BL-138
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: 2006 November2007 350Z
CONSULT-III Function (IPDM E/R)NIS00031
CONSULT-III APPLICATION ITEM
Data Monitor
Active Test
Trouble DiagnosisNIS00032
WORK FLOW

“POWER DOOR LOCK SYSTEM” Diagnosis; refer to BL-35, "Work Flow" .
HORNThis test is able to check vehicle security horn (horn alarm) operation. The horns will be activated
for 0.5 seconds after “ON” on CONSULT-III screen is touched.
HEAD LAMPThis test is able to check vehicle security lamp (headlamp alarm) operation. The headlamps will
be activated for 0.5 seconds after “ON” on CONSULT-III screen is touched. Test Item Description
Monitored Item Description
HL LO REQ Indicates [ON/OFF] condition of headlamp low beam.
HL HI REQ Indicates [ON/OFF] condition of headlamp high beam.
HOOD SW Indicates [ON/OFF] condition of hood switch.
THFT HRN REQ Indicates [ON/OFF] condition of horn relay.
Test Item Description
LAMPSThis test is able to check theft warning lamp (headlamp alarm) operation. The headlamps will be
activated for 0.5 seconds after “ON” on CONSULT-III screen is touched.
HORNThis test is able to check theft warning horn (horn alarm) operation. The horns will be activated for
0.5 seconds after “ON” on CONSULT-III screen is touched.
LIIA0123E

BL-148
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: 2006 November2007 350Z
Diagnostic Procedure 4NIS00038
CHECK VEHICLE SECURITY HORN ALARM
First perform the “SELF-DIAG RESULTS” of “BCM” with CONSULT-III, then perform the trouble diag-
nosis of malfunction system indicated in “SELF-DIAG RESULTS” of “BCM”. Refer to BCS-16, "
CAN
Communication Inspection Using CONSULT-III (Self-Diagnosis)" .
1. CHECK HORN OPERATION
Check if horn sounds with horn switch.
Does horn operate?
YES >> GO TO 2.
NO >> Check horn circuit. Refer to WW-53, "
HORN" .
2. CHECK IPDM E/R INPUT SIGNAL
Check voltage between IPDM E/R connector E9 terminal 51 and ground.
OK or NG
OK >> Replace IPDM E/R.
NG >> GO TO 3.
3. CHECK HORN RERAY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R and horn relay connector.
3. Check continuity between IPDM E/R harness connector E9 terminal 51 and horn relay harness connector
E21 terminal 1.
OK or NG
OK >> Horn circuit is OK.
NG >> Repair or replace harness.
Diagnostic Procedure 5NIS00039
CHECK VEHICLE SECURITY HEADLAMP ALARM
1. CHECK HEAD LAMP OPERATION
Does headlamp come on when turning lighting switch “ON”?
YES or NO
YES >> Headlamp alarm circuit is OK.
NO >> Check headlamp system. Refer to,,, LT- 3 2 , "
HEADLAMP (FOR CANADA) - DAYTIME LIGHT
SYSTEM -"LT- 5 , "HEADLAMP (FOR USA)" . 51 (G/B) – Ground : Battery voltage.
PIIA6403E
1 (G/B) - 51(G/B) : Continuity should exist.
PIIA6404E
