2007 NISSAN 350Z display

POWER DOOR LOCK SYSTEM
BL-35
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
Work FlowNIS0000M
1. Check the symptom and customer's requests.
2. Understand the outline of system. Refer to BL-23, "
System Description" .
3. Does power door lock system operate normally? If Yes, GO TO 6, If No, GO TO 4.
4. INSPECTION END.
CONSULT-III Function (BCM)NIS0000N
CONSULT-III can display each diagnostic item using the diagnostic test modes shown following.
WORK SUPPORT
DATA MONITOR
*1: For Coupe
*2: For Roadster
ACTIVE TEST
BCM diagnosis
partInspection item, self-diagnosis
modeContent
Door lockWork support Changes the setting for each function.
Data monitor Displays BCM input data on real-time basis.
Active test Sends drive signals to door lock actuator to perform operation check.
Work item Description
DOOR LOCK-UNLOCK SET Select unlock mode can be changed in this mode. Selects ON-OFF of select unlock mode.
ANTI-LOCK OUT SETKey reminder door mode can be changed in this mode. Selects ON-OFF of key reminder door
mode.
Monitor item “operation” Content
KEY ON SW “ON/OFF” Indicates [ON/OFF] condition of key switch.
LOCK SW DR/AS “ON/OFF” Indicates [ON/OFF] condition of lock signal from lock/unlock switch of driver and passenger side.
UNLK SW DR/AS “ON/OFF”Indicates [ON/OFF] condition of unlock signal from lock/unlock switch of driver and passenger
side.
KEY CYL LK-SW “ON/OFF” Indicates [ON/OFF] condition of lock signal from key cylinder.
KEY CYL UN-SW “ON/OFF” Indicates [ON/OFF] condition of unlock signal from key cylinder.
LK BUTTON/SIG “ON/OFF” Indicates [ON/OFF] condition of lock signal from key fob.
UN BUTTON/SIG “ON/OFF” Indicates [ON/OFF] condition of unlock signal from key fob.
IGN ON SW “ON/OFF” Indicates [ON/OFF] condition of ignition switch.
DOOR SW-DR “ON/OFF” Indicates [ON/OFF] condition of driver side door switch.
DOOR SW-AS “ON/OFF” Indicates [ON/OFF] condition of passenger side door switch.
BACK DOOR SW*
1“ON/OFF” Indicates [ON/OFF] condition of back door switch.
TRNK OPN MNTR*
2“ON/OFF” Indicates [ON/OFF] condition of trunk lid opener switch.
Test item Content
ALL D/LK MTRThis test is able to check all door lock actuators lock operation. These actuators lock when “ON” on
CONSULT-III screen is touched.
DR D/UN MTRThis test is able to check driver side door lock actuator unlock operation. This actuator unlock when
“ON” on CONSULT-III screen is touched.
NON DR D/UNThis test is able to check door lock actuators (except driver side door lock actuator) unlock operation.
These actuator unlock when “ON” on CONSULT-III screen is touched.

FUEL FILLER LID OPENER
BL-55
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
CONSULT-III Function (BCM)/For RoadsterNIS00011
CONSULT-III can display each diagnostic item using the diagnostic test modes shown following.
DATA MONITOR
ACTIVE TEST
BCM diagnosis
partInspection item, self-diagnosis
modeContent
Fuel lidData monitor Displays BCM input data on real-time basis.
Active test Sends drive signals to fuel lid opener actuator to perform operation check.
Monitor item “operation” Content
F/LID OPN SW Indicates [ON/OFF] condition of fuel lid opener switch.
Test item Content
FUEL LID OPENThis test is able to check fuel lid opener actuator unlock operation. This actuator unlocks when “ON” on
CONSULT-III screen is touched.

BL-72
REMOTE KEYLESS ENTRY SYSTEM
Revision: 2006 November2007 350Z
Terminals and Reference Value for IPDM E/RNIS0001C
*: In the state that horn reminder operates.
CONSULT-III Function (BCM)NIS0001D

CONSULT-III can display each diagnostic item using the diagnostic test modes shown following.
*:Refer to BCS-16, "CAN Communication Inspection Using CONSULT-III (Self-Diagnosis)" . Te r m i -
nal Wire
colorItemSignal
input/out-
putConditionVoltage (V)
(Approx.)
38 B Ground — — 0
48 L CAN – HInput/
Output—0
49 P CAN – LInput/
Output—0
51 G/B Horn relay InputWhen door lock is operated using
key fob*
(ON → OFF)Battery voltage → 0
60 B Ground — — 0
BCM diagnosis
positionInspection items and diagnosis mode Description
MULTI REMOTE
ENTData monitorDisplays the input remote keyless entry system data to
BCM on real–time basis.
Active test Sends a drive signal to check the operation.
Work support Changes the setting for each function.

BL-74
REMOTE KEYLESS ENTRY SYSTEM
Revision: 2006 November2007 350Z
Active Test
CONSULT-III Application Items for IPDM E/RNIS0001H
DATA MONITOR
ACTIVE TEST
KEY ON SW Indicates [ON/OFF] condition of key switch.
DOOR SW-DR Indicates [ON/OFF] condition of driver side door switch.
DOOR SW-AS Indicates [ON/OFF] condition of passenger side door switch.
BACK DOOR SW Indicates [ON/OFF] condition of back door switch (For Coupe).
LOCK SW DR/AS Indicates [ON/OFF] condition of lock signal from lock/unlock switch.
UNLK SW DR/AS Indicates [ON/OFF] condition of unlock signal from lock/unlock switch.
KEY CYL LK SW Indicates [ON/OFF] condition of lock signal from door key cylinder switch.
LK BUTTON/SIG Indicates [ON/OFF] condition of lock signal from key fob.
UN BUTTON/SIG Indicates [ON/OFF] condition of unlock signal from key fob.
PANIC BTN Indicates [ON/OFF] condition of panic signal from key fob.
TRUNK OPNR SW Indicates [ON/OFF] condition of trunk room lamp switch (For Roadster).
TRUNK BTN/SIGIndicates [ON/OFF] condition of back door open signal from key fob.
Indicates [ON/OFF] condition of trunk open signal from key fob. (For Roadster)
TRUNK OPN MNTR Indicates [ON/OFF] condition of trunk lid opener switch. (For Roadster)
UN BUTTON ON Indicates [ON/OFF] condition of unlock signal from key fob.
LK/UN BTN ON Indicates [ON/OFF] condition of lock/unlock signal at the same time from key fob.
DOOR SW-RR This is displayed even when it is not equipped.Monitored Item Description
Test Item Description
INT LAMPThis test is able to check interior lamp operation. The interior lamp is turned on when “ON” on CON-
SULT-III screen is touched.
IGN ILLUM This is displayed even when it is not equipped.
TRUNK/BACK DOORThis test is able to check back door (For Coupe) or trunk lid (For Roadster) opener actuator opera-
tion. The back door (For Coupe) or trunk (For Roadster) is unlocked when “ON” on CONSULT-III
screen is touched.
HORNThis test is able to check panic alarm and horn reminder operations. The horn activate for 0.02 sec-
onds after “ON” on CONSULT-III screen is touched.
HEAD LAMP(HI)This test is able to check headlamps panic alarm operation. The headlamp illuminates for 0.5 sec-
onds after “ON” on CONSULT-III screen is touched.
POWER WINDOW DOWNThis test is able to check power window open operation. The front power windows activate for 10
seconds after “ON” or CONSULT-III screen is touched.
FLASHER RIGHTThis test is able to check hazard reminder operation. The right hazard lamp turns on when “ON” on
CONSULT-III screen is touched.
FLASHER LEFTThis test is able to check hazard reminder operation. The left hazard lamp turns on when “ON” on
CONSULT-III screen is touched.
FLASHER RIGHT (CAN)This test is able to check hazard reminder operation. The right hazard indicator lamp turns on when
“ON” on CONSULT-III screen is touched.
FLASHER LEFT (CAN)This test is able to check hazard reminder operation. The left hazard indicator lamp turns on when
“ON” on CONSULT-III screen is touched.
Monitored Item Description
HORN CHIRP Indicates [ON/OFF] condition of horn function by IPDM E/R.
Test Item Description
HORNThis test is able to check horn operation. Horn activates when “ON” on CONSULT-III screen is
touched.

TRUNK LID OPENER
BL-119
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
CONSULT-III Function (BCM)NIS0002Q
CONSULT-III can display each diagnostic item using the diagnostic test modes shown following.
ACTIVE TEST
BCM diagnosis
partInspection item, self-diagnosis
modeContent
TrunkDATA MONITOR Displays the input data of BCM in real time basis.
ACTIVE TEST Give a drive signals to load to check the operation check.
Test item Content
TRUNK/BACK DOORThis test is able to check trunk lid opener actuator unlock operation. This actuator unlocks when “ON” on
CONSULT-III screen is touched.

VEHICLE SECURITY (THEFT WARNING) SYSTEM
BL-137
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
Terminals and Reference Value for IPDM E/RNIS0002Z
CONSULT-III Function (BCM)NIS00030
CONSULT-III APPLICATION ITEM
Work Support
Data Monitor
Active Test
Terminal Wire
colorItemSignal
Input/
OutputConditionVoltage [V]
(Approx.)
38 B Ground — — 0
48 L CAN-HInput/
Output——
49 P CAN-LInput/
Output——
51 G/B Horn relay Output ON → OFF 0 → Battery voltage
60 B Ground — — 0
Test Item Description
SECURITY ALARM SET This mode is able to confirm and change security alarm ON-OFF setting.
THEFT ALM TRGThe switch which triggered vehicle security alarm is recorded. This mode is able to confirm and
erase the record of vehicle security alarm. The trigger data can be erased by touching “CLEAR”
on CONSULT-III screen.
Monitored Item Description
IGN ON SW Indicates [ON/OFF] condition of ignition switch.
ACC ON SW Indicates [ON/OFF] condition of ignition switch in ACC position.
KEY CYL LK SW Indicates [ON/OFF] condition of lock signal from key cylinder switch.
KEY CYL UN SW Indicates [ON/OFF] condition of unlock signal from key cylinder switch.
DOOR SW-DR Indicates [ON/OFF] condition of driver side door switch.
DOOR SW-AS Indicates [ON/OFF] condition of passenger side door switch.
BACK DOOR SW Indicates [ON/OFF] condition of back door switch.
TRUNK OPNR SW Indicates [ON/OFF] condition of trunk room lamp switch. (Roadster models)
TRUNK OPN MNTRThis is displayed even when it is not equipped.
Indicates [ON/OFF] condition of trunk lid opener switch. (Roadster models)
TRUNK KEY SW This is displayed even when it is not equipped.
DOOR SW-RR This is displayed even when it is not equipped.
HOOD SW Indicates [ON/OFF] condition of hood switch.
LOCK SW DR/ASIndicates [ON/OFF] condition of lock signal from driver and passenger side door lock/unlock
switch.
UNLK SW DR/ASIndicates [ON/OFF] condition of unlock signal from driver and passenger side door lock/unlock
switch.
LK BUTTON/SIG Indicates [ON/OFF] condition of lock signal from key fob.
UN BUTTON/SIG Indicates [ON/OFF] condition of unlock signal from key fob.
TRUNK BTN/SIGIndicate [ON/OFF] condition of back door open signal from key fob (for Coupe).
Indicates [ON/OFF] condition of trunk open signal from key fob (for Roadster).
Test Item Description
THEFT INDThis test is able to check security indicator lamp operation. The lamp will be turned on when “ON”
on CONSULT-III screen is touched.

BL-146
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: 2006 November2007 350Z
Diagnostic Procedure 2NIS00036
CHECK SECURITY INDICATOR LAMP
1. SECURITY INDICATOR LAMP ACTIVE TEST
With CONSULT-III
Check “THEFT IND” in “ACTIVE TEST” mode with CONSULT-III.
Without CONSULT-III
1. Disconnect BCM connector.
2. Check voltage between BCM connector M90 terminal 23 and
ground.
OK or NG
OK >> Security indicator lamp is OK.
NG >> GO TO 2.
2. CHECK POWER SUPPLY CIRCUIT FOR SECURITY INDICATOR LAMP
1. Disconnect security indicator lamp connector.
2. Check voltage between security indicator lamp connector M34 terminal 1 and ground.
OK or NG
OK >> GO TO 3.
NG >> Check the following.

10A fuse [No. 19, located in fuse block (J/B)]

Harness for open or short between security indicator
lamp and fuse
3. CHECK SECURITY INDICATOR LAMP CIRCUIT
1. Check continuity between BCM harness connector M90 terminal
23 and security indicator lamp harness connector M34 terminal
2.
2. Check continuity between BCM harness connector M90 terminal
23 and ground.
OK or NG
OK >> Check indicator lamp condition.
NG >> Repair harness or connector.Perform operation shown on display.
Indicator lamp should illuminate.
23 (G/OR) - Ground : Battery voltage
PIIA9850E
1 (R/W) - Ground : Battery voltage
PIIA2491E
23 (G/OR) - 2 (G/OR) : Continuity should exist.
23 (G/OR) - Ground : Continuity should not exist.
PIIB7462E

BL-156
NVIS (NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS)
Revision: 2006 November2007 350Z
Trouble DiagnosesNIS0003J
SYMPTOM MATRIX CHART 1
Self-diagnosis related item
SYMPTOMDisplayed “SELF-DIAG
RESULTS” on CON-
SULT-III screen.DIAGNOSTIC PROCE-
DURE
(Reference page)SYSTEM
(Malfunctioning part or
mode)REFERENCE PART NO.
OF ILLUSTRATION ON
SYSTEM DIAGRAM

Security indicator
lighting up*

Engine cannot be
startedCHAIN OF ECM-IMMU
[P1612]PROCEDURE 1
(BL-158
)In rare case, “CHAIN OF
ECM-IMMU” might be
stored during key regis-
tration procedure, even if
the system is not mal-
functioning.—
Open circuit in battery
voltage line of BCM cir-
cuitC1
Open circuit in ignition
line of BCM circuitC2
Open circuit in ground
line of BCM circuitC3
Open or short circuit
between BCM and ECM
communication lineC4
ECM B
BCM A
DIFFERENCE OF KEY
[P1615]PROCEDURE 2
(BL-159
)Unregistered key D
BCM A
CHAIN OF IMMU-KEY
[P1614]PROCEDURE 3
(BL-160
)Malfunction of key ID
chipE5
Communication line
between ANT/ AMP and
BCM:
Open circuit or short cir-
cuit of battery voltage
line or ground lineE1
E2
Open circuit in power
source line of ANT/ AMP
circuitE3
Open circuit in ground
line of ANT/ AMP circuitE4
NATS antenna amp. E6
BCM A
ID DISCORD, IMM-ECM
[P1611]PROCEDURE 4
(BL-161
)System initialization has
not yet been completed.F
ECM B
