2007 NISSAN 350Z sensor

TROUBLE DIAGNOSIS
AT-69
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
30
Slips/Will
Not
EngageNo shock at all or the
clutch slips when
vehicle changes
speed D
4 → D5 or
M
4 → M5 .ON vehicle1. A/T fluid level and stateAT- 4 9
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-108,
AT-139
3. Front brake solenoid valveAT-147
4. Direct clutch solenoid valveAT-149
5. CAN communication lineAT- 9 4
6. Line pressure testAT- 5 0
7. Control valve with TCMAT-215
OFF vehicle8. Torque converterAT-255
9. Oil pump assemblyAT-271
10. Front brake (brake band)AT-255
11. Input clutchAT-276
12. Gear systemAT-246
13. High and low reverse clutchAT-286
31When you press the
accelerator pedal and
shift speed D5 → D4
or M
5 → M4 the
engine idles or the A/
T slips.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-108,
AT-139
3. Front brake solenoid valveAT-147
4. Direct clutch solenoid valveAT-149
5. CAN communication lineAT- 9 4
6. Line pressure testAT- 5 0
7. Control valve with TCMAT-215
OFF vehicle8. Torque converterAT-255
9. Oil pump assemblyAT-271
10. Input clutchAT-276
11. Gear systemAT-246
12. High and low reverse clutchAT-286
13. Direct clutchAT-288
No. Items Symptom Condition Diagnostic ItemReference
page

AT-70
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
32
Slips/Will
Not
EngageWhen you press the
accelerator pedal and
shift speed D4 → D3
or M
4 → M3 the
engine idles or the A/
T slips.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 8,
AT- 1 3 9
3. Input clutch solenoid valveAT- 1 4 5
4. Front brake solenoid valveAT- 1 4 7
5. CAN communication lineAT- 9 4
6. Line pressure testAT- 5 0
7. Control valve with TCMAT- 2 1 5
OFF vehicle8. Torque converter AT- 2 5 5
9. Oil pump assemblyAT- 2 7 1
10. 3rd one-way clutchAT- 2 7 4
11. Gear systemAT- 2 4 6
12. High and low reverse clutchAT- 2 8 6
13. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT-17, "
Cross-sectional View" .)AT- 2 5 5
14. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-sectional View" .)AT- 2 5 5
33When you press the
accelerator pedal and
shift speed D3 → D2
or M
3 → M2 the
engine idles or the A/
T slips.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 8,
AT- 1 3 9
3. High and low reverse clutch solenoid valveAT- 1 5 1
4. Direct clutch solenoid valveAT- 1 4 9
5. CAN communication lineAT- 9 4
6. Line pressure testAT- 5 0
7. Control valve with TCMAT- 2 1 5
OFF vehicle8. Torque converterAT- 2 5 5
9. Oil pump assemblyAT- 2 7 1
10. 3rd one-way clutchAT- 2 7 4
11. Gear systemAT- 2 4 6
12. Direct clutchAT- 2 8 8
13. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-sectional View" .)AT- 2 5 5
No. Items Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-71
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
34
Slips/Will
Not
EngageWhen you press the
accelerator pedal and
shift speed D2 → D1
or M
2 → M1 the
engine idles or the A/
T slips.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-108,
AT-139
3. Direct clutch solenoid valveAT-149
4. CAN communication lineAT- 9 4
5. Line pressure testAT- 5 0
6. Control valve with TCMAT-215
OFF vehicle7. Torque converterAT-255
8. Oil pump assemblyAT-271
9. 3rd one-way clutchAT-274
10. 1st one-way clutchAT-281
11. Gear systemAT-246
12. Reverse brakeAT-255
13. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 7 , "
Cross-sectional View" .)AT-255
14. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-sectional View" .)AT-255
35With selector lever in
“D” position, accelera-
tion is extremely poor.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Line pressure testAT- 5 0
3. Accelerator pedal position sensorAT-131
4. CAN communication lineAT- 9 4
5. PNP switchAT-102
6. A/T positionAT-206
7. Control valve with TCMAT-215
OFF vehicle8. Torque converterAT-255
9. Oil pump assemblyAT-271
10. 1st one-way clutchAT-281
11. Gear systemAT-246
12. Reverse brakeAT-255
13. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 7 , "
Cross-sectional View" .)AT-255
14. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-sectional View" .)AT-255
No. Items Symptom Condition Diagnostic ItemReference
page

AT-72
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
36
Slips/Will
Not
EngageWith selector lever in
“R” position, accelera-
tion is extremely poor.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Line pressure testAT- 5 0
3. Accelerator pedal position sensorAT- 1 3 1
4. High and low reverse clutch solenoid valveAT- 1 5 1
5. CAN communication lineAT- 9 4
6. PNP switchAT- 1 0 2
7. A/T positionAT- 2 0 6
8. Control valve with TCMAT- 2 1 5
OFF vehicle9. Gear systemAT- 2 4 610. Output shaftAT- 2 5 5
11. Reverse brakeAT- 2 5 5
37While starting off by
accelerating in 1st,
engine races or slip-
page occurs.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Line pressure testAT- 5 0
3. Accelerator pedal position sensorAT- 1 3 1
4. CAN communication lineAT- 9 4
5. Control valve with TCMAT- 2 1 5
OFF vehicle6. Torque converterAT- 2 5 5
7. Oil pump assemblyAT- 2 7 1
8. 3rd one-way clutchAT- 2 7 4
9. 1st one-way clutchAT- 2 8 1
10. Gear systemAT- 2 4 6
11. Reverse brakeAT- 2 5 5
12. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT-17, "
Cross-sectional View" .)AT- 2 5 5
13. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-sectional View" .)AT- 2 5 5
No. Items Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-73
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
38
Slips/Will
Not
EngageWhile accelerating in
2nd, engine races or
slippage occurs.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Line pressure testAT- 5 0
3. Accelerator pedal position sensorAT-131
4. CAN communication lineAT- 9 4
5. Direct clutch solenoid valveAT-149
6. Control valve with TCMAT-215
OFF vehicle7. Torque converterAT-255
8. Oil pump assemblyAT-271
9. 3rd one-way clutchAT-274
10. Gear systemAT-246
11. Direct clutchAT-288
12. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-sectional View" .)AT-255
39While accelerating in
3rd, engine races or
slippage occurs.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Line pressure testAT- 5 0
3. Accelerator pedal position sensorAT-131
4. CAN communication lineAT- 9 4
5. High and low reverse clutch solenoid valveAT-151
6. Control valve with TCMAT-215
OFF vehicle7. Torque converterAT-255
8. Oil pump assemblyAT-271
9. 3rd one-way clutchAT-274
10. Gear systemAT-246
11. High and low reverse clutchAT-286
12. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 7 , "
Cross-sectional View" .)AT-255
13. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-sectional View" .)AT-255
No. Items Symptom Condition Diagnostic ItemReference
page

AT-74
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
40
Slips/Will
Not
EngageWhile accelerating in
4th, engine races or
slippage occurs.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Line pressure testAT- 5 0
3. Accelerator pedal position sensorAT- 1 3 1
4. CAN communication lineAT- 9 4
5. Input clutch solenoid valveAT- 1 4 5
6. Control valve with TCMAT- 2 1 5
OFF vehicle7. Torque converterAT- 2 5 5
8. Oil pump assemblyAT- 2 7 1
9. Input clutchAT- 2 7 6
10. Gear systemAT- 2 4 6
11. High and low reverse clutchAT- 2 8 6
12. Direct clutchAT- 2 8 8
41While accelerating in
5th, engine races or
slippage occurs.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Line pressure testAT- 5 0
3. Accelerator pedal position sensorAT- 1 3 1
4. CAN communication lineAT- 9 4
5. Front brake solenoid valveAT- 1 4 7
6. Control valve with TCMAT- 2 1 5
OFF vehicle7. Torque converterAT- 2 5 5
8. Oil pump assemblyAT- 2 7 1
9. Front brake (brake band)AT- 2 5 5
10. Input clutchAT- 2 7 6
11. Gear systemAT- 2 4 6
12. High and low reverse clutchAT- 2 8 6
42 Slips at lock-up.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Line pressure testAT- 5 0
3. Engine speed signalAT- 11 3
4. Turbine revolution sensorAT- 1 0 6
5. Torque converter clutch solenoid valveAT- 1 2 5
6. CAN communication lineAT- 9 4
7. Control valve with TCMAT- 2 1 5
OFF vehicle8. Torque converterAT- 2 5 59. Oil pump assemblyAT- 2 7 1
No. Items Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-75
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
43
Slips/Will
Not
EngageNo creep at all.
Refer to AT-177,
"Vehicle Does Not
Creep Backward in
“R” Position" , AT-179,
"Vehicle Does Not
Creep Forward in “D”
Position" .ON vehicle1. A/T fluid level and stateAT- 4 9
2. Line pressure testAT- 5 0
3. Accelerator pedal position sensorAT-131
4. Direct clutch solenoid valveAT-149
5. PNP switchAT-102
6. CAN communication lineAT- 9 4
7. A/T positionAT-206
8. Control valve with TCMAT-215
OFF vehicle9. Torque converterAT-255
10. Oil pump assemblyAT-271
11. 1st one-way clutchAT-281
12. Gear systemAT-246
13. Reverse brakeAT-255
14. Direct clutchAT-288
15. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 7 , "
Cross-sectional View" .)AT-255
16. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-sectional View" .)AT-255
44Vehicle cannot run in
all positions.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Line pressure testAT- 5 0
3. PNP switchAT-102
4. A/T positionAT-206
5. Control valve with TCMAT-215
OFF vehicle6. Oil pump assemblyAT-2717. Gear systemAT-246
8. Output shaftAT-255
No. Items Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-77
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z49
Does Not
ChangeDoes not change M
3
→ M
2 .
Refer to AT-199, "
A/T
Does Not Shift: 3rd
Gear → 2nd Gear" .ON vehicle1. PNP switchAT-102
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT-206
4. Manual mode switchAT-157
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT-215
OFF vehicle7. Front brake (brake band)AT-2558. Input clutchAT-276
9. High and low reverse clutchAT-286
50Does not change M
2
→ M
1 .
Refer to AT-201, "
A/T
Does Not Shift: 2nd
Gear → 1st Gear" .ON vehicle1. PNP switchAT-102
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT-206
4. Manual mode switchAT-157
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT-215
OFF vehicle7. Input clutchAT-2768. High and low reverse clutchAT-286
9. Direct clutchAT-288
51Cannot be changed to
manual mode.
Refer to AT-196,
"Cannot Be Changed
to Manual Mode" .ON vehicle1. Manual mode switchAT-157
2. Turbine revolution sensorAT-106
3. CAN communication lineAT- 9 4
52
OthersShift point is high in
“D” position.ON vehicle1. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-108
,
AT-139
2. Accelerator pedal position sensorAT-131
3. CAN communication lineAT- 9 4
4. A/T fluid temperature sensorAT-134
5. Control valve with TCMAT-215
53Shift point is low in “D”
position.ON vehicle1. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-108
,
AT-139
2. Accelerator pedal position sensorAT-131
3. CAN communication lineAT- 9 4
4. Control valve with TCMAT-215
No. Items Symptom Condition Diagnostic ItemReference
page
