2007 MERCEDES-BENZ E63AMG WAGON Owner's Manual

144 Controls in detailLightingUSA only
By default, the daytime running lamp mode
is deactivated. Activate the daytime run-
ning lamp mode using the control system,
see “Setting daytime running lamp mode
(USA only)” (
page 176).
When the engine is running, and you turn
the exterior lamp switch to
positionCorB, the manual head-
lamp mode has priority over the daytime
running lamp mode.
The corresponding exterior lamps switch
on (
page 141).Locator lighting and night security illu-
mination
Locator lighting and night security illumi-
nation are described in the “Control sys-
tem” section, see (
page 177) and
(
page 178).
Fog lamps
i
With the daytime running lamp mode activat-
ed and the exterior lamp switch in positionM,
you cannot switch on the high beam headlamps.
The high beam flasher is available at all times.
For nighttime driving turn the exterior lamp
switch in positionB orU to permit activa-
tion of the high beam headlamps.
Warning!
G
In low ambient lighting or foggy conditions,
only switch from position U to B with
the vehicle at a standstill in a safe location.
Switching from U to B will briefly
switch off the headlamps. Doing so while
driving in low ambient lighting conditions
may result in an accident.
i
Fog lamps will operate with the parking
lamps and / or the low beam headlamps on. Fog
lamps should only be used in conjunction with
low beam headlamps. Consult your State or
Province Motor Vehicle Regulations regarding
permissible lamp operation.
i
Fog lamps cannot be switched on with the
exterior lamp switch in positionU. To switch
on the fog lamps, turn the exterior lamp switch to
positionB first.

145 Controls in detail
Lighting
Front fog lamps
Switch on the low beam
headlampsB (
page 141).

Pull out the exterior lamp switch to first
stop.
The front fog lamps switch on.
The green indicator lamp‡ in the
exterior lamp switch comes on
(page 141).

Push in the exterior lamp switch.
The front fog lamps switch off.
The green indicator lamp‡ in the
exterior lamp switch goes out.Rear fog lamp (driver’s side only)

Switch on the low beam
headlampsB (
page 141).

Pull out the exterior lamp switch to sec-
ond stop.
The front fog lamps and the rear fog
lamp switch on.
The yellow indicator lamp† in the
exterior lamp switch comes on
(page 141).

Push in the exterior lamp switch to first
stop.
The rear fog lamp switches off.
The yellow indicator lamp† in the
exterior lamp switch goes out.
The front fog lamps remain lit.
Combination switchCombination switch1High beam
2High beam flasher

146 Controls in detailLightingHigh beam
Turn the exterior lamp switch to
positionB (
page 141).

Push the combination switch in direc-
tion of arrow1 to switch on the high
beam.
The high beam headlamp indicator
lampA in the instrument cluster
comes on (
page 26).

Pull the combination switch in direction
of arrow2 to its original position to
switch off the high beam.
The high beam headlamp indicator
lampA in the instrument cluster
goes out.
High beam flasher

Pull the combination switch briefly in
direction of arrow2.
Corner-illuminating front fog lamps*
The corner-illuminating front fog lamps im-
prove illumination of the area in the direc-
tion into which you are turning.
The corner-illuminating front fog lamps will
operate with the engine running and with

the exterior lamp switch in
positionB (
page 141)
or


the exterior lamp switch in
positionU (
page 141)
or


the daytime running lamp mode
activated (
page 143).Driving forward
Switching on corner-illuminating front
fog lamps

Switch on the left or right turn signal
(page 56), depending on whether
you are turning left or right.
The respective front fog lamp comes on
and illuminates the area in the direc-
tion into which you are turning.
or

Turn steering wheel in desired direc-
tion.
The front fog lamp on the side of your
steering direction comes on.
i
With the automatic headlamp mode activat-
ed: The corner-illuminating front fog lamps will
only come on in low ambient lighting conditions.
i
If you are driving faster than 25 mph
(40 km/h), the corner-illuminating function is
not available.
i
If you have switched on the turn signal for
one side but turn the steering wheel in the oppo-
site direction, the corner-illuminating front fog
lamp comes on for the side indicated by the turn
signal.
The corner-illuminating front fog lamp remains lit
for a maximum of 3 minutes. Afterward, it goes
out even if the turn signal is still switched on.

147 Controls in detail
Lighting
Switching off corner-illuminating front
fog lamps
The combination switch for the turn signal
resets automatically after major steering
wheel movements. This will switch off the
corner-illuminating front fog lamps if they
were activated by switching on the left or
right turn signal.If the turn signal should stay on after mak-
ing the turn, the turn signal and the cor-
ner-illuminating front fog lamps can be
switched off by returning the combination
switch to its original position.Driving in reverse
Switching on corner-illuminating front
fog lamps

Place the gear selector lever in
positionR.
The front fog lamp opposite to your
steering direction comes on.
Switching off corner-illuminating front
fog lamps

Place the gear selector lever out of
positionR.
The respective front fog lamp goes out.
i
The corner-illuminating front fog lamps tem-
porarily come on on both sides of the vehicle if
you turn the steering wheel in one direction and
then again in the other direction shortly thereaf-
ter.
i
The corner-illuminating front fog lamps will
come on automatically depending on the steer-
ing angle, even if you did not switch on either
turn signal.
If the corner-illuminating front fog lamps came
on automatically, they will also go out automati-
cally depending on the steering angle.
i
There may be a brief delay before the cor-
ner-illuminating front fog lamps switch off.

148 Controls in detailLightingHazard warning flasher
The hazard warning flasher can be
switched on at all times, even with the
SmartKey removed from the starter switch
or with the SmartKey with KEYLESS-GO*
removed from the vehicle.
The hazard warning flasher switches on
automatically when an air bag deploys.
The hazard warning flasher switch is locat-
ed on the upper part of the center console.
1Hazard warning flasher switchSwitching on hazard warning flasher

Press the hazard warning flasher
switch1.
All turn signals are flashing.Switching off hazard warning flasher

Press hazard warning flasher switch1
again.
i
With the hazard warning flasher activated
and the combination switch set for either left or
right turn, only the respective left or right turn
signals will operate when the ignition is switched
on.
i
If the hazard warning flasher has been acti-
vated automatically, press hazard warning flash-
er switch1 once to switch it off.

149 Controls in detail
Lighting
Interior lighting in the front
The controls are located in the overhead
control panel.1Left front reading lamp on/off
2Automatic control on/off
3Rear interior lighting on/off
4Right front reading lamp on/off
5Front interior lighting on/off
6Interior lighting
7Ambient lighting
8Front reading lamps
Deactivating automatic control

Press switch2.
The interior lighting remains switched
off in darkness, even when you:

unlock the vehicle


remove the SmartKey from the
starter switch


open a door


open the tailgate
Activating automatic control

Press switch2.
The interior lighting switches on in
darkness, when you:

unlock the vehicle


remove the SmartKey from the
starter switch


open a door


open the tailgate
The interior lighting switches off after a
preset time (
page 179).
!
An interior lamp switched on manually does
not go out automatically.
Leaving an interior lamp switch in the ON posi-
tion for extended periods of time with the engine
turned off could result in a discharged battery.
i
The interior lighting is factory-set to auto-
matic mode.
i
If a door remains open, the interior lighting
switches off automatically after approximately
5minutes.
An interior lamp switched on manually does not
go out automatically.

150 Controls in detailLightingManual control
Switching front/rear interior lighting on
and off
Press front/rear interior lighting
switch5 or 3 (
page 149) to switch
on the desired interior light.

Press front/rear interior lighting
switch5 or 3 again to switch off the
respective interior light.
Switching front reading lamps on and off
The front reading lamps are located in the
lower edge of the interior rear view mirror.

Press front reading lamp
switch1or4 (
page 149) to
switch on the desired front reading
lamp.

Press front reading lamp
switch1or4 again to switch off the
respective front reading lamp.Ambient lighting
You can switch the ambient lighting7
(
page 149) on and off, using the “Control
system” (
page 178).
Interior lighting in the rear
The overhead control panel is located
above the rear seat bench.
1Left rear reading lamp on/off
2Left rear reading lamp
3Ambient lighting switch, to brighten
4Ambient lighting
5Right rear reading lamp
6Right rear reading lamp on/off
7Ambient lighting switch, to dim
8Rear interior lamp

151 Controls in detail
Lighting
Rear reading lamps
Press rear reading lamp
switch1or6 to switch on the re-
spective rear reading lamp.

Press rear reading lamp
switch1or6 again to switch off the
respective rear reading lamp.
Ambient lighting

Press ambient lighting switch3 or7
repeatedly until ambient lighting4
has reached the desired intensity.
You can switch the ambient lighting on and
off, using the “Control system”
(
page 178).
Door entry lamps
For better orientation in the dark, the cor-
responding door entry lamps will switch on
in the darkness when you open a door and
the automatic control is activated.
The door entry lamps will switch off when
the corresponding door is closed.
Cargo compartment lamps
The cargo compartment lamps switch on if
the cargo compartment is opened.
If you leave the tailgate open for an extend-
ed period of time, the cargo compartment
lamps will switch off automatically after
approximately 10 minutes.
i
If you turn the SmartKey in the starter
switch to position0 and switch off the head-
lamps, the door entry lamps will remain lit for ap-
proximately 5 minutes.
