These operating conditions are obtained pressing in
sequence the air recirculation button C.
After a preset time, the climate control system will
turn air recirculation off automatically for safety
reasons, thus enabling outside air inlet.IMPORTANT The air recirculation system
makes it possible to reach the required heating or
cooling conditions faster.
It is however inadvisable to use it on rainy/cold
days as it would considerably increase the
possibility of the windows misting inside, especially
if the climate control system is off.
When the outside temperature is below 5-7°C, air
recirculation is switched off (air is taken from the
outside) to prevent misting.
WARNINGIt is inadvisable to use the air recirculation feature with low outside temperature
as the windows might mist over quickly.

96
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
Climate control compressor on/off
button B
Press the
√button, when the button
led is on, to switch the compressor
off. The led will go off. By pressing
again the button when the led is off, the system
automatic control of the compressor activation is
restored; this condition is indicated by button led
lighting up.
When the air conditioner compressor is off, the
system deactivates air recirculation to prevent
window misting up. Although the system is still able
to maintain the required temperature, the message
FULL on the display will go off. If the system is no
longer able to keep the required temperature, also
the message AUTO will turn off.
IMPORTANT Air at a temperature lower than that
of the outside air cannot be let into the passenger
compartment when the compressor is off.
Furthermore, in particular environmental
conditions, the windows could mist up fast because
the air is no longer dehumidified.Setting will be stored also when the engine is
stopped.
Either press again button √(in this case the system
operates as heater only) or AUTO to reset automatic
control of the compressor.
With compressor off, if the outside temperature is
higher than the set temperature, the system cannot
reach the required temperature. This will be
signalled by the flashing of set temperature value on
the display for a few seconds, then the message
AUTO will go off.
When the compressor is off, it is possible to reset
manually the fan speed (no bar displayed).
When the compressor is on and the engine is
running, fan speed cannot be lower than the
minimum (one bar displayed).

97
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
Button for fast windscreen and
front side window
demisting/defrosting F
Press this button: the climate control
system will automatically switch on
all the functions required for fast windscreen and
front side window demisting/defrosting, that is:
❒climate control system compressor on (with
proper climatic conditions);
❒air recirculation off;
❒maximum air temperature HI on both areas;
❒fan speed according to engine coolant
temperature in order to limit letting cold air into
the passenger compartment for demisting the
windows;
❒air flow directed to the windscreen and front side
window vents;
❒heated rear windowIMPORTANT The fast windscreen
demisting/defrosting function stays on for approx.
3 minutes after the engine coolant temperature
exceeds 50°C (petrol versions) or 35°C
(Multijet versions).
When the max. demisting/defrosting function is on,
the led on the relevant button and that on the
heated rear window button turn on. Message FULL
AUTO on the display will turn off.
When the max. demisting/defrosting function is on,
the only manual operations possible are manual
adjustment of the fan and switching rear window
heating off.
Press button F or air recirculation button C or
compressor button B or AUTO buttons N o H to
reset the previous system operation conditions.

98
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
Button for demisting/defrosting
the heated rear window and door
mirrors G
Press this button to switch on the
heated rear window
demisting/defrosting function. The led on the
button will come on.
This function will be automatically switched off
after the preset time, or pressing the button again or
when stopping the engine. It will not start up
automatically when the engine is started again.
IMPORTANT Do not apply stickers on the inside of
the rear window over the heating filaments to avoid
damage that might cause it to stop working
properly.❒climate control system compressor off;
❒fan off.
The heated rear window can be switched on and off
normally when the system is off by pressing button
G.
IMPORTANT The climate control system electronic
unit stores the system settings made before the
system was switched off and restores them as soon
as a button is pressed (with the exception of the
heated rear window button). The function which
the button corresponds to will be switched on, if it
was off when the system was switched off. It will be
kept if, on the other hand, it was on when the
system was switched off.
Press the AUTO button to switch the climate control
system back on.
OFF button E (system off)
To switch the climate control system
off, press button E, also the display
will go off.
The climate control system
conditions when the system is off are the following:
❒Every led off;
❒set temperatures not displayed;
❒air recirculation on, thus isolating the passenger
compartment;

99
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
EXTERNAL LIGHTS
The left-hand stalk controls the external lights and the direction
indicators.
The external lights can only be switched on when the ignition key is
at MAR.
LIGHTS SWITCHED OFF
Turn the knurled ring to
å.
SIDELIGHTS
Turn the knurled ring to 6.
The warning light 3on the instrument cluster will come on.
DIPPED BEAM HEADLIGHTS
Turn the knurled ring to 2.
L0D0066m
L0D0067m
L0D0068m

100
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
MAIN BEAM HEADLIGHTS
When the knurled ring is at 2pull the lever towards the steering
wheel (stable position).
The warning light 1on the instrument cluster will come on.
Pulling the lever towards the steering wheel again, the main beams
are turned off (and the dipped beams on).
FLASHING THE HEADLIGHTS
Pull the lever towards the steering wheel (unstable position)
regardless of the position of the knurled ring.
IMPORTANT Check on the display that stable position is not
engaged.
L0D0069m
L0D0070m

101
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
DIRECTION INDICATORS
Move the stalk:
❒up (stable position 1): to engage the right-hand direction
indicator;
❒down (stable position 2): to engage the left-hand direction
indicator.
Warning light ForDwill come on flashing on the instrument cluster.
Indicators are switched off automatically when the steering wheel is
straightened.
If you want the indicator to flash briefly to show that you are about to
change lane, move the stalk up or down without clicking into position
(unstable position). When released the stalk will return to its home
position.
L0D0071m

102
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
“FOLLOW ME HOME” DEVICE
This function allows the illumination of the space in front of the car
for a preset time.
Activation
With the ignition key at STOP or removed, pull the stalk towards the
steering wheel and operate it within 2 minutes from when the engine
is turned off.
At each single movement of the stalk, the staying on of the lights is
extended by 30 seconds up to a maximum of 210 seconds; then the
lights are switched off automatically.
Each time the lever is operated, the 3warning light turns on
together with the message on the display (see section “Warning lights
and messages”).
Deactivation
Keep the stalk pulled towards the steering wheel for more than 2
seconds.
L0D0070m
