2007 Lancia Musa technical specifications

FUEL CONSUMPTION
The fuel consumption figures given in the table below are determined on the basis of the homologation tests set
down by specific European Directives.
The procedures below are followed for measuring consumption:
❒urban cycle: cold starting followed by driving that simulates urban use of the car;
❒extra-urban cycle: frequent accelerating in all gears, simulating extraurban use of the car; the speed varies
between 0 and 120 km/h;
❒combined consumption: is calculated weighing about 37% of urban cycle consumption and about 63% of
extraurban consumption.
IMPORTANT The type of route, traffic situations, weather conditions, driving style, general conditions of the
car, trim level/equipment/accessories, load, climate control system, roof rack, other situations that affect air
drag may lead to different fuel consumption levels than those measured.
Fuel consumption according to Directive 1999/100/EC (litres x 100 km)Urban Extra-urban Combined
1.48V(◊7.9 5.2 6.2
1.416V(5 gears) 8.5 5.5 6.6
1.416V(6 gears) 8.7 5.4 6.6
1.416VDual FuNction System 8.3 5.4 6.4
1.3 Multijet 70HP 6.2 4.5 5.1
1.3 Multijet 90HP 6.0 4.0 4.7
1.3 Multijet 70 HP Dual FuNction System 6.0 4.4 5.0
1.3 Multijet 90 HP Dual FuNction System 5.8 3.9 4.6
1.9 Multijet 6,5 4.4 5.2
(◊) Engine model provided for certain versions/markets only
335
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARDAND CONTROLS
SAFETY
DEVICES
ACORRECT
USE OF
THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS

CO2EMISSIONS
The CO2, emission levels at the exhaust given in the following table refer to combined consumption.
CO
2emissions according to 1999/100/EC Directive (g/km)
336
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARDAND CONTROLS
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
1.48V(◊)1.416V1.416VDual5 gears 6 gears FuNction System
146 157 157 153
(◊) Engine model provided for certain versions/markets only
1.3 Multijet 1.3 Multijet 1.3 Multijet 70HP 1.3 Multijet 90HP 1.9 Multijet70HP 90HP Dual FuNction System Dual FuNction System
135 124 132 122 137
(◊) Engine model provided for certain versions/markets only

337
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
DASHBOARDAND CONTROLS
INDEX
INDEX
ABS (system) ...................... 138
ASR (system) ...................... 142
Accessories purchased
by the user ........................ 149
Air bags (front) ................... 175
– driver's air bag ............... 176
– passenger's front air bag . 176
– passenger's front air bag
manual deactivation ...... 177
– side bags .......................... 178
Air vents ............................. 82
Ashtray (Smokers’ kit) ....... 123
At the filling station............. 154
Automatic two-zone climate
control system ..................... 88
Battery
– checking the charge ........ 305
– jump starting .................. 254
– recharging ...................... 286
– replacing ........................ 306
Bodywork
– maintenance .................. 314
– version codes .................. 321
Bonnet ................................ 134
Boot ................................... 129
– extension ........................ 134– light ................................ 279
Brake lights
– bulb replacement ............ 276
Brakes
– fluid level ...................... 303
– handbrake ..................... 187
– technical data ................. 324
Bulb (replacement).............. 268
Capacities ........................... 332
Car inactivity ..................... 208
Car maintenance............... 290
– additional checks ............ 294
– Annual Inspection
Schedule ......................... 294
– scheduled service ............ 291
– Service Schedule ............. 292
Carrying children safely ...... 165
Ceiling lights ....................... 112
– bulb replacement ............ 277
Cellular telephone
– presetting........................ 148
Checking fluid levels ......... 297
Child lock ........................... 14Cigar lighter (Smokers’ kit) ... 123
Clutch ................................ 323
CO
2emissions .................... 336
Correct use of the car ....... 183
Cruise Control .................... 109
Current sockets ................... 122
Dashboard and controls.. 7-23
Diesel fuel filter .................. 304
Dimensions.......................... 329
Dipped beam headlights
– bulb replacement ............ 272
– control ........................... 99
Direction indicators ............ 101
– bulb replacement ............ 273
– control ........................... 101
Door pockets ....................... 120
Doors .................................. 11
– emergency device for
locking doors from
outside ........................ 11-252
Dual FuNction System
gearbox ............................. 189
– oil level ........................... 301
Dualdrive
(electric power steering) ... 150

338
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
DASHBOARDAND CONTROLS
INDEX
Emergency device for
locking doors from the
outside........................... 15-252
Engine
– fuel feed ......................... 322
– identification code .......... 321
– injection/ignition ........... 184
– technical data ................ 322
Engine compartment .......... 297
Engine coolant gauge .......... 28
Engine coolant level ............ 101
Engine oil
– checking level ................. 299
– consumption ................... 299
– technical specifications ... 333
Environment (protection) .... 156
EOBD (system) .................. 144
ESP (system) ...................... 140
External lights ..................... 99
Fix &Go (tyre repair kit) .... 256
Flashing the headlights ....... 100
Fluids and lubricants .......... 333
Follow me home (device) .... 102
FPS (fuel cut-off switch) .... 117
Front fog lights
– bulb replacement ............ 274– control button ................. 115
Fuel
– consumption ................... 335
– fuel cut-off switch ........... 117
– level gauge ..................... 27
– fuel cut-off switch ........... 117
Fuel filler cap ...................... 155
Fuses ................................... 280
Glass/can holders................ 120
Handbrake ......................... 187
Hazard lights
– control ........................... 115
Head restraints ................... 77
Headlights .......................... 103
(electric adjusting device) .. 103
Heated rear window ...........85-97
Identification data ............. 319
Ignition switch .................... 20
In an emergency................ 251
Instrument panel ................ 26
Instruments ......................... 27
Interior equipment ............. 125
Interior fittings
– current socket ................. 122
– glass / can holder ........120-121– magnetic card/ticket
slots ................................ 121
– oddment compartments .. 119
– rear CD compartment
with glass/can holder ..120-121
– roof bracket .................... 121
– upper oddment
compartments ................ 118
Interiors ............................. 317
Isofix (child seat) ................ 172
Jack ................................... 265
Jacking the car .................... 287
Key kit and door locking .... 10
Lancia CODE (system) ...... 8
Light control buttons .......... 115
Load limiters ....................... 163
Lubricants (specifications) .. 333
Magnetic card/ticket slots ... 121
Main beam headlights
– bulb replacement ............ 272
– control ........................... 100

339
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
DASHBOARDAND CONTROLS
INDEX
– flashing .......................... 100
Manual climate control
system .............................. 83
Mechanical gearbox (use) .... 188
Multifunction display .......... 37
– controls........................... 38
Number plate light
– bulb replacement ........... 277
Oddment compartments ..... 119
– upper .............................. 118
Outlets ................................ 122
Parking ............................. 187
Parking sensors ................... 152
Performance ........................ 330
Plates ................................. 319
Power windows ................... 126
Pretensioners ....................... 162
Prolonged car inactivity ...... 208
Protecting the environment.. 156
Radio transmitters and
cellular telephones ............. 148
Rain sensor ......................... 106Rear fog lights
– bulb replacement ............ 276
– control button ................. 116
Rear window washer
– control ........................... 108
– fluid level ...................... 302
Rear window wipers
– blades ............................ 311
– control ........................... 104
– nozzles ............................ 313
– smart washing ................ 105
Rearview mirrors ................. 79
Rev counter ......................... 27
Reversing light
– bulb replacement ............ 275
Rims and tyres .................... 325
Roof racks ......................... 136
Rubber tubing ..................... 311
Safety devices................... 157
Seat belts
– general instructions ....... 163
– height adjustment .......... 160
– maintenance .................. 165
– S.B.R. system .................. 159
– use ............................ 158-160Seats ................................... 70
Side bags ............................ 178
Side/taillights
– bulb replacement ....... 274-275
– control ........................... 99
Smart washing .................... 105
Snow chains ....................... 207
Sound system
– installation .................... 147
– preset system ................. 147
Spark plugs ......................... 322
Speedometer........................ 27
Starting the engine
– bump starting ................. 255
– emergency start-up ......... 253
– ignition switch ............... 22
– jump starting ................. 254
– JTD engines .................... 184
– petrol engines ................ 184
– stopping the engine ......... 186
– warming up the engine .. 186
Steering ............................... 324
Steering lock ...................... 22
Steering wheel (adjustment) 69
Sunroof ............................... 124
Sun visors ........................... 123

340
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
DASHBOARDAND CONTROLS
INDEX
Suspensions ......................... 324
Symbols .............................. 8
Technical specifications.. 318
Third brake light
– bulb replacement ........... 276
Towing the car..................... 287
Towing trailers .................... 203
T.P.M.S. (system)................. 145
Transmission ....................... 323
Transporting children
safely ................................. 165
Tyre Pressure Monitoring
System (T.P.M.S.) .............. 145
Ty r e s
– correct tyre reading......... 325
– snow tyres....................... 327
– standard ......................... 327
Using the Dual FuNction System
gearbox ............................. 189
Warning lights and
messages.......................... 209
Weights ............................... 331Wheel
– changing ........................ 261
– spare wheel ..................... 327
Wheel geometry .................. 325
Windows (cleaning) ............. 316
Windscreen washer
– control ............................ 104
– fluid level ....................... 302
Windscreen wiper
– blades ............................ 311
– control ........................... 104
– nozzles ............................ 313
– smart washing ............... 105
