2007 Lancia Musa technical specifications

63
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
“Trip computer” information are displayed according to the following diagram:
See “Initial check”
and “Access to
menu screen”
Previously
displayed
screen, e.g.:(*)
%%%%
%%
continues on next page
&= “Reset General trip” and “Trip B” excluding
“Cruising range” (see paragraph “Reset
General trip”).The two screens concerning a trip
item alternate three times, then the
second one stays on fixed on the
display.
%
(*)
(*)
(*) (*) (*)
(*)
%= Press “TRIP” button for less than two seconds - &= Press “TRIP” button for over two seconds

64
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
continued from previous pageTrip B ON?NO
YES
Return to
previously
displayed screen,
e.g.:
8:3020oC%%%%
&= “Reset Trip B”
(see paragraph “Reset Trip B”).
(*)(*)(*) (*)
%= Press “TRIP” button for less than two seconds - &= Press “TRIP” button for over two seconds

65
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
After resetting “Trip” by pressing the button with &mode, the following functions are displayed:
Reset GENERAL TRIP
&= “Reset General trip” and “Trip B”
(excluding “Cruising range”).
&= “Reset Trip B”
Reset TRIP B
All values set to zero
Only partial values are set to zero
%= Press “TRIP” button for less than two seconds - &= Press “TRIP” button for over two seconds

66
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
Cruising range= = Shows the distance in km (or
mi) that the car can still cover before needing fuel,
assuming that driving conditions are kept unvaried.
The display will show “- - - - in the following
cases:
❒value for range to empty lower than 50 km or
fuel level below 4 litres; in this event before
“- - - -” the message “Warning, limited range”
will be displayed (this message will be displayed
also if not in TRIP COMPUTER mode);
❒in case of car parked with engine running for a
long period, when the car moves off the range to
empty indication will be displayed again.
Travelled distance= shows the km (or miles)
covered from last reset (*).
Average fuel consumption= shows the average
consumption calculated from last reset (*), this
value can be expressed in l/100 km, km/l or mpg.
Instant consumption = shows the fuel
consumption variation updated every second, it can
be expressed in l/100 km or mpg. In case of car
parked with engine running the display will show
“- - - -”. When the car moves off the instant
consumption indication will be displayed again.
Average speed= shows the average speed of the
car in relation with total time elapsed from last reset
(*) and it can be expressed in km/h or in mph.Travel time= time elapsed from last reset (*).
(*) Reset can be:
– “manual”, reset is performed by the driver by
pressing the relevant button (see paragraph
“Control buttons”)
– “automatic”, reset is performed when the
travelled distance reaches 9999.9 km or when
Travel time reaches 99:59 (99 hours and 59
minutes)
– after reconnecting the battery.
IMPORTANT Lacking information, Trip computer
values are displayed with “- - - -”. When normal
operating condition is reset, calculation of different
units will restart regularly. Values displayed before
the failure will not be reset (*).
IMPORTANT After battery disconnection/
connection certain displayed values are equal to
“- - - -” until significant data for calculation are
available.

67
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
INSTRUMENT PANEL, DISPLAY AND BUTTON LIGHTING ADJUSTMENT
(LIGHT RHEOSTAT)
With this function it is possible to adjust the lighting (dimming/brightening) of the instrument cluster and two-
zone climate control display (where provided).
To adjust proceed as follows:
See “Initial check”
and “Access to
menu screen”
– +– +
Automatic return to standard screen
after few seconds or by
pressing button
Q
Previously
displayed
screen, e.g.:Use buttons +/– to carry out required
light adjustment.
L0D0040m
Q= Press “MODE” button for less than two seconds
R= Press “MODE” button for over two seconds

68
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
INERTIAL FUEL CUT-OFF SWITCH OPERATION WARNING
MESSAGE
The message shown in the figure is displayed automatically when the
fuel cut-off switch comes into operation after a crash.
This switch stops fuel supply.
See paragraph “Inertial fuel cut-off switch”.
WARNING
If after warning message displaying you smell fuel or see leaks from the fuel
system, do not reset the switch to avoid fire risk.

69
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
WARNING
Any adjustment of the steering wheel position must be carried out only with the
car stationary and the engine turned off.
STEERING WHEEL ADJUSTMENT
The steering wheel can be adjusted both in height A and axially B.
Proceed as follows:
❒release the lever pulling it towards the steering wheel (position 2);
❒adjust the steering wheel as required;
❒lock the lever pushing it forwards (position 1).
L0D0055m
WARNING
It is absolutely forbidden to carry out whatever after-market operation involving
steering system or steering column modifications (e.g.: installation of anti-theft
device) that could badly affect performance and safety, cause the lapse of
warranty and result in car non-compliance with the regulations in force.

70
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
SEAT ADJUSTMENT
FRONT SEATS
Moving the seat backwards or forwards
Lift the lever A and push the seat forwards or backwards: in the
driving position the arms should rest on the rim of the steering wheel.
Always check that the seat is firmly locked in the runners by trying to
move it back and forth.
Seat height adjustment (driver’s side) (where provided)
Move repeatedly lever B upwards or downwards to achieve the
required height.
IMPORTANT Adjustment must be carried out only seated in the
driver’s seat with the car at a standstill.
Back rest angle adjustment
Move lever D as shown by the arrow, set the back rest in the required
position, then release the lever.
Lumbar adjustment (where provided)
Turn knob C clockwise or counterclockwise to increase or decrease
lumbar adjustment.
After adjustments, always check that the seat is firmly locked in the runners.
WARNING
L0D0041m
L0D0042m
