2007 INFINITI FX35 washer fluid

FRONT WIPER AND WASHER SYSTEM WW-37
C
D E
F
G H
I
J
L
M A
B
WW
Revision: 2006 July 2007 FX35/FX45
Inspection of Washer NozzleNKS004P0
CHECK VALVE
Blow check valve. Confirm that the air ventilates. Also confirm that
inhalation is impossible.
Inspection of Front Wiper and Washer Switch CircuitNKS004P8
Refer to LT- 11 8 , "Combination Switch Inspection" .
Removal and Installation of Front Wiper and Washer SwitchNKS00330
REMOVAL
1. Remove steering column upper cover. Refer to IP-10, "INSTRU-
MENT PANEL ASSEMBLY" .
2. Disconnect wiper and washer switch connector.
3. Pull wiper and washer switch toward the passenger door while pressing pawls in direction shown by the arrow in the figure, and
remove it from the base.
INSTALLATION
Installation is the reverse order of removal.
Removal and Installation of Washer TankNKS00331
REMOVAL
1. Remove bolt and pull out washer tank inlet out of washer tank.
2. Remove front fillet molding (RH). Refer to EI-14, "
FRONT
BUMPER" .
3. Remove fender protector front (RH). Refer to EI-24, "
FENDER
PROTECTOR" .
4. Remove front bumper fascia assembly. Refer to EI-14, "
FRONT
BUMPER" .
5. Disconnect washer pump connector and wash fluid level sensor connector.
6. Remove washer tank mounting bolt and nuts.
PKIA3131E
PKIB6026E
SKIA5076E
PKIC9705E

REAR WIPER AND WASHER SYSTEM WW-51
C
D E
F
G H
I
J
L
M A
B
WW
Revision: 2006 July 2007 FX35/FX45
Removal and Installation of Rear Wiper Arm, Adjustment of Wiper Arms Stop
Location
NKS004P1
REMOVAL
1. Turn rear wiper switch ON to operate wiper motor, then turn rear wiper switch OFF (auto stop).
2. Remove rear wiper arm cap, and remove rear wiper arm nut.
3. Remove rear wiper arm from the vehicle.
INSTALLATION
1. Clean up the pivot area as shown in the figure. This will reduce possibility of rear wiper arm nuts looseness.
2. Prior to rear wiper arms installation, turn rear wiper switch ON to operate wiper motor, and then turn rear wiper switch OFF (auto
stop).
3. Lift the blade up and then set it down onto back door window glass surface to set the blade center to lowest heat wire immedi-
ately.
4. Tighten rear wiper arm nuts to specified torque.
5. Spray washer fluid. Turn on rear wiper switch ON to operate wiper motor, and then turn rear wiper switch OFF (auto stop).
6. Ensure that wiper blade stop within the following range.
7. Install rear wiper arm cap.
Removal and Installation of Rear Wiper BladeNKS004P2
REMOVAL
1. Remove rear wiper arm. Refer to WW-51, "REMOVAL" .
2. Turn rear wiper blade 90 degrees against rear wiper arm, and pull it out downward for removal.
CAUTION:
Replace rear wiper blade as rear wiper blade assembly.
SKIA0082J
Rear wiper arm nut : 8.8 N·m (0.90 kg-m, 78 in-lb)
Lowest heat wire : ± 3.75 mm ( ± 0.148 in)
PKID0496E
SKIA6169E

WW-54
REAR WIPER AND WASHER SYSTEM
Revision: 2006 July 2007 FX35/FX45
Removal and Installation of Washer NozzleNKS004P5
REMOVAL
1. Remove high-mounted stop lamp. Refer to LT- 1 2 8 , "High-
Mounted Stop Lamp" .
2. Remove screw and remove washer nozzle from high-mounted stop lamp.
INSTALLATION
Installation is the reverse order of removal. Adjust nozzle spray location. Refer to WW-53, "Washer Nozzle
Adjustment" .
Check ValveNKS004P6
Blow check valve. Confirm that the air ventilates. Also confirm that
inhalation is impossible.
CAUTION:
A check valve is provided in the washer fluid line. Be careful not
to connect check valve to washer tube in the wrong direction.
Inspection of Front Wiper and Washer Switch CircuitNKS004P7
Refer to LT- 11 8 , "Combination Switch Inspection" .
Removal and Installation of Rear Wiper and Washer SwitchNKS0033N
Refer to WW-37, "Removal and Installation of Front Wiper and Washer Switch" .
Removal and Installation of Washer TankNKS0033O
Refer to WW-37, "Removal and Installation of Washer Tank" .
Removal and Installation of Front and Rear Washer pumpNKS0033P
Refer to WW-38, "Removal and Installation of Front and Rear Washer Pump" .
PKIB6132E
SEL411H
