TROUBLE DIAGNOSIS FOR SYMPTOMS BRC-55
[VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
Revision: 2006 July 2007 FX35/FX45
Vehicle Jerks During VDC/TCS/ABS ControlNFS000O3
1. CHECK ENGINE SPEED SIGNAL
Perform CONSULT-II “DATA MONITOR” to check engine speed.
Is engine speed at idle 400 rpm or higher?
YES >> GO TO 3.
NO >> GO TO 2.
2. CHECK ABS WARNING LAMP DISPLAY
Make sure warning lamp turns off approximately 2 seconds after the ignition switch is turned ON or when driv-
ing.
OK or NG
OK >> System is normal.
NG >> GO TO 3.
3. CHECK ECM SELF-DIAGNOSTIC RESULTS
Perform ECM self-diagnosis.
Are self-diagnosis items displayed?
YES >> Check the corresponding items. Refer to EC-87, "TROUBLE DIAGNOSIS" (VQ35DE), EC-749,
"TROUBLE DIAGNOSIS" (VK45DE) in “Engine Control (EC section)”.
NO >> GO TO 4.
4. CHECK A/T SELF-DIAGNOSTIC RESULTS
Perform A/T self-diagnosis.
OK or NG
OK >> GO TO 5.
NG >> Check the corresponding items. Refer to AT- 4 4 , "
TROUBLE DIAGNOSIS" in “A/T”.
5. CHECK SELF-DIAGNOSTIC RESULTS 1
Perform self-diagnosis of ABS actuator and electric unit (control unit).
Are self-diagnosis items displayed?
YES >> Check the corresponding items, make repairs, and perform ABS actuator and electric unit (control unit) self-diagnosis again.
NO >> GO TO 6.
6. CHECK CONNECTOR
1. Disconnect ABS actuator and electric unit (control unit) connector E56 and ECM connector, check termi- nals for deformation, disconnection, looseness, and so on. If any malfunction is found, repair or replace
connector.
2. Securely reconnect connector and perform self-diagnosis.
OK or NG
OK >> If poor connect, damaged, open or short circuit is found, repair or replace connector terminal.
NG >> GO TO 7.
7. CHECK SELF-DIAGNOSTIC RESULTS 2
Re-perform ABS actuator and electric unit (control unit) self-diagnosis.
Are self-diagnosis items displayed?
YES >> Repair or replace malfunctioning items.
NO >> GO TO 8.

CO-1
ENGINE COOLING SYSTEM
B ENGINE
CONTENTS
C
D E
F
G H
I
J
K L
M
SECTION
A
CO
Revision: 2006 July 2007 FX35/FX45
ENGINE COOLING SYSTEM
VQ35DE
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 3
Precautions for Liquid Gasket ............................. ..... 3
REMOVAL OF LIQUID GASKET SEALING ..... ..... 3
LIQUID GASKET APPLICATION PROCEDURE ..... 3
PREPARATION ...................................................... ..... 5
Special Service Tools .......................................... ..... 5
Commercial Service Tools ................................... ..... 6
OVERHEATING CAUSE ANALYSIS ..................... ..... 7
Troubleshooting Chart ......................................... ..... 7
COOLING SYSTEM ............................................... ..... 9
Cooling Circuit ..................................................... ..... 9
System Chart ...................................................... ... 10
ENGINE COOLANT ............................................... ....11
Inspection ............................................................ .... 11
LEVEL CHECK ................................................ .... 11
LEAK CHECK .................................................. .... 11
Changing Engine Coolant ................................... .... 11
DRAINING ENGINE COOLANT ...................... .... 11
REFILLING ENGINE COOLANT ..................... ... 12
FLUSHING COOLING SYSTEM ...................... ... 13
RADIATOR ............................................................. ... 14
Components ........................................................ ... 14
Removal and Installation ..................................... ... 14
REMOVAL ........................................................ ... 14
INSTALLATION ................................................ ... 15
INSPECTION AFTER INSTALLATION ............ ... 15
Checking Radiator Cap ....................................... ... 15
Checking Radiator ............................................... ... 16
RADIATOR (ALUMINUM TYPE) ........................... ... 17
Components ........................................................ ... 17
Disassembly and Assembly ................................ ... 17
PREPARATION ................................................ ... 17
DISASSEMBLY ................................................ ... 17
ASSEMBLY ...................................................... ... 18
INSPECTION ................................................... ... 20 COOLING FAN .......................................................
... 21
Components ........................................................ ... 21
Removal and Installation ..................................... ... 21
REMOVAL ........................................................ ... 21
INSTALLATION ................................................ ... 21
INSPECTION AFTER INSTALLATION ............. ... 21
Disassembly and Assembly ................................. ... 21
DISASSEMBLY ................................................ ... 21
INSPECTION AFTER DISASSEMBLY ............. ... 21
ASSEMBLY ...................................................... ... 21
WATER PUMP ....................................................... ... 22
Components ........................................................ ... 22
Removal and Installation ..................................... ... 22
REMOVAL ........................................................ ... 22
INSPECTION AFTER REMOVAL .................... ... 24
INSTALLATION ................................................ ... 24
INSPECTION AFTER INSTALLATION ............. ... 26
WATER INLET AND THERMOSTAT ASSEMBLY . ... 27
Components ........................................................ ... 27
Removal and Installation ..................................... ... 27
REMOVAL ........................................................ ... 27
INSPECTION AFTER REMOVAL .................... ... 28
INSTALLATION ................................................ ... 28
INSPECTION AFTER INSTALLATION ............. ... 28
WATER OUTLET AND WATER PIPING ................ ... 29
Components ........................................................ ... 29
Removal and Installation ..................................... ... 29
REMOVAL ........................................................ ... 29
INSTALLATION ................................................ ... 30
INSPECTION AFTER INSTALLATION ............. ... 30
SERVICE DATA AND SPECIFICATIONS (SDS) ... ... 31
Standard and Limit ............................................... ... 31
ENGINE COOLANT CAPACITY (APPROXI-
MATE) ............................................................... ... 31
RADIATOR ....................................................... ... 31
THERMOSTAT ................................................. ... 31

CO-2Revision: 2006 July 2007 FX35/FX45
VK45DE
PRECAUTIONS ......................................................... 32
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .............................................................. ... 32
PREPARATION ...................................................... ... 33
Special Service Tools .......................................... ... 33
Commercial Service Tools ................................... ... 33
OVERHEATING CAUSE ANALYSIS ..................... ... 34
Troubleshooting Chart ......................................... ... 34
COOLING SYSTEM ............................................... ... 36
Cooling Circuit ..................................................... ... 36
System Chart ....................................................... ... 37
ENGINE COOLANT ............................................... ... 38
Inspection ............................................................ ... 38
LEVEL CHECK ................................................. ... 38
LEAK CHECK ................................................... ... 38
Changing Engine Coolant .................................... ... 38
DRAINING ENGINE COOLANT ....................... ... 38
REFILLING ENGINE COOLANT ...................... ... 39
FLUSHING COOLING SYSTEM ...................... ... 40
RADIATOR ............................................................. ... 41
Components ........................................................ ... 41
Removal and Installation ..................................... ... 41
REMOVAL ........................................................ ... 41
INSTALLATION ................................................. ... 43
INSPECTION AFTER INSTALLATION ............. ... 43
Checking Radiator Cap ....................................... ... 43
Checking Radiator ............................................... ... 44
RADIATOR (ALUMINUM TYPE) ............................ ... 45
Components ........................................................ ... 45
Disassembly and Assembly ................................. ... 45
PREPARATION ................................................ ... 45
DISASSEMBLY ................................................ ... 45
ASSEMBLY ...................................................... ... 46
INSPECTION .................................................... ... 48 COOLING FAN .......................................................
... 49
Components (Crankshaft Driven type) ................. ... 49
Removal and Installation ...................................... ... 49
REMOVAL ......................................................... ... 49
INSPECTION AFTER REMOVAL ..................... ... 49
INSTALLATION ................................................. ... 49
Components (Motor Driven Type) ........................ ... 50
Removal and Installation ...................................... ... 50
REMOVAL ......................................................... ... 50
INSTALLATION ................................................. ... 50
Disassembly and Assembly (Motor Driven Type) ... 50 DISASSEMBLY ................................................. ... 50
INSPECTION AFTER DISASSEMBLY ............. ... 50
ASSEMBLY ....................................................... ... 50
WATER PUMP ........................................................ ... 51
Components ......................................................... ... 51
Removal and Installation ...................................... ... 51
REMOVAL ......................................................... ... 51
INSPECTION AFTER REMOVAL ..................... ... 52
INSTALLATION ................................................. ... 52
INSPECTION AFTER INSTALLATION ............. ... 52
THERMOSTAT AND WATER CONTROL VALVE .. ... 53
Components ......................................................... ... 53
Removal and Installation ...................................... ... 54
REMOVAL ......................................................... ... 54
INSPECTION AFTER REMOVAL ..................... ... 54
INSTALLATION ................................................. ... 54
INSPECTION AFTER INSTALLATION ............. ... 55
SERVICE DATA AND SPECIFICATIONS (SDS) ... ... 56
Standard and Limit ............................................... ... 56
ENGINE COOLANT CAPACITY (APPROXI-
MATE) ............................................................... ... 56
RADIATOR ........................................................ ... 56
THERMOSTAT .................................................. ... 56
WATER CONTROL VALVE ............................... ... 56

OVERHEATING CAUSE ANALYSIS CO-7
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
Revision: 2006 July 2007 FX35/FX45
OVERHEATING CAUSE ANALYSISPFP:00012
Troubleshooting ChartNBS003JR
Symptom Check items
Cooling sys-
tem parts
malfunction Poor heat transfer
Water pump malfunction Worn or loose drive belt
—
Thermostat stuck closed —
Damaged fins Dust contamination or
paper clogging
Physical damage
Clogged radiator cooling
tube Excess foreign material
(rust, dirt, sand, etc.)
Reduced air flow Cooling fan does not oper-
ate
Fan assembly —
High resistance to fan rota-
tion
Damaged fan blades
Damaged radiator shroud — — —
Improper engine coolant
mixture ratio —— —
Poor engine coolant quality — Engine coolant density —
Insufficient engine coolant Engine coolant leaks Cooling hose
Loose clamp
Cracked hose
Water pump Poor sealing
Radiator cap Loose
Poor sealing
Radiator O-ring for damage, deterio-
ration or improper fitting
Cracked radiator tank
Cracked radiator core
Reservoir tank Cracked reservoir tank
Overflowing reservoir tank Exhaust gas leaks into
cooling system Cylinder head deterioration
Cylinder head gasket dete-
rioration

CO-8
[VQ35DE]
OVERHEATING CAUSE ANALYSIS
Revision: 2006 July 2007 FX35/FX45
Except cool-
ing system
parts mal-
function — Overload on engine
Abusive driving
High engine rpm under no
load
Driving in low gear for
extended time
Driving at extremely high
speed
Powertrain system mal-
function
—
Installed improper size
wheels and tires
Dragging brakes
Improper ignition timing
Blocked or restricted air
flow Blocked bumper —
—
Blocked radiator grille
Installed car brassiere
Mud contamination or
paper clogging
Blocked radiator —
Blocked condenser Blocked air flow
Installed large fog lamp
Symptom Check items

ENGINE COOLANT CO-11
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
Revision: 2006 July 2007 FX35/FX45
ENGINE COOLANTPFP:KQ100
InspectionNBS003JU
LEVEL CHECK

Check if the reservoir tank engine coolant level is within the
“MIN” to “MAX” when the engine is cool.

Adjust the engine coolant level as necessary.
LEAK CHECK

To check for leaks, apply pressure to the cooling system with the
radiator cap tester (commercial service tool) and radiator cap
tester adapter (SST).
WARNING:
Do not remove radiator cap when engine is hot. Serious
burns could occur from high-pressure engine coolant
escaping from radiator.
CAUTION:
Higher test pressure than specified may cause radiator
damage.
NOTE:
In a case that engine coolant decreases, replenish radiator with engine coolant.

If anything is found, repair or replace damaged parts.
Changing Engine CoolantNBS003JV
WARNING:

To avoid being scalded, do not change engine coolant when the engine is hot.

Wrap a thick cloth around radiator cap and carefully remove radiator cap. First, turn radiator cap a
quarter of a turn to release built-up pressure. Then turn radiator cap all the way.
DRAINING ENGINE COOLANT
1. Remove front engine undercover with power tool.
2. Open radiator drain plug at the bottom of radiator, and then remove radiator cap.
When draining all of engine coolant in the system, open water drain plugs on cylinder block. Refer
to EM-124, "
DISASSEMBLY" .
3. Remove reservoir tank as necessary, and drain engine coolant and clean reservoir tank before installing.
SMA412B
Testing pressure : 157 kPa (1.6 kg/cm
2 , 23 psi)
SLC756A
SBIA0444E

CO-12
[VQ35DE]
ENGINE COOLANT
Revision: 2006 July 2007 FX35/FX45
4. Check drained engine coolant for contaminants such as rust, corrosion or discoloration.
If contaminated, flush the engine cooling system. Refer to CO-13, "
FLUSHING COOLING SYSTEM" .
REFILLING ENGINE COOLANT
1. Install reservoir tank if removed, and radiator drain plug.
CAUTION:
Be sure to clean drain plug and install with new O-ring.
If water drain plugs on cylinder block are removed, close and tighten them. Refer to EM-129,
"ASSEMBLY" .
2. Make sure that each hose clamp has been firmly tightened.
3. Remove air relief plug on heater hose.
4. Fill radiator, and reservoir tank if removed, to specified level.

Pour engine coolant through engine coolant filler neck
slowly of less than 2 (2-1/8 US qt, 1-3/4 lmp qt) a minute
to allow air in system to escape.

Use Genuine Nissan Long Life Antifreeze/Coolant or
equivalent mixed with water (distilled or demineralized).
Refer to MA-12, "
RECOMMENDED FLUIDS AND LUBRI-
CANTS" .

When engine coolant overflows air relief hole on heater hose,
install air relief plug with new O-ring.
5. Install radiator cap.
6. Warm up until opening thermostat. Standard for warming-up time is approximately 10 minutes at 3,000 rpm.

Make sure thermostat opening condition by touching radiator hose (lower) to see a flow of warm water.
CAUTION:
Watch water temperature gauge so as not to overheat engine.
7. Stop the engine and cool down to less than approximately 50 °C (122 °F).

Cool down using fan to reduce the time. Radiator drain plug:
: 1.18 N·m (0.12 kg-m, 10 in-lb)
SBIA0445E
Engine coolant capacity
(With reservoir tank at “MAX” level)
: Approximately 8.6 (9-1/8 US qt, 7-5/8 lmp qt)
SMA182B
Reservoir tank engine coolant capacity
(At “MAX” level)
: 0.8 (7/8 US qt, 3/4 lmp qt)
Air relief plug: : 1.19 N·m (0.12 kg-m, 11 in-lb)
SMA412B

ENGINE COOLANT CO-13
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
Revision: 2006 July 2007 FX35/FX45

If necessary, refill radiator up to filler neck with engine coolant.
8. Refill reservoir tank to “MAX” level line with engine coolant.
9. Repeat steps 4 through 7 two or more times with radiator cap installed until engine coolant level no longer drops.
10. Check cooling system for leaks with engine running.
11. Warm up the engine, and check for sound of engine coolant flow while running engine from idle up to 3,000 rpm with heater temperature controller set at several position between “COOL” and “WARM”.

Sound may be noticeable at heater unit.
12. Repeat step 11 three times.
13. If sound is heard, bleed air from cooling system by repeating step 4 through 7 until engine coolant level no longer drops.
FLUSHING COOLING SYSTEM
1. Install reservoir tank if removed, and radiator drain plug.
If water drain plugs on cylinder block are removed, close and tighten them. Refer to EM-129,
"ASSEMBLY" .
2. Remove air relief plug on heater hose.
3. Fill radiator with water until water spills from the air relief hole, then close air relief plug. Fill radiator and reservoir tank with water and reinstall radiator cap.
4. Run the engine and warm it up to normal operating temperature.
5. Rev the engine two or three times under no-load.
6. Stop the engine and wait until it cools down.
7. Drain water from the system. Refer to CO-11, "
DRAINING ENGINE COOLANT" .
8. Repeat steps 1 through 7 until clear water begins to drain from radiator. Radiator drain plug:
: 1.18 N·m (0.12 kg-m, 10 in-lb)
SBIA0445E
Air relief plug: : 1.19 N·m (0.12 kg-m, 11 in-lb)
