2007 Hyundai Getz Owner's Manual

FEATURES OF YOUR HYUNDAI 1- 63
B500D01TG-GAT POWER OUTLET (If installed)
These supply 12V electric power to operate electric accessories or equip- ment only when the key is in the "ON" or "ACC" position.
!
CAUTION:
o Use when the engine is running and remove a plug from the power outlet after using the electric ap- pliance. Using when the engine stops or remaining the electricappliance with plugged in for many hours may cause the battery to be discharged.
o Do not use the power outlet to connect electric accessories orequipment other than those de-signed to operate on 12 volts.
o Some electronic devices can cause
electronic interference whenplugged into the power outlet. These devices may cause exces- sive audio noise and malfunctionsin other electronic systems or de- vices used in your vehicle.
B500D01TB-D
!
Do not hold the cigar lighter at the depressed position which may result in damage to the vehicle wiring or anelectrical fire. If it is necessary to replace the ciga- rette lighter, use only a genuine Hyundaireplacement part.
CAUTION:
Do not use electric accessories orequipment other than the Hyundai genuine parts in the socket.

1- 64 FEATURES OF YOUR HYUNDAI
B430A01TB-GAT FRONT ASHTRAY (If installed)
HTB2036
The front ashtray may be opened by pulling it up by its top edge. To close the ashtray cover firmly, let the lid gripprotrude outside. To remove the ash- tray to empty or clean it, pull the cover up all the way out.Either holder can be a drink holder or a ashtray holder.
Front side
B450A01TB-GAT DRINK HOLDER The drink holder is used for holding cups or cans. Either holder can be a drink holder or aashtray holder. Rear side
B455A01TB-EAT CONSOLE TRAY Multipurpose receptacles are located in the centre console these can be used for pens or CD cases. HTB2037-D
HTB105-D

FEATURES OF YOUR HYUNDAI 1- 65
!
B460A01Y-AAT SUNROOF (Not all models) Sun Shade
Your HYUNDAI is equipped with a sliding sunshade which you can manu- ally adjust to let in light with the sunroof closed, or to block sunlight.
Loading condition Switch
position
Driver only Driver + front passenger Full passengers (including driver)Full passengers (including driver) + full trunk loading (or light trailer loading)Driver + full trunk loading (or maximum trailer loading) 0
1 2
3 0
B470A01FC
WARNING:
Never adjust the sunshade while driving.
B340G01S-EAT HEADLIGHT LEVELING DEVICE SYSTEM To adjust the headlight beam level ac- cording to the number of the passen- gers and the loading weight in the lug-gage area, turn the beam leveling switch. The higher the number of the switch position, the lower the headlight beamlevel. Always keep the headlight beam at the proper leveling position, or head- lights may dazzle other road users.Listed below are the examples of rec- ommended switch settings. For loading conditions other than those listed be-low, adjust the switch position so that the beam level may be the nearest as the condition obtained according to thelist.
HTB181-D

1- 66 FEATURES OF YOUR HYUNDAI
!
B460B01GK-GAT Opening the Sunroof System The sunroof can be electrically opened or closed with the ignition key in the "ON" position. The sunroof is moved toits fully open position by pushing the "Open" switch, and to stop at the de- sired position, push in any switches(Open, Close, Up, Down). To close, press and hold the "CLOSE" button. Release the button when the sunroofreaches the desired position. HFC2021
HFC2022
B460C01GK-GAT Tilting the Sunroof System The sunroof is moved to its fully tilt up position by pushing the "UP" switch, and to stop at the desired position,push in any switches (Open, Close, Up, Down). To tilt down, press and hold the"DOWN" button. Release the button when the sunroof reaches the desired position. NOTE: After washing the car or after there is rain, be sure to wipe off any water that is on the sunroof before oper-ating it.
WARNING:
o Do not close a sunroof if anyone’s hands, arms or body are between the sliding glass and the sunroof sash, as this could result in in-jury.
o Do not place your head or arms
out of the sunroof opening at anytime.
CAUTION:
o Do not open the sunroof in se- verely cold temperature or when it is covered with ice or snow.
o Periodically remove any dirt that may have accumulated on theguide rails.
!

FEATURES OF YOUR HYUNDAI 1- 67
2. Insert the hexagonal head wrench
provided with the vehicle into the socket. This wrench can be found in the vehicle's luggage compartmentor glove box.
3. Turn the wrench counterclockwise
to open or clockwise to close thesunroof. HGK033B460E01TB-GAT Resetting the Sunroof System If the battery has been recharged, disconnected, if the sunroof is oper- ated with the hexagonal head wrenchmanually, or if the sunroof operation is stopped by that ignition key is turned to the "OFF" position while it is moving,you may need to reset the sunroof. To do this;
1. Turn the ignition switch "OFF".
2. With pressing "open" "up" button at
the same time, turn the ignition switch "ON".
3. If the sunroof is set like this, the
sunroof is reset with tilting up/downautomatically once for all.
! CAUTION:
If the sunroof is not reset, it may not be operated properly.
B460D02TB-AAT Manual Operation of Sunroof If the sunroof does not electrically op- erate:
HGK032
1. Remove the cap located in the rear roof panel by using a coin or screw driver.

1- 68 FEATURES OF YOUR HYUNDAI
With Sunroof
B480A01E-EAT INTERIOR LIGHT Map Light The two map lights are located at each side of the interior light. The lights may be operated by depress-ing the switch to turn on the light and pressing again to turn off the light. This light produces a spot beam for conve-nient use as a map light at night or as a personal light for the driver or the pas- senger.Without Sunroof
HTB050
The interior courtesy light has a button of three positions. The three positions are:
oDR Type A In the "DR" position, the interior cour- tesy light comes on when any door isopened regardless of the ignition key position. The light goes out when the door is closed.
B490A02TB-EAT INTERIOR LIGHT
HTB303
With Sunroof
Without sunroof
Type B In the "DR" position, the interior cour- tesy light comes on when any door isopened regardless of the ignition key position. The light goes out gradually 6 seconds after the door is closed.
oON In the "ON" position, the light stays on at all times. NOTE: Ensure the light is turned to the "OFF" position after use. Leaving in the on position for prolonged peri-ods will discharge the battery.
o OFF In the "OFF" position, the light stays off at all times even though a door is open.

FEATURES OF YOUR HYUNDAI 1- 69
B491A01TB-GAT SPECTACLE CASE (Not all models)
HTB102-D
The spectacle case is located on the driver side of roof trim. Pull the end of the cover to open the spectacle case.
!
!
WARNING:
To avoid the possibility of injury, the glove box lid must be kept closed whilst the vehicle is in motion.
o To open the glove box, pull the glove box release lever.
B500A01A-EAT GLOVE BOX
HTB101-D
WARNING:
Do not keep objects such as sharp or unsuitable things inside the spec- tacle case. Such objects can bethrown out in the event of a sudden stop or an accident, possibly injur- ing the passengers in the vehicle. B500B01O-AAT Illuminated Glove Box Opening the glove box will automati- cally turn on the light when the multi-function switch is turned to the first/ second position.

1- 70 FEATURES OF YOUR HYUNDAI
B510B01FC-EAT Electric Type (Not all models)
The outside rear view mirror can be adjusted in any direction to give the maximum rear view vision.The remote control outside rear view mirror switch controls the adjustments for passenger side door mirror. HTB104-D
CAUTION:
If the mirror control is jammed withice, do not attempt to break it free using the control handle or by ma- nipulating the face of the mirror. Usean approved spray de-icer (not radia- tor antifreeze) to release the frozen mechanism or move the vehicle to awarm place and allow the ice to melt.
!
YB270A2-A OUTSIDE REAR VIEW MIRROR Manual Type (Not all models)
HTB306
The outside rear view mirrors are equipped with a remote control for your convenience. It is operated by the con-trol lever in the bottom front corner of the window. Before driving away, always check thatyour mirrors are positioned so you can see directly behind you. When using the mirror, always exercise caution whenattempting to judge the distance of vehicles behind you.
